SGML, HTML, XML: Do We Really Need All That?

1
SGML, HTML, XMLDo We Really Need All That?

• ISMT Multimedia
• Fall 2002
• Dr Vojislav B Mišic

2
Lecture Overview

• What is a markup language?
• HTML markup whats good, whats wrong
• Extensions to HTML (dHTML and style sheets, XML
  and XSL, )
• XML
• Basic elements
• Well-formed vs. valid XML
• Writing a DTD
• Examples of XML

3
Markup languages

• What is markup?
• Text (actual contents of the document)
• is interspersed with markings
• Markup is related to the text
• notes on the content
• notes on text presentation
• but virtually anything can be marked (remember
  Fermats last theorem?)
• Markup language allows separation of concerns
  content vs. presentation

4
Standards for markup

• SGML (IBM) a standardized way to write other
  markup languages (actually, a meta-language)
• SGML-based language is specified using a DTD
  (Document Type Definition)
• SGML is not really a user-friendly language,
  hence its use was rather limited, even though
  software support for it does exist

5
Other markup languages

• TeX (Knuth) is another widely used markup
  language
• Performs extremely well for complex texts with
• mathematical formulas and symbols
• cross-references
• different typefaces
• foreign language

6
A TeX example

• \beginequation\labelcoh1
• \Psi (S) \displaystyle
• \frac\displaystyle
• \sum_x \in R (S)
• \left( \ S_w (x) - 1 \right)
• \displaystyle
• \sum_x \in R (S)
• \left( \ S - 1 \right)
• \endequation

7
HTML

• HTML (HyperText Markup Language) is the language
  of the Internet
• Allows platform-independent browsing
• Text-only at first, media later
• Hyperlinks, limited visual formatting
• However, it is far from perfect, and is gradually
  being replaced (current version 4.01)

8
HTML markup

• First you write the text, then add appropriate
  markup tags
• Tags can describe logical entities
• Headings of different levels H1, H2,
• Lists and list elements (UL, OL, LI)
• But tags can describe visual effects (display
  rendering)
• Bold and italic text (B, IT)
• Font and typeface changes

9
If you make an error

• Anything not recognized as correct HTML is
  essentially ignored
• HTML browser just treats it as plain text and
  displays it directly
• In this manner, users are still able to see most
  of the source, albeit without proper formatting
• Your opinion is this good or bad?

10
HTML editing

• HTML source is ASCII and essentially layout
  independent
• Plain text editors can be used
• You can put extra white space to your hearts
  content, with no effect on what is displayed by
  the browser
• Most browsers allow you to view and save the HTML
  source of the document displayed the quickest
  way to learn HTML
• HTML is interpreted editing changes are
  displayed (almost) instantly

11
HTML on the Internet

• HTML browsers can display graphics and other
  media objects
• Although HTML by itself provides only the most
  primitive support for multimedia
• Tags can specify target URLs (hyperlinks)
• Error tolerance ensures that anyone with a
  browser (any browser) can access HTML documents
• all of which made HTML the language of choice
  for hypertext on the Internet

12
More HTML features

• Visual formatting is allowed but not forced
• you can specify a typeface, but the browser will
  substitute another one of its own choice if the
  one specified is not available
• User can easily change the presentation
• just resize window and select different
  fonts/sizes
• Browser differences (IE vs. Navigator)
  actually, not very important any more

13
HTML Interactivity

• Interactivity at first limited to hyperlinks
• Forms introduced later (Navigator 3)
• Form support still limited, most often a client-
  or server-side scripting is required
• Proliferation of scripting languages
• CGI scripts
• JavaScript and Jscript (more details later)
• Vbscript, ASP
• perl

14
Is HTML a Good Markup Language?

• Logical and visual formatting capabilities
  together
• Some people argue for cleaner separation of
  logical from visual formatting
• Others want more author control
• Many extensions (some proprietary)
• Changes generally lean towards greater author
  control over document rendering more direct
  formatting instructions included

15
Dynamic HTML

• Commercial term there is no such thing as a
  dHTML standard
• Combination of HTML with new technologies
• Stylesheets add greater author control
• Scripting allows improved interactivity,
  including user input
• Even simple animations are possible
• As always, not quite compatible extensions by
  Microsoft and Netscape

16
HTML styles

• In standard HTML, logical markup tags (such as
  ltH1gt) have predefined properties for
• Typeface
• Font size
• Mode
• Line spacing
• Properties cannot be changed, and we cannot
  define our own tags
• The only way is to use a (possibly way too long)
  sequence of appropriate primitive tags every time
  not a very convenient solution

17
Stylesheets to the rescue

• Cascaded stylesheets (CSS) cleaner separation of
  markup from actual content
• Style a named set of properties that define
  presentation of a chunk of text (character,
  paragraph, )
• Styles are present in text processing software
  (WinWord) but in some markup languages as well
  (TeX)
• CSS is used with HTML, but its not HTML
  although browsers know how to handle them together

18
CSS Syntax

• A CSS-compatible stylesheet contains a set of
  rules, each with a selector (name), a number of
  properties and their values
• Rules can be
• Inline (within a HTML tag, in document body)
• Embedded (in the head of a HTML document)
• External, in a separate file which is then linked
  or imported into a HTML document
• Position of the rule defines the scope of its
  effect on the document

19
CSS Selectors

• HTML selectors text portions of HTML tags
• Class selectors can be applied to any HTML tag
• ID selectors usually applied only once per page
  to a particular HTML tag
• Type of HTML tag defines the scope of CSS
  properties
• Block level (DIV, LI, H1)
• Inline (B, FONT, TT)
• Replaced tags (IMG)

20
CSS Properties

• Always of the form propertyvalue
• Categories of properties control
• Typefaces (fonts, size, mode)
• Text (kerning, leading, alignment)
• Lists (bullets, indentation)
• Colors (borders, text, rules, background)
• Margins
• Positioning of individual elements

21
CSS Rule with a HTML selector

• Effective redefinition of HTML tags, e.g.B
  fonts bold 18pt times,serif
  text-decoration underline
• Redefines the ltBgt (boldface) tag throughout the
  rest of the document
• Dont forget to close the brace!

22
CSS Rule with a class selector

• Independent style, applicable to any HTML
  tag.extra font-size 28pt .huge
  font-size 48pt
• Class selector must be referred to within the
  HTML tagltB class"extra"gtExtralt/BgtltB
  class"huge"gtHUGElt/Bgt

23
CSS Rule with a class selector

• May be linked to a specific HTML tagp.mini
  font-size 8pt p.big font-size 14pt
• Class selector may be applied to this HTML tag
  onlyltP classmini"gtminilt/PgtltP
  classbig"gtBIGlt/Pgt

24
CSS Rule with an ID selector

• Another independent style, applicable to any HTML
  tagarea1 position relative
  margin-left 9em color red
• ID is specified within the HTML tagltSPAN
  ID"area1"gt ... lt/SPANgt

25
More on CSS selectors

• Several CSS selectors may share the same
  definition, and individual selectors may get
  additional properties separately
• CSS rules can refer to tags nested within other
  tags, e.g.,P B background pink
• redefines the ltBgt tag only when encountered
  within the ltPgt tag

26
Adding CSS to your document

• Within a style container in the document
  headltHEADgtltSTYLE TYPE"text/css"gtlt!--
  CSS rules go here--gtlt/STYLEgtlt/HEADgt
• HTML comment tags hide the CSS rules form non-CSS
  browsers

27
Importing CSS into your document

• Create a separate file, stylefile.css, then
  writeltHEADgtltLINK RELstylesheets
  TYPE"text/css HREF"stylefile.cssgtlt/HEAD
  gt
• Several files may be added in this manner

28
More on CSS

• Single line comments start with //
• Multiline comments between matched pairs of /
  and /
• A stylesheet file may import another stylesheet
  file (hence the name CSS) with the
  statement_at_import url(stylefile)
• But the last rule listed wins!
• Also beware of browser differences!

29
More CSS capabilities

• Font selection
• Text control
• List properties
• Background properties
• Absolute and relative positioning (but this is
  very dangerous!)
• Visibility (which probably has little use by
  itself but it can be quite useful when changed
  though appropriate scripts)
• Stacking (vertical) order

30
Document Object Model

• DOM describes the structure of HTML HTML document
  as a hierarchy
• Thus allowing a script written in a suitable
  language to access and manipulate only selected
  element (or elements) within that document
• document.images.b1.src"button_on.gif" describes
  a path from root or top (which is the document
  itself) to a particular element an image file
• Then, a script can manipulate this element (e.g.,
  hide, show, replace, move, ) in response to
  certain events

31
XML

• eXtended Markup Language a simplified (easier,
  more consistent) version of SGML
• XML-compliant languages defined with appropriate
  DTDs
• XML parsers signal syntax errors (unlike HTML)
  use of authoring tools implied
• current uses (with more to follow)
• SMIL for synchronized multimedia
• RDF for resource definition exchange

32
What is XML?

• A method for putting structured data in a text
  file
• Data stored on disk can be in binary or text
  format
• Binary formats are often more concise
• Text format allows human inspection
• XML is a set of rules/guidelines/conventions for
  designing text formats for such data, to produce
  files that are
• Easy to generate and read (by a computer)
• Unambiguous and platform-independent
• Extensible, easy to localize/internationalize

33
XML looks like HTML but isn't HTML

• XML makes use of
• tags (words bracketed by 'lt' and 'gt') and
• attributes (of the form name"value")
• HTML specifies what each tag attribute means
  (and often how the text between them will look in
  a browser)
• XML uses the tags only to delimit pieces of data
  and leaves the interpretation to the application

34
XML is text, but isn't meant to be read

• XML files are text files, but they are not made
  for human readers
• Text format allows experts (such as programmers)
  to more easily debug applications
• Text format allows the use of a simple text
  editor to fix a broken XML file
• Rules for XML files much stricter than for HTML
• Applications are not allowed to try to
  second-guess the creator of a broken XML file
  if the file is broken, just stop and issue an
  error message

35
XML is verbose, but that is not a problem

• XML is a text format and uses tags to delimit the
  data
• Therefore, XML files are nearly always larger
  than comparable binary formats
• But disk space isn't as expensive anymore as it
  used to be, and compression/decompression can be
  fast and reliable
• Communication protocols can compress data on the
  fly, thus saving bandwidth as effectively as a
  binary format

36
XML is good

• XML is license-free
• XML is platform-independent
• XML is well-supported
• Choosing XML is a lot like choosing SQL
• you still have to build your own database and
  your own programs/procedures that manipulate it
• but there are many tools available and many
  people that can help you
• XML isn't always the best solution, but it is
  always worth considering

37
XML is a family of technologies

• XML the specification that defines what "tags"
  and "attributes" are
• Xlink describes a standard way to add hyperlinks
  to an XML file
• CSS is applicable to XML as it is to HTML
• XSL an advanced language for style sheets
  (presentation and manipulation)
• XSLT a transformation language
• SMIL Synchronized Multimedia Modeling
• and others

38
Well-formed vs. valid XML

• Well-formed vs. valid XML
• Well-formed documents comply with XML
  well-formedness constraints, which require that
• Elements properly nest within each other
• Elements use other markup syntax correctly
• XML allows you to use elements of your own
  naming ESSAY, SECTION, PARAGRAPH, NOTE,
  IMPORTANT
• unlike HTML, which forces all documents into a
  fixed document type

39
Writing XML One, Two

• XML Declaration declares the nature of XML
  documents to document readers
• lt?xml version"1.0" standalone"yes"?gt
• lt?xml version"1.0" standalone"no"?gt
• lt?xml version"1.0 standalone"no
  encoding"UTF-8"?gt
• Root element contains all other elements (i.e.,
  the rest of the document)
• Root element is synonymous with your document
  type
• Root element cannot be repeated

40
An XML example

• lt?xml version"1.0" standalone"yes"?gt
  ltTRIVIAgtltMATHgtltQUESTIONgtWhat is the square
  root of 25lt/QUESTIONgtltANSWERgt5lt/ANSWERgtlt/MATHgt
  ltGENERALgtltQUESTIONgtWhat is the season after
  Summerlt/QUESTIONgtltANSWERgtFalllt/ANSWERgtltANSWERgtAu
  tumn lt/ANSWERgtlt/GENERALgtlt/TRIVIAgt

41
Rules for XML elements

• All elements must have opening and closing (start
  and end) tags
• ltMATHgt ... lt/MATHgt
• There are exceptions tags like
• ltQUESTION ... /gt
• Case matters CML is case-sensitive
• Proper tag nesting must be observed
• You can add whitespace to your hearts content
  it is ignored in processing

42
XML Writing

• Describe content with elements of your own naming
• Invent a new element each time you introduce
  content that significantly differs from any
  previous
• More elements greater control you will have
  later, when you use it
• Add attributes to elements
• Attributes describe the content or behavior of
  elements

43
Another Example

• lt?xml version"1.0" standalone"yes"?gtltHELPgtltTIT
  LEgtXML Helplt/TITLEgtltQUERY area"XML"gtltQUESTIONgt
  Where do I start?lt/QUESTIONgtltANSWERgtStart with
  your root element. Break your document down into
  parts, fill them in, repeat.lt/ANSWERgtlt/QUERYgtlt
  QUERY area"XML"gtltQUESTIONgtAre my element names
  are well chosen?lt/QUESTIONgtlt/HELPgt

44
XML Writing 4

• Parsing checking well-formedness
• ltPRICEgt57.80lt/PRICEgtltPETgtltCAT type"Cornish
  Rex"gtCat nests properly within PET.lt/CATgtlt/PETgtlt
  WEATHERgtFoggy no closing tagltLEVELgtIntermedia
  teltLEVELgt improper tagltPASSWORDgtplanetB612lt/PAS
  SWDgt wrong spellingltDISTANCE TYPEKM
  120lt/DISTANCEgt missing closing
  bracketltCARgtltenginegtengine does not nest
  properly within CARlt/CARgtlt/enginegt improper
  nesting

45
Valid XML

• Valid XMLunlike well-formed onerequires a
  Document Type Definition
• DTD a set of rules that a particular document
  type must follow
• The rules state the name and contents of each
  element, and the contexts in which a particular
  element can and must exist
• DTD enables communication with databases
• Valid XML documents may be accompanied by style
  sheets for proper presentation

46
Whats in a DTD

• Two essential structures the element and the
  attribute
• Root element contains all other elements
• Contents of other elements defined recursively
  starting from the root, until you reach
  text-level elements, e.g.,
• lt!ELEMENT NAME CONTENTgt
• Elements may have attributes, which are defined
  within the element definition, or separately,
  e.g.,
• lt!ATTLIST ELEMENT-NAME NAME CDATA IMPLIEDgt

47
Writing a DTD

• lt!ELEMENT novel (preface,chapter,biography?,criti
  calessay)gt
• lt!ELEMENT preface (paragraph)gt
• lt!ELEMENT chapter (title,paragraph,section)gt
• lt!ELEMENT section (title,paragraph)gt
• lt!ELEMENT biography (title,paragraph)gt
• lt!ELEMENT criticalessay (title,section)gt
• lt!ELEMENT paragraph (PCDATAkeyword)gt
• lt!ELEMENT title (PCDATAkeyword)gt
• lt!ELEMENT keyword (PCDATA)gt

48
DTD Declarations (1)Element type declaration

• Each element type includes a name, content, and
  possibly a set of attributes
• A document can contain many conforming elements
  of that type
• Sequence ordered list of components (,)
• Choice alternative components ()
• Components may be optional (?)
• Components may be required and repeatable ()
• Components may be optional and repeated ()
• Mixed-content declarations must include PCDATA ,
  parsed character data (i.e., text) as their first
  member

49
DTD Declarations (2)Attribute List Declarations

• Much more variation here ?
• String type attributes (CDATA) virtually
  unconstrained text strings
• Enumeration attributes require a list of options
  to pick from
• Attribute defaults
• REQUIRED, required
• IMPLIED, optional
• FIXED "value", a fixed value,
• "value", a default but overridable value
• Usage
• ltELEMENT-NAME NAME"value"gt

50
An Attribute List Example

• lt!ELEMENT MEMO (TO,FROM,SUBJECT,BODY,SIGN)gtlt
  !ATTLIST MEMO importance (HIGHMEDIUMLOW)
  "LOW"gtlt!ELEMENT TO (PCDATA)gtlt!ELEMENT
  FROM (PCDATA)gtlt!ELEMENT SUBJECT
  (PCDATA)gtlt!ELEMENT BODY (P)gtlt!ELEMENT P
  (PCDATA)gtlt!ELEMENT SIGN
  (PCDATA)gtlt!ATTLIST SIGN signatureFile CDATA
  IMPLIED email CDATA
  REQUIREDgt

51
XML Writing

• Add an XML declaration
• Valid XML documents must include the appropriate
  DTD
• either as a set of internal definitions, or
• lt!DOCTYPE NAME SYSTEM definitions gt
• as a reference to an external DTD file,
• lt!DOCTYPE NAME SYSTEM "file gt
• or both simultaneously
• lt!DOCTYPE NAME SYSTEM "file definitions gt
• DTD enables the parser to check validity of the
  document (errors are NOT permitted!)

52
Writing and Parsing Valid XML

• First suggestion use a specialized editor
• Lots of choices, some of which are free ?
• Second suggestion use a validating parser
• Again, lots of choices are available, mostly in
  Java, some in C, perl, JavaScript
• IE5 includes an XML parser (not quite up to the
  standard, yet)
• XML interfaces to be included in standard DBMS
  systems Oracle, DB2, MS SQL Server

53
SMIL

• Synchronized Multimedia Integration Language
• based on XML specification, endorsed by W3C
  http//www.w3.org/TR/PR-smil
• integration of a set of independent media objects
  into a synchronized presentation
• enables authors to describe
• temporal behavior of a presentation
• spatial layout of the presentation
• hyperlinks between media objects

54
Basic elements of a SMIL specification

• smil element can have an id attribute, and it can
  contain body and head children elements
• head contains information not related to temporal
  behavior
• head can contain the following children layout,
  switch (but not both), and meta (zero or more)
• layout determines how the elements in the body
  are positioned on an abstract rendering surface
  (audio or visual)
• if no layout is specified, the rendering is
  implementation dependent
• Alternative layouts specified with a switch
  element

55
Basic elements (III)

• each element has an id and a type
• element type specifies the layout language used
  in the layout element (default
  text/smil-basic-layout)
• the default type information contains region and
  root-layout elements
• non-default type information is simply character
  data
• SMIL basic layout is a subset of the visual
  rendering model
• only positionable media object elements are
  controlled by the SMIL basic layout

56
A region example

• A text element is set to a 5 pixel distance from
  the top border of the rendering window
• ltsmilgt ltheadgt ltlayoutgt ltregion
  id"a" top"5" /gt lt/layoutgt lt/headgt
  ltbodygt lttext region"a" .../gt
  lt/bodygtlt/smilgt

57
Meta attributes

• define properties of a document
• each meta element specifies a single
  property/value pair
• the list of properties is open-ended
• authoring tools should ensure that all meta
  elements have a title with meaningful description
• information related to temporal and linking
  behavior of the document
• Parallel/sequential playback of the children
• Complex synchronization possible
• Synchronization alternatives possible

58
Hyperlinking elements

• navigational links between elements
• links are unidirectional and single-headed
• SMIL supports name fragment identifiers and the
  '' connector (just like HTML
  http//foo.com/some/pathanchor1)
• the a element used as in HTML associates a link
  with a complete media object only
• New link (presentation) can replace the old one
• New link (presentation) can be added to the old
  one
• New link (presentation) can pause the old one

59
Summary

• XML is HTML done right
• Widespread use in many areas web publishing,
  document processing, multimedia, B2B electronic
  commerce
• Tools added daily
• Database connection crucial for success

60
XML links

• www.w3c.org
• http//www.software.ibm.com/xml/
• http//msdn.microsoft.com/xml/
• www.xml.org
• www.xml.com
