Advanced SQL

1
Advanced SQL
2
Learning Objectives

• SQL queries examples
• Advanced SQL
• Queries
• Commands

3
MySQL Datatypes

• BOOL, BIT
• INTEGER or INT (may be UNSIGNED)SMALLINT,
  MEDIUMINT, BIGINTmay be followed by optional M
• FLOAT (M, D)
• DOUBLE(M,D) or REAL(M,D)
• DECIMAL(M,D) or NUMERIC(M,D) is unpacked
  floating-point
• CHAR(M), CHAR, VARCHAR(M), TEXT or BLOB,
  MEDIUMTEXT or MEDIUMBLOB, LONGTEXT or LONBLOB
  (LOB Large OBject)
• DATE, DATETIME, TIMESTAMP (yyyy-mm-dd-hh.mm.ss.nnn
  nnn), TIME, YEAR
• ENUM, SET

4
Data Manipulation Commands

• Common SQL Commands

5
Data Entry and Saving

• Enters data into a table
• Saves changes to disk

INSERT INTO lttable namegt (attribute_name_1,
) VALUES (attribute_1_value, attribute_2_value,
etc.)
COMMIT lttable_ namegt
6
Listing Table Contents and Other Commands

• Allows table contents to be listed
• UPDATE command makes data entry corrections
• ROLLBACK command restores database back to
  previous condition if COMMIT hasnt been used
• DELETE command removes table row

SELECT ltattribute namesgt FROM lttable namesgt
7
Queries

• Creating partial listings of table contents

SELECT ltcolumn(s)gtFROM lttable namegtWHERE
ltconditionsgt
Table 5.4 Mathematical Operators
8
Examples

• Mathematical operators
• Mathematical operators on character attributes
• Mathematical operators on dates

SELECT P_DESCRIPT, P_INDATE, P_PRICE, V_CODE FROM
PRODUCT WHERE V_CODE ltgt 21344
SELECT P_CODE,P_DESCRIPT,P_ONHAND,P_MIN,P_PRICEFR
OM PRODUCTWHERE P_CODE lt 1558-QWI
SELECT P_DESCRIPT,P_ONHAND,P_MIN,P_PRICE,PINDATEF
ROM PRODUCTWHERE P_INDATE gt 01/20/2002
9
Computed Columns

• New columns can be created through valid
  computations or formulas
• Formulas may contain mathematical operators
• May contain attributes of any tables specified in
  FROM clause
• Alias is alternate name given to table or column
  in SQL statement

SELECT P_DESCRIPT,P_ONHAND,P_PRICE,P_ONHANDP_PRIC
E AS TOTVALUE FROM PRODUCT
10
Operators

• Logical AND, OR, NOT
• Rules of precedence
• Conditions within parenthesis executed first
• Boolean algebra
• Special
• BETWEEN - defines limits
• IS NULL - checks for nulls
• LIKE - checks for similar string (st, _st)
• IN - checks for value in a set
• EXISTS - opposite of IS NULL

SELECT FROM PRODUCTWHERE V_CODE 21344 OR
V_CODE 24288
11
Advanced Data ManagementCommands

• ALTER - changes table structure
• ADD - adds column
• MODIFY - changes column characteristics
• Entering data into new column

ALTER TABLE lttable namegtADD (ltcolumn namegt ltnew
column characteristicsgt) ALTER TABLE lttable
namegtMODIFY (ltcolumn namegt ltnew column
characteristicsgt)
UPDATE PRODUCTSET P_SALECODE 2WHERE P_CODE
1546-QQ2
12
Advanced Data Management Commands

• Dropping a column
• Arithmetic operators and rules of precedence

ALTER TABLE VENDORDROP COLUMN V_ORDER
13
Advanced Data Management Commands

• Copying parts of tables
• Deleting a table from database
• Primary and foreign key designation

INSERT INTO ltreceiving tablegt ltreceiving tables
column namesgtSELECT ltcolumn names of the columns
to be copiedgtFROM ltcontributing table namegt
DROP TABLE PART
ALTER TABLE LINE ADD PRIMARY KEY (INV_NUMBER,
LINE_NUMBER) ADD FOREIGN KEY (INV_NUMBER)
REFERENCES INVOICE ADD FOREIGN KEY (PROD_CODE)
REFERENCES PRODUCT
14
Advanced Data Management Commands
INSERT INTO PART (PART_CODE, PART_DESCRIPT,
PART_PRICE) SELECT P_CODE, P_DESCRIPT, P_PRICE
FROM PRODUCT
The table PART must have been created beforehand
15
Example Aggregate Function Operations

• COUNT (count not null values)
• MAX and MIN

SELECT COUNT(DISTINCT V_CODE)FROM
PRODUCT SELECT COUNT(DISTINCT V_CODE)FROM
PRODUCTWHERE P_PRICE lt 10.00
SELECT MIN(P_PRICE)FROM PRODUCT SELECT P_CODE,
P_DESCRIPT, P_PRICEFROM PRODUCTWHERE P_PRICE
MAX(P_PRICE)
16
Example Aggregate Function Operations (cont.)

• SUM
• AVG

SELECT SUM(P_ONHAND P_PRICE)FROM PRODUCT
SELECT P_DESCRIPT, P_ONHAND, P_PRICE, V_CODEFROM
PRODUCTWHERE P_PRICE gt (SELECT AVG(P_PRICE)
FROM PRODUCT)ORDER BY P_PRICE DESC
17
More Complex Queries and SQL Functions

• Ordering a listing
• Results ascending by default ASC
• Descending order uses DESC
• Cascading order sequence

ORDER BY ltattributegt
ORDER BY ltattributegt DESC
ORDER BY ltattribute 1, attribute 2, ...gt
18
More Complex Queries and SQL Functions (cont.)

• Listing unique values
• DISTINCT clause produces list of different values
• Aggregate functions
• Mathematical summaries

SELECT DISTINCT V_CODE FROM PRODUCT
19
More Complex Queries and SQL Functions (cont.)

• Grouping data
• Creates frequency distributions
• Only valid when used with SQL arithmetic
  functions
• HAVING clause operates like WHERE for grouping
  output

SELECT P_SALECODE, MIN(P_PRICE)FROM
PRODUCT_2GROUP BY P_SALECODE
SELECT V_CODE,COUNT(DISTINCT(P_CODE)),AVG(P_PRICE)
FROM PRODUCT_2 GROUP BY V_CODE HAVING
AVG(P_PRICE) lt 10
20
More Complex Queries and SQL Functions (cont.)
21
More Complex Queries and SQL Functions (cont.)
22
More Complex Queries and SQL Functions (cont.)
23
More Complex Queries and SQL Functions (cont.)

• Virtual tables creating a view
• CREATE VIEW command
• Creates logical table existing only in virtual
  memory
• SQL indexes

CREATE VIEW PRODUCT_3 ASSELECT P_DESCRIPT,
P_ONHAND, P_PRICEFROM PRODUCTWHERE P_PRICE gt
50.00
CREATE INDEX P_CODEXON PRODUCT(P_CODE)
24
More Complex Queries and SQL Functions (cont.)
25
More Complex Queries and SQL Functions (cont.)

• Joining database tables
• Data are retrieved from more than one table
• Recursive queries joins a table to itself
• Outer joins can be used when null values need
  to be included in query result

SELECT PRODUCT.P_DESCRIPT, PRODUCT.P_PRICE,
VENDOR.V_NAME, VENDOR.V_CONTACT,
VENDOR.V_AREACODE, VENDOR.V_PHONEFROM PRODUCT,
VENDORWHERE PRODUCT.V_CODE VENDOR.V_CODE
SELECT A.EMP_NUM,A.EMP_LNAME,A.EMP_MGR, B.EMP_LNAM
E FROM EMP A, EMP B WHERE A.EMP_MGRB.EMP_NUM ORDE
R BY A.EMP_MGR
26
More Complex Queries and SQL Functions (cont.)
27
Updatable Views

• Common operation in production environments is
  use of batch routines to update master table
  attributes using transaction data
• Overnight batch jobs
• Not all views are updatable (primary key has to
  be unique)
• Restrictions
• GROUP BY expressions cannot be used
• Cannot use set operators---UNION, INTERSECTION,
  etc.
• Most restrictions based on use of JOINS or group
  operators in views

28
More Complex Queries and SQL Functions (cont.)
29
Procedural SQL

• SQL shortcomings
• Doesnt support execution of stored procedures
  based on logical condition
• Fails to support looping operations
• Solutions
• Embedded SQL can be called from within procedural
  programming languages
• Shared Code is isolated and used by all
  application programs.
• Procedural SQL (PL/SQL) stored within the
  database, executed by DBMS, and invoked by the
  end user
• Triggers
• Stored procedures
• PL/SQL functions

30
Procedural SQL (cont.)

• Procedural SQL allows the use of procedural code
  and SQL statements that are stored within the
  database.
• The procedural code is executed by the DBMS when
  it is invoked by the end user.
• End users can use procedural SQL (PL/SQL) to
  create
• Triggers
• Stored procedures
• PL/SQL functions

31
Triggers

• Procedural SQL code invoked before or after data
  row is selected, inserted, or updated
• Associated with a database table
• Table may have multiple triggers
• Executed as part of transaction
• Can enforce particular constraints
• Automate critical actions and provide warnings
  for remedial action
• Can update values, insert records, and call
  procedures
• Add processing power

32
Triggers (cont.)

• Oracle example

CREATE OR REPLACE TRIGGER lttrigger_namegtBEFORE/A
FTER DELETE/INSERT/UPDATE OF ltcolumn_name ON
lttable_namegtFOR EACH ROWBEGIN PL/SQL
instructions END
33
Triggers
34
Stored Procedures

• Named collection of procedural and SQL statements
  stored in database
• Invoked by name
• Executed as unit
• Invoked with EXEC

CREATE OR REPLACE PROCEDURE procedure_name
(argument IN/OUT data-type, etc) IS/AS
BEGIN DECLARE variable name and data
type PL/SQL or SQL statementsEND
EXEC store_procedure_name (parameter, parameter,
)
35
Stored Procedures
36
PL/SQL Stored Functions

• Named group of procedural and SQL statements that
  returns a value
• Invoked from within stored procedures or triggers
• Cannot be invoked from within SQL statements

CREATE FUNCTION function_name (argument IN
data-type, etc)RETURN data-typeAS BEGIN PL/SQL
statements RETURN (value) END
37
Artist Database ERD and Tables
Figure 5.55
38
General Rules Governing Relationships Among
Tables
Figure 5.56 MN, Both Sides Mandatory
(D/RESTRICT, U/CASCADE
Figure 5.57 MN, Both Sides Optional(D/CASCADE,
U/CASCADE)
39
General Rules Governing Relationships Among
Tables
Figure 5.58 MN, One Side Optional
Figure 5.59 1M, Both Sides Mandatory
(D/RESTRICT, U/CASCADE)
40
General Rules Governing Relationships Among
Tables
Figure 5.60 1M, Both Sides Optional
Figure 5.61 1M, Many Side Optional, One Side
Mandatory
41
General Rules Governing Relationships Among
Tables
Figure 5.62 1M, One Side Optional, One Side
Mandatory
Figure 5.63 11, Both Sides Mandatory
42
General Rules Governing Relationships Among
Tables
Figure 5.64 11, Both Sides Optional
Figure 5.65 11, One Side Optional, One Side
Mandatory(D/SET NULL, U/CASCADE)
43
General Rules Governing Relationships Among
Tables (Cont.)
Figure 5.66 Weak Entity, Foreign Key Located in
Weak Entity
Figure 5.67 Multivalued Attributes (New Table in
1M Relationship, Foreign Key CAR_VIN in the New
Table
