Introducing GIS and Remote Sensing

1
Introducing GIS and Remote Sensing

• Introduction to Mapping and GIS

2
Rowan University
Think about all the activity occurring though out
a landscape. How can we map, manage and analyze
all that is going on? GIS!
3
US Census Data in Excel
Think about keeping information about phenomenon
on a landscape. How could you do it?
4
US Census Data in GIS
GIS organizes that data with a map. But GIS is
much more.
5
Data Types
Aspatial datadata not tied to a location on the
earths surface
Spatial datadata associated with a location on
earth Much of the information we deal with daily
has some spatial component.
6
What is GIS?

• Data Management -
• Manages various kinds of GIS data including
  vector, raster, images, tables, other data files
• Data models and architectures
• Conversion between formats
• Import/export utilities
• Interacts with RDBMS (SQL Server, Oracle, etc)

7
What is GIS?

• Analysis
• Spatially aware data
• Attribute and spatial query
• Proximity and Overlay
• Advanced geoprocessing techniques
• Decision support
• Flexible, customization
• Programming, scripting (to perform analysis)

8
What is GIS?

• Visualization
• Maps! Maps! Maps!
• If a picture is worth a 1000 words
• Professional cartographic tool
• Charts, graphs, tables, etc
• Various coordinate systems
• 2D and 3D
• Web, desktop, handheld, etc

9
What is GIS?

• Data Management Database View
• Analysis Model View
• Visualization Map View

10
G vs. IS

• GIS uses maps to spatially analyze and search for
  patterns in the data that would otherwise not be
  found. (Content)
• GIS stores, manipulates, and displays data files
  and relationships in a information system using
  standard computing practices. (IT)
• With advances in technology, GIS users must now
  deal with both aspects!

11
The G

• G Geographic
• Denotes the concept of spatial location on
  Earths surface
• Importance of relative location (not just where
  you are but where you are in relation to
  everything else)
• Theories and techniques in Geography form the
  basis of GIS

12
The I

• I Information
• Substance (knowledge) about location
• Factual and interpretative
• Tables Maps Analysis
• Transformation of table information into spatial
  context for analysis
• Technology and computer systems

13
What about just GI?

• Yes, it is used quite often.
• Commonly used as a replacement for or broadening
  of the term GIS data
• But

14
What About the S in GIS?

• Systems
• Science
• Studies
• Services

15
Geospatial?

• Geographic GIS Geospatial
• Move in recent years to better define the
  industry and to focus on data (business) over
  geographic principles (academic)
• Geospatial includes all subcomponents of GIS
  embedded in other areas (remote sensing, GPS etc.)

16
Not Just Computer Cartography
17
Core of GIS Layers
18
Importance of Layers in GIS

• Geographic data Representation of reality
• Reality is complex.
• GIS utilizes a layer approach
• Each layer only includes information about one
  type of phenomenon.
• Data layers must be aligned with one another

19
Importance of Layers

• Proximity
• Finding what is near or within a distance from a
  certain location or feature
• e.g., all houses within 100 yards of a stream
• Overlay
• Combining two layers to create new information
• e.g., habitat based on veg, elevation, and temp

20
Families of GIS Data (1)

• Vector mode or coordinate based
• Three vector objects existpoints, lines,
  polygons these are called features.
• They are represented by X,Y coordinates
• sometimes Z (3D), sometimes M (linear reference)
• Information about features is (are) called
  attributes.
• Two types of vector modelstopological and object
• Topological means the data models stores
  relationships between vectors
• Vector objects exist independent of any other
  nearby features

21
Families of GIS Data (2)

• Raster mode or grid cell
• Entire study area is covered by a grid
• Each cell within grid is given a value
• Values can be integer or decimal
• Data can be discrete or continuous
• Cell size is variable and linked to the file size
  of the raster data
• Areas outside of the grid are ignored
• Grid must be expanded if those areas are to be
  included

22
Modeling Geospatial Reality
Raster Model
Vector Model
Real World
23
Coding Vector GIS
24
Coding Vector GIS
Vector Mode Model of Reality
Reality
25
Coding Raster GIS Data
26
Coding Raster GIS Data
1 1 1 1 2 3 4 4 1 1 1 2 2
3 4 4 1 2 2 2 3 3 4 4 2 2
2 3 3 4 4 4 3 3 3 3 5 5
5 5 1 1 1 1 6 5 5 5 1 1 1
1 1 5 5 5 1 1 1 1 1 1 5 5
Raster Mode Model of Reality
Reality
27
Advantages of Vector

• Vector data make maps that look more like maps we
  are use to seeing on paper.
• The shapes of features are accurately
  represented.
• Vector data can have TOPOLOGY
• Vector data is good for managing attributes
• Vector data can have smaller dataset
• Only the objects need to be represented in the
  database (empty space in-between is not captured)
• Vector

28
Disadvantages of Vector

• Complicated data structure
• Software must manage many data tables
• Not good at representing geographic features that
  gradually change over location
• For example elevation or moisture in soil
• Slower processing time

29
Advantages of Raster

• Good at depicting continuously changing surfaces
  such as elevation or soil moisture
• Grid format is simple data structure
• Easier for computer to make analytical
  calculations
• Ideal for utilizing remote sensing images

30
Disadvantages of Raster

• Maps can be blocky looking (depending on the size
  of the grid cells)
• Cells can only be coded for one attribute when
  there may be more than one attribute at each
  location
• Can have very large datasets (depending on the
  size of the grid cell)
• Is NOT TOPOLOGICAL data structure

31
Remote Sensing

• Remotely-Sensed data is one of the most important
  sources of data for GIS.
• RS means - Acquiring data from a distance
• Usually uses electromagnetic energy
• sunlight, radar, laser
• Originally captured on photographic film
• Recent platforms utilize digital sensors

32
Early Remote Sensing Platforms
33
What kinds of devices collect the data?

• Aircraft
• High altitude
• Low altitude
• Spacecraft
• Landsat
• SPOT
• Weather satellites
• GeoEye-1

Geosynchronous Orbitwhen the satellite moves at
the same speed as the spinning earth results in
the camera staying over the same spot of the earth
34
Aircraft Images
35

• Black and Whiteor
• Panchromatic
• Sensitive to visible light

36
Digital Orothographic Photos

• Digital photos of the earth
• Usually acquired by aircraft
• Orthographic means that the photo has all
  distortion removed
• A regular photo from an airplane will have
  distortion due to
• Parallax effect that distance away from the
  center point of a photo will always have
  distortion
• Terrain the hills and valleys or a land area
  will cause distortion in the photo
• An orthographic photo is adjusted by computer
  software to make the image line up with a flat
  map

37
Digital OIrthographic Photo-quad Infrared
You are here
38
Remote Sensing Mediums

• Black and White or Panchromatic
• Sensitive to visible light
• True Color
• Similar to color film
• Infrared
• Sensitive to infrared frequencies that cant be
  seen by humans
• Developed by military for identifying tanks
  painted with camouflage
• Good for evaluating conditions of vegetation
• Good for evaluating moisture in soil
• False-color adjusted
• When frequencies of received data are shifted to
  allow or enhanced human viewing
• Multi spectral
• When more than a single band of energy is
  captured
• Color is multi-spectral (3 bands)
• Some satellites can have 7 or even more bands
  of sensitivity

39
The Electromagnetic Spectrum
40
The Visible Spectrum

• The visible spectrum is only a tiny window
• We are blind to 99.99 of the energy in the
  universe
• We have created devices that allow us to see
  beyond the range of human vision

41
Satellite Images

• Weather satellite image Winter in North America.

42
What are the spatial units for which data are
collected?

• Pixel or Picture Element
• Smallest unit of data collection
• Features smaller than the pixel size cant be
  distinguished
• Pixel Sizes
• Landsat MSS 79 meters
• Landsat TM 30 meters
• SPOT 10 meters
• IKONOS 1 meter
• GeoEye-1 0.41 meters

43
Spatialresolutionkeeps gettingbetter...
GeoEye-1
44
1, 3, and10 meters
Spatial resolution keeps getting better...
45
Temporal Resolution

• Remote sensing images begin to get old as soon as
  they are taken
• Satellites repeatedly circle the earth
• Airplanes must be commissioned every time they
  photograph (expensive).
• NJ aerial photography was taken 1995, 2002, and
  2007.
• Statewide aerials often have to be taken in
  multiple years (95/97) (07/08)

46
What is GIS?

• Now that weve learned the essential elements
  that make up a GIS
• and have seen examples of how GIS is being used
• lets take a look at the big picture.

47
GIS Is Evolving
Systems
Networks
Projects
Integrated
Coordinated
Cooperative
. . . Moving to the Internet and Web Services
48
How is GIS used?

• Sometimes, the best way to learn about GIS is to
  see how its being used..
• Science
• Emergency management
• Government record-keeping
• Business location
• Environmental management
• Planning
• Crime mapping

49
Creating a Digital Earth
Measuring and Integrating Spatial and Thematic
Information
. . . A Nervous System for Spaceship Earth
50
Violence in Darfur

• Image shows 2004 2006.
• Area too large and dangerous for small
  peacekeeping force.
• Violence tracked using satellite images.
• Article.

51
California Wildfires

• LA Times and local residents are mapping the
  spread of major wildfires.
• Using web-based GIS to present and catalog data.
• Article.

52
GeoCommons

• GeoCommons is a "mashup" maker
• Upload your data excel or GIS and have it
  mapped
• Find data others have shared
• Make maps, then export to Google Earth
