Components vs. Objects

1
Components vs. Objects

• Luigia Petre
• Turku Centre for Computer Science
• Åbo Akademi University,
• FIN-20520 Turku, Finland
• (Presented at Nordic Workshop on Programming
  Theory, Bergen, Norway, Oct 11-13, 2000)

2
Software Engineering Abstractions

• Component-based SE constructing new systems
  from already existing, service-providing
  components
• Object-based SE constructing a new system in
  terms of interacting, distinct units of
  information and services called objects

3
Motivation

• Both components and objects
• have encapsulation properties
• are accessed via well-defined interfaces
• are considered to improve the reuse of software
• are considered to alleviate the software
  evolution phase
• are thought of being natural abstractions of
  real-world entities
• a real-world entity can be modelled / implemented
  using either notion

4
Our Aim

• ...is to answer to
• (a) What is the essential difference between
  components and objects?
• (b) (Why) do we need them both?

5
Components (1)

• Software components units of composition with
  contractually specified interfaces and context
  dependencies only
• A SW component
• can be deployed independently
• is subject to composition by third parties

6
Components (2)

• gt possibly 3 parties involved
• one specifies the component,
• one implements the specification of a component,
• one deploys / use the component

Component (binary unit)
contractual interfaces
contractual dependencies
7

Component (binary unit)
contractual interfaces
contractual dependencies
8
Components (3)

• A system built up from components
• is more robust
• is more flexible (alleviates evolution)
• has a shorter development time / process
• The foremost advantage reuse of software

9
Objects (1)

• Object - abstraction from a real-world entity,
  with associated items of information and a set of
  specific operations
• It has
• a unique and invariant identifier
• a class to which it belongs
• a state that has a certain value

10
Classes (1)

• Class - abstract data type with a set of
  properties (attributes and operations) common to
  its objects
• - has the means of creating objects with these
  properties

11
Classes (2)

Person
?Person ???Driver
superclass / base class
?Person ???Physician
inheritance
Physician
Driver
subclasses / derived classes
12
Objects (2)

• Objects interaction -- using each others
  operations
• Objects visibility -- the state and the
  implementation of the operations is hidden
• A system built up from objects
• is modular (designing classes rather than the
  whole system)
• is reusable (inheritance)
• alleviates evolution (objects are fundamental and
  stable, implementation is hidden)

13
The conceptual difference their role

• Objects
• describe / implement real-world entities (and
  their hierarchies)
• mathematical modelling approach to software
• partition the state space

• Components
• describe / implement services of real-world
  entities
• engineering approach to software
• partition the service space

14
Example Mail Delivery System (MDS)

• Services
• input mail
• send mail
• load mail into the transportation means
• transport mail to destination
• confirm delivery

15
MDS Component View

• We need a component (PostCar) that is able
• to move
• to have a certain loading capacity
• We need a component (Driver) that is able
• to drive for x hours in a row
• to drive certain types of cars
• to receive a salary of no more than y

16
MDS Object View

• We need a class PostCar, with
• a move operation
• a capacity attribute
• We need a class Driver, with attributes in some
  ranges

17
Components vs. Objects Service vs. Identity

• Using a service from a component
• specify the required service and use any
  component providing an implementation of that
  service
• Using a service from an object
• specify what object is used and use the service
  that particular object (with the particular
  state) can provide

18
Using Components and Objects

• Components -- service-oriented gt they describe
  best the functionality of a system
• Objects -- identity-oriented gt they describe
  best the problem domain of a system
• Consequently, we should
• start the software development with components
• develop each component in terms of objects

19
UML Diagrams Outline (1)

MDS
Drive
Input Mail
Load
Unload
Send Mail
Confirm Delivery
Customer
Dispatch
Transport
20
UML Diagrams Outline (2)

MDS
Drive
Input Mail
Load
Unload
Send Mail
Confirm Delivery
Customer
Dispatch
Transport
21
UML Diagrams Outline (3)
Driver

Drive
Load
Driver
Task
Unload
On Duty
1
1
On leave
Outage
0..1
0..1
TruckDriver
CarDriver
BusDriver
22
Conclusions

• Components -- service-oriented gt best as
  functional abstractions
• Objects -- identity-oriented gt best as problem
  domain abstractions
• Components and objects -- best as software
  construction abstractions
