Introduction to Intersection Control
Objectives

• Understand why some sort of control is essential
  to allocate right-of-way at intersections
• Understand there is a hierarchy of intersection
  control (a traffic signal is not a panacea)
• Learn how to check sight distances available at
  an intersection
• Learn about the warrants for stop and yield
  controls
• Learn how to check traffic signal warrants

5
Today

• Types of intersections
• Counting the number of conflicts at intersections
• Hierarchy of intersection control
• Method to check sight distances at intersections
• Warrants for STOP and YIELD signs
• Warrants for traffic signals

6
Types of Intersections

• At-grade
• Three leg (tee, wye)
• Four leg (simplest two one way streets)
• Multi-leg
• Rotary
• Grade separation
• Crossing separated without connection
• Interchange
• Diamond (also tight diamond)
• Urban (single point urban)
• Directional
• Cloverleaf
• Partial Cloverleaf (parclo)
• Tee
• Wye

7
Intersection Philosophy

• Miminize potential conflicts
• Vehiclesall modes
• Pedestrians
• Bicyclists
• Considerations
• Human
• Driving habits, decision/reaction time
• Traffic
• Demand, capacities, turning movements, delay,
  vehicle speeds, size and types of vehicles
• Physical
• Adjacent property, sight distance, geometric
  features, aesthetics, air quality, environmental
• Economic
• Cost, benefits, energy consumption

8
Control Devices

• Control may be achieved by using traffic signals,
  signs, markings, or markers that regulate, guide,
  warn, and/or channel traffic.
• Manual on Uniform Traffic Control Devices (MUTCD)
• Detailed standards for the physical design of the
  device, covering size, shape, colors, legend
  types, and specific legend.
• Detailed standards and guidelines on where
  devices should be physically located or placed in
  relationship to the roadway.
• Warrants, or conditions which justify, the use of
  a particular device.

9
Control Devices

• Requirements to make a traffic control device
  effective
• Fulfill a need ? Place proper device, only the
  one needed
• Command attention ?Make device stand out by
  color, shape, etc. (design)
• Convey a clear simple meaning ? Do not confuse
  driver with wordy legends only one instruction
  per device. (design)
• Command the respect of road users ?When you place
  it, you really mean it. (placement)
• Give adequate time for proper response ? Make it
  visible well in advance of decision point
  (placement)

10
Control Devices

• Design
• (color, size shape to meet requirements
  above),
• Placement
• (within cone of clear vision),
• Operation
• (right device at the right place),
• Maintenance
• (to maintain legibility),
• Uniformity
• (provide uniformity in use of control devices).

11
Control Devices

• SIGNS
• MARKINGS

12
Assessing the Viability of Basic Rules of the Road

• Sight distance must be adequate before driver is
  held accountable for her actions.
• Check if adequate SSD is available.
• SSD must be satisfied before traffic volumes are
  considered.

Similar triangles
13
Rule 1
Both vehicles have at least one safe SSD to the
collision point
Step 1 Assume Vehicle A is located one safe SSD
from collision point.
Step 2 Based on assumed position, find location
of Vehicle B when it first becomes visible. Call
it dB(act)
Step 3 Vehicle B must have one safe SSD. Call it
dB(min).
Step 4 If dB(act) lt dB(min), then adequate SSD
for has been provided. Otherwise, violated and
under Rule 1, not safe.
14
Rule 2
Vehicle A must travel 18 feet past collision
point in same time that Vehicle B travels to a
point 12 feet before the collision point
dB
dA
15
Sample Problem
Step 1
Step 2
Step 3
Step 4
dB(act) ltlt dB(min,R1) and dB(min,R2) Both rules
were violated.
