Tools for Sound, Speech, and Multi-modal
Interaction

• Johnny Lee
• 05-830 Advanced UI Software

2
Sound
3
Sound

• Authoring Tools
• Recording, Playback
• SFX libraries
• Editing,Mixing
• MIDI
• Developer Tools
• Software APIs
• FFT libraries

4
Recording Sound

• Most laptops have built-in mono microphones

(Schoeps)
5
Recording Sound
6
Recording Sound
7
Playing Sound

• Most laptops have built in speakers

8
Multichannel Audio

• ProTools by Digidesign up to 64 channels of
  24-bit, 48Khz audio I/O

9
Multichannel Audio
10
(No Transcript)
11
Sound Libraries

• SoundIdeas (http//www.sound-ideas.com/)
• General 6000
• Hanna Barbara (http//gs304.sp.cs.cmu.edu/sfx/)
• Lots of other smaller suppliers of stock sound
  libraries

12
Editing/Mixing Sounds

• LogicAudio, SoundForge, Peak, SoundEdit16, many
  others.
• Edits sound kind of like a text-editor.
• Sophisitcated DSP (some realtime)
• Synchronization with video and MIDI support

13
MIDI

• Musical Instrument Digital Interface
• Hardware communication layer
• 5-pin din, uni-directional with pass-thru
• Software protocol layer
• MIDI Commands are 2-3 bytes
• Note specification
• Device configuration (128 controllers)
• Device Control/Synchronization

14
MIDI

• Lots of general purpose fields
• Simple electronics (2 resistors and PIC
  processor)
• Semi-popular option for simple control/robotics
  applications.

15
MOD files

• File size can be tiny if using a MIDI synthesizer
  is used at playback time.
• Playback quality depends on the quality of the
  synthesizer
• MOD files (module format) combine MIDI data with
  WAV samples to produce high quality consistent
  playback in a relatively small file.

16
(No Transcript)
17
Software APIs for sound
18
Microsoft DirectX 9.0

• DirectX is
• DirectDraw 2D drawing
• Direct3D 3D drawing
• DirectInput input/haptic devices
• DirectPlay network gaming
• DirectShow video streams
• DirectSound wave audio I/O
• DirectMusic soundtrack management and MIDI
• DirectSetup DirectX installation routines

19
DirectSound

• WAV capture
• Multi-channel sound playback
• Full duplex
• 3D specification of sound sources.
• Some real-time DSP Chorus, Compression, Flange,
  Distortion, Echo, Reverb

20
DirectMusic

• Coordinates several sound files (MIDI, wav, etc.)
  into soundtracks.
• Sequencing (timelines, cueing, and
  synchronization).
• Supports dynamic composition, variation, and
  transitioning between songs/parts.
• Dynamic content authored in DirectMusic Producer

21
DirectMusic

• Compositions can be made with DLS (downloadable
  sound) files a cross-platform smart audio
  file format designed for dynamic loading in
  interactive applications.
• DLS MIDI WAV for interactive apps

22
MacOS X Core Audio
23
MacOS X Core Audio

• Sound Manager routines for resource management
  and play/recording sound
• AudioToolbox sophisitcated DSP architecture,
  sequencing/composition
• MIDI Services device abstraction, control, and
  patching
• Audio HAL medium level I/O access (real-time,
  low-latency, multi-channel, floating point is
  standard access)
• IOKit low level device access
• Drivers, Hardware - blarg
• Full Java API provided

24
Java

• Basic data structures and routines for loading,
  playing, and stopping sounds.
• java.applet.AudioClip
• javax.sound.midi
• javax.sound.midi.spi
• javax.sound.sampled
• javax.sound.sampled.spi
• I/O device access is somewhat limited.
• Ive been told that synchronization is a problem
  in Java.

25
Voice as Sound

• Voice as sound using non-verbal voice input for
  interactive control. Takeo Igarashi, John F.
  Hughes UIST 2001 155-156
• STFT, FFT analysis
• Extension to SUITEKeys

26
Fourier Transform(FT)

• Simple properties about a sound can be gotten
  by looking at the data file duration, volume
• More interesting analysis requires some DSP
  mainly Fourier Transform.

27
Fourier Transform

• FT extracts the frequency content from a given
  segment of audio.

28
Fourier Transform
29
Fast Fourier Transform(FFT)

• FFT is a fast computational algorithm for doing
  discrete Fourier transform (DFT).
• Implementations available in most languages.
• Good reference source Numerical Recipes in C

30
Speech (spech)
31
Speech Synthesis

• Three categories of speech synthesizers
• Articulatory synth - uses physical model of the
  physiology of speech production and physics of
  sound generation in the vocal apparatus
• Formant synth - acoustic-phonetic approach to
  synthesis. Applies hundreds of filters loosely
  associated to the movement of articulators using
  rules.
• Concatenative synth - segmental database that
  reflects the major phonological features of a
  language. Creates smooth transitions and basic
  processing to match prosodic patterns
• (http//cslu.cse.ogi.edu/HLTsurvey/ch5node4.html)

32
ATT Natural Voices

• US English, UK English, French, Spanish, German,
  Korean
• Can build a new voice font from an existing
  person
• Examples
• Male Voice
• Custom UK English
• Voice Font
• French

33
Phoenix Semantic Frame Parser

• Center for Spoken Language Research, University
  of Colorado, Boulder
• http//communicator.colorado.edu/phoenix/license.h
  tml
• System for processing and parsing natural
  language

34
Phoenix
35
Phoenix
Details and Syntax for creating frames and
networks http//communicator.colorado.edu/phoenix
/Phoenix_Manual.pdf
36
Universal Speech Interfaces
Universal speech interfacesgt Ronald Rosenfeld ,
Dan Olsen , Alex Rudnickygt Interactions October
2001gt Volume 8 Issue 6

• In essence, we attempt to do for speech what
  Palms Graffiti has done for mobile text entry.

• http//www-2.cs.cmu.edu/usi/USI-manifesto.htm
• Speech is an ambient medium.
• Speech is descriptive rather than referential.
• Speech require modest physical resources.
• Only speech will scale as digital technology
  progresses.
• 3 Speech interaction techniques Natural Language
  (NLI, NLP), Dialog Trees, Command and Control

37
(No Transcript)
38
Universal Speech Interfaces

• Look and FeelSound and Say
• Universal Metaphors familiar ways of doing
  things across applications.
• Universal User Primitives standard dialog
  interaction techniques, detection, recovering
  from error, asking for help, navigation, etc.
• Universal Machine Primitives standardize
  machine responses and meanings to increase user
  understanding.

39
Java Speech

• JSAPI Java Speech API
• Speech Generation
• Structure Analysis Java Synthesis Markup
  Language (JSML)
• Text Pre-Processing abbreviation, acronyms,
  1998
• Text-to-Phoneme Conversion
• Prosody Analysis
• Waveform Production
• Speech Recognition
• Grammar Design - Java Speech Grammar Format
  (JSGF)
• Signal Processing
• Phoneme Recognition
• Word Recognition
• Result Generation

40
Windows .NET Speech SDK

• Basically the .NET-ified SAPI 5.1 (Speech API)
• Continuous Speech Recognition (US English,
  Japanese, and Simplified Chinese)
• Concatenative Speech Synthesis (US English and
  Simplified Chinese)
• Interface is broken into two components
• Application Programming Interface (API)
• Device Driver Interface(DDI)

41
Windows .NET Speech SDK

• Speech Synthesis API
• ISpVoiceSpeak(my text, voice)
• Speech Synthesis DDI
• Prases text into an XML doc
• Calls the TTSEngine
• Manages sound and threading details

42
Windows .NET Speech SDK

• Speech Recognition API
• Define context
• Define grammar
• Request type (dictation or command/control)
• Event is fired when recognized
• Speech Recognition DDI
• Interfacing and configuring the SREngine
• Manages sound and threading details.

43
Windows .NET Speech SDK

• Speech Application Language Tags (SALT)
  extension to HTML for speech integration in to
  webpages
• Speech Recognition Grammar Specification (SRGS)
  support for field parsing
• Telephony Controls interfaces with telephone
  technology to develop voice-only apps.

44
MacOS X Speech

• Barely changed since 1996, MacInTalk 3
• US English only
• Full Java API
• Speech Synthesis Manager (PlainTalk)
• algorithmic voice generation
• Speech Recognition Manager
• OS wide push-to-talk Command/Control
• Customizable vocabulary w/scripting
• Uses Language Model grammar
• No dictation support

45
Dragon Naturally Speaking

• Commercial Recognition software
• Dictation
• Command and control
• API available for developers for application
  integration
• http//www.scansoft.com/naturallyspeaking/

46
Sphinx

• Open source speech recognizer from CMU
  (http//fife.speech.cs.cmu.edu/sphinx/)
• Auto-builds language model/grammervocabulary
  from example sentences
• CMU-Cambridge Statistical Language Modeling
  Toolkit semi-machine learning algorithms for
  digesting a large example corpus into a usable
  model
• Uses CMU Pronouncing Dictionary
• SphinxTrain - builds new acoustic models
• Audio recording, transcript, pronunciation
  dictionary/vocabulary, phoneme list

47
SUITEKeys

• Manaris,B., McCauley,R., MacGyvers,V., An
  Intelligent Interface for Keyboard and Mouse
  Control--Providing Full Access to PC
  Functionality via Speech, Proceedings of 14th
  International Florida AI Research Symposium
  (www.cs.cofc.edu/manaris/)
• Developed for individuals with motor
  disabilities.
• Interface layer that generates keyboard and mouse
  events for the OS
• Recognizes keyboard strokes/operations
  backspace, function twleve, control-alt-delete,
  page down, press. release
• Recognizes mouse buttons and movement
  left-click, move down. Stop, 2 units above
  clock, move to 5-18

48
Suede
Scott R. Klemmer , Anoop K. Sinha , Jack Chen ,
James A. Landay , Nadeemgt Aboobaker , Annie Wanggt
Proceedings of the 13th annual ACM symposium on
User interface software andgt technology November
2000

• Wizard of OZ tool for prototyping speech
  interfaces
• Allows the developer to quicky generate a state
  machine representing the possible paths through a
  speech interface and stores recorded system
  responses.
• Operator simulates a functional system during
  evaluation by stepping through the state machine.
• Runtime transcripts are recorded for later
  analysis.

49
(No Transcript)
50
Mulitmodal Interaction
51
Multimodal Interaction

• According to Scott The term multi-modal
  interface usually refers to speech and
  something else because speech alone wasnt good
  enough.
• Though, should probably mean more than one
  (simultaneous?) input modality
• Point, click, gesture, type, speak, write, touch,
  look, bite, shake, think, sweat, etc (lots of
  sensing techniques).

52
Multimodal Interaction

• Lots of things have used them, but no real
  tools or werent simultaneous.
• Cohen, P.R., Cheyer, A., Wang, M., and Baeg, S.C.
  An open agent architecture. AAAI 94 Spring
  Symposium Series on Software AgentsAAAI, (Menlo
  Park, CA, 1994) reprinted in Readings in Agents.
  MorganKaufmann, 1997, 197204.
• Brad Myers, Robert Malkin, Michael Bett, Alex
  Waibel, BenBostwick, Robert C. Miller, Jie Yang,
  Matthias Denecke, Edgar Seemann,Jie Zhu, Choon
  Hong Peck, Dave Kong, Jeffrey Nichols,
  BillScherlis. "Flexi-modal and Multi-Machine User
  Interfaces",ltigtIEEE Fourth International
  Conference on Multimodal Interfaceslt/igt,Pittsburgh
  , PA. October 14-16, 2002. pp. 343-348.

53
Multimodal Interfaces

• A common concept is mode-ing or modifying
  interaction.
• Gives extra context for recognizers (e.g. point
  and speak)
• Multiplies functionality of an interaction (e.g
  tool stones, left/right/no click)
• Rekimoto, J., Sciammarella, E. (2000)
  ToolStone effective use of physical
  manipulation vocabularies of input devices.
  Proceedings of the ACM Symposium on User
  Interface Software and Technology, pp. 109-117,
  November 2000
• Also, a need for an input interpretation layer
  for widgets that can be specified in multiple
  ways.
