Facility Layout

1
Facility Layout

• Ross L. Fink

2
Facility Layout Types

• Classic
• Process (functional, departmental)
• Product (assembly line)
• Fixed Position
• Cellular

3
Process Layout
4
Product Layout
5
Advantages of Process Layout

• More product variety
• Less investment in equipment
• Can share equipment across products
• Redundant equipment
• Training is easier
• Maintenance is easier

6
Disadvantages of Process Layout

• More work-in-process (WIP) inventory
• More skilled workers
• More difficult Scheduling--workers and materials
• Quality control more difficult
• Higher variable cost of production

7
Advantages of Product Layout

• Lower variable cost of production
• Easier scheduling--workers and materials
• Higher quality--easier to manage quality
• Lower work-in-process (WIP) inventory
• Can use less skilled workers

8
Disadvantages of Product Layout

• Larger investment in equipment
• Less flexibility in product offering
• Harder to develop workers
• Little sharing of equipment
• Little or no backup equipment
• Worker dissatisfaction with job

9
Fixed Position Layout

• Material, equipment, and workers brought to
  product
• Used for items that are difficult to move--large
  items

10
Changes to Classical Layout Types

• Process--arrangement of departments (minimize
  material flow)
• Product--use of general purpose equipment
• Mixed layouts-using different layout types for
  different products

11
Cellular Layouts

• Work cell--equipment and workers are arranged to
  produce a family of related products
• Based on group technology
