Title: AP Unit III C 2


1
AP Unit III C 2
  • Steady state direct current circuits with
    batteries and resistors only

2
  • a) Students should understand the behavior of
    series and parallel combinations of resistors, so
    they can
  • (1) Identify on a circuit diagram whether
    resistors are in series or parallel.
  • (2) Determine the ratio of the voltages across
    resistors connected in series or the ratio the
    currents through resistors connected in parallel.
  • (3) Calculate the equivalent resistance of a
    network of resistors that can be broken down into
    series and parallel combinations.

3
  • (4) Calculate the voltage, current, and power
    dissipation for any resistor in such a network of
    resistors connected to a single power supply.
  • (5) Design a simple series-parallel circuit that
    produces a given current through and potential
    difference across one specified component and
    draw a diagram for the circuit using conventional
    symbols

4
  • (b) Students should understand the properties of
    ideal and real batteries, so they can
  • (1) Calculate the terminal voltage of a battery
    of specified emf and internal resistance from
    which a known current is flowing.
  • (2) Calculate the rate at which a battery
    supplying energy to a circuit or is being charged
    up by a circuit.

5
  • (c) Students should be able to apply Ohms Law
    and Kirchoffs rules to direct current circuits
    in order to
  • (1) Determine a single unknown current, voltage,
    or resistance.
  • (d) Students should understand the properties of
    voltmeters and ammeters, so they can
  • (1) State whether the resistance of each is high
    or low.
  • (2) Identify or show correct methods of
    connecting meters into circuits in order to
    measure voltage or current

6
Series Circuits
  • The resistance in a series circuit is equal to
    the sum of the resistances around the circuit.
  • RT R1 R2 R3

7
Parallel Circuits
  • The total resistance an a parallel circuit is
    from the inverses of the individual resistances
  • 1/ RT 1/R1 1/R2 1/R3

R1
R2
R3
8
  • If a series circuit has 3 resistors each of 15 O,
    calculate the total resistance in the circuit.
  • If a parallel circuit has 3 resistors each of 15
    O, calculate the total resistance in the circuit.
  • Three resistors in parallel, 15 O, 25 O, 35 O.
    Calculate the total resistance in the circuit.

9
Kirchoffs Laws
  • First Law At a junction the total current
    entering the junction is equal to the total
    current leaving the junction
  • Second law The net e.m.f. (electromotive force)
    around a circuit loop is equal to the sum of the
    p.d.s around the loop.

10
Voltmeters
  • Voltmeters are connected in parallel ACROSS the
    component they are measuring the potential
    difference of.
  • They have a high internal resistance so
    negligible current goes through them.

V
11
Ammeters
  • Have low resistance and measure the current going
    THROUGH the circuit so must be connected in
    SERIES with the components.

A
