Title: Manifold Tuning


1
Manifold Tuning
  • Erik Fernandez
  • Michelle Hood
  • Sladana Lazic

2
Overview
  • What are the intake and exhaust manifolds
  • What is manifold tuning
  • Theory of manifold tuning
  • Helmholtz Resonator
  • Compression-expansion waves
  • Other tuning considerations
  • Flow friction through manifold
  • Charge Heating

3
What is a Manifold?
  • Intake Manifold
  • A set of passages or pipes used to conduct air or
    a fuel/air mixture to the cylinders.

4
Intake Manifold Types

5
What is a Manifold?
  • Exhaust Manifold
  • A set of passages or pipes which conduct exhaust
    gases from the engine.

6
Exhaust Manifold Types
7
Manifold Tuning
  • What is it?
  • Tuning is the optimization of the manifold
    configuration
  • Why is it important?
  • Engine breathing is enhanced if the intake
    manifold is configured to optimize the pressure
    pulses in the intake system
  • The more air-fuel mixture an engine burns the
    more power it produces
  • Volumetric efficiency is also increased

8
Manifold Tuning
  • What is Volumetric Efficiency?
  • The efficiency with which the engine can move the
    charge into and out of the cylinders
  • It is a ratio of what volume of fuel and air
    actually enters the cylinder during induction to
    the actual capacity of the cylinder
  • What is engine breathing?
  • An engine's ability to fill its cylinders with
    air-fuel mixture and then discharge the burnt
    exhaust gases

9
Helmholtz Resonator
10
Helmholz Resonator
  • A Helmholtz resonator is a simple harmonic
    oscillator where the mass is provided by the air
    in a narrow neck while the spring is provided by
    a volume of trapped air.
  • When modeled as a second order differential
    spring-mass system the natural frequency of the
    Helmholtz resonator is.

a velocity of sound A area of the valve V
volume of the trapped air L length of the pipe
11
Helmholz Resonator (Complications)
  • Most of the time the valve is not fully open,
    therefore we model it as an orifice with area
    A1.
  • After applying the Bernoulli equation, Newtons
    Second Law, and linearize it we get a more
    realistic result for frequency

12
Helmholtz Resonator (a four cylinder engine)
  • The branches of the inlet manifold that lead to
    the three closed valves are modeled as the
    Helmholtz resonator.
  • Modeled with two pipes L1 and L2, and a volume V
    that is equal to the volume of the three manifold
    branches that are leading to the closed valves

13
Organ Pipes-compression expansion waves
14
Organ Pipes
  • Mass in pipes is compressible
  • Two types of wave
  • Compression Wave
  • Corresponds to an increase in pressure
  • Expansion Wave
  • Corresponds to a decrease in pressure

15
Organ Pipes continued
  • Incident waves can be transmitted or reflected
  • Transmission
  • Transmitted wave is of the same type as the
    incident wave
  • Reflection
  • If incident wave sees a larger cross section,
    reflected wave is of the other type
  • If incident wave sees a small cross section,
    reflected wave is of the same type

16
Organ Pipes continued
  • After the valve opens, pressure in the cylinder
    drops sending an expansion wave up the pipe
  • Expansion wave is reflected as a compression wave

17
How to Optimize Runner Length
Where ? is the ratio of valve open angle to
pi a is the Isentropic Speed of sound V is the
fluid velocity N is the number of revolutions
per second
18
How to Optimize Runner Length
  • With a fixed fluid velocity the trend can be
    observed
  • Higher Engine speeds Require shorter runners
  • Lower Engine Speeds require longer runners

Graph of Intake Runner Length vs. Engine RPM
using the previous equation.
19
Implications for Manifold Tuning
  • Can only tune for a very narrow rpm range
  • The tuning effect will decrease on either side of
    selected rpm speed.

20
Practical Applications
  • Engine Compartment space limits intake runner
    length
  • Possible Solutions
  • Manifold Folding
  • Separate tuned runners
  • Reduce runner length by factor

21
Manifold Folding
  • Manifold can be folded to achieve optimum low
    speed rpm length
  • A valve can switch between the two paths the
    waves take

22
Manifold Folding cont.
  • Example of folded manifold with two way valve
  • This setup can be done for each intake runner or
    the air intake itself to serve all the cylinders

23
Separate Tuned Runners
  • Each cylinder has two intake runners
  • Have a long runner for low rpm and a short runner
    for high rpm
  • Valve actuators switch between the two runners

24
Separate Tuned Runners cont.
Low RPM Runner
Throttle Body
High RPM Runner
Vacuum Actuated Valve
Intake Plenum
25
Reducing Runner Length by factors
  • If a runner length is too large its total length
    can be reduced by a factor.
  • A 20 inch long runner can be reduced by a factor
    of 4 and a 5 inch runner will be equivalent.

Intake Velocity Stacks
26
Exhaust System Tuning
  • Exhaust Manifold tuning is similar to intake
    manifold tuning
  • The same wave theory can be used to optimize
    header length
  • Compression wave is emitted and the expansion
    wave returns to clear the exhaust gases

27
Exhaust System Tuning cont.
  • Exhaust temperature greatly affects header length
  • Higher Temperature increases speed of sound

28
Exhaust System Tuning cont
  • Header Length as a function of gas temperature

29
Implications For Exhaust Manifold Tuning
  • Because of the higher temperatures Longer headers
    must be used.

30
Additional Exhaust Tuning Considerations
  • Gas exit speed
  • High velocity gas indicates restriction
  • Low velocity gas makes power curve peaky and
    hurts low end power
  • Header pipe diameter
  • Larger diameter tubes allow gases to expand,
    thus slowing down gas speed and wave speed

31
Additional Exhaust Tuning Considerations
  • Collector package
  • Number of pipes per collector
  • Outlet sizing
  • Collector shape

32
Header Configurations
  • 4-2-1 Configuration
  • 4-1 Configuration
  • Allows pulses to interact in a way that makes
    more torque

33
Exhaust Collectors
  • Collectors merge all of the primary pipes
    together
  • Dead space in the middle should be eliminated to
    reduce turbulence

More efficient merge of primaries
Simplest way of joining primaries together
Merge collector is one of the best ways for
joining primaries, primaries joined smoothly to
avoid turbulence
34
Exhaust Collector Length
  • The longer the collector, the higher up the power
    band is shifted
  • Need enough length to smoothly join gases from
    primaries to avoid turbulence

35
Other Tuning Considerations
  • Flow Friction through Manifold
  • Charge heating

36
Flow Friction Through Manifold
  • Although not as crucial as the unsteady
    compressible flow dynamics, flow friction plays a
    role in manifold tuning
  • By lowering the surface roughness the air flow
    becomes smoother

37
Flow Friction Through Manifold cont.
  • Porting and polishing is one of the best ways for
    aftermarket engine improving
  • Once engines are modified, more intake manifold
    is needed to make more power

Ported Intake passages from Subaru WRX
38
Intake Charge Heating
  • As the intake charge gets colder the mass going
    into the engine increases due to increased
    density
  • Primary Sources of Intake Charge Heating
  • Hot inducted air from engine compartment
  • Heat transfer from manifold to intake charge
  • Heat transfer from intake valve to intake charge
  • (only for force inducted engines) turbocharger
    or supercharger
  • A very important issue on Force Inducted engines
  • Intake charge can reach extreme temperatures
  • Extreme intake temperatures can lead to
    detonation

39
Intake Charge Heating Solutions
  • Cold air induction
  • Intake manifold and cylinder head thermal coating
  • Intercooler (force inducted engines only)
  • Nitrous oxide injection
  • Alcohol/water injection

40
Intake Charge Heating Solutions cont.
Cold air intake
Intercooling
Alcohol/Water injection
41
Summary and Conclusion
  • Manifolds are passages that conduct air/fuel
    mixtures
  • Intake manifolds conduct air/fuel into the
    cylinder
  • Exhaust manifolds conduct waste combustion
    products out of the cylinder
  • The main goal of manifold tuning is to increase
    the volumetric efficiency
  • Manifold tuning involves not only fluid mechanics
    but also thermodynamics
  • Intake and exhaust manifolds must be designed to
    complement each other
  • Several factors within the intake and exhaust
    system contribute to loss of volumetric
    efficiency

42
Questions?
