phi

1
phi

• public health for the internet
• joe hellerstein
• intel research uc berkeley

2
agenda

• three visions driving j
• building block the PIER query engine
• challenges, synergies

3
vision 1 shift network security from medicine to
public health

• security tools focused on medicine
• vaccines for viruses
• improving the world one patient at a time
• weakness/opportunity in the public health arena
• public health population-focused,
  community-oriented
• epidemiology incidence, distribution, and
  control in a population
• j a new approach
• enable population-wide measurement
• engage end users education and prevention
• understand risky behaviors, at-risk populations.

4
a center for disease control?

• staniford/paxson/weaver 2002
• am I being targeted?
• is this remote host a bad guy?
• is there a new type of activity?
• is there global-scale activity
• who owns the center? what do they control?
• this will be unpopular at best
• electronic privacy for individuals
• the internet as a broadly surveilled police
  state?
• dan geer, former cto of _at_Stake
• provider disincentives
• Transparency maintenance cost
• and hardly ubiquitous
• can monitor the chokepoints (isps)
• but inside intranets??
• e.g. corporate IT
• e.g. berkeley dorms
• e.g. grassroots WiFi agglomerations?

5
energizing the end-users

• endpoints are ubiquitous
• internet, intranet, hotspot
• toward a uniform architecture
• end-users will help
• populist appeal to home users is timely
• enterprise IT can dictate endpoint software
• differentiating incentives for endpoint vendors
• the connection peer-to-peer technology
• harnessed to the good!
• ease of use
• built-in scaling
• decentralization of trust and liability

p2p technology is ripe. a noble app here with
significant uptake?
6
demo time
7
vision 2 shared network monitoring

• endpoint monitoring becoming a trend
• NETI_at_Home (GA Tech)
• DIMES (TAU)
• ForNet (Polytechnic)
• DShield
• DOMINO (Wisconsin)
• we share the vision!
• but all facing key challenges in getting uptake
• whats in it for the community members?
• disincentives privacy security risks

8
a communal approach

• enable multiple efforts with a single distributed
  infrastructure
• extensible endpoint sensors and visualizations
• shared engine connecting them up
• a group bands together on the hard systems and
  crypto
• cost-effective data processing and analysis
• verifiable data and processing
• distributed resource limiting
• toolkit of privacy-preserving, distributed
  dataflow components
• a theme dissemination is as important as
  collection
• attract end-users with visible community
  information
• enable real-time swapping across research teams
• there may be much more here (see next vision!)
• intel research is prepared to invest in this
  community
• as we did with planetlab

9
vision 3 the network oracle

• imagine that you knew everything about the
  internet, at every moment
• network maps
• link loading
• point-to-point latency and bandwidth
• event detections (e.g., from firewalls)
• naming (DNS, ASes, etc.),
• end-system software configuration information
• router configurations and routing tables
• how would this change things?
• the design of protocols
• the design of networked applications
• network and system management (performance and
  security)
• the economy (and policy) of nw clients and isps
• etc.

10
a dirty (not-so) secret

• were sneaking up on the oracle already
• overlays are a subversive attempt to wrest
  control from ISPs
• overlays compute and disseminate measurements
• measurement and functionality appetite growing
• everybodys favorite planetlab exercise
  all-pairs ping
• detour routing a la RON
• custom routing a la i3/ROSE
• but this is not being done systematically
• every overlay does its own thing, opaquely
• granularity of aggregation in time and space not
  well explored
• measurement dissemination often 2ndary/implicit
• algorithmic/architectural choices abound, little
  exploration
• and the brass ring remains

11
wrapping up 3 visions

• multiple rationales to pursue this agenda
• commonalities
• many networked sensors
• many computational agents for data processing
• many destinations for result dissemination
• decentralized infrastructure
• organic scaling
• no centralized maintenance
• no single unified repository of raw data (privacy
  ramifications)
• differences (invariably!)
• desired data granularities, in time and space
• reach of querying and dissemination
• sensitivity to privacy issues
• goal a shared infrastructure
• shared effort to develop and extend it, seeded by
  intel research
• shared bootstrap deployment (planetlab and beyond)

12
agenda

• three visions driving j
• building block the PIER query engine
• challenges, synergies

13
pier p2p information exchange retrieval

• a wide-area distributed dataflow engine
• designed to scale to thousands or millions of
  nodes
• outfitted with streaming relational operators,
  recursive graph queries
• fully extensible dataflow graphs, SQL-like
  interface for convenience
• built on distributed hash table (DHT) overlays
• a put()/get() hashtable interface for the
  Internet.
• content-based routing, soft-state semantics
• pier is DHT-agnostic (CAN ? chord ? bamboo)
• a very different design point than DB2, Oracle,
  etc.
• scale machines, not necessarily bytes
• relaxed consistency a requirement (not really a
  dataBASE at all)
• organic scaling
• data lives in its natural habitat

14
initial pier applications

• f intrusion app
• real-time snort aggregation from 300 planetlab
  nodes
• identification of top-10 attackers (validating
  DOMINO)
• real time joins who are my attackers attacking
• plausible end-user visualizations
• transitive closures and other graph algorithms
• distributed gnutella crawler
• distributed web crawler
• shortest paths queries (distance vector routing)
• improved filesharing for rare items
• deployed as hybrid gnutella ultrapeer on 50
  planetlab nodes
• intercepts gnutella queries, identifies rare
  items and publishes
• 18 decrease in number of unnecessarily empty
  query results
• 66 possible with better rare item
  identification
• upshot reasons to believe the generality is real

15
pier in the j context

• goal is for pier to serve as an information plane
• gather data from sensors
• perform basic filtering, aggregation, combination
• though aggregation can be rather fancy (e.g.
  wavelet encoding)
• disseminate the right cooked data to the right
  people
• and do so in a trusted way
• privacy and security
• manageability
• but only a piece of the puzzle
• active probing
• mapping
• backbone monitors
• network forensics, tomography
• honeypots
• etc.
• we wont do all of this ourselves!
• gathering playmates

16
agenda

• three visions driving j
• building block the PIER query engine
• challenges, synergies

17
Challenges
18
current limitations of pier

• query per client
• no systematic sharing of computation/results
  across queries
• locality control forfeited to dht
• difficult to express local gossiping rules
• queries, not triggers
• alerts currently supported via polling
• loose query semantics
• network dynamics and timing make guarantees hard
• active monitoring
• we can do it, but its not systematic
• security/privacy
• were attacking many of these now

19
so, is pier the right infrastructure

• not today
• though many of the decisions seem sound
• level of indirection between task specification
  and execution
• non-hierarchical model provides flexibility and
  simplicity
• vs. domain hierarchy (a la ip naming)
• vs. data hierarchies (a la xml)
• extensible aggregation relational operators
  covers a lot of territory
• monitoring
• routing

20
potential synergies

• design of shared info plane
• scenarios requirements
• architectural brickbats
• built-in components
• complementary components
• and requirements for integration
• understanding the opportunity
• what if the network oracle existed
• fostering the community
• leveraging each others efforts to get mindshare
• resources
• if the intel genie granted you a wish
• (think about building/leveraging community)

21
backup slides
22

23
(No Transcript)
24
(No Transcript)
25
A Note on Structured Data on Networks

• Industrial Revolution for Information
• Mechanized data generation
• Sensing the physical world
• Monitoring software, networks, machines
• Tracking objects, processes, behaviors
• Uniformity of products
• Mass Transport of Data and Computation
• Data generators and consumers spread over the
  Internet and the Planet
• Happening at both extremes
• Compare to hand-generation of text
