Week 10 a

1
Week 10 - a

• Introduction to Recursion
• Divide and Conquer

2
Sample Programs Referenced(code located in
course folder)

• Count the Digits
• Factorial (HANDOUT)
• Fibonacci
• Recursive Exponent
• Paths through a Grid

• TracingRecursion
• Recursive Palindromes
• Divide and Conquer

3
Recursion

• Recursion is a basic problem solving technique
  that divides a problem into smaller subproblems
• These subproblems may also be divided into
  smaller subproblems
• When the subproblems are small enough to solve
  directly the process stops
• A recursive algorithm is a problem solution that
  has been expressed in terms of two or more easier
  to solve subproblems

4
Alternate Descriptions ofRecursion

• A programming technique in which a method calls
  itself
• A different way to look at repetition other than
  iteration

5
Illegal Recursion

• Recursive Directions--Infinite Recursion
• "Back to the Future"--Infinite Recursion

6
Recursion is Mysterious

• You must ass u me that a method already exists as
  you are defining it.
• "Leap of Faith"

7
The Two Requirements

• 1) Base (Stopping) Case
• Recursion stops here
• Missing with Ziggy and Michael J. Fox
• 2) Inductive (Recursive) Case
• Convert to simpler problem
• Also missing with Ziggy and Michael J. Fox
• They call for the same problem again
• Basic structure of a recursive function
• if (base case is reached)
• give solution
• else
• reduce problem to simpler version using recursion

8
Counting Digits in n

• Recursive definition
• if n is between 10 and 10
• the number of digits is 1
• otherwise
• the number of digits is 1 more than the number
  of digits in n/10
• Example
• digits(321) 1 digits(321/10) 1
  digits(32)
• 1 1 digits(32/10) 1
  1 digits(3)
• 1 1 (1)
• 3

9
Counting Digits with Java

• public static int numberOfDigits(int n)
• if ((-10 lt n) (n lt 10))
• return 1
• else
• return 1 numberOfDigits(n/10)

10
Factorial

• Write a function that, given n, computes n!
• n! 1 2 ... (n-1) n
• Example
• 5! 1 2 3 4 5 120
• Specification
• Receive n, an integer.
• Precondition n gt 0
• Return n!, a long (to avoid integer overflow).

11
Analysis

• Consider n! 1 2 ... (n-1) n
• but (n-1)! 1 2 ... (n-1)
• substituting n! (n-1)! n
• We have defined the ! function in terms of
  itself.
• Historically, this is how the function was
  defined before computers (and for-loops) existed.

12
Base Case

• Recursive functions are designed in a 3-step
  process
• 1. Identify a base case -- an instance of the
  problem whose solution is trivial.
• Example The factorial function has two base
  cases
• if n 0 n! 1
• if n 1 n! 1

13
Induction Step

• 2. Identify an induction step -- a means of
  solving the non-trivial (or big) instances of
  the problem using one or more smaller instances
  of the problem.
• Example In the factorial problem, we solve the
  big problem using a smaller version of the
  problem
• n! (n-1)! n
• 3. Form an algorithm from the base case and
  induction step.

14
Algorithm

• // factorial(n)
• Receive n.
• If n lt 1
• return 1.
• Else
• return factorial(n-1) n.

15
Factorial Exercise
16
factorial in Java

• / factorial(n), defined recursively
• ...
• /
• public static long factorial(int n)
• if (n lt 1)
• return 1 // stopping condition
• else
• return factorial(n-1) n // inductive step
• // end of factorial method

17
Fibonacci Numbers

• Fibonacci series (of integers) occurs frequently
  in nature as the growth rate for certain
  idealized animal populations
• The series begins with 0 and 1, and each
  successive number is the sum of the two previous
  numbers
• Fib(0) 0, Fib(1) 1, Fib(n) Fib(n-2)
  Fib(n-1)
• 0, 1, 1, 2, 3, 5, ?
• Base case(s)?
• Recursive (inductive) step?
• Review and try in BlueJ

18
Fibonacci Sequence

• 0, 1, 1, 2, 3, 5, 8, 13, 21, 34, 55, 89, 144, ...

public static int fib(int n) // precondition
n gt 0 if (n lt 2) return n else
return fib(n-1) fib(n-2) // end of fib
function
19
Math.pow(x,n) method

• Write a recursive algorithm to calculate the nth
  power of x
• x x x x x (n times)
• Base case?
• what condition?
• return what?
• Inductive step?
• what simpler call to the same function?

20
Evaluating Exponents Recursively

• static int power(int x, int n)
• // raise x to the power n
• // precondition n gt 0
• if (n 0)
• return 1
• else
• return x power(x, n 1)
• // end of power function

21
Paths through a Grid"Lost in Manhattan" (1 of 3)
46th Street
7th Avenue
45th Street
5th Avenue
6th Avenue
44th Street
43rd Street
42nd Street
North North North North East East East North
North East North North
22
Paths through a Grid"Lost in Manhattan" (2 of 3)

• Two choices at each intersection
• North or East
• Start at myRow, myCol (42,7)
• Want to get to dinerRow, dinerCol (46,5)
• method is to determine total number of different
  paths one could take

23
Paths through a Grid"Lost in Manhattan" (3 of 3)

• Total number of paths number if started going
  East plus number if started going North
• If we started by going north one block, we would
  now be dealing with simpler problem
• Problem keeps getting simpler until we are
  looking down the street or avenue and see the
  Diner (i.e. we reach the correct row or column)
• There is now only one path without going the
  wrong direction

24
Paths Program

• Constructor sets up destination row and column
  (target)
• Loop to allow user to enter starting location
  (row col)
• Run in BlueJ
• Look at Code

25
Java BREAK
26
Pushdown Stack

• Stack is a data structure
• First In, Last Out (like cafeteria trays)
• Stack used to automatically track info for
  function calls
• return addresses
• call-by-value parameters
• local variables
• Every time a function is called, a set of data
  goes on the stack, it disappears when the
  function returns
• Recursion the stack grows

27
Recursion ClassContains Several Sample Methods

• public static int numberOfDigits( int n )
• // counts the number of digits in a whole number
• public static int numberOfDigits( int n )
• // counts the number of digits in a whole number
• public static int numberOfDigitsInf( int n )
• // calculates traces the factorial of a number
• public static long factorial( int n )
• // calculates x raised to the n power
• public static long power( int x, int n )
• // calculates x raised to the n power more
  efficiently
• public static long power2( int x, int n)
• public static void printReverse(String s)

28
Tracing Recursion

• Could we add print statements to method to have
  it trace the process?
• What would be printed by the following?
• public static int numberofDigits(int n)
• System.out.println("--gt n is " n)
• if ((-10 lt n) (n lt 10))
• return 1
• else
• return 1 numberofDigits(n/10)

29
Tracing Recursion

• How do we trace the upward spiral?
• See Recursion Project
• Note numberOfDigitsTrace method in Recursive
  class
• print statements when enter and before returns
• need to compute the return value separate from
  the return statement
• could we put the print after the return? why/why
  not?
• What should be printed?
• Try it

30
Review the 2 Requirements

• 1) Base (Stopping) Case
• Recursion stops here
• 2) Inductive (Recursive) Case
• Convert to simpler problem
• Basic structure of a recursive function
• if (base case is reached)
• give solution
• else
• reduce problem to simpler version using recursion

What happens if we forget to include the base
case?
31
Infinite Recursion

• If we have no simple case that just returns a
  value instead of calling the method again, could
  we create an infinite loop?
• What would the following code do?
• public static int numberOfDigitsInf( int n )
• System.out.println("--gt n is " n)
• int returnValue 1 numberOfDigitsInf( n/10
  )
• System.out.println("lt-- Returning "
  returnValue)
• return returnValue
• // end numberOfDigitsInf
• Try it in the project does it ever return
  anything?
• Wait until stack overflows

32
Strings and Recursion

• Write a recursive algorithm for printing a string
  in reverse order
• Base case?
• Recursive (inductive) step?
• Try it in Recursion project
• Note implicit use of a "Stack"

33
Palindromes(review)

• AHA! BOB MOM DAD
• KAYAK
• RADAR
• SOLOS
• DEIFIED
• A TOYOTA
• BIRD RIB
• DON'T NOD
• GNU DUNG
• RACE CAR
• TOP SPOT
• DAMMIT, I'M MAD!
• "MADAM, I'M ADAM" (said to Eve in Garden of Eden)

• WONTONS? NOT NOW.
• RACE FAST, SAFE CAR.
• NEVER ODD OR EVEN
• DENNIS AND EDNA SINNED
• STEP ON NO PETS
• WAS IT A CAT I SAW?
• TOO HOT TO HOOT!
• NOT NEW YORK, ROY WENT ON
• A SLUT NIXES SEX IN TULSA
• MA IS AS SELFLESS AS I AM
• A MAN, A PLAN, A CANAL PANAMA
• CIGAR? TOSS IT IN A CAN, IT IS SO TRAGIC.

34
Palindromes

• A palindrome is a string that reads the same
  forwards and backwards
• e.g. radar or 1991 or ab cdc ba
• How could we use recursion to test to see if a
  string is a palindrome?
• Base case?
• Recursive (inductive) step?
• Write an algorithm
• Trace it by hand with the examples above and with
  a non-palindrome?
• Implement the algorithm in Java
• Review and try in Recursion project

35
Divide and Conquer

• Using this method, each recursive subproblem is
  about one-half the size of the original problem
• If we could define power so that each subproblem
  was based on computing kn/2 instead of kn 1 we
  could use the divide and conquer principle
• Recall the efficiency of Binary Search vs. Linear
• Recursive divide and conquer algorithms are often
  more efficient than iterative algorithms

36
Evaluating Exponents UsingDivide and Conquer

• static int power(int x, int n)
• if (n 0)
• return 1
• else
• int t power(x, n/2)
• if ((n 2) 0)
• return t t
• else
• return x t t
• // end of divide conquer power

37
HW Assignment 9Prefix Notation

• In prefix notation, operators are followed by
  their two operands. (e.g. 12 3 is interpreted
  as 123)
• Your program must use recursion to allow nested
  expressions with multiple operators.
• Note that the order of execution can be specified
  without use of parentheses.
• See examples on next slide

38
HW Assignment 92 "Volunteers" to Board
(odd/even problems)

• 5 / 3 2
• 2 3 5 7
• 12345
• 123 456
• 2 3 5 7 1
• 2 3 4 5
• 1 2 3 4 5 6
• / 8 / 4 2

39
HW Assignment 92 "Volunteers" to Board
(odd/even problems)

• 5 / 3 2 6.5
• 2 3 5 7 210.0
• 12345 12345.0
• 123 456 579.0
• 2 3 5 7 1 18.0
• 2 3 4 5 26.0
• 1 2 3 4 5 6 21.0
• / 8 / 4 2 4.0

40
HW Assignment 9main Method

• public static void main(String args)
• String expression
• StringBuffer expBuffer
• double result
• while (true)
• expression JOptionPane.showInputDialog(
• "Please enter a Polish
  Expression")
• expBuffer new StringBuffer(expression)
• if (expression.equals("")) break
• result eval(expBuffer)
• System.out.println(expression " "
  result)
• // end of input loop
• // end of main method

41
HW Assignment 9Sample Run

• Run instructor's version of HW 9
• You will be modifying the code to read all
  expressions from an external file

42
Java BREAK
