Summing Algorithmic Execution

1
Summing Algorithmic Execution

• More big-Oh discussion

2
Making an Identity Matrix

• void makeIdentityMatrix (double m)
• int n m.length
• for (int i 0 i lt n i)
• for (int j 0 j lt n j)
• mij 0.0
• for (int i 0 i lt n i)
• mii 1.0

3
Adding asymoptotic times

• Clearly first loop is O(n2), second loop is O(n).
• MakeIdentityMatrix is O(n2).
• Why not O(n2 n)?

4
Toss out everything but the dominant function

• Remember how we tossed out constant factors?
• Also toss out everything except the dominate
  function
• So what functions dominate each other?

5
A hierarchy of Dominance

• n! factorial
• 2n exponential
• nd, - d gt 3 Polynomial n3 Cubic n2 Quadratic
• n sqrt(n)-no name, just n root n
• n log n -just n log n
• n linear
• sqrt(n) root-n
• log n Logarithmic
• 1 constant

6
Justifications for Summing Rule

• Why do small rain drops stay on your car window?
• Why do large ones roll off?
• What are the forces on the drop?

7
Characteristic Curves

• Each function has a characteristic curve
• Multiplying by a constant, or adding a constant,
  only makes it larger or smaller, doesn't change
  essential shape

8
A dominate function always wins

• As n gets large, the characteristic shape of a
  function will always assert itself.
• The dominant function will always get larger

9
Another Argument

• Assume we can perform a task every microsecond
  (106 operations per second).
• Assume that n is 105.
• How long to execute an algorithm?

10
Function and Running time

• 2n -more than a century
• n3  31.7 years
• n2  2.8 hours
• n sqrt(n) 31.6 seconds
• n log(n)  1.2 seconds
• n  0.1 second
• sqrt(n) - 3.2 10-4 seconds
• log(n) -1.2 10-5 seconds

11
BUT!!!!!

• All this assumes that n is or can become large.
• How fast can you do matrix multiplication?
• There are O(n 2.5) algorithms, but the constants
  are huge, so for practical n the normal algorithm
  is faster.

12
Adding terms

• So if we were talking about adding O(n3) O(n2)
• The second part would be adding 2.8 hours to 31.7
  years
• The smaller term just becomes irrelevant

13
New Topic - Correctness

• Ok. Now we know how fast an algorithm will
  execute -- how do we know it is correct?
• Key tool - invariants (and assertions)
• Simply a statement of what we know about the
  state of the variables when execution reaches a
  given point in a program.

14
An Example Program

• int triangle(int a, int b, int c)
• if (a b)
• if (b c) return 1
• else
• return 2
• else if (b c)
• return 2
• else
• return 3

15
Keep track of what you know

• int triangle(int a, int b, int c)
• if (a b)
• if (b c) / we know ab bc
  /return 1
• else / we know ab and b ! c /
• return 2
• else if (b c) / we know a!b and b c/
• return 2
• else / we know a ! b and b ! c /
• return 3 / HA-- THERE IS AN ERROR! /

16
How to show this is correct.

• double minimum(double values)
• int n values.length
• double minValue values0
• for (int i 1 i lt n i)
• if (valuesi lt minValue)
• minValue valuesi
• return minValue

17
Loop Invariants

• double minValue values0
• for (int i 1 i lt n i)
• // minValue is smallest element in 0 .. i-1
• if (valuesi lt minValue)
• minValue valuesi
• // minValue is smallest element in 0 .. i
• // minValue is smallest element in 0 .. (n-1)
• return minValue

18
Binary Search

• int binarySearch(double data, double test)
• int low 0
• int high data.length
• while (low lt high)
• mid (low high) / 2
• if (datamid lt testValue) low mid 1
• else high mid
• return low

19
The Invariant

• int low 0 int high data.length
• // index lt low are smaller than test value
• // index gt high are bigger or equal to test
  value
• while (low lt high)
• mid (low high) / 2
• if (datamid lt testValue) low mid 1
• else high mid
• // what is true here?

20
Questions??
