SCEC

1
Pegasus
SCEC
wave.usc.edu
RLS Server (4.0) - GT 4.0 - iODBC 3.51.2 - MyODBC
3.51.06 - MySQL lrc1000, rli1000

• MCS Server
• (3.1)
• GT 3.2.1
• - OGSI-DAI 4.0
• - MySQLmcs_v3

• VDS Full
• (1.3.8)
• GT 3.2.1
• MySQL scec_vds

MySQL Database (4.1.9)
USC HPCC
RLS Server Synchronization
hpc.usc.edu
Meta Data
RLS Server (4.0) - GT 4.0 - iODBC 3.51.2 -
MyODBC 3.51.06 - MySQL lrc1000, rli1000

• MCS Server
• (3.1)
• GT 3.2.1
• - OGSI-DAI 4.0
• - MySQLmcs_v3

• VDS Worker
• (1.3.8)
• GT 3.2.1

Meta Data
MySQL Database (3.23.58)
TeraGrid Sites (SDSC, NCSA)
---.---.teragrid.org
RLS Server (4.0) - GT 4.0 - iODBC 3.51.2 -
MyODBC 3.51.06 - MySQL lrc1000, rli1000

• VDS Worker
• (1.3.8)
• GT 3.2.1

gridFTP (3.95)
MySQL Database (3.23.52)
