Title: 2002 MetalNonMetal Fatalities


1
2002 Metal/Non-Metal Fatalities
2
  • January 9, 2002, a 21 year-old laborer with 14
    months mining experience was fatally injured at a
    surface dimension stone mine. The victim was
    descending a grade in a front-end loader and
    exited the machine after losing control. The
    loader continued down the grade and ran over the
    victim.
  • Self propelled mobile equipment should be
    provided with service brakes that are capable of
    stopping and holding the equipment on the
    steepest grade that it travels.
  • Seat belts should be provided and worn when
    operating mobile equipment
  • Preventive maintenance programs should be
    implemented to identify and repair defects that
    affect safety on mobile equipment.

3
  • January 12, 2002, a 63-year-old equipment
    operator with 30 years mining experience was
    fatally injured at a surface pebble stone mine.
    The victim was standing by a pick-up truck when
    he was struck from behind by a run-a-way
    front-end loader. The loader operator lost
    control of the equipment after the engine stalled
    while descending a grade.

4
  • Self propelled mobile equipment should be
    provided with service brakes that are capable of
    stopping and holding the equipment on the
    steepest grade that it travels.
  • Preventive maintenance programs should be
    implemented to identify and repair defects that
    affect safety on mobile equipment.
  • Part 46 training should be made available to all
    employees.
  • Preshift examinations should be conducted prior
    to operation.
  • Backup alarms should be audible above the
    surrounding noise level.

5
  • January 21, 2002, a 23 year-old utility person
    with 5 years mining experience was fatally
    injured at a surface cement operation. The victim
    was fatally injured when he climbed into a silo
    to unplug a blockage and was engulfed by
    material.
  • A safety harness attached to a lifeline should
    always be used when persons enter silos, hoppers
    or surge piles. A second person should constantly
    adjust the lifeline to eliminate slack.
  • Safe access should be provided and maintained to
    all working places.
  • Silos should be equipped with mechanical devices
    or other effective means of handling material so
    persons are not required to work where they are
    exposed to entrapment by sliding material.

6
  • January 21, 2002, a 51 year-old loader operator
    with 6 weeks mining experience was fatally
    injured at a sand and gravel operation. The
    victim and a coworker were in the process of
    draining the water from the log washer at the end
    of the shift. The victim climbed inside the
    machine to remove debris and was crushed by the
    paddles when a third employee inadvertently
    started the machine from the plant control consol

7
  • Power disconnect switches should be locked out
    and posted with signed tags by the individuals
    performing work prior to work commencing.
  • Wherever possible, startup switches should have a
    time delay along with simultaneous audible and
    visual warnings to alert persons of impending
    hazardous motion.
  • Companies should develop and implement procedures
    that address possible hazards for all maintenance
    tasks.

8
  • February 1, 2002, a 38 year-old ledge foreman
    with 10 years mining experience, died of injuries
    he received on January 14, 2002, when he fell 28
    feet at a dimension stone quarry. The victim was
    positioned between a grout bucket and a ladder
    near the edge of the ledge. When a large rock was
    loaded into the bucket, it tipped and knocked the
    victim off the ledge.
  • A safety harness and a life line should be worn
    when persons work where there is a risk of injury
    from a fall.
  • Safe access should be provided and maintained to
    and from all work areas.
  • Railings or cables should be installed when
    persons are required to work or travel near the
    edge of a ledge.
  • Safe work procedures should be established prior
    to commencing tasks.

9
  • February 13, 2002, a 53-year-old electrician
    with five years mining experience was fatally
    injured at a crushed stone operation. The victim
    and several coworkers were changing a generator
    on a power shovel. In preparation for lifting the
    generator, a hoist that was mounted overhead on
    an I-beam was being trammed into position when it
    ran off the end of the I-beam, fell and struck
    the victim who was performing work below.



10
  • Mechanical stops should be installed to prevent
    over travel of rail mounted hoists.
  • Procedures that evaluate possible hazards and
    assure prompt corrective action should be
    implemented prior to work beginning.
  • Mechanical equipment should be inspected prior to
    use and all defects should be promptly corrected.

11
  • April 4, 2002, a 54 year-old mechanic with 32
    years mining experience was fatally injured at
    the surface lime plant of an underground
    limestone mine. The victim was positioned on the
    ground to guard access to the drop area while
    several co-workers threw filled dust collector
    bags from the elevated bag house. The victim was
    struck by one of the bags that weighed about 90
    pounds.

12
  • Formal procedures that address possible hazards
    should be implemented prior to beginning major
    maintenance tasks.
  • A restricted drop area must be established prior
    to dropping materials from elevated locations.
  • All persons should be removed from drop areas and
    barricades or barriers should be installed to
    prohibit access to protect personnel from falling
    material.

13
  • March 30, 2002, a 67 year-old process operator
    (leadman) with 29 years mining experience was
    seriously injured at a cement operation. The
    victim was helping clear a blockage inside a
    cement clinker drag conveyor located in a tunnel.
    When the access door for the enclosed conveyor
    was opened, hot clinker spilled into standing
    water generating a steam outburst that burned the
    victim. The victim died from his injuries on
    April 5, 2002.

14
  • A protocol that address potential hazards should
    be developed prior to beginning major maintenance
    tasks.
  • Special protective clothing and equipment should
    be provided and worn to protect persons from
    environmental hazards or irritants.
  • Water should not be permitted to accumulate where
    it could come in contact with hot materials.

15
  • April 22, 2002, a 22 year-old drill operator with
    one year mining experience was fatally injured at
    a dimension stone quarry. The victim was drilling
    in the quarry when his clothing became entangled
    in the rotating drill steel.
  • Equipment operators should stop drill rotation
    when performing tasks near the rotating steel.
  • Loose fitting clothing should not be worn when
    working around drilling machinery.

16
  • April 24, 2002, a 22-year-old mechanic with five
    months mining experience was fatally injured at a
    crushed stone operation. The victim was
    conducting a performance test on the parking
    brake. He drove the loader up a 16 percent ramp
    when it stopped, rolled backwards and struck the
    edge of a waste pile. The loader rolled on its
    side and the victim, who was not wearing a seat
    belt, was thrown out of the cab.

17
  • Brake tests should be performed first in a non
    -hazardous environment to ensure all systems are
    fully functional before testing the brakes on the
    steepest typical operating grade.
  • Brake holding tests should only be conducted near
    the base of the grade and only where a safe
    escape route is provided.
  • Equipment operators should wear seatbelts
    whenever the vehicle is in motion.
  • Self-propelled mobile equipment should be
    provided with service brakes capable of stopping
    and holding the equipment on the steepest grade
    it travels.

18
  • May 3, 2002, a 62-year-old contract dozer
    operator with 20 years of experience, drowned at
    a surface limestone operation. The victim was
    operating a dozer to level a pad for a dragline,
    when he over traveled the edge of the pad and
    sank. Several hours later, a dragline moved into
    position and began extracting material from the
    pit. The dragline brought up several pieces of
    the dozer. A search for the victim started
    immediately, but he was not found until May 6,
    2002.
  • Determine the relationship of the water's edge to
    the work area prior to operating mobile
    equipment.
  • Provide flotation devices in the operator's cab
    on mobile equipment working near water.

19
  • June 1, 2002, a 32 year-old conveyor attendant
    with 5 years mining experience was fatally
    injured at an open pit copper operation. The
    victim became entangled in a tripper conveyor
    pulley.
  • Always lock out or block moving machinery against
    motion before working nearby unless all pulleys
    and pinch points are guarded or located where
    persons can not contact them.
  • Ensure that accessible pinch points on conveyor
    pulleys are guarded from contact.
  • Establish and enforce policies that prohibit work
    or travel near unguarded machinery components.

20
  • June 3, 2002, a 41 year-old maintenance mechanic
    with 11 years mining experience was fatally
    injured at a cement operation. The victim and
    co-workers had cleared a plugged chute and then
    jogged the kiln feed bucket elevator to make sure
    it was free. The elevator drive assembly failed
    and the victim was struck by metal fragments.
  • Locate operating controls for pumps, motors and
    rotating components away from potential
    trajectory paths.
  • Test all safety systems, including reverse
    movement protection features, on a regular basis.
  • Establish a schedule for rebuilding or
    replacement of equipment.

21
June 12, 2002, a 35-year-old maintenance worker
with 7 years mining experience was fatally
injured at an alumina operation. The victim was
drilling out scale that had accumulated inside
heater tank pipes. The drill motor, detached from
the gear box, fell from the drill mast and struck
the victim.
22
  • Establish procedures that require scheduled
    inspections and maintenance of equipment.
  • Ensure adequate pre-operational checks are
    conducted and identified needs for maintenance
    are properly addressed.
  • Ensure component fasteners meet or exceed
    manufacturer's specifications and are adequately
    tightened.
  • Provide backup secure methods for components
    subjected to constant vibration.

23
July 2, 2002, a 51-year-old laborer with 21 weeks
mining experience was fatally injured at a
surface crushed stone mine. He was removing a
support structure on a portable conveyor. The
conveyor was positioned on a hydraulic jack
supported by two wooden blocks when it shifted
and fell crushing the victim.
  • Train all personnel in hazard recognition and
    safe work procedures.
  • Ensure that blocking material is competent,
    substantial, and adequate to support and
    stabilize the load.
  • Ensure that equipment is properly blocked to
    prevent accidental movement.
  • Never block with steel on steel or depend on
    hydraulics to support a load.

24
August 5, 2002, a 56-year-old maintenance worker
with 27 years of experience was fatally injured
at a lime plant. The victim was found lying
inside one of the rooms of a dust collector bag
house. Apparently, after the victim entered the
room, the door inadvertently closed and he could
not get out. Conditions inside the room were hot
and dusty.
25
  • Establish safe work procedures and ensure that
    they are being followed by personnel assigned to
    do maintenance work.
  • Ensure that safe entry procedures are being
    followed and examine exit routes at all bag
    houses.
  • Provide latches on both sides of all doors.
  • Maintain communications with personnel working in
    remote locations.
  • Always use personal protective equipment
    appropriate for the assigned task.

26
August 6, 2002, a 47-year-old contract switchman
with 25 years of experience, was fatally injured
at a trona mine. The accident occurred at night.
The victim, switching cars at a surface load out
area, was caught between a 15-car train he was
riding and a stationary car as the train moved.
  • Provide illumination sufficient to recognize
    hazards in all work areas.
  • Identify possible hazards and safe work
    procedures before moving rail cars.
  • Provide communications between personnel assigned
    to move rail cars.
  • Maintain continuous clearance of at least 30
    inches from the farthest projection of moving
    railroad equipment on at least one side of the
    tracks.

27
August 17, 2002, a 31-year-old contract miner
with 4 years of experience was fatally injured in
a tunnel construction project at an open pit
copper mine. A transformer switch, mounted on a
rail car, was being moved forward as construction
advanced. The victim was electrocuted when he
contacted a 480 volt cable and a junction box to
move them from rubbing the rail car. The cable
and junction box were part of the lighting system
located along the side of the tunnel.
28
  • Protect circuits against excessive overloads by
    fuses or breakers of the correct type and
    capacity.
  • Ensure that all metal enclosing or encasing
    electrical circuits is grounded or provided with
    equivalent protection.
  • Provide equipment grounding conductors, with a
    sufficiently low impedance to limit the voltage
    to ground, for metal enclosures.

29
August 20, 2002, a 20-year-old truck driver, with
one year of experience, was fatally injured at a
crushed stone mine. The victim backed his dump
truck under a bin to receive material being
washed from the bin. He exited the truck and
stood on a concrete support foundation. While the
victim was talking with the lead man situated
above the bins, another haul truck backed under
an adjacent bin and struck him causing fatal
injuries.
30
  • Establish procedures that require all personnel
    to be positioned so they are not exposed to
    self-propelled moving equipment.
  • Ensure that equipment operators proceed
    cautiously when entering areas with tight
    clearance or areas where personnel are present.
  • Establish procedures that require communications
    to be maintained between equipment operators and
    their co-workers.

31
September 10, 2002, a 58 year-old contract drill
operator with 15 years drilling experience was
fatally injured at a crushed stone operation. The
victim had positioned the truck-mounted chassis
drill, set the jacks and raised the truck chassis
off the ground. He was raising the drill mast
into position when a previously damaged jack foot
connection may have allowed the "ball end" to
suddenly drop into the receiving socket. This
caused the drill to become unstable, tip over and
crush the operator inside the operator's cab.
32
  • Ensure pre-operational checks are conducted and
    identified needs for maintenance are properly
    addressed.
  • Establish procedures that ensure jack components
    are locking in position properly and the unit is
    level before positioning mast.
  • Use adequate cribbing to prevent the jacks from
    sinking into the ground.
  • Know the limitations of your drill and follow the
    procedures in the operators manual.

33
September 10, 2002, a 57 year-old equipment
operator with 25 years mining experience was
fatally injured at a crushed stone operation. The
victim was approaching the stone load out when
apparently the rear brake line ruptured. The
truck left the road, traveled several hundred
feet and struck a tree. The victim, who was not
wearing the seat belt provided, was found on the
ground near the truck.
34
  • Ensure pre-operational checks are conducted and
    identified needs for maintenance are properly
    addressed.
  • Establish procedures that require scheduled
    inspection and maintenance of mobile equipment.
  • Ensure that service brakes will stop and hold
    equipment prior to operating mobile equipment.
  • Enforce policies that require seat belts be worn
    by mobile equipment operators.

35
September 16, 2002, a 42 year-old welder with 2
years mining experience was fatally injured at a
crushed stone operation. The victim was lying on
a wet, metal screen deck welding a wear plate in
a confined area when he apparently touched the
energized welding rod to his chest and received
an electrical shock.
36
  • Establish procedures that require welders to
    cover metal with approved insulated mats or dry
    wood when lying to weld in confined areas.
  • Ensure that maintenance activities are planned
    and possible hazards are eliminated.
  • Provide the proper supplies and equipment to
    complete all tasks.

37
September 23, 2002, a 30 year-old contract
employee with 18 months experience was fatally
injured at a cement plant. The victim apparently
climbed out of the elevated man lift platform to
gain access to a work location on the metal roof
when he lost his footing and fell 46 feet to the
ground.
38
  • Train all employees, including contractors, in
    hazard recognition and ensure they follow all
    safety requirements.
  • Establish secure anchor locations and require
    harnesses attached to secure lines be utilized by
    persons at elevated locations.
  • Maintain continuous fall protection when working
    at elevated locations.

39
September 23, 2002, a 43 year-old plant operator
with 17 months experience was fatally injured at
a crushed stone operation. The victim was
removing fines that had packed around a winged
tail pulley of a belt that had been buried by
spillage. As the spillage was removed, the bound
conveyor belt moved backward a short distance and
caught the victim's arm between the belt and the
tail pulley.
40
  • Ensure manufacturer's recommendations are
    reviewed and miners are trained regarding
    maintenance tasks prior to beginning work.
  • Identify and discuss possible hazards and address
    steps to eliminate them.
  • Ensure the proper tools are provided and used to
    complete all required tasks.
  • Block all equipment or machinery components to
    prevent possible movement.

41
October 12, 2002, a 52-year-old co-owner of a
sand and gravel operation was fatally injured.
The victim accompanied her husband to the mine to
assist in setting up a new weighing facility
while he used a front-end loader to fill in dirt
around the newly installed truck scales.
Apparently the victim inadvertently walked into
the path of the loader as it was backing.
42
  • Establish procedures that prohibit entering the
    work area of mobile equipment unless the operator
    is aware of your presence.
  • Ensure that you make eye contact with mobile
    equipment operators before approaching their work
    areas.

43
October 14, 2002, a 25-year-old front-end loader
operator, with 3 months mining experience was
fatally injured at a sand and gravel operation.
The victim parked his loader near the toe of a 33
foot highwall and left the operator's cab when
material sloughed off the highwall and buried
him.
44
  • Train all employees in hazard recognition and
    ensure they follow all safety requirements.
  • Ensure that loose ground and overhanging material
    is taken down or block all access to those areas.
  • Adopt mining methods that will maintain wall,
    bank or slope stability in all work areas.

45
October 17, 2002, a 45-year-old front-end loader
operator, with 11 years mining experience was
fatally injured at a sand and gravel operation.
The victim and a coworker were positioned on a
conveyor attaching lifting chains suspended from
the bucket of a track mounted back hoe. The
victim was caught between the back hoe bucket and
the conveyor frame when the boom and bucket moved
unexpectedly.
46
  • Identify possible hazards and take necessary
    action to ensure safe operation prior to
    beginning repair or maintenance tasks.
  • Block all equipment or machinery components to
    prevent possible movement.
  • Establish procedures that require mobile man
    lifts be used where safe access is not provided.

47
October 21, 2002, a 48-year-old equipment
operator with 11 years mining experience was
fatally injured at a sand and gravel operation.
The victim was operating a front-end loader
feeding a power screen plant when he backed one
of the wheels over a drop-off. The loader, which
was not provided with a ROPS cab, rolled over,
crushing the victim.
48
  • Establish procedures that restrict the use of
    front-end loaders manufactured prior to June 30,
    1969 to flat ground.
  • Ensure that berms are provided on elevated edges
    of roadways where a drop-off exists.
  • Ensure adequate pre-operational checks are
    conducted on all self- propelled mobile equipment
    and defects are promptly corrected.

49
October 24, 2002, a 27-year-old fuel handler with
2 years 7 months mining experience was fatally
injured at a cement operation. The victim was
attempting to bleed air from the liquid
waste-fuel system when the in-line grinder
ruptured. The escaping waste fuel ignited,
engulfing the victim in flames.
50
  • Ensure process safety management principles are
    used to identify possible hazards related to
    waste fuel handling.
  • Establish safe work procedures and train
    employees for each task, including a general
    knowledge of the system and its hazards.
  • Ensure all safety system monitoring and shutdowns
    are installed correctly, are operational and are
    tested periodically.
  • Ensure appropriate personal protective equipment,
    including fire retardant clothing is worn by all
    persons entering or working in areas where
    hazardous/flammable material spills or releases
    are possible.
  • Locate pump start/stop switches remotely and
    require pumps be shut down prior to bleeding off
    pressurized waste fuel systems.
  • Ensure in-line pressure relief devices are
    installed on all pressurized waste fuel systems.
  • Install flow sensing devices which automatically
    shut down the pump if flow stops for any critical
    period of time.

51
October 17, 2002, a 49-year-old mine rescue team
trainer with 26 years mining experience and a
38-year-old co-trainer with 2 years mining
experience were fatally injured, at an abandoned
underground gold mine. Both were participating
under oxygen in an exercise to evaluate
conditions in this mine. As the team was walking
up the steep decline to return to the surface,
the victims experienced breathing difficulties
and collapsed. The first victim was pronounced
dead at the scene. The second victim was
transported to a medical facility where he
succumbed to his injuries on October 23, 2002.
52
  • Ensure all self contained breathing apparatus are
    properly checked and equipped as to manufacturers
    recommendations prior to their use.
  • During non emergency exercises, ensure that
    underground mine areas that rescue teams plan to
    enter are ventilated and free of serious hazards.
  • Maintain continuous communications with the
    surface whenever mine rescue personnel encounter
    toxic gases, explosive gases or any conditions
    that pose serious danger.

53
November 13, 2002, a 30-year-old dozer operator
with 11 years mining experience was fatally
injured at a crushed stone operation. The victim
was pushing up previously shot rock near the base
of a 21-foot highwall. A large portion of the
highwall failed, collapsing the ROPS on the dozer
and fatally injuring the victim.
54
  • Train employees in hazard recognition and ensure
    they follow all safety requirements.
  • Inspect highwalls thoroughly prior to work being
    performed.
  • Ensure loose ground and overhanging material is
    taken down or block all access to those areas.
  • Adopt mining methods that ensure mobile equipment
    is operated perpendicular to the face of a
    highwall.

55
December 9, 2002, a 47-year-old truck driver with
1 year10 months mining experience was fatally
injured at a crushed stone operation. The victim
was in the process of removing a 12 foot long
section of a walkway attached to a portable
inclined conveyor. As he was cutting a metal
attachment using an acetylene torch, the section
of walkway collapsed on him.
56
  • Analyze maintenance tasks and identify possible
    hazards prior to the commencement of work.
  • Establish job procedures to eliminate hazards and
    ensure personnel are trained to utilize the
    proper equipment and tools.
  • Secure all equipment or machinery components to
    prevent movement.
  • Ensure personnel are adequately trained and
    assisted as necessary when performing maintenance
    work.
Write a Comment
User Comments (0)
About PowerShow.com
