Intro to Reverse Engineering

1
Intro to Reverse Engineering

• intropy

2
Intro
3
Why do we reverse engineer?

• Closed source software
• Vulnerability Research
• Product verification
• Proprietary formats
• Interoperability
• SMB on UNIX
• Word compatible editors
• Virus research

4
Why should you give a fuck?

• Basis of computing
• Reverse engineering teaches the inner workings of
  any processor
• Learning how the processor handles data helps in
  understanding many other aspects of computer
  security
• All the cool kids are doing it (not really)

5
Real Time RCE (Debugging)

• Debuggers that disassemble
• OllyDbg
• WinDbg
• SoftIce
• Code actually runs
• The application actually executes all
  instructions as if it was ran normally
• Uses interrupts to control execution of the
  program
• Swaps out the current instruction with an
  interrupt instruction code
• Swaps it back when the execution is continued

6
Static Analysis (Dead Listing)

• Traditional disassemblers
• IDA Pro
• W32Dasm
• objdump
• Code does not execute
• The disassembler parses the file format and
  related code sections
• Good disassemblers do deep recursive analysis to
  ensure proper instruction disassembly
• Allows the user the ability to look at what code
  will do without actually running it
• Does not allow the ease of live
  disassembly/debugging
• Viewing registers
• Inspecting the contents of memory

7
File Formats
8
What are file formats?

• Files that adhere to a specific format often
  being executable by an operating system
• Executable files are created from source code and
  libraries by a compiler
• Data files can be created by anything from a text
  editor to an mp3 encoder

9
Executable Contents

• Machine code
• Instructions the program will run
• Memory locations
• code addresses
• function addresses
• Program data
• Static variables
• Strings
• Loader data
• Imports
• Exports

10
Sections

• Allows the loader to find various information
• Not finite, executables can have user defined
  sections

11
Executable Formats

• ELF Executable and Linker Format
• History
• Originally published by UNIX system laboratories
  as a dynamic, linkable format to be used in
  various UNIX platforms
• What uses ELF
• Linux
• Solaris
• Most modern BSD based unixs
• Dissection
• Header
• Sections

12
ELF Header

• The header contains various information the
  operating system loading needs
• e_ident Contains various identification
  fields including Endianess, ELF
  version, Operating System
• e_type Identifies the object file
  type including relocatable, executable,
  or core file
• e_machine Contains the processor type including
  Intel 80386, HPPA, PowerPC
• e_version Contains the file version
  information
• e_entry - Contains the entry point for
  the executable
• e_phoff Contains the program files
  header offset in bytes
• e_shoff Contains the section header
  offset
• e_flags Contains the processor specific
  flags
• e_ehsize Contains the ELF header size in
  bytes

13
ELF Sections

• Each section of an ELF executable contain various
  information needed to execute
• .bss - This section holds uninitialized data
  that contributes to the program's memory
  image. By definition, the system initializes the
  data with zeros when the program begins to
  run.
• .comment - This section holds version control
  information.
• .ctors - This section holds initialized
  pointers to the C constructor functions.
• .data - This section holds initialized data
  that contribute to the program's memory
  image.
• .data1 - This section holds initialized data
  that contribute to the program's memory
  image.
• .debug - This section holds information for
  symbolic debugging. The contents are
  unspecified.
• .dtors - This section holds initialized
  pointers to the C destructor functions.
• .dynamic - This section holds dynamic linking
  information.

14
ELF Sections Cont

• .dynstr - This section holds strings needed for
  dynamic linking, most commonly the strings
  that represent the names associated with symbol
  table entries.
• .dynsym - This section holds the dynamic linking
  symbol table.
• .fini - This section holds executable
  instructions that contribute to the process
  termination code. When a program exits normally
  the system arranges to execute the code in
  this section.
• .got - This section holds the global offset
  table.
• .hash - This section holds a symbol hash table.
• .init - This section holds executable
  instructions that contribute to the process
  initialization code. When a program starts to run
  the system arranges to execute the code in
  this section before calling the main program
  entry point.
• .interp - This section holds the pathname of a
  program interpreter. If the file has a
  loadable segment that includes the section, the
  section's attributes will include the
  SHF_ALLOC bit. Otherwise, that bit will be off.
• .line - This section holds line number
  information for symbolic debugging, which
  describes the correspondence between the program
  source and the machine code. The contents are
  unspecified.

15
ELF Sections Cont

• .note - This section holds information in the
  Note Section'' format described below.
• .plt - This section holds the procedure linkage
  table.
• .relNAME - This section holds relocation
  information. By convention, NAME'' is
  supplied by the section to which the relocations
  apply. Thus a relocation section for .text
  normally would have the name .rel.text
• .rodata - This section holds read-only data
  that typically contributes to a non- writable
  segment in the process image.
• .rodata1 - This section holds read-only data
  that typically contributes to a non- writable
  segment in the process image.
• .shstrtab - This section holds section names.
• .strtab - This section holds strings, most
  commonly the strings that represent the names
  associated with symbol table entries.
• .symtab - This section holds a symbol table. If
  the file has a loadable segment that includes
  the symbol table, the section's attributes will
  include the SHF_ALLOC bit. Otherwise the
  bit will be off.
• .text - This section holds the text'' or
  executable instructions, of a program.

16
Executable Formats Cont

• PE Portable Executable
• History
• Microsoft migrated to the PE format with the
  introduction of the Windows NT 3.1 operating
  system. It is based of a modified form of the
  UNIX COFF format
• What uses PE
• Windows NT
• Window 2000
• Windows XP
• Windows 2003
• Windows CE
• Dissection
• DOS Stub
• The DOS stub contains a message that the
  executable will not run in DOS mode
• Optional Header (Not optional
• RVA
• Relative virtual addressing
• Sections

17
Optional Header

• The optional header in a PE executable contains
  various information regarding the executable
  contents needed for the OS loader
• SizeOfCode - Size of the code (text)
  section, or the sum of all code sections
  if there are multiple sections.
• AddressOfEntryPoint Address of the entry
  function to start execution from
• BaseOfCode - RVA of the start of the
  code relative to the base address
• BaseOfData RVA of the start of the
  data relative to the base address
• SectionAlignment Alignment of sections
  when loaded into memory
• FileAlignment Alignment of section on
  disk
• SizeOfImage - Size, in bytes, of image,
  including all headers must be a
  multiple of Section Alignment
• SizeOfHeaders - Combined size of MS-DOS
  stub, PE Header, and section
  headers rounded up to a multiple of
  FileAlignment.
• NumberOfRvaAndSizes - Number of data-dictionary
  entries in the remainder of the
  Optional Header. Each describes a location and
  size.

18
Sections

• The sections in a PE file contain various pieces
  of the executable needed to run including various
  RVAs and offsets
• .text Contains all executable code
• .idata Contains imported data such as dll
  addresses
• .edata Contains any exported data
• .data Contains initialized data like global
  variables and string literals
• .bss Contains un-initialized data
• .rsrc Contains all module resources
• .reloc Contains relocation data for the OS
  loader

19
Data Formats

• Different than executable formats
• Doesnt usually contain machine code
• Has structure but not always defined sections
• A reverser often needs to reverse how a file
  format functions
• Proprietary formats are not always published
• Reversing allows compatibility (i.e. Microsoft
  doc)
• Data rights management
• Often the only way to get what you pay for is to
  take action

20
Assembly Language
21
What is it

• Lowest level of programming (besides microcode)
• Direct processor register access utilizing
  architecture defined instructions
• Output of most compilers

22
How is it used

• Directly using an assembler
• NASM
• ml
• as
• Output by a high level compiler
• GCC
• cl

23
What does it looks like

• Depends on the instruction set
• IA32
• mov eax, 0x1
• PA-RISC
• copy r14,r25
• ARM
• LDR r0,r8

24
Instruction Sets

• The mneumonics for the opcodes handled by the
  processor
• Minimal set of commands that achieve a
  programming goal

25
Different Instruction Set Architectures

• RISC - Reduced Instruction Set Computing
• Fixed length 32 bit instructions
• 32 general purpose registers
• Vendors
• IBM (PowerPC)
• HP (PA-RISC)
• Apple (PowerPC)
• CISC - Complex Instruction Set Computing
• Multibyte instructions
• Multiple synonymous opcodes
• 16 registers
• Vendors
• Intel (IA-32)
• DEC PDP-11
• Motorola (m68K)

26
Registers and the Stack
27
Overview

• Purpose
• Registers are used to store temporary data
• Pointers
• Computations
• The stack is used to manage data
• Variables
• Data

28
Stack Layout

• Stack is dynamic but builds as it goes
• Addresses start at a higher address and builds to
  lower addresses
• The stack is generally allocated in 4 byte chunks

29
Register sizes

• Register sizes depend on the supported
  architecture
• 32 bit
• 64 bit
• IA32
• 16 registers 32 bits (4 bytes) each
• RISC
• 32 general purpose registers 64 bits 8 bytes
  each

30
IA32 Registers

• EBP Stack frame base pointer
• Points to the start of the functions stack frame
• ESP Stack source pointer
• Points to the current (top) location on the stack
• EIP Instruction pointer
• Points to the next executable instruction

31
IA32 Registers Cont

• General Purpose registers
• Used in general computation and control flow
• EAX Accumulator register
• EBX General data register
• ECX Counter register
• EDX General data register
• ESI Source index register
• EDI Destination index register
• Segment registers
• Used to segment memory and compute addresses
• CS Code segment register
• SS - Stack segment register
• DS - Data segment register
• ES - Extra (More data) segment register
• FS - Third data segment register
• GS Fourth data segment register
• EFLAGS
• CF Carry Flag
• SF Signed Flag

32
Overview of IA-32 Instruction Set

• mov Moves source to destination
• lea Loads effective address
• jmp Jump
• jne Jump if not equal
• jg Jump if greater than
• call Unconditional function call
• ret Returns from a function to the caller
• add Adds two values
• sub subtracts two values
• xor XORs two values
• cmp Compares two registers

33
Calling conventions

• Calling conventions define how the callers data
  is arranged on the stack
• cdecl
• Most common calling convention
• Dynamic parameters
• Caller unwinds stack
• pop ebp
• ret
• fastcall
• Higher performance
• First two parameters are passed over registers
• stdcall
• Common in Windows
• Parameters are received in reverse order
• Function unwinds stack
• ret 0x16

34
Example

• PUSH EBP Pushes the contents
  of EBP onto the stack
• MOV EBP, ESP Moves the
  address of ESP to EBP
• CMP DWORD PTR EBPC, 111 Subtract
  what is at EBP12 with 111
• JNZ 00401054 If previous
  compare is not zero jump to
  00401054
• MOV EAX, DWORD PTR EBP10 Move what is
  at EBP16 to EAX
• CMP AX, 64 Subtract what we
  moved to EAX with 64
• JNZ 00401068 If the
  comparison does not equal 0 jump to
  address
• POP EBP Store the current
  value on the stack in EBP
• RET Return to the caller

35
OllyDbg
36
Overview

• Purpose
• OllyDbg is a general purpose win32 user land
  debugger. The great thing about it is the
  intuitive UI and powerful disassembler
• Licensing
• OllyDbg is free (shareware), however it is not
  open source and the source code is not available
• Extensibility
• OllyDbg has defined a plugin architecture
  allowing extensibility via powerful plugins

37
Window Layouts

• Window layouts are the various parts of the UI
  that contain pertinent information
• Code window Displays the executable machine
  code
• Register window Allows the user to watch the
  contents of each register during execution
• Memory window Allows the user to view the
  contents of various memory locations
• Stack window Displays the stack, including
  memory addresses and values

38
Working in OllyDbg

• Navigation
• Moving
• Searching
• Commenting
• Can be entered in the code window with the or
  keys
• Listing Names
• The names window displays all functions or
  imported functions used in the program
• Listing them is easy via the shortcut Ctrl N
• Showing Memory
• Displaying memory can be useful when looking for
  strings or other important data
• Displaying the memory map window can be achieved
  via Alt M

39
Working in OllyDbg Cont

• Breakpoints
• Breakpoints allow the debugger to stop at a
  specified address or instruction
• There are two types of breakpoints in general
• Software breakpoints
• Handled by the operating system
• Set by navigating to the specified address and
  hitting F2
• Hardware breakpoints
• Handled by the processor
• Set by finding a place in memory you want to
  break on access and right clicking selecting the
  proper option
• Olly also provides a way to view and turn on and
  off breakpoints via the breakpoints window with
  Alt B

40
Working in OllyDbg Cont

• Controlling Execution
• Starting the process
• Once the target program is either loaded or
  attached in Olly you can start execution. This
  will actually set up an initial breakpoint at the
  application entry point
• There are several ways you can proceed from the
  entry point
• Single stepping
• Executes one instruction at a time and can be
  achieved by hitting F7
• Steps into every function
• Tedious as fuck
• Execute until return
• Executes until the ret instuction is encoutered
  which can be achieved by hitting Ctrl F9
• Executes all instructions in the current function
• Faster than single stepping but not as
  comprehensive

41
Working in OllyDbg Cont

• Watching execution
• Registers
• Handled in the register window
• Red highlighting indicates a register has changed
• Stack
• Handled in the stack window
• Display can be address or relative address from
  ebp
• Call stack
• Displays the functions the current function has
  been called from
• Can be displayed with the shortcut Alt K

42
OllyDbg Case Study(smarty word for demo)

• Example
• Program displays a popup box
• Goal is to make the proper box show and exit
• Patching
• Allows us to modify the executable assembly code
  and save it to a new file with the changes

43
OllyDbg Plugins

• OllyDbg provides a downloadable PDK for plugin
  development
• Several plugins exist that provide extra
  usability
• Heap Vis
• Breakpoint manager
• Ollyscript

44
IDA Pro
45
Overview

• IDA Pro was originally designed as a powerful
  disassembler
• Supports 30 processors
• It has since been broadened to include a built in
  debugger
• Designed for reverse engineers with quickness and
  robustness in mind
• This sometimes makes the learning curve step
• Extensible plugin architecture and scripting
  language

46
Window Layouts

• Customizing window layouts
• Each saved session will store any customized
  layouts
• A default layout can also be saved
• Customized layouts are provided to help the user
  with workflow and can consist of any combination
  or number of windows

47
Navigation

• Shortcuts
• Most actions have equivalent shortcuts associated
  with them
• Some of the most used
• Enter Jumps into the function under the
  cursor
• Esc Returns to the previous cursor position
• Jumping
• IDA allows the user to jump to various parts of a
  binary file easily
• Some of the jumps
• Entry point Jumps to the entry point of the
  binary
• By name Allows the user to jump to a specific
  function or string in the binary
• By address Allows the user to jump to a
  specific address
• Markers
• Markers can be used to tag locations in the
  binary for future reference
• Markers are set using Alt M and naming
• Jumping to a marker is easily achieved with Ctrl
  M

48
Editing

• Comments
• Comments allow you to organize and document
  important parts of the binary
• Comments can be entered using the shortcut keys
  or
• Function names can be renamed to something more
  descriptive
• Often times symbols are not available for the
  binary and naming each functions allows you to
  understand and track your work
• Functions can be renamed using the shortcut Alt
  P

49
Windows

• IDA View
• Displays the disassembled binary
• Hex View
• Display the hex view of the current cursor
  position
• Names
• The names windows displays textual names and
  addresses in the binary
• Strings
• The strings window contains any ascii strings
  present in the executable
• Imports
• The imports window contains the imported
  functions from dlls
• Functions
• The functions window allows you to view all
  functions and their addresses

50
Graphing

• IDA Pro has a powerful graphing engine that
  allows a user to visualize call graphs and xrefs
• Flow chart graphs display the current functions
  machine code and any branches
• Function call graph will display the call flow of
  all the functions in the executable (Can be
  large)
• Xref graphs display the to and from xrefs with
  machine code

51
SDK/Plugins

• The SDK allows the user to develop plugins for
  use in IDA Pro
• Plugins are generally written in C/C and
  compiled against the SDK libraries and headers
• Using the plugins you can write
• processor modules
• input processing modules
• plugin modules
• Some good plugins
• x86emu Allows ida to do runtime emulation
• IDAPython Access the IDA API in Python
• Processes Stalker Allows visualization and run
  time tracing

52
Flirt

• Fast Library Identification and Recognition
  Technology
• Flirt is a means for IDA Pro to identify imported
  functions and compilers by matching against a
  database of known signatures
• This greatly speeds up analysis by automatically
  naming discovered functions
• Only works with C/C functions

53
IDC Scripting

• The IDC scripting engine allows the user to
  achieve small tasks through the IDC scripting
  engine
• IDC resembles C and has many helpful functions
  built in
• PatchByte
• Comment
• FindCode

54
Plugins

• Plugins are compiled files used to do large tasks
  and can be integrated with the UI
• Many plugins already exists
• idapalace.com
• datarescue.com/community/plugins

55
Decompiling
56
Overview

• Decompiling is different than disassembling in
  that it tries to reconstruct machine code to
  readable (and ultimately compilable) source code
• Native compiled code is difficult to reconstruct
  because of the compilers behavior when optimizing
  the produced code
• Virtual machine code is much easier to achieve
  readable code because of its nature. It must be
  compiled into a intermediate language with all
  necessary information the target platform may
  need to run
• .Net
• Java

57
.Net

• .Net is compiled down into MSIL (Microsoft
  intermediate language) and is a good example of
  decompiling
• .Net must provide the operating system with a
  wealth of information including symbol names, and
  data structures

58
Native code

• Native code is a language that has been compiled
  down into machine language
• Often times because of optimization a compiler
  inadvertently obfuscates the higher lever source
  code
• Decompiling is not quite to the point of
  producing a good representation of the original
  source code

59
Decompilers

• .Net
• ILDasm
• Remotesoft Salamander
• Reflector for .Net
• Java
• JODE
• JAD (Disappeared)
• Native
• Boomerang

60
Decompilation Demo

• Thanks fend3r!

61
Conclusion

• Reverse engineering is a vast and complex world
• With a lot of practice though it becomes much
  easier
• A good reverser knows their tools inside and out
• Workflow and organization are the keys to
  reversing

62
Shirt Quiz

• Name the IA-32 registers
• What does .Net assemble into
• In OllyDbg how do you list the Names
• What is the IA-32 instruction to Compare two
  integers
• How does the IA-32 processor handle signedness
• What does the IDC scripting language resemble
• How many processors does IDA support (roughly)
• In IDA how do you quickly follow a CALL

63
References

• Reversing - http//www.wiley.com/WileyCDA/WileyTit
  le/productCd-0764574817.html
• ELF File format - http//www.skyfree.org/linux/ref
  erences/ELF_Format.pdf
• PE File Format - http//msdn.microsoft.com/library
  /default.asp?url/library/en-us/dndebug/html/msdn_
  peeringpe.asp
• http//lsd-pl.net/references.html
• OllyDbg - http//ollydbg.de/
• OllyDbg Plugins - http//ollydbg.win32asmcommunity
  .net/stuph/
• IDA Pro - http//www.datarescue.com/
• IDC - http//www.datarescue.com/idadoc/707.htm
• IDA Plugins - http//home.arcor.de/idapalace/
• Reflector - http//www.aisto.com/roeder/dotnet/
• JODE - http//jode.sourceforge.net/
• Boomerang - http//boomerang.sourceforge.net/
• Crackmes.de - http//www.crackmes.de/

64
Fucking done.

• Questions?
