Sensors

1
Sensors

• Electronics

2
What is a sensor?

• A sensor is a type of transducer.
  Direct-indicating sensors, for example, a mercury
  thermometer, are human-readable. Other sensors
  must be paired with an indicator or display, for
  instance a thermocouple. Most sensors are
  electrical or electronic, although other types
  exist.
• Sensors are used in everyday life. Applications
  include automobiles, machines, aerospace,
  medicine, industry and robotics.
• Technological progress allows more and more
  sensors to be manufactured on the microscopic
  scale as micro sensors using MEMS technology. In
  most cases a micro sensor reaches a significantly
  higher speed and sensitivity compared with
  macroscopic approaches.

3
What types of sensors are available?

• Thermal
• Electromagnetic
• Mechanical
• Optical
• Chemical
• Acoustic

4
Thermal Sensors

• React to changes in temperature.

5
Electromagnetic Sensors

• React to changes in electron flow or electrical
  current.

6
Mechanical Sensors

• React to changes in physical position or contact
  with another surface.

7
Optical Sensors

• React to changes in lighting conditions in a
  particular environment.

8
Chemical Sensors

• React to changes in the chemical composition of a
  liquid or gas.

9
Acoustic Sensors

• React to changes in a particular sound, echo or
  tone.

10
Electromagnetic Spectrum
