Java Electronic Commerce Framework JECF

1
Java Electronic Commerce Framework (JECF)

• CSIT 72 Electronic Commerce Technologies

2
What is the Java Wallet?

• The Java Wallet is a family of products written
  in the Java programming language that are
  designed to enable secure electronic commerce
  operations and offer users an extensible platform
  for online commerce
• The Java Wallet incorporates the
• Java Commerce Client,
• Commerce JavaBeans components,
• Gateway Security Model, and
• Java Commerce Messages.
• These products can be used independently of one
  another. Users might even be unaware that they
  have a Java Wallet running in their machine when
  several Commerce JavaBeans components are
  included in some other application.
• Because it is implemented in Java, the Java
  Wallet will run everywhere Java is available.
  This includes all popular browsers and the
  increasing number of operating systems and
  network computers that incorporate Java.

3
What is the Java Commerce Client?

• The Java Commerce Client (JCC) is Sun
  Microsystem's client side solution for secure
  electronic commerce transactions. As an open,
  extensible platform, the JCC provides
  functionality that reduces the time and effort
  developers require to build electronic commerce
  applications. JCC users are provided with a
  Wallet-like user interface, a database, and an
  extensible platform that enables the use of a
  variety of payment instruments and protocols for
  a nearly unlimited number of E-commerce
  operations.
• Once the JCC is configured on a client machine,
  the JCC user can download and install new
  Instrument, Protocol, and Operation Commerce
  JavaBeans components developed by third party
  software providers. The JCC user can also extend
  the JCC with internal services, like address
  books, and transaction logs, that are also
  available as Commerce JavaBeans components. The
  JCC provides merchants with the ability to create
  heavily branded user interfaces that can be tied
  to merchant-specific operations, such as a
  purchase on a specific merchant site or a
  transaction with a given bank.
• The JCC offers a flexible solution in the rapidly
  evolving world of electronic commerce on the
  Internet.

4
Java Commerce Client (JCC) Components
5
What are the Java Commerce APIs?

• The Java Commerce APIs implement basic services
  within the Java Commerce Client. They provide
  foundation services that allow developers to
  easily create new electronic commerce
  applications, like on-line shopping malls, home
  banking or electronic brokerage. The classes that
  form the Java Commerce APIs are designed to
  enable
• Rapid Commerce Component Development. The
  Commerce JavaBeans specification provides for
  rapid development and deployment of commerce
  components. Once components are packaged in
  signed jar files (known as cassettes), they can
  be made available to end users via download or
  disk.
• Easy, Secure Downloading and Installation of
  Cassettes. The Java Commerce API contains support
  for an installation subsystem that facilitates
  the download and installation of new commerce
  components into the Java Wallet.
• Secure Interoperation of Commerce JavaBeans
  components. Once commerce components are
  installed and registered, the Java Commerce API
  enables their secure, constrained interoperation
  using the Gateway Security Model.
• Secure Storage of Private End-User Information.
  The Java Commerce APIs contain a database that
  securely holds personal information, like credit
  card numbers or transaction histories. The
  database uses the security functionality built
  into the Java Developer's Kit to ensure the
  privacy of this data.
• Rapid Development of Secure Payment Mechanisms.
  The Java Commerce APIs allow developers to
  quickly go from payment protocol specifications
  to working implementations.

6
JCC Storing/Retrieving Objects in the Database
7
What is a Commerce JavaBeans Component?

• A Commerce JavaBeans component is a reusable
  commerce component that meets specific interface
  requirements. Commerce JavaBeans enable
  developers to easily write commerce components
  that can extend the functionality of the JCC.
• The Commerce JavaBeans model extends the
  JavaBeans model to provide interface typing and
  support for the Gateway Security Model. Commerce
  JavaBeans components show some functionality
  within standard JavaBeans builder tools, but they
  only manifest full functionality in Commerce
  JavaBeans-aware environments such as the JCC.
• The Commerce JavaBeans API Specification will be
  published soon.

8
What is a Commerce JavaBeans Component?

• The following Commerce JavaBeans interfaces are
  defined for use with the JCC
• Transacted (Issues events that allow transaction
  checkpointing and recovery. This interface is
  extended by both Operation and Protocol
  interfaces.)
• Operation (Implemented for purchase, ATM
  transfer, financial planning. . .)
• Protocol (Implemented for post, SET, Mondex. . .)

• Instrument (Implemented for credit card, coupon,
  voucher, frequent-flyer miles card. . .)
• User interface (Implemented for alternate GUIs
  designed by Commerce JavaBeans component
  developers)
• Service (Implemented for address book, cassette
  management, instrument management. . . )
• Preference (Implemented for user preference
  configuration)
• Gate (Implementation provides a secure shield
  around protected APIs)

9
What is a Commerce JavaBeans Component?

• The Commerce JavaBeans class is derived from
  java.beans.Beans. Therefore, the Commerce
  JavaBeans class presents the same functionality
  as java.beans.Beans but with a slightly broader
  interface tailored to support Commerce JavaBeans
  components.
• Commerce JavaBeans components are contained in
  cassettes. When a cassette is downloaded and
  installed, the JCC can make use of the Commerce
  JavaBeans component(s) it contains to perform
  commerce operations. For example, the JCC could
  use a Purchase Operation Bean in conjunction with
  a credit card Instrument and an SET Protocol Bean
  to perform a secure online purchase. The Commerce
  JavaBeans model is extensible, so developers can
  create new types of Commerce JavaBeans components
  as the need for them arises.

10
What is a Cassette?

• A Cassette is package for Commerce JavaBeans
  components.
• A Cassette is a JAR (Java archive) file that
• Contains resources (one or more Commerce
  JavaBeans components, shared interfaces,
  graphics, etc.)
• Is digitally signed with one or more Roles. Each
  role provides specific capabilities to the
  contents of a cassette.
• Contains information about the contents of the
  JAR file which enables the JCC to download,
  install, and register Commerce JavaBeans
  components.

11
JCC Graphical User Interface Schematic
12
JCC Context Instantiation and Gate Registration
13
JCC Gateway Security Model
14
JCC Cassette Installation Environment
15
JCC Cassette Download Scenario
16
JCC Cassette Registry
17
JCC Operation Point of View
18
JCC/Device Driver Interface
19
JCC Acquirer to Smart Card Communication
20
JCC Smart Card Layering
21
JCC Localization Using Properties File
22
What is the Java Smart Card API?

• The javax.smartcard package provides an API that
  enables communication between portable Java
  applications and smart cards, independent of
  hardware devices. The Java Smart Card layer makes
  the card reader and port transparent to the Java
  application communicating with the smart card,
  providing a direct channel between application
  and smart card. The Java application only
  requires intimate knowledge of the smart card
  itself, for example, what kinds of APDUs the card
  understands. The implementation of
  javax.smartcard included with the Java Wallet is
  preliminary and should be considered a prototype.

• For more information on the Java Smart Card API,
  visit the Java Wallet Smart Card API Page.

23
Will the Java Commerce APIs Be Part of JDK?

• The Java Commerce APIs are delivered separately
  from JDK. The Java Commerce APIs constitute a
  standard extension to the JDK.

24
How Can I Get More Detailed Information?

• Additional information is available on the Java
  Wallet Documentation Page.
• Please read the Java Wallet Architecture White
  Paper.

25
The Future of the Java Wallet

• Several major enhancements, along with some minor
  ones, of the Java Wallet are planned for future
  releases.
• At some point, the current Java Wallet
  architecture will be extended with one that
  supports a thin wallet. The current Java Walletis
  called fat because it resides entirely on the
  client. A thin wallet, by contrast, would exist
  on a server. In a thin wallet architecture, Java
  Wallet users could access their Wallets from any
  networked computer, from networked kiosks, or
  from any device that supports Java and has an
  Internet connection. In developing thin
  applications, the majority of the application
  must reside on the server, where it does most of
  its work, displaying output to and receiving
  input from users. The trick in designing thin
  applications is to separate the framework from
  the display. As little code as possible should be
  downloaded from the server. The user then
  interacts across a network connection with an
  application residing on the server.
