Title: IceCube DOM Calibration


1
IceCube DOM Calibration
  • Jim Braun

2
Motivation
3
DOM-Cal Big Picture
  • Application runs on DOM
  • Can calibrate all DOMs in parallel
  • Stores calibration data on DOM flash memory
  • Java client
  • Coordinates calibration
  • Reads calibration data from DOM
  • Produces DOM-Cal XML calibration files
  • Calibrator class reads XML file, applies
    calibration constants
  • All code in dom-cal project on glacier
  • Authors John Kelley, Jim Braun, Kael Hanson

DOM-Cal Client
DOM hub
XML Files
Database
Calibrator.java
Analysis
4
Calibration Routine
  • ATWD Calibration
  • Reconstruct PMT voltage waveform from ATWD data
  • Requires
  • Voltage calibration of ATWD
  • Measurement of amplifier gain for ch0, ch1, and
    ch2
  • Frequency calibration of ATWD
  • Baseline measurement
  • PMT Gain Calibration
  • Find relationship between PMT gain and applied
    voltage
  • PMT Transit Time Calibration (NEW!)
  • Find PMT transit time as a function of applied
    voltage

5
ATWD Calibration
  • Bootstrap process!

Muons
Mainboard LED
V 5 x bias_dac / 4096
V 0.0001220 x (0.4 x disc_dac 0.1 x bias_dac)
f 20MHz
6
Pulser Calibration
  • Determine relationship between pulser DAC setting
    and peak voltage
  • Use known relationship between discriminator DAC
    and voltage
  • Set discriminator DAC, adjust pulser DAC until
    50 of pulses cross discriminator threshold
  • At this point, the pulser peak voltage
    corresponds to known discriminator voltage.
  • Peak voltage distribution is very narrow

7
Pulser Calibration
  • Repeat for 10 discriminator voltages
  • Relationship is very linear
  • Now know pulser peak voltage given DAC setting
  • Will use this relationship in amplifier
    calibration

8
ATWD Voltage Calibration
  • Determine relationship between ATWD value and
    signal voltage
  • Use known bias DAC voltage relationship
  • Bias is independent of amplifier gain
  • Set bias, record average ATWD value
  • For each bin (0-127) of each signal channel (0-2)
    of each ATWD (0-1)
  • O(100) samples
  • Apply linear fit to ATWD value vs. voltage data
  • Pedestal patterns are eliminated

9
ATWD Voltage Calibration
  • Now know voltage of any ATWD bin given a channel
    number, bin number, and value
  • Requires 768 linear fits!
  • ATWD response not entirely linear
  • Need to calculate and subtract small baseline
    offset for each channel during precision
    measurements

10
Baseline Calibration
  • New in DOM-Cal 5.0
  • Measures average baseline offset for each ATWD
    channel
  • Need to measure baseline whenever the internal
    state of the DOM changes
  • Known to affect baseline
  • Analog multiplexer
  • Mainboard LED power supply
  • PMT high voltage
  • Affects low gain channel the most
  • Main source of Hagars ch1ch2 charge discrepancy

11
Baseline Calibration
  • We care most about affect of high voltage and
    residual baseline from imperfect ATWD calibration
  • Take baseline data both with HV off and HV at
    values spanning DOM operating points
  • Store all data points
  • Use baseline value closest to operational HV when
    calibrating TestDAQ data
  • For gain calibration, domcal chooses only the
    voltages where baseline calibration points exist

12
Amplifier Calibration
  • Calibrate high gain channel (0) with pulser
  • Pulser too weak to accurately calibrate lower
    gain channels
  • Set pulser peak to a known voltage, record peak
    voltage after amplification in ch0
  • Use ATWD ch0 calibration data to find peak
    voltage
  • Maximize ATWD sampling speed to better localize
    peak
  • Record mean and error of O(250) ch0 peaks
  • Ratio of mean voltage and known pulser voltage
    yields amplification factor

13
Amplifier Calibration
  • Need source of high amplitude pulses to calibrate
    ch1 and ch2 amplifiers
  • Use PMT signals! new in DOM-Cal 5.0
  • Muons work well at surface
  • Mainboard LED needed in deep ice
  • LED power supply shifts baseline, need to
    recalibrate
  • For ch1
  • Select pulses which have an ATWD peak value of
    600-800 counts
  • Too few ch0 counts -- too much error in ch1 peak
    voltage
  • Too many ch0 counts -- ch0 nonlinearity becomes
    significant

14
Amplifier Calibration
  • For ch1
  • Record ratio of ch1 peak voltage to ch0 peak
    voltage for O(250) iterations
  • We know ch0 gain, so ch1 gain is given by the
    product of ch0 gain and voltage ratio.
  • For ch2
  • We now know ch1 gain, use previous procedure to
    find ch2 gain
  • Slow with muons (lt1 Hz)
  • Slow when discriminator rate is high
  • Use LED if necessary

15
ATWD Frequency Calibration
  • Select mainboard oscillator in ATWD analog
    multiplexer channel (channel 3)
  • At various sampling speed DAC values, count
    number of bins between positive zero crossings in
    ATWD waveform
  • Average O(100) clock waveforms
  • Assuming oscillator operates in spec _at_ 20MHz,
    ATWD frequency is given by 20MHz bins
  • Not quite linear
  • newer version will sample closer to 850 DAC value

16
Gain Calibration
  • Capture PMT single photoelectron pulses in ATWD
  • Glass radioactivity emits enough light
  • Apply ATWD calibration to get PMT V(t) waveform
  • I(t) given by V(t)/50W
  • I(t) pulse integrated from 4 bins to 8 bins of
    pulse maximum (-14ns - 28ns), yielding SPE
    charge
  • Repeat O(5000) times, histogram charge data, and
    apply nonlinear fit

17
Gain Calibration
18
Gain Calibration
Repeat from 1200V to 1900V in 100V intervals
19
Gain Calibration
Mean SPE charge vs. voltage is a power law
The number of photoelectrons for any pulse at a
given HV is now determined
20
Java Client
  • In dom-cal project on glacier
  • Main class icecube.daq.domcal.DOMCal
  • Run with no args for usage instructions
  • Reads calibration data from DOM flash
  • Stores calibration data in local XML files
  • Stores data in domprodtest database
  • Can initiate calibration
  • Can run calibrations on many DOMs and DOM hubs in
    parallel
  • Most will never need to use the java client

21
DOM-Cal XML Files
  • Hopefully, users wont need to know much about
    the XML files or database structure either!
  • Access provided through calibration applications
  • XML files are reasonably easy to read if needed
  • Contain
  • DOM hardware ID (No name..sorry Mark)
  • Temperature
  • Date
  • DAC settings and ADC readings
  • Calibration information
  • Linear fit data
  • Baseline data
  • Gain histogram data

22
DOM-Cal Calibrator
  • Icecube.daq.domcal.Calibrator java class provides
    access to calibration data.
  • I3DOMCalibration equivalent object in IceTray
  • Create a Calibrator for each DOM
  • new Calibrator(XML_File)
  • Most important routine
  • atwdCalibrateToPmtSig()
  • Takes an array of raw ATWD data and applies
    calibration to yield true voltage signal
  • Other methods to access raw data, described in
    javadoc
  • http//www.amanda.wisc.edu/jbraun/domcaldoc/

23
DOM-Cal Results
  • Currently running DOM-Cal v4.3 at pole
  • Baseline shift apparent in data from String 21
    and from last years FAT runs
  • Analog multiplexer enabled in all string-21 runs
    just recently disabled

24
DOM-Cal Results
  • DOM-Cal 5.0 results are encouraging
  • Baseline calibrated to zero for all channels
  • No analog multiplexer effects
  • Amplifier gains now calculated much more
    accurately
  • Pulse heights now agree between all three ATWD
    channels

25
DOM-Cal Results
  • The bad news
  • Probably wont see much gain when analyzing
    String 21 data, even with DOM-Cal 5.0
  • Local coincidence readout rate is a few Hz
  • Interval is long enough for baseline to drift
  • Hopefully there is a firmware fix!

26
DOM-Cal 6.0
  • Other features DOM-Cal may deal with
  • PMT transit time almost finished!
  • Signal droop
  • Evidence time constant can be easily measured
    (Chris W.)
  • Ch0 time offset, bandwidth limitation
