Chapter 9: Work

1
Chapter 9 Work Energy
2
Work

• Is only done when a force causes a change in
  motion of an object.
• Work Equation work force x distance
• W Fd
• SI units Joules (J) or Nm or kgm2/s2

3
Work Example

• Imagine a father playing with his daughter by
  lifting her repeatedly in the air. How much work
  does he do with each lift, assuming he lifts her
  2.0 m and exerts an average force of 190 N?
• WFd
• W190 N x 2.0 m 380Nm or 380 J

4
Remember

• To convert from mass to force (weight) use
• wmg g 9.81 m/s2
• Plug the value for weight into the work equation
  for force.

5
Power

• The rate at which the work is done.
• Power Equation power work or PW
•
  time t
• SI units watts (W) or J/s

6
Power Example

• It takes 100kJ of work to lift an elevator 18 m.
  If this is done in 20 s, what is the average
  power of the elevator during the process?
• PW
• t
• P 1x105 J 5000 J/s or 5000 W or 5kW
• 20 s

7
Machines

• They redistribute the work put into them.
• Example Car jack
• Does the amount of work change?
• No, but it makes the work easier!
• They multiply and redirect forces.

8
Mechanical Advantage

• Different forces can do the same amount of work.
• Mechanical advantage measures how much a machine
  multiplies force or increases distance.
• MA greater than 1 multiplies force
• MA less than 1 increases distance or speed

9
M.A. Equation

• M.A. output force input distance
• input force output distance
• NO UNITS! Yea!

10
Simple Machines

• 2 families of basic machines
• 1. Levers 2. Inclined planes
• - lever - inclined plane
• - pulley - wedge
• - wheel axle - screw

11
Levers

• Lever parts

12
Levers cont.

• 3 types of levers
• First-class
• crowbar
• seesaw
• scissors
• Second-class
• wheelbarrow
• Third-class
• tweezers
• tongs

13
Lever M.A.

• M.A. Effort Arm Force Effort Distance
• Resistance Arm Force Resistance
  Distance
• ACTUAL
  THEORETICAL
• Effort Force x Effort Distance

• Resistance Force x
  Resistance Distance

14
Interactives

• Lever Example 1
• Lever Example 2

15
Inclined Planes

• This is your basic ramp.
• Spreads work over a large distance.
• Long gradual ? easier to push object.
• Short steep ? harder to push object.

16
Inclined plane M.A.

• M.A. Run Object wt.
• Rise Force
• Example Determine the force needed to lift the
  block.

10 m 20 kg (cross multiply) 5 m F (10
m)F 20 kg x 5 m F 10 kg
17
Pulleys

• Modified levers.
• Center represents fulcrum.

18
Pulley M.A.

• M.A. Objects Wt. Force Distance
• Force Object Distance
• or of upward forces.
• Single fixed pulleys ALWAYS
  have a MA of

ONE!
19
MA
4
MA
2
20
Wheel Axle M.A.

• M.A. Wheel Circumference
• Axle Circumference
• Example 30 cm 6
• 5 cm
• Easy or Hard?

21
Compound machines

• Made up of more than one simple machine.
• Examples

22
What is Energy?

• The ability to do work.
• Measured in Joules
• 2 Types
• Potential
• Kinetic

23
Potential Energy

• Stored energy.
• Example Rubberband
• Depends on MASS and HEIGHT
• Equation
• Grav. PE mass x gravity x height
• PE mgh

24
P.E. Example

• A 65 kg rock climber ascends a cliff. What is
  the climbers gravitational potential energy at a
  point 35 m above the base of the cliff?
• PE mgh
• PE 65 kg (9.81 m/s2) (35m)
• PE 22000 kgm2/s2 or J

25
Kinetic Energy

• Energy due to motion.
• Depends on MASS and SPEED.
• More on speed than mass.
• Equation
• Kinetic energy ½ x mass x speed squared
• KE ½ m?2

26
K.E. Example

• What is the kinetic energy of a 44 kg cheetah
  running at 31 m/s?
• KE ½ m?2
• KE ½(44 kg)(31m/s)2
• KE 21000 kgm2/s2 or J

27
(No Transcript)
28
Other Forms of Energy

• Mechanical energy sum of potential and kinetic
  energy.
• PE KE or mgh ½ m?2

• Potential
• Chemical energy
• Sugars/organic molecules stored in tissue
• Nuclear energy

• Kinetic
• Thermal
• Photosynthesis
• Digestion
• Respiration
• Electricity
• Light

Animation
29
Energy Transformations

• Potential can become kinetic.
• Kinetic can become potential.
• Examples
• Roller Coaster
• Flight of a Ball
• Pendulum

30
Energy Conservation

• Law of Conservation of Energy
• Energy cannot be created or destroyed.
• Energy doesnt appear out of nowhere.
• Energy doesnt disappear.
• Systems may be open or closed.

31
Efficiency

• Not all work done by a machine is useful work.
• The other work may be transferred to heat.
• NO machine is 100 efficient. Why?
• Work output never equals and cannot exceed work
  input!

32
Flash Clip
GO BACK
33
GO BACK
34
GO BACK
35
