Title: Generic Emulator Test System GETS


1
Generic Emulator Test System (GETS)
D. Cosi Dataspazio S.p.A.
M.Irvine, J.Ochs VEGA Informations-Technologien
GmbH
2
Project Organisation
  • The GETS study is performed under contract to
    ESOC.
  • ESOC Technical Officer is David Verrier.
  • VEGA is the prime contractor.
  • Dataspazio responsible for development of GETS
    off-line tools.
  • VEGA responsible for test tool development.

3
Introduction
  • All recent operational simulators, developed for
    ESOC, have included one or more processor
    emulators running the actual flight software.
  • ESOC have frequently had problems with the
    availability and quality of the flight software
    to be used within an emulator.

4
Purpose
  • The aim of the GETS study is to demonstrate that
    it is possible to have configurable flight
    software that implements the key parts of the
    Packet Utilisation Standard and acts as source
    and sink of telemetry and telecommand packets.
  • This software can be reused across missions to
    help the simulator development and to postpone
    the need of the real flight software.

5
Components
  • The Generic Emulator Test System consists of
    four components
  • Configuration Editor
  • Development System
  • Generic Emulator Software
  • Validation System

6
Configuration Editor
  • load and export TM, TC and BUS configurations.
  • provide a set of GUIs

7
Development System
  • load configuration
  • generate part of software
  • build the software binary image (ERC32)
  • export MIB files
  • provide GUI

8
Generic Emulator Software (GES)
  • Import the configuration
  • implement the key parts of the Packet
    Utilisation Standard
  • exchange data with external devices via APIs

9
Validation System
  • Windows/SIMSAT-2003 simulator
  • validate the flight software
  • include an ERC32 emulator (ESOC ERC32 or TSIM)
  • provide an external spacecraft subsystem model
    (TC sink and TM source)
  • support testing with MCS connection
  • support testing stand-alone - TCs injected and
    TM output stream decoding

10
GETS Overview
11
TM Parameter Editor
  • The TM Parameter Editor allows to define and
    update telemetry parameters. Each parameter is
    characterised by
  • Name, it uniquely identifies the parameter.
  • Size, size (number of bits) of the parameter.
  • PTC, Parameter Type Code. It controls the
    encoding format of the parameter. It is used by
    SCOS-2000 in order to decode the value of
    parameters extracted from TM packets
  • PFC, Parameter Format Code. Along with the
    Parameter Type Code this field controls the
    length of the parameter. It is used by SCOS-2000
    for parameters extracted from TM packets

12
TM Packet Editor
  • TM Packet Editor allows to
  • define a new TM packet to be added to the current
    TM configuration
  • update TM packet header parameters and
    characteristics (time period and VCID)
  • remove a TM packet from the current TM
    configuration
  • Add TM parameters to a TM packet
  • remove TM parameters from a TM packet.

13
TM Packet Editor
  • The TM Packets table displays the list of packets
    currently defined.
  • Name, TM packet name. It uniquely identifies the
    telemetry packet.
  • APID, packet APID field of the packet header.
  • Length, packet length field. It specifies the
    number of octets contained within the packet data
    field.
  • DFH, Data Field Header Flag. It indicates the
    presence or absence of a data field header.
  • Type, service type (packet data field header).
    It indicates the service to which the telemetry
    source packet relates.
  • Subtype, service subtype (packet data field
    header). Together with the service type, the
    subtype uniquely identifies the nature of the
    service report constituted by this telemetry
    source packet.
  • VCID, virtual channel identifier where the packet
    has to be routed.
  • Period, packet generation time period.
  • Time Code, it defines the telemetry source packet
    time field in the packets data field header
    (NONE, CDS or CUC).

14
TM Packet Editor
  • The Source Data table defines the source data
    field of the of the selected packet, it consists
    of the following fields
  • Par. Name, name of the telemetry parameter
    located at the specified byte and bit offsets in
    the packet.
  • Byte-offset, number of bytes between the start of
    the TM parameter and the first byte of the packet
    (Byte 0).
  • Bit-offset, number of bits between the start of
    the TM parameter and the specified byte offset

15
Bus Editor
The Bus Editor allows to define the OBDH bus
interrogations or MIL 1553 bus transactions to be
performed by the flight software to retrieve the
telemetry source data generated by the on-board
models.
16
Bus Editor
17
TC Parameter Editor
  • The TC Parameter Editor allows to define and
    update telecommand parameters. Each parameter is
    characterised by
  • Name, it uniquely identifies the parameter.
  • Size, size (number of bits) of the parameter.
  • PTC, Parameter Type Code. It controls the
    encoding format of the parameter. It is used by
    SCOS-2000 in order to decode the value of
    parameters extracted from packets
  • PFC, Parameter Format Code. Along with the
    Parameter Type Code this field controls the
    length of the parameter. It is used by SCOS-2000
    for parameters extracted from packets

18
TC Packet Editor
  • TC Packet Editor allows to
  • add a new TC packet to the current TC
    configuration
  • update the TC packet header parameters
  • remove a TC packet from the current TC
    configuration
  • add a TC parameter to a TC packet
  • remove a TC parameter from a TC packet

19
TC Packet Editor
  • The TC Packets table displays the list of packets
    currently defined.
  • Name, TC packet name. It uniquely identifies the
    telecommand packet.
  • APID, packet APID field of the packet header.
  • Length, packet length field. It specifies the
    number of octets contained within the packet data
    field.
  • DFH, Data Field Header Flag. It indicates the
    presence or absence of a data field header.
  • Type, service type (packet data field header). It
    indicates the service to which the telecommand
    packet relates.
  • Subtype, service subtype (packet data field
    header). Together with the service type, the
    subtype uniquely identifies the nature of the
    service request constituted by this telecommand
    packet.
  • ACK, acknowledge (packet data field header). It
    indicates which acknowledgements, in the form of
    telecommand verification packets, shall be sent
    to the ground to notify acceptance and to verify
    execution of the telecommand packet.

20
TC Packet Editor
  • The Application Data table defines the
    application data field of the of the selected
    packet,
  • Par. Name, name of the telecommand parameter
    located at the specified byte and bit offsets in
    the packet.
  • Byte-offset, number of bytes between the start of
    the TC parameter and the first byte of the packet
    (Byte 0).
  • Bit-offset, number of bits between the start of
    the TC parameter and the specified byte offset.
  • Default Value, value to be assigned to the
    parameter by default.

21
Development System
  • The Development System allows to
  • Load configuration files, exported by the
    Configuration Editor, which specialise the
    Generic Emulator Software.
  • Produce a set of MIB files correspondent to the
    defined configuration.
  • Generate a set of files used to complete the
    software source code in accordance with the
    defined configuration
  • Build the Generic Emulator Software binary image

22
Generic Emulator Software - Services
  • TM(1,1) Telecommand Acceptance Report - Success
  • TM(1,2) Telecommand Acceptance Report - Failure
  • TM(1,7) Telecommand Execution Completed Report -
    Success
  • TM(1,8) Telecommand Execution Completed Report
    Failure
  • TC(2,1) Distribute ON/OFF Commands
  • TC(2,2) Distribute Register Load Commands
  • TC(3,5) Enable Housekeeping Parameter Report
    Generation
  • TC(3,6) Disable Housekeeping Parameter Report
    Generation
  • TM(3,25) Housekeeping Parameter Report
  • TM(5,1) Normal/Progress Report
  • TM(5,2) Error/Anomaly Report - Low Severity
  • TM(5,3) Error/Anomaly Report - Medium Severity
  • TM(5,4) Error/Anomaly Report - High Severity
  • TC(9,1) Change Time Report Generation Rate
  • TM(9,2) Time Report

23
Generic Emulator Software - Services
  • TC(14,1) Enable Forwarding of Telemetry Source
    Packets
  • TC(14,2) Disable Forwarding of Telemetry Source
    Packets
  • TC(14,3) Report Enabled Telemetry Source Packets
  • TM(14,4) Enabled Telemetry Source Packets Report
  • TC(14,5) Enable Forwarding of Housekeeping
    Packets
  • TC(14,6) Disable Forwarding of Housekeeping
    Packets
  • TC(14,7) Report Enabled Housekeeping Packets
  • TM(14,8) Enabled Housekeeping Packets Report
  • TC(14,13) Enable Forwarding of Event Report
    Packets
  • TC(14,14) Disable Forwarding of Event Report
    Packets
  • TC(14,15) Report Enabled Event Report Packets
  • TM(14,16) Enabled Event Report Packets Report
  • TC(17,1) Perform Connection Test
  • TM(17,2) Link Connection Report

24
Portability
Configuration Editor and Development System have
been developed in Java. The Generic Emulator
Software has been developed in ANSI-C. GCC-ERC32
cross-compiler available for Sun SPARC Solaris,
IBM PC Linux and Microsoft Windows
25
Project Work-Flow
Requirements Phase - production of Software
Requirements document. Architectural Design Phase
- perform architectural design, production of SAD
and ICD documents. Implementation Phase - coding
and testing of the components. Acceptance Phase -
delivery, acceptance testing and training.
26
GETS - Work Flow
27
Project Status
Requirements Phase - completed. Architectural
Design Phase - completed D1 delivery -
Configuration Editor and Development System.
Delivered to ESOC, re-delivery planned 14 Nov. D2
delivery - contains all GETS components including
Validation System (VS). Planned for 16 December
2005. Remaining activities - completion of VS and
GES integration, formal testing and delivery.
28
Questions ?
  • Thanks for your attention !

29
Contacts in Dataspazio
30
Contacts in VEGA
