Internet Measurements

1
Internet Measurements
2
Internet

• Web of interconnected networks
• Grows with no central authority
• Autonomous Systems optimize local communication
  efficiency
• The building blocks are engineered and studied in
  depth
• Global entity has not been characterized
• Most real world complex-networks
  have non-trivial properties.
• Global properties can not be inferred from local
  ones
• Engineered with large technical diversity
• Range from local campuses to transcontinental
  backbone providers

3
Internet Measurements

• Need for Internet measurements arises due to
  commercial, social, and technical issues
• Realistic simulation environment for developed
  products,
• Improve network management
• Robustness with respect to failures/attacks
• Comprehend spreading of worms/viruses
• Know social trends in Internet use
• Scientific discovery
• Scale-free (power-law), Small-world, Rich-club,
  Dissasortativity,

4
Internet Topology Measurement
CAIDA 2006
5
Internet Topology Measurement
CAIDA 2006
6
Internet Topology Measurement
Dandelion 2001
7
Internet Topology Measurement
8
Walrus
9
Internet Topology Measurement
CAIDA 2006
10
Internet Topology MeasurementsProbing

• Direct probing
• Indirect probing

IPB
IPD
Vantage Point
IPB TTL64
IPD TTL64
D
B
C
A
IPB
IPC
IPD TTL2
IPD TTL1
11
Autonomous System Level Mapping
Historical
12
(No Transcript)
13
(No Transcript)
14
Autonomous System Level Mapping
15
(No Transcript)
16
Traffic Measurements

• Monitoring and measuring network traffic
• to produce better models of network behavior
• to diagnose failures and detect anomalies
• to defend against unwanted traffic
• Live weather map
• Internernet2
• PlanetLab

17
Code-Red Worm

• On July 19, 2001, more than 359,000 computers
  connected to the Internet were infected with the
  Code-Red (CRv2) worm in less than 14 hours
• Spread

18
Sapphire Worm

• was the fastest computer worm in history
• doubled in size every 8.5 seconds
• infected more than 90 percent of vulnerable hosts
  within 10 minutes.

19
Witty Worm

• reached its peak activity after approximately 45
  minutes
• at which point the majority of vulnerable hosts
  had been infected
• World
• USA

20
Nyxem Email Virus

• Estimate of total number of infected computers is
  between 470K and 945K
• At least 45K of the infected computers were also
  compromised by other forms of spyware or botware
• Spread

21
Scam Hosting

• Study dynamics of scam hosting infrastructure

22
Measurement Studies

• Glasnost
• tests whether BitTorrent is being blocked or
  throttled
• BW-meter
• Measurement tools for the capacity and load of
  Internet paths
• NPAD Diagnostics Servers
• Automatic diagnostic server for troubleshooting
  end-systems and last-mile network problems
• iPlane
• construct a router interface-level atlas of the
  Internet
• measuring link attributes
• Hubble
• find persistent Internet black holes as they occur

23
Internet Measurements

• The Internet is man-made, so why do we need to
  measure it?
• Because we still dont really understand it
• Sometimes things go wrong
• Malicious users
• Measurement for network operations
• Detecting and diagnosing problems
• What-if analysis of future changes
• Measurement for scientific discovery
• Creating accurate models that represent reality
• Identifying new features and phenomena

24
Questions ?
25
Internet Topology MeasurementTopology Collection
(traceroute)

• Probe packets are carefully constructed to elicit
  intended response from a probe destination
• traceroute probes all nodes on a path towards a
  given destination
• TTL-scoped probes obtain ICMP error messages from
  routers on the path
• ICMP messages includes the IP address of
  intermediate routers as its source
• Merging end-to-end path traces yields the network
  map

IPB
IPA
IPC
IPD
Destination
Vantage Point
TTL1
TTL2
TTL3
TTL4
D
A
B
C
S
26
Internet Topology MeasurementBackground
Internet2 backbone
S
s.3
s.2
s.2
n.1
n.3
n.3
N
c.2
w.1
w.2
u.1
c.1
W
C
c.3
w.3
w.3
u.2
U
c.4
k.1
k.2
K
u.3
l.1
k.3
Trace to NY
a.1
a.2
l.2
L
A
l.3
l.3
a.3
a.3
h.2
Trace to Seattle
H
h.3
h.1
h.4
h.4
h.4
d
27
Internet Topology MeasurementBackground
s.1
f
e
S
s.3
n.2
s.2
n.1
n.3
N
c.2
w.1
w.2
c.1
u.1
W
C
c.3
w.3
u.2
U
c.4
k.1
k.2
K
u.3
l.1
k.3
a.1
a.2
l.2
L
A
l.3
a.3
h.2
H
h.3
h.1
h.4
d
28
Topology SamplingIssues

• Sampling to discover networks
• Infer characteristics of the topology
• Different studies considered
• Effect of sample size Barford 01
• Sampling bias Lakhina 03
• Path accuracy Augustin 06
• Sampling approach Gunes 07
• Utilized protocol Gunes 08
• ICMP echo request
• TCP syn
• UDP port unreachable

29
Anonymous Router Resolution Problem

• Anonymous routers do not respond to traceroute
  probes and appear as a ? in path traces
• Same router may appear as a ? in multiple traces.
• Anonymous nodes belonging to the same router
  should be resolved.
• Anonymity Types
• Ignore all ICMP packets
• ICMP rate-limiting
• Ignore ICMP when congested
• Filter ICMP at border
• Private IP address

30
Anonymous Router Resolution Problem
f
Internet2 backbone
e
S
N
C
W
U
K
L
A
H

• Traces
• d - ? - L - S - e
• d - ? - A - W - ? - f
• e - S - L - ? - d
• e - S - U - ? - C - ? - f
• f - ? - C - ? - ? - d
• f - ? - C - ? - U - S - e

d
31
Anonymous Router Resolution Problem
U
K
C
N
S
f
L
H
A
W
e

• Traces
• d - ? - L - S - e
• d - ? - A - W - ? - f
• e - S - L - ? - d
• e - S - U - ? - C - ? - f
• f - ? - C - ? - ? - d
• f - ? - C - ? - U - S - e

d
Sampled network
32
Graph Based InductionCommon Structures
Parallel nodes
Complete Bipartite
Clique
Star
33
Alias Resolution
.33

• Each interface of a router
• has an IP address.
• A router may respond with
• different IP addresses to
• different queries.
• Alias Resolution is the process of grouping the
  interface IP addresses of each router into a
  single node.
• Inaccuracies in alias resolution may result in a
  network map that
• includes artificial links/nodes
• misses existing links

.5
.18
Denver
.7
.13
34
IP Alias ResolutionProblem
s.1
f
e
S
s.3
n.2
s.2
n.1
N
n.3
c.2
u.1
w.1
w.2
c.1
W
C
c.3
u.2
U
w.3
k.1
c.4
k.2
u.3
K
k.3
l.1
a.1
l.2
a.2
L
A
l.3
a.3
h.2

• Traces
• d - h.4 - l.3 - s.2 - e
• d - h.4 - a.3 - w.3 - n.3 - f
• e - s.1 - l.1 - h.1 - d
• e - s.1 - u.1 - k.1 - c.1 - n.1 - f
• f - n.2 - c.2 - k.2 - h.2 - d
• f - n.2 - c.2 - k.2 - u.2 - s.3 - e

H
h.3
h.1
h.4
d
35
IP Alias ResolutionProblem
U
K
C
N
S
f
Sampled network
L
H
A
W
e
d

• Traces
• d - h.4 - l.3 - s.2 - e
• d - h.4 - a.3 - w.3 - n.3 - f
• e - s.1 - l.1 - h.1 - d
• e - s.1 - u.1 - k.1 - c.1 - n.1 - f
• f - n.2 - c.2 - k.2 - h.2 - d
• f - n.2 - c.2 - k.2 - u.2 - s.3 - e

36
Genuine Subnet ResolutionProblem

• Alias resolution
• IP addresses that belong to the same router
• Subnet resolution
• IP addresses that are connected over the same
  medium

IP1
IP1
IP2
IP3
IP2
IP3
