Multicore Commercial Processors
2
Some Examples

• Desktop and Server/Enterprise Space
• Intel
• AMD
• SUN Microsystems
• The Embedded Space Freescale Semiconductor

3
Focus

• The Chip Level Architecture
• What do we have on chip?
• The Core Architecture
• Note the presence/absence/configuration of
  concepts studied earlier in class
• Rationalize the design decisions that led to the
  preceding
• What can/should we expect next?
• Building systems using multicore chips

4
The Intel Core Duo Processor Series
5
Intel Core Duo

• Homogeneous cores
• Bus based on chip interconnect
• Shared Memory
• Traditional I/O

Classic OOO Reservation Stations, Issue ports,
Schedulersetc
Source Intel Corp.
Large, shared set associative, prefetch, etc.
6
Intel Core Duo Vital Stats

• 151 million transistors Shared 2 MB L2 cache
• Each core has a 12 stage pipeline (Yonah)
• Low-power (less than 25 watts) Dual Core
  microprocessor
• Supports Intels Vanderpool virtualization
  technology
• EM64T (Intel x86-64 extensions) is not supported
• Desktop market not severe due to lack of OS and
  software
• Sossaman processor for servers, which is based on
  Yonah, also lacks EM64T-support ? severe
  disadvantage
• Communication between the L2 cache and both
  execution cores is handled by an arbitration bus
  unit
• Eliminates cache coherency traffic over the FSB
• Raises the core-to-L2 latency
• The increase in clock frequency offsets the
  impact
• Core processors communicate with the system
  chipset over a 667 MT/s front side bus (FSB), up
  from 533 MT/s used by the fastest Pentium M.
• Intel Core Solo uses the same two-core die as the
  Core Duo, but features only one active core
• Chips failing quality control can be sold
• Core 2 Duo processors will also include the
  ability to disable one core to conserve power

7
The Core micro-architecture
Source Ars Technica
8
The Core Execution core
Source Ars Technica
9
Intel Core Duo

• High memory latency due to the lack of on-die
  memory controller (further aggravated by
  system-chipset's use of DDR-II RAM)
• Main-memory transactions have to pass through
  the Northbridge of the chipset
• Higher latency compared to the AMD's Turion
  platform.
• Weakness shared by the entire line of Pentium
  processors
• L2-cache is quite effective at hiding main-memory
  latency
• Execution units
• Three 64-bit integer exec units
• one CIU (complex) two SIU (simple)
• Two FPUs
• Poor Floating Point Unit (FPU) throughput
• Limited to little "performance per watt" in
  single threaded applications compared to its
  predecessor.

10
Core 2 Duo and Core Duo
Source Intel Corp.

• Very similar architectures
• Bump in the processor speed
• Increase in Level 2 cache. (2MB to 4MB)
• Both chips have a 65-nm process technology
  architecture and support a 667 MHz front-side-bus
  (FSB).
• 14 stage pipeline

11
Intel CoreTM2 Duo Processor
Process Technology 65 nm
Number of Processor Cores 2
L2 Cache Size (shared between 2 processor cores) Up to 4MB
Transistor Gate Height / Gate Oxide Thickness (65 nm) 1.2 nm
Transistor Gate Length (for 65nm Process Technology) 35 nm
Line Width 65 nm
Number of Transistors 291 million
Processor Die Size 143 mm2
Average Power lt1.1 Watt
12
Intel Core 2 Duo
Source Hard Core Hardware
13
Wide Dynamic Execution
Source Bit Tech
14
Wide Dynamic Execution
Source Bit Tech
15
Wide Dynamic Execution

• Pipe width of 4 execution units per chip (Pentium
  M/Pentium 4 Netburst have 3)
• Delivery of more instructions per clock cycle
• Pipeline depth of 14 vs. 31 in Pentium Prescott 4
• Compromise between efficient execution of short
  instructions and long instructions
• Ops fusion
• Less work for the processor pipeline to run
• Micro-ops fusion
• fuse together repetitive instructions in x86 code

• Macro-ops fusion
• works on the x86 instructions themselves, not
  just their micro derivatives.
• Instruction loads and micro-ops can be reduced by
  approximately 15 and 10, respectively

16
Intelligent Power Capability
Source Bit Tech
17
Intelligent Power Capability

• SpeedStep technology
• Dyamic clock speed reduction
• Intel mobile processors include this already
• Enhanced SpeedStep used in Core 2 Duo
• Controller that turns on sections of the
  processor as needed. One core can be shut down
  for single-threaded applications
• Power consumption decreased by enhancements to
  Intel's 65nm process node
• use Low-K dielectrics and strained silicon
• use low-leakage and "sleep" transistors

18
Advanced Smart Cache
Source Bit Tech
19
Advanced Smart Cache
Source Bit Tech

• Both cores share data stored in the L2 cache via
  an arbitration bus unit embedded in the cache.
• Dynamically allocates cache space between the two
  cores, minimising bus traffic by allowing both
  cores to access one copy of data
• Does larger L2 cache matter?
• Studies point out that improvements in execution
  time are low from a 2MB to 4MB for most
  applications (2-4)

20
Smart Memory Access
Source Bit Tech
21
Smart Memory Access
Execution with and without memory disambiguation
Memory Aliasing

• Improved prefetch units
• Memory disambiguation
• Allows re-ordering instructions more efficiently

Execution without memory disambiguation
Example from http//arstechnica.com/articles/paedi
a/cpu/core.ars/8
Source Ars Technica
22
Advanced Digital Media Boost
Source Bit Tech
23
Advanced Digital Media Boost

• Streaming SIMD Extension (SSE) instructions
• SSE instructions are an extension of the standard
  x86 instruction set.
• Utilized in multimedia encoding, decoding, image
  manipulation and encryption
• SSE instructions are 128-bit.
• Up from 64-bits
• Double the SSE performance over previous
  generation

24
Comparison of SSE to prior processors
Source Ars Technica
25
Intel Conroe Vs Presler
Conroe
Presler

• What is the major difference?
• Shared L2 versus separate caches

Source Bit Tech
26
Intels Roadmap for Multicore
Mobile processors
Enterprise processors
Desktop processors
8C 12MB shared (45nm)
8C 12MB shared (45nm)
QC 8/16MB shared
DC 3MB /6MB shared (45nm)
DC 3 MB/6 MB shared (45nm)
QC 4MB
DC 2/4MB shared
DC 4MB
DC 16MB
DC 2/4MB shared
DC 2MB
DC 4MB
SC 1MB
DC 2MB
DC 2/4MB
SC 512KB/ 1/ 2MB
2006
2008
2007
2006
2008
2007
2006
2008
2007
Source Adapted from Toms Hardware

• Drivers are
• Market segments
• More cache
• More cores
• 80 core processor prototype has been designed!

27
Intel Chipset Example
Source Extreme Tech
28
