Manycore Algorithms

1
Manycore Algorithms

• David A. Bader

2
Driving Manycore Applications
Revolutionary change in applications for the 21st
century!
3
HPCs success has been its failure!
For decades, HPC has been on a vicious cycle of
enabling applications that run well on HPC
systems.
Applications

• Manycores disruption can open the door for a
  revolutionary transformation!
• For the first time in decades, manycore will
  allow innovation in real-world algorithms

4
Enabling 21st Century Applications(slightly
modified slide from 7 YEARS ago!)

• Manycore apps will require
• Integer performance
• Strings, lists, trees, graphs
• Combinatorics
• Optimization
• Computational geometry
• Irregular data accesses
• Dynamic programming, backtracking
• Heuristics and solutions to NP-hard problems
• Innovate tomorrows applications must drive
  manycore!

• Current HPC systems are designed for
  physics-based simulations that use
• Floating-point, linear algebra
• Top 500 List measures Linpack!
• Regular operations (high-degrees of locality)
• e.g., Matrices, FFT, CG
• Low-order polynomial-time algorithms
• Focus of current HPC/petascale algorithms
• Dense linear algebra
• Sparse linear algebra
• FFT or multi-grid
• Global scatter-gather operations
• Dynamically evolving coordinate grids
• Dynamic load-balancing
• Particle-based or lattice-gas algorithms
• Continuum equation solvers

5
May You Live in Tumultuous Times.
May You Live in Interesting Times.
6
Manycore Challenge List Ranking

• Challenge Given a linked list stored in memory,
  find the distance from each node to the head
• Sequential approach is trivial (2 lines of code,
  linear time)
• Linear speedup with the number of processors in
  theory (PRAM)
• No speedup has ever been reported using MPI
• Rationale List ranking is the basis for many
  irregular parallel algorithms, and is
  representative of many client applications.

Input Random List of 226 elements

• SWARM SoftWare and Algorithms for Running on
  Manycore
• Supported by Microsoft Research Faculty Award in
  Parallelism and Concurrency
• Library of efficient implementations of parallel
  programming primitives and example kernels
• Prefix-sums, pointer-jumping, list ranking,
  divide and conquer, pipelining, graph algorithms,
  symmetry breaking, graph algorithms
• Computational model for analyzing algorithms on
  multimanycore systems
• Portable
• Microsoft Visual Studio, Linux, AIX, Solaris
• Intel Xeon, AMD Opteron, IBM Power6, Sun US T1
• Shared Source under the Microsoft Permissive
  License (Ms-PL)
• http//multicore-swarm.sourceforge.net/

7
Concluding Remarks

• Is Manycore the next CB radio or is it for real?
• Its here, baby! Sit back, relax, and enjoy the
  ride!
• What will Multicore do to the computing
  ecosystem?
• Require real-world algorithmic innovations for
  the first major time in several decades
• Can innovative algorithmic techniques exploit the
  opportunities and address the challenges of
  multi-core?
• Absolutely, aided by synergistic architectural
  components
• How will programming models and supporting system
  software change to accommodate the unique
  properties and peculiarities of multi-core
  structures?
• Composability is a must. Models must give
  performance advantage for using architectural
  features
• Challenges for memory hierarchy between memory
  and on chip resources.
• Processors cheap, memory bandwidth expensive.
  Compute in the memory when possible ?
  transactions!
• Where will the parallelism come from?
  Hw/Sw/Compiler/OS?
• The user ? explicitly parallel algorithms, and
  systems ? architecture-driven thread-level
  speculation
• Is a single programming model the right solution?
• No pick the right tool for the problem domain
  specialized programming models
• Do we have to use all those 1024 cores?
• Yes, while theres no more free lunch in
  computing, most problems can reveal this amount
  of concurrency.

8
Acknowledgment of Support

• National Science Foundation
• CSR A Framework for Optimizing Scientific
  Applications (06-14915)
• CAREER High-Performance Algorithms for
  Scientific Applications (06-11589 00-93039)
• ITR Building the Tree of Life -- A National
  Resource for Phyloinformatics and Computational
  Phylogenetics (EF/BIO 03-31654)
• DBI Acquisition of a High Performance
  Shared-Memory Computer for Computational Science
  and Engineering (04-20513).
• IBM PERCS / DARPA High Productivity Computing
  Systems (HPCS)
• DARPA Contract NBCH30390004
• IBM Shared University Research (SUR) Grant
• Sony-Toshiba-IBM (STI)
• Sun Academic Excellence Grant
• Microsoft Research
