Chapter 7Fracture Macroscopic Aspects
2
Goofy Duck Analog for Modes of Crack Loading
Goofy duck analog for three modes of crack
loading. (a) Crack/beak closed. (b) Opening
mode. (c) Sliding mode. (d) Tearing mode.
(Courtesy of M. H. Meyers.)
3
Theoretical Tensile Strength
4
Theoretical Cleavage Strength
5
Stress Concentration
Lines of force in a bar with a side notch. The
direction and density of the lines indicate the
direction and magnitude of stress in the bar
under a uniform stress s away from the notch.
There is a concentration of the lines of force at
the tip of the notch.
6
Inglis Stress Concentration
7
Stress Concentration due to a Circular Hole

• Stress distribution in a large plate containing a
  circular hole.
• (b) Stress concentration factor Kt as a function
  of the radius of a circular hole in a large plate
  in tension.

8
Stress Concentration due to an Elliptical Hole
Stress concentration at an elliptical hole for a
3b.
9
Griffith Criterion of Crack Propagation
10
Crack in Thin and Thick Plates
Crack in (a) thin (t1) and (b) thick (t2) plates.
Note the plane-stress state in (a) and the
plane-strain state in (b).
11
Dislocation Emission at Crack Tip
Dislocations emitted from a crack tip in copper.
TEM. (Courtesy of S. M. Ohr.)
12
Plane Stress and Plane Strain
13
Linear Elastic Fracture Mechanics
Inherent material resistance to crack growth, KR
and its relationship to the applied stress s and
crack size a.
14
Three Modes of Fracture
The three modes of fracture. (a) Mode I opening
mode. (b) Mode II sliding mode. (c) Mode III
tearing mode.
15
Stress Field at a Crack Tip
16
Crack Tip Stress Field
17
Some Crack and Loading Configurations
18
Plastic Zone Correction
Plastic-zone correction. The effective crack
length is (a ry).
19
DugdaleBilbyCottrellSwinden Model of a Crack.
20
Plastic Zone at Crack Tip Plane Stress and Plane
Strain
21
Variation of Fracture Toughness with Thickness
(a) Variation infracture toughness (Kc) with
plate thickness (B) for Al 7075-T6 and H-11
Steel. (Reprinted with permission from J. E.
Srawley and W. F. Brown, ASTM STP 381
(Philadelphia ASTM, 1965), p 133, and G. R.
Irwin, in Encyclopaedia of Physics, Vol. VI
(Heidelberg Springer Verlag, 1958). (b)
Schematic variation of fracture toughness Kc and
percentage of flat fracture P with the plate
thickness B.
22
Elastic Body with a Crack

• Elastic body containing a crack of length 2a
  under load P.
• (b) Diagram of load P versus displacement e.

23
Crack Extension Force
24
Crack Opening Displacement
25
Crack Opening Displacement
26
Body under External Forces
A body subjected to external forces F1, F2, . .
., Fn and with a closed contour .
27
J Integral
28
J Integral
29
R Curves for Brittle and Ductile Material
30
Different Parameters for Fracture Toughness
31
Fracture Toughness vs. Yield Stress
32
Fracture Toughness Effect of Impurities
Variation of fracture toughness KIc with tensile
strength and sulfur content in a steel. (Adapted
from A. J. Birkle, R. P. Wei, and G. E.
Pellissier, Trans. ASM, 59 (1966) 981.)
33
Plane Strain Fracture Toughness
34
Fracture Toughness vs. Yield Strength for
Different Alloys
35
Measures of Crack Tip Opening Displacement
36
Strength Distribution for a Brittle and Ductile
Solid
37
Weibull Distribution
38
Typical Values of Weibull Modulus
39
Weibull Plots for Steel and Two Alumina samples
Weibull plots for a steel, a conventional
alumina, and a controlled-particle-size (CPS)
alumina. Note that the slope (Weibull modulus
m)?8 for steel. For CPS alumina, m is double that
of conventional alumina. (After E. J. Kubel, Adv.
Mater. Proc., Aug (1988) 25.)
40
Probability of Failure for Three Ceramics
Probability of failure of flexural strength
(4-point bend test with inner and outer spans 20
and 40 mm, respectively, and cross section of 3
4 mm) for three ceramics. (Courtesy of C. J.
Shih.)
