Enterprise Application Integration and Process Modelling

1
Enterprise Application Integrationand Process
Modelling
Erik Perjons DSV, KTH/SU
2
Why focusing on business processes?

• re-engineering the business processes to make
  them more effective/efficient

• easy to understand for non-technical people

• discover and adopt to changed customer demands

• automate the activities in business processes

3
Stove pipe problem
Production
Market
Shipment
Purchase
Customer service
Management
4
Business processes cross departments
5
Solution Integrated IT systems
6
Why problem integrating IT systems?

• Different platforms, programming languages, and
  formats
• No interfaces
• Legacy systems with no documentation
• Different semantics in the systems (different
  meanings of e.g. customer, region,
  product)
• Need of a routing mechanism

7
Problem Constantly changing business processes
8
Integration solutions

• ERP and Enterprise systems
• - replace existing IT systems with
• a new one
• EAI middleware
• - integrate existing IT systems
• Electronic collaboration solutions (B2B
  solutions)
• - integrate the suppliers and customers
  systems
• Data warehousing
• - extract some data from existing IT systems
  and load it into a new system for decision
  support

9
ERP systems/Enterprise systems
10
Integration solutions

• ERP and Enterprise systems
• - replace existing IT systems with a new one
• EAI middleware
• - integrate existing IT systems (RPC,
  CORBA, XML, Message Broker, BPMS)
• Electronic collaboration solutions (B2B
  solutions)
• - integrate the suppliers and customers
  systems
• Data warehousing
• - extract some data from existing IT systems
  and load it into a new system for decision
  support

11
EAI Point-to-Point solutions
12
EAI Many-to-Many solutions
13
Message Brokers and BPMS
14
Business Process Management Systems (BPMS)

also called Process Brokers, Process Automation
Systems, Workflow Management Systems
- directly executable business models - support
process design (modelling), execution,
analysis, simulation and optimisation of
business processes - automate the business
processes, or the information flow
15
Categorisation of Business Process Modelling
Languages

• Static-oriented languages
• visualise the input and output from activities,
  but not the logical order/time, e.g. IDEF0, data
  flow diagram
• Activity-oriented languages
• decribes which activities follows and precede
  another in a process, e.g EPC, UML activity
  diagram
• State-oriented languages
• describes which states follow and precede another
  in a process, e.g UML state diagram
• Communication oriented languages
• - focus on the interaction between prople and
  systems, and between systems, e.g UML sequence
  diagram, BML, SDL

16
Basic process language concepts

• Four basic process language concepts, which have
  the following intuitive meaning

• A time point is an instant in time, not further
  decomposible
• An event is an noteworthy occurence
• A state shows the condition of a process and can
  be represented in several way, e.g. as a set of
  attribute values
• A activity is something that is performed in a
  process

17
Different meaning of basic terms

• Two examples (there are more)

State
State
State
State
State
State
Activity
Activity
Event
Event
Time points
Time points
18
Meta models and reference meta model

RosemannGreen, 2002
19
Data flow diagram
20
UML Activity Diagram
FowlerScott, 1997
21
UML State Diagram
FowlerScott, 1997
22
Business Modelling Language (BML)
23
Business Modelling Language (BML)
24
Business Modelling Language (BML)
25
Process Broker project

• The purpose of the project is to investige BPMS
  (Process Brokers), in particular
• business process modelling languages
• method for application and process
  integration

26
Process Broker project - Telecom case
27
Vita Nova project
The purpose of the project is to investige the
potential of BPMS in Health and Medical
Services DSVs assignment is to develop a
framework for evaluating business processes
models, BPMS and methods for integrating
business processes
28
Loosely-Structured Business Processes project

• The purpose of the project is to investige BPMS
  for loosely-structured business processes
• focused on goal and state modelling
• try to define patterns for such business
  processes
• case studies decision-making and lobbying

29
ebXML and EC4 project
- ebXML is a global standard developed by
UN/CEFACT and OASIS - EC4 stands for Electronic
Commerce and Collaboration Center - aims at
disseminate knowledge about electronic commerce
and collaboration among researchers, students and
SME
30
Integration solutions

• ERP and Enterprise systems
• - replace existing IT systems with a new one
• EAI middleware
• - integrate existing IT systems
• Electronic collaboration solutions (B2B
  solutions)
• - integrate the suppliers and
• customers systems
• Data warehousing
• - extract some data from existing IT systems
  and load it into a new system for decision
  support

31
B2B - Electronic CollaborationIntegration
Shipment
Market
Production
Customer service
Management
Purchase
Suppliers
Customers
32
Business Processes spanning several organisations
Company 1
P1.3
P1.1
P1.4
P1.2
33
ebXML Electronic CollaborationIntegration Levels
34
SOA
Web services and CORBA are different
implementations of Service Oriented Architecture
(SOA)
Service Broker
Find
Publish
Service Requestor
Service Provider
Request Bind
35
Integration solutions

• ERP and Enterprise systems
• - replace existing IT systems with a new one
• EAI middleware
• - integrate existing IT systems
• Electronic collaboration solutions (B2B
  solutions)
• - integrate the suppliers and customers
  systems
• Data warehousing
• - extract some data from existing IT systems
  and load it into a new system for decision
  support

36
Data warehousing architecture
37
Data warehousing definition
Data warehousing is a collection of decision
support technologies, aimed at enabling the
knowledge worker (executive, manager, analyst) to
make better and faster decisions.
ChaundhuriDayal, 1997
