XML

1
Chapter 24

• XML

2
CHAPTER GOALS

• Understanding XML elements and attributes
• Understanding the concept of an XML parser
• Being able to read and write XML documents
• Being able to design Document Type Definitions
  for XML documents

3
XML

• Stands for Extensible Markup Language
• Lets you encode complex data in a form that the
  recipient can parse easily
• Is independent from any programming language

4
XML Encoding of Coin Data
ltcoingt ltvaluegt0.5lt/valuegt ltnamegthalf
dollarlt/namegt lt/coingt
5
Advantages of XML

• XML files are readable by both computers and
  humans
• XML formatted data is resilient to change
• It is easy to add new data elements
• Old programs can process the old information in
  the new data format

6
Differences Between XML and HTML

• Both are descendants of SGML (Standard
  Generalized Markup Language)
• XML is a simplified version of SGML
• XML is very strict but HTML (as used today) is
  not
• XML tells what the data means HTML tells
  how to display data

7
Differences Between XML and HTML

• XML tags are case-sensitive
• ltLIgt is different from ltligt
• Every XML start tag must have a matching end tag
• If a tag has no end-tag, it must end in /gt
• ltimg src"hamster.jpeg"/gt
• XML attribute values must be enclosed in quotes
• ltimg src"hamster.jpeg" width"400" height"300"/gt

8
Structure of an XML Document

• An XML data set is called a document
• The document starts with a header
• lt?xml version 1.0?gt
• The data are contained in a root element
• lt?xml version 1.0?gt
• ltpursegt
• more data
• lt/pursegt
• The document contains elements and text

9
Structure of an XML Document

• An XML element has one of two forms
• ltelementTag optional attributesgt contents
  lt/elementTaggt
• or
• ltelementTag optional attributes/gt
• The contents can be elements or text or both
• An example of an element with both elements and
  text (mixed content)
• ltpgtUse XML for ltstronggtrobustlt/stronggt data
  formats.lt/pgt
• Avoid mixed content for data descriptions

10
Structure of an XML Document

• An element can have attributes
• The a element in HTML has an href attribute
• lta href"http//java.sun.com"gt ... lt/agt
• An attribute has a name (such as href) and a
  value
• The attribute value is enclosed in either single
  or double quotes
• Attribute is intended to provide information
  about the content
• ltvalue currency"USD"gt0.5lt/valuegt
• or
• ltvalue currency"EUR"gt0.5lt/valuegt
• An element can have multiple attributes

11
Parsing XML Documents

• A parser is a program that
• Reads a document
• Checks whether it is syntactically cornet
• Takes some action as it processes the document
• There are two kinds of XML parsers
• SAX (Simple Access to XML)
• DOM ( Document Object Model)

12
Parsing XML Documents

• SAX parser
• Event-driven
• It calls a method you provide to process each
  construct it encounters
• More efficient for handling large XML documents

• DOM parser
• Builds a tree that represents the document
• When the parser is done, you can analyze the
  tree
• Easier to use for most applications

13
JAXP

• Stands for Java API for XML Processing
• Provides a standard mechanism for DOM parsers to
  read and create documents
• Part of Java1.4 and above
• Earlier versions need to download additional
  libraries

14
Parsing XML Documents

• Document interface describes the tree structure
  of an XML document
• A DocumentBuilder can generate an object of a
  class that implements Document interface
• Get a DocumentBuilder by calling the static
  newInstance method of the DocumentBuilderFactory
  class
• Call newDocumentBuilder method of the factory
  to get a DocumentBuilder
• DocumentBuilderFactory factory
  DocumentBuilderFactory.newInstance()
• DocumentBuilder builder factory.newDocumentBui
  lder()

15
Parsing XML Documents

• To read a document from a file
• String fileName . . .
• File f new File(filename)
• Document doc builder.parse(f)
• To read a document from a URL on the Internet
• String urlName . . .
• URL u new URL(urlName)
• Document doc builder.parse(u)
• To read from an input stream
• InputStream in . . .
• Document doc builder.parse(in)

16
Parsing XML Documents

• You can inspect or modify the document
• The document tree consists of nodes
• Two node type are Element and Text
• Element and Text are subinterfaces of the Node
  interface

17
An XML Document

• lt?xml version"1.0"?gt
• ltitemsgt
• ltitemgt
• ltproductgt
• ltdescriptiongtInk Jet Refill
  Kitlt/descriptiongt
• ltpricegt29.95lt/pricegt
• lt/productgt
• ltquantitygt8lt/quantitygt
• lt/itemgt
• ltitemgt
• ltproductgt
• ltdescriptiongt4-port Mini
  Hublt/descriptiongt
• ltpricegt19.95lt/pricegt
• lt/productgt
• ltquantitygt4lt/quantitygt
• lt/itemgt
• lt/itemsgt

18
Tree View of XML Document
previous start next
previous start next
19
Parsing XML Documents

• Start inspection of the tree by getting the
  root element
• Element root doc.getDocumentElement()
• To get the child elements of an element
• Use the GetChildNodes method of the Element
  interface
• The nodes are stored in an object of a class
  that implements the NodeList interface
• Use a NodeList to visit the child nodes of an
  element
• getLength method gives the number of elements
• item method gets an item in the node list
• Code to get a child node
• NodeList nodes root.getChildNodes()
• int i . . . //a value between o and
  getlength() - 1
• Node child nodes.item(i)
• The XML parser keeps all white spaces if you
  don't use a DTD
• You can include a test to ignore the white space

20
Parsing XML Documents

• Get an element name with the getTagName
• Element priceElement . . .
• String name priceElement.getTagName()
• To find the value of the currency attribute
• String attributeValue priceElement.getAttribu
  te("currency")
• You can also iterate through all attributes
• Use a NamedNodeMap
• Each attribute is stored in a Node

21
Parsing XML Documents

• Some elements have children that contain text
• Document builder creates nodes of type Text
• If you don't use mixed content elements
• Any element containing text has a single Text
  child node
• Use getFirstChild method to get it
• Use getData method to read the text
• To determine the price stored in the price
  element
• Element priceNode . . .
• Text priceData (Text)priceNode.getFirstChild(
  )
• String priceString priceNode.getData()
• double price Double.parseDouble(priceString)


22
File ItemListParser.java

• 001 import java.io.File
• 002 import java.io.IOException
• 003 import java.util.ArrayList
• 004 import javax.xml.parsers.DocumentBuilder
• 005 import javax.xml.parsers.DocumentBuilderFacto
  ry
• 006 import javax.xml.parsers.ParserConfigurationE
  xception
• 007 import org.w3c.dom.Attr
• 008 import org.w3c.dom.Document
• 009 import org.w3c.dom.Element
• 010 import org.w3c.dom.NamedNodeMap
• 011 import org.w3c.dom.Node
• 012 import org.w3c.dom.NodeList
• 013 import org.w3c.dom.Text
• 014 import org.xml.sax.SAXException
• 015
• 016 /
• 017 An XML parser for item lists

23

• 018 /
• 019 public class ItemListParser
• 020
• 021 /
• 022 Constructs a parser that can parse
  item lists
• 023 /
• 024 public ItemListParser()
• 025 throws ParserConfigurationException
• 026
• 027 DocumentBuilderFactory factory
• 028 DocumentBuilderFactory.newInstance
  ()
• 029 builder factory.newDocumentBuilder()

• 030
• 031
• 032 /
• 033 Parses an XML file containing an item
  list
• 034 _at_param fileName the name of the file
• 035 _at_return an array list containing all
  items in the XML file
• 036 /

24

• 038 throws SAXException, IOException
• 039
• 040 File f new File(fileName)
• 041 Document doc builder.parse(f)
• 042
• 043 // get the ltitemsgt root element
• 044
• 045 Element root doc.getDocumentElement()

• 046 return getItems(root)
• 047
• 048
• 049 /
• 050 Obtains an array list of items from a
  DOM element
• 051 _at_param e an ltitemsgt element
• 052 _at_return an array list of all ltitemgt
  children of e
• 053 /
• 054 private static ArrayList getItems(Element
  e)
• 055
• 056 ArrayList items new ArrayList()

25

• 058 // get the ltitemgt children
• 059
• 060 NodeList children e.getChildNodes()
• 061 for (int i 0 i lt children.getLength(
  ) i)
• 062
• 063 Node childNode children.item(i)
• 064 if (childNode instanceof Element)
• 065
• 066 Element childElement
  (Element)childNode
• 067 if (childElement.getTagName().equ
  als("item"))
• 068
• 069 Item c getItem(childElement)

• 070 items.add(c)
• 071
• 072
• 073
• 074 return items
• 075
• 076

26

• 078 Obtains an item from a DOM element
• 079 _at_param e an ltitemgt element
• 080 _at_return the item described by the
  given element
• 081 /
• 082 private static Item getItem(Element e)
• 083
• 084 NodeList children e.getChildNodes()
• 085 Product p null
• 086 int quantity 0
• 087 for (int j 0 j lt children.getLength(
  ) j)
• 088
• 089 Node childNode children.item(j)
• 090 if (childNode instanceof Element)
• 091
• 092 Element childElement
  (Element)childNode
• 093 String tagName
  childElement.getTagName()
• 094 if (tagName.equals("product"))
• 095 p getProduct(childElement)
• 096 else if (tagName.equals("quantity
  "))

27

• 098 Text textNode
  (Text)childElement.getFirstChild()
• 099 String data
  textNode.getData()
• 100 quantity Integer.parseInt(da
  ta)
• 101
• 102
• 103
• 104 return new Item(p, quantity)
• 105
• 106
• 107 /
• 108 Obtains a product from a DOM element
• 109 _at_param e a ltproductgt element
• 110 _at_return the product described by the
  given element
• 111 /
• 112 private static Product getProduct(Element
  e)
• 113
• 114 NodeList children e.getChildNodes()
• 115 String name ""
• 116 double price 0

28

• 118
• 119 Node childNode children.item(j)
• 120 if (childNode instanceof Element)
• 121
• 122 Element childElement
  (Element)childNode
• 123 String tagName
  childElement.getTagName()
• 124 Text textNode
  (Text)childElement.getFirstChild()
• 125
• 126 String data textNode.getData()

• 127 if (tagName.equals("description")
  )
• 128 name data
• 129 else if (tagName.equals("price"))

• 130 price Double.parseDouble(dat
  a)
• 131
• 132
• 133 return new Product(name, price)
• 134
• 135
• 136 private DocumentBuilder builder

29
File ItemListParserTest.java

• 01 import java.util.ArrayList
• 02
• 03 /
• 04 This program parses an XML file containing
  an item list.
• 05 It prints out the items that are described
  in the XML file.
• 06 /
• 07 public class ItemListParserTest
• 08
• 09 public static void main(String args)
  throws Exception
• 10
• 11 ItemListParser parser new
  ItemListParser()
• 12 ArrayList items parser.parse("items.xm
  l")
• 13 for (int i 0 i lt items.size() i)
• 14
• 15 Item anItem (Item)items.get(i)
• 16 System.out.println(anItem.format())
• 17
• 18
• 19

30
Creating XML Documents

• We can build a Document object in a Java program
  and then save it as an XML document
• We need a DocumentBuilder object to create a new,
  empty document
• DocumentBuilderFactory factory
  DocumentBuilderFactory.newInstance()
  DocumentBuilder builder factory.newDocumentBuild
  er()
• Document doc builder.newDocument() //empty
  document
• The Document class has methods to create elements
  and text nodes

31
Creating XML Documents

• To create an element use createElement method and
  pass it a tag
• Element itemElement doc.createElement("item")

• To create a text node, use createTextNode and
  pass it a string
• Text quantityText doc.createTextNode("8")
• Use setAttribute method to add an attribute to
  the tag
• priceElement.setAttribute("currency", "USD")

32
Creating XML Documents

• To construct the tree structure of a document
• start with the root
• add children with appendChild
• To build an XML tree that describes an item
• // create elements
• Element itemElement doc.createElement("item")
• Element productElement doc.createElement("produc
  t")
• Element descriptionElement
• doc.createElement("description")
• Element priceElement doc.createElement("price")

• Element quantityElement
• doc.createElement("quantity")
• Text descriptionText
• doc.createTextNode("Ink Jet Refill Kit")
• Text priceText doct.createTextNode("29.95")
• Text quantityText doc.createTextNode("8")

33

• // add elements to the document
• doc.appendChild(itemElement)
• itemElement.appendChild(productElement)
• itemElement.appendChild(quantityElement)
• productElement.appendChild(descriptionElement)
• productElement.appendChild(priceElement)
• descriptionElement.appendChild(descriptionText)
• priceElement.appendChild(priceText)
• quantityElement.appendChild(quantityText)

34
Creating XML Documents

• Use a Transformer to write an XML document to a
  stream
• Create a transformer
• Transformer t TransformerFactory.newInstance()
  .newTransformer()
• Create a DOMSource from your document
• Create a StreamResult from your output stream
• Call the transform method of your transformer
• t.transform(new DOMSource(doc),
• new StreamResult(System.out))

35
An XML Tree that Describes a Product
36
File ItemListBuilder.java

• 001 import java.util.ArrayList
• 002 import javax.xml.parsers.DocumentBuilder
• 003 import javax.xml.parsers.DocumentBuilderFacto
  ry
• 004 import javax.xml.parsers.ParserConfigurationE
  xception
• 005 import org.w3c.dom.Document
• 006 import org.w3c.dom.Element
• 007 import org.w3c.dom.Text
• 008
• 009 /
• 010 Builds a DOM document for an array list
  of items.
• 011 /
• 012 public class ItemListBuilder
• 013
• 014 /
• 015 Constructs an item list builder.
• 016 /
• 017 public ItemListBuilder()

37

• 018 throws ParserConfigurationException
• 019
• 020 DocumentBuilderFactory factory
• 021 DocumentBuilderFactory.newInstance
  ()
• 022 builder factory.newDocumentBuilder()

• 023
• 024
• 025 /
• 026 Builds a DOM document for an array
  list of items.
• 027 _at_param items the items
• 028 _at_return a DOM document describing the
  items
• 029 /
• 030 public Document build(ArrayList items)
• 031
• 032 doc builder.newDocument()
• 033 Element root createItemList(items)
• 034 doc.appendChild(root)
• 035 return doc
• 036

38

• 038 /
• 039 Builds a DOM element for an array list
  of items.
• 040 _at_param items the items
• 041 _at_return a DOM element describing the
  items
• 042 /
• 043 private Element createItemList(ArrayList
  items)
• 044
• 045 Element itemsElement
  doc.createElement("items")
• 046 for (int i 0 i lt items.size() i)
• 047
• 048 Item anItem (Item)items.get(i)
• 049 Element itemElement
  createItem(anItem)
• 050 itemsElement.appendChild(itemElement
  )
• 051
• 052 return itemsElement
• 053
• 054
• 055 /
• 056 Builds a DOM element for an item.

39

• 058 _at_return a DOM element describing the
  item
• 059 /
• 060 private Element createItem(Item anItem)
• 061
• 062 Element itemElement
  doc.createElement("item")
• 063 Element productElement
• 064 createProduct(anItem.getProduct())

• 065 Text quantityText doc.createTextNode(

• 066 "" anItem.getQuantity())
• 067 Element quantityElement
  doc.createElement("quantity")
• 068 quantityElement.appendChild(quantityTex
  t)
• 069
• 070 itemElement.appendChild(productElement)

• 071 itemElement.appendChild(quantityElement
  )
• 072 return itemElement
• 073
• 074
• 075 /
• 076 Builds a DOM element for a product.

40

• 078 _at_return a DOM element describing the
  product
• 079 /
• 080 private Element createProduct(Product p)
• 081
• 082 Text descriptionText
• 083 doc.createTextNode(p.getDescriptio
  n())
• 084 Text priceText doc.createTextNode(""
  p.getPrice())
• 085
• 086 Element descriptionElement
• 087 doc.createElement("description")
• 088 Element priceElement
  doc.createElement("price")
• 089
• 090 descriptionElement.appendChild(descript
  ionText)
• 091 priceElement.appendChild(priceText)
• 092
• 093 Element productElement
  doc.createElement("product")
• 094
• 095 productElement.appendChild(descriptionE
  lement)
• 096 productElement.appendChild(priceElement
  )

41

• 098 return productElement
• 099
• 100
• 101 private DocumentBuilder builder
• 102 private Document doc
• 103

42
File ItemListBuilderTest.java

• 01 import java.util.ArrayList
• 02 import org.w3c.dom.Document
• 03 import javax.xml.transform.Transformer
• 04 import javax.xml.transform.TransformerFactory

• 05 import javax.xml.transform.dom.DOMSource
• 06 import javax.xml.transform.stream.StreamResult

• 07
• 08 /
• 09 This program tests the item list builder.
  It prints the
• 10 XML file corresponding to a DOM document
  containing a list
• 11 of items.
• 12 /
• 13 public class ItemListBuilderTest
• 14
• 15 public static void main(String args)
  throws Exception
• 16
• 17 ArrayList items new ArrayList()

43

• 18 items.add(new Item(new
  Product("Toaster", 29.95), 3))
• 19 items.add(new Item(new Product("Hair
  dryer", 24.95), 1))
• 20
• 21 ItemListBuilder builder new
  ItemListBuilder()
• 22 Document doc builder.build(items)

• 23 Transformer t TransformerFactory
• 24 .newInstance().newTransformer()
• 25 t.transform(new DOMSource(doc),
• 26 new StreamResult(System.out))
• 27
• 28

44
Document Type Definitions

• A DTD is a set of rules for correctly formed
  documents of a particular type
• Describes the legal attributes for each element
  type
• Describes the legal child elements for each
  element type
• Legal child elements are described with an
  ELEMENT rule
• lt!ELEMENT items (item)gt
• The items element (the root in this case) can
  have 0 or more item elements
• Definition of an item node
• lt!ELEMENT item (product, quantity)gt
• Children of the item node must be a product node
  followed by a quantity
• node

45
Document Type Definitions

• Definition of product node
• lt! ELEMENT product (description, price)gt
• The other nodes
• lt!ELEMENT quantity (PCDATA)gt
• lt!ELEMENT description (PCDATA)gt
• lt!ELEMENT price (PCDATA)gt
• PCDATA stands for parsable character data which
  is just text
• Can contain any characters
• Special characters have to be encoded when
  they occur in character data

46
Encodings for Special Characters
47

• DTD for Item List

lt!ELEMENT items (item)gt lt!ELEMENT item
(product, quantity)gt lt!ELEMENT product
(description, price)gt lt!ELEMENT quantity
(PCDATA)gt lt!ELEMENT description
(PCDATA)gt lt!ELEMENT price (PCDATA)gt
48
Regular Expressions for Element Content
49

• Document Type Definitions

• A DTD gives you control over the allowed
  attributes
• of an element
• lt!ATTLIST Element Attribute Type Defaultgt
• Type can be any sequence of character data
  specified as CDATA
• Type can also specify a finite number of
  choices
• lt!ATTLIST price currency (USD EUR JPY )
  REQUIRED gt

50

• Common Attribute Types

51

• Attribute Defaults

52

• Document Type Definitions

• IMPLIED keyword means you can supply an
  attribute or not.
• lt!ATTLIST price currency CDATA IMPLIED gt
• If you omit the attribute, the application
  processing the XML data implicitly assumes some
  default value
• You can specify a default to be used if the
  attribute is not specified
• lt!ATTLIST price currency CDATA "USD" gt

53

Parsing with Document Type Definitions

• Specify a DTD with every XML document
• Instruct the parser to check that the document
  follows the rules of the DTD
• Then the parser can be more intelligent about
  parsing
• If the parser knows that the children of an
  element are elements, it can suppress white
  spaces

54

Parsing with Document Type Definitions

• An XML document can reference a DTD in one of
  two ways
• The document may contain the DTD
• The document may refer to a DTD stored
  elsewhere
• A DTD is introduced with a DOCTYPE declaration

55

Parsing with Document Type Definitions

• If the document contains the DTD, the
  declaration looks like this
• lt!DOCTYPE rootElement rules gt
• Example
• lt?xml version"1.0"?gt
• lt!DOCTYPE items
• lt!ELEMENT items (item)gt
• lt!ELEMENT item (product, quantity)gt
• lt!ELEMENT product (description, price)gt
• lt!ELEMENT quantity (PCDATA)gt
• lt!ELEMENT description (PCDATA)gt
• lt!ELEMENT price (PCDATA)gt
• gt

56
ltitemsgt ltitemgt ltproductgt
ltdescriptiongtInk Jet Refill Kitlt/descriptiongt
ltpricegt29.95lt/pricegt lt/productgt
ltquantitygt8lt/quantitygt lt/itemgt ltitemgt
ltproductgt ltdescriptiongt4-port Mini
Hublt/descriptiongt ltpricegt19.95lt/pricegt
lt/productgt ltquantitygt4lt/quantitygt
lt/itemgt lt/itemsgt
57

Parsing with Document Type Definitions

• If the DTD is stored outside the document, use
  the SYSTEM keyword inside the DOCTYPE declaration

• This indicates that the system must locate the
  DTD
• The location of the DTD follows the SYSTEM
  keyword
• A DOCTYPE declaration can point to a local file

• lt!DOCTYPE items SYSTEM "items.dtd" gt
• A DOCTYPE declaration can point to a URL
• lt!DOCTYPE items
• SYSTEM "http//www.mycompany.com/dtds/ite
  ms.dtd"gt

58

Parsing with Document Type Definitions

• When your XML document has a DTD, use
  validation when parsing
• Then the parser will check that all child
  elements and attributes conformto the ELEMENT
  and ATTRIBUTE rules in the DTD
• The parser throws an exception if the document
  is invalid
• Use the setValidating method of the
  DocumentBuilderFactorybefore calling
  newDocumentBuilder method
• DocumentBuilderFactory factory
  DocumentBuilderFactory.newInstance()
  factory.setValidating(true)
• DocumentBuilder builder factory.newDocumentBuild
  er() Document doc builder.parse(. . .)

59

Parsing with Document Type Definitions

• If the parser validates the document with a
  DTD, you can avoid validity checks in your code
• You can tell the parser to ignore white space
  in non-text elements
• factory.setValidating(true) factory.setIgnoring
  ElementContentWhitespace(true)
• If the parser has access to a DTD, it can fill
  in defaults for attributes

60
File ItemListParser.java

• 001 import java.io.File
• 002 import java.io.IOException
• 003 import java.util.ArrayList
• 004 import javax.xml.parsers.DocumentBuilder
• 005 import javax.xml.parsers.DocumentBuilderFacto
  ry
• 006 import javax.xml.parsers.ParserConfigurationE
  xception
• 007 import org.w3c.dom.Attr
• 008 import org.w3c.dom.Document
• 009 import org.w3c.dom.Element
• 010 import org.w3c.dom.NamedNodeMap
• 011 import org.w3c.dom.Node
• 012 import org.w3c.dom.NodeList
• 013 import org.w3c.dom.Text
• 014 import org.xml.sax.SAXException
• 015
• 016 /
• 017 An XML parser for item lists

61

• 018 /
• 019 public class ItemListParser
• 020
• 021 /
• 022 Constructs a parser that can parse
  item lists
• 023 /
• 024 public ItemListParser()
• 025 throws ParserConfigurationException
• 026
• 027 DocumentBuilderFactory factory
• 028 DocumentBuilderFactory.newInstance
  ()
• 029 factory.setValidating(true)
• 030 factory.setIgnoringElementContentWhites
  pace(true)
• 031 builder factory.newDocumentBuilder()

• 032
• 033
• 034 /
• 035 Parses an XML file containing an item
  list
• 036 _at_param fileName the name of the file

62

• 038 /
• 039 public ArrayList parse(String fileName)
• 040 throws SAXException, IOException
• 041
• 042 File f new File(fileName)
• 043 Document doc builder.parse(f)
• 044
• 045 // get the ltitemsgt root element
• 046
• 047 Element root doc.getDocumentElement()

• 048 return getItems(root)
• 049
• 050
• 051 /
• 052 Obtains an array list of items from a
  DOM element
• 053 _at_param e an ltitemsgt element
• 054 _at_return an array list of all ltitemgt
  children of e
• 055 /
• 056 private static ArrayList getItems(Element
  e)

63

• 058 ArrayList items new ArrayList()
• 059
• 060 // get the ltitemgt children
• 061
• 062 NodeList children e.getChildNodes()
• 063 for (int i 0 i lt children.getLength(
  ) i)
• 064
• 065 Element childElement
  (Element)children.item(i)
• 066 Item c getItem(childElement)
• 067 items.add(c)
• 068
• 069 return items
• 070
• 071
• 072 /
• 073 Obtains an item from a DOM element
• 074 _at_param e an ltitemgt element
• 075 _at_return the item described by the
  given element
• 076 /

64

• 078
• 079 NodeList children e.getChildNodes()
• 080
• 081 Product p getProduct((Element)childre
  n.item(0))
• 082
• 083 Element quantityElement
  (Element)children.item(1)
• 084 Text quantityText
• 085 (Text)quantityElement.getFirstChil
  d()
• 086 int quantity Integer.parseInt(quantit
  yText.getData())
• 087
• 088 return new Item(p, quantity)
• 089
• 090
• 091 /
• 092 Obtains a product from a DOM element
• 093 _at_param e a ltproductgt element
• 094 _at_return the product described by the
  given element
• 095 /
• 096 private static Product getProduct(Element
  e)

65

• 098 NodeList children e.getChildNodes()
• 099
• 100 Element descriptionElement
  (Element)children.item(1)
• 101 Text descriptionText
• 102 (Text)descriptionElement.getFirstC
  hild()
• 103 String description
  descriptionText.getData()
• 104
• 105 Element priceElement
  (Element)children.item(1)
• 106 Text priceText
• 107 (Text)priceElement.getFirstChild()

• 108 double price Double.parseDouble(price
  Text.getData())
• 109
• 110 return new Product(description,
  price)
• 111
• 112
• 113 private DocumentBuilder builder
• 114

66
File ItemListParserTest.java

• 01 import java.util.ArrayList
• 02
• 03 /
• 04 This program parses an XML file containing
  an item list.
• 05 The XML file should reference the
  items.dtd
• 06 /
• 07 public class ItemListParserTest
• 08
• 09 public static void main(String args)
  throws Exception
• 10
• 11 ItemListParser parser new
  ItemListParser()
• 12 ArrayList items parser.parse("items.xm
  l")
• 13 for (int i 0 i lt items.size() i)
• 14
• 15 Item anItem (Item)items.get(i)
• 16 System.out.println(anItem.format())
• 17
• 18
• 19
