Requirements Analysis and Design Engineering

1
RequirementsAnalysis andDesignEngineering

• Southern Methodist University
• CSE 7313

2
Module 17 Validating the system
3
Agenda

• Traceability
• Validating the system
• Safety critical systems

4
Role of traceability

• Ability to trace is significant factor in quality
  software implementation
• Tracking relationships and relating them is key
  in many high assurance processes
• Impact of change is often missed
• Small changes can create significant safety and
  reliability problems

5
Traceability defined

• IEEE The degree to which a relationship can be
  established between two or more products of the
  development process, especially products having a
  predecessor-successor or master-subordinate
  relationship to one another

6
Traceability relationship

• traced-to
• traced-from

Vision Document (features)
Traceability link
Actor
SW requirement (use case)
7
Traceability relationship

• Additional meanings can be placed on these
  relationships
• tested by
• traced to
• implemented by

8
Implicit vs Explicit

• Explicit traceability development of
  relationships stemming from external
  considerations supplied by the team
• product feature and use case
• Implicit traceability driven by methodology and
  structure of the model
• hierarchical requirements have implicit
  relationship between parent and related child

9
Implicit vs Explicit

• Other implicit examples
• modeling tools in the development process may
  provide other traceability relationships (use
  cases and actors that interact with the use case)

10
Project Relationships
Need
Note This traceability link is optional, as it
can be derived from the link between the product
fea- ture and the use case selection. This link
is often used to relate the prod- uct features to
the use cases before the use case selections are
written
Traces to
Product Feature
Traces to
Traces to
Use case
Traces to
Software Requirements
Use case selection
11
Additional Traceability Options

• Additional less traditional elements of a project
  can be traced if they add value
• issue for unresolved issues
• assumptions and rationales
• action items
• requests for new/revised features
• glossary and acronym terms
• bibliographic references

12
Augmented Traceability relationships
Need
Note This traceability link is optional, as it
can be derived from the link between the product
feature and the use case section. This link is
often used to relate the product features to the
use cases before the use case sections are written
The SW requirements make up the formal SRS,
of which the use case model is an interpretation
Traces to
Product Features
Traces to
SW Rqmts
Traces to
Traces to
Use case
Glossary term
Traces to
Traces to
Traces to
In this case, we are tracing items to the
glossary terms, as well as from then,
as described when defining glossary terms as one
of the supporting traceability types
Actor
Use case selection
13
Verification and traceability

• Must consider whether or not you have correctly
  and completely considered all of the links that
  should be established
• Deeper consideration often leads to some
  revisions
• Should hold formal and informal reviews
• Its not all mechanical processing

14
Validating the system
15
Validation (IEEE)

• the process of evaluating a system or component
  during or at the end of the development process
  to determine whether it satisfies requirements
• Use validation to conform that the implemented
  system conforms to the requirements established.

16
Acceptance Tests

• Bringing the customer into the final validation
  process in order to gain assurance that the
  product works the way the customer really needs
  it to
• May be part of the contract provisions
• IT environments do this by a customer alpha or
  beta evaluation

17
Acceptance Tests

• Based on a specific number of scenarios that the
  user specifies and executes in the usage
  environment
• Freedom to think outside the box
• Construct interesting ways to test the system to
  gain confidence that the system works as needed
• Based on certain key use cases

18
Acceptance Tests

• Apply these use cases interesting combinations
• under certain types of system load and other
  environmental factors
• interoperability with other applications
• OS dependencies
• others likely to be present in the users
  environment

19
Acceptance Tests

• Iterative development environments will have
  generations of acceptance tests run at various
  milestones
• Will most often find at least some undiscovered
  ruins

20
Validation Testing

• Primary activities in validation are testing
  activities
• IEEE 829-1983 IEEE Standard for SW test
  documentation
• The development process must
• include planning for test activities
• time and resources to design the tests
• time and resources to execute the tests

21
Implementation documentation
User needs
Vision document
SRS package
Requirement specification
Hazard Analysis
Use cases
Implementation units (functions, use case
realizations, modules)
Test protocols
Test suites
22
Validation Traceability

• Validation traceability gives confidence that two
  important goals have been addressed
• 1. Do we have enough tests to cover everything
  that needs testing?
• 2. Do we have any extra or gratuitous tests that
  serve no useful purpose?
• Validation focuses on whether the product works
  as it supposed to

23
Requirements based testing

• Quality can be achieved only by testing the
  system against its requirements
• Many complex systems will pass all unit tests but
  fail as a system
• unit tests interact in more complex behaviors
• resulting system has not been adequately tested
  against the requirements

24
Use case and test cases
Test case 2
Test model
Test case 3
Test case 1
(traceability links)
Use case 2
Use case 1
Use cases
25
Testing design constraints

• Consider design constraints requirements
• Include design constraints as part of the
  validation effort
• Many design constraints will yield to simple
  inspections
• use abbreviated test procedure

26
Design Constraint validation approaches
27
Using ROI to determine effort

• Must perform cost/benefit wrt VV activities
• Plan VV activities based on
• 1. What are the social and economic consequences
  of a failure of our system?
• 2. How much VV do we need to do to ensure that
  we do not experience these consequences?

28
VV depth

• Depth defines the level of VV effort to be
  applied to a system element
• greater the depth, the more resources
• Match depth of the review to the importance of
  the element
• inspection
• simple test
• extensive white box testing

29
VV depth activities

• Examination review the code or take some
  measurements.
• Prescribed and minimally invasive look is taken
  at the element under test
• minimal depth of review of an element
• Walkthrough peer group walks the element through
  its paces
• process is a structured inspection performed by a
  wider audience
• search for weaknesses, oversights, etc

30
VV depth activities

• Independent reviews unrelated but knowledgeable
  group examines the element and searches for
  weaknesses
• may provide additional insights that were not in
  the mind set of the project group

31
VV depth activities

• Black box test treats the element as a module
  that cannot be internally inspected
• supply inputs to the box and observe the boxs
  outputs to ensure that the element is working to
  the required standards
• performed via instrumented code or with system
  emulators and other tools to simulate and record
  operation

32
VV depth activities

• White box test allows you to open the box and
  examine the internal workings of the element
• most modules have too many combinatorial pathways
  to test in a reasonable amount of time
• apply reasonable approach that does not take too
  much time
• coverage instead of combination

33
VV coverage

• Coverage defines the extent of coverage of system
  elements to be verified and validated
• The amount of traceability and the corresponding
  level of specificity in the requirements
  determines coverage

34
What to verify and validate

• 1. Verify and validate everything
• smaller projects
• simple and consistent application
• ensures uniformity
• selective VV can be appropriate if you know
  what the risks are
• omitted elements are done so for a good reason
• NOT run out of time or money

35
What to verify and validate

• Possible repercussions
• embarrassment over and element not conforming to
  customer specification
• elements not working properly per the
  specification
• worst case an unsafe product that can cause harm
  to its users

36
What to verify and validate

• 2. Use a hazard analysis to determine VV
  necessities
• Hazard analysis is the detailed examination of a
  device from the user and patient perspectives.
  Its purpose is to detect potential design flaws -
  possibilities of failure that could cause harm -
  and to enable manufacturers to correct them
  before a device is released for use

37
What to verify and validate

• Hazard analysis guides the selection of project
  elements for VV
• Always perform a hazard analysis for a human
  safety critical system

38
Safety Critical Systems
39
Why worry about safety?

• Safety is not discussed in the literature
• Safety is not taught in colleges
• Without training or guidance, embedded systems
  are assuming more safety roles every day!

40
Examples of safety-related computing systems

• Medical equipment (monitoring and therapy)
• Flight computers
• Automobile braking and engine control
• Chemical process control
• Robotic assembly systems
• couple dozen deaths each year in Japan because of
  wayward robots

41
Examples of safety-related computing systems

• Military Weapondry
• Nuclear power plants
• Financial systems

42
Therac-25 Story

• Radiation therapy treatment device
• Released in 1982
• Used S/W to enhance usability and lower cost of
  production
• Compounding of process, design, and
  implementation failures led to massive overdoses
  that killed 3 patients
• Fixing identified problem did not make the device
  safer

43
Other stories

• First Shuttle launch delayed 2 days because
  backup computer would not start correctly when an
  error was discovered
• Patriot missle failed because of clock drift and
  effectiveness downgraded from 95 to 13
• 8080-based cement factory process control system
  mistakenly stacked huge boulders 80 ft above the
  ground which fell and crushed cars and damaged
  the building

44
Other stories

• Stray electromagetic interference blamed for 19
  robot inflicted deaths in Japan
• Low energy radiation blamed for several deaths
  related to reprogramming cardiac pacemakers
• Attempted suicides after incorrect diagnosis of
  diseases

45
Other Stories

• Grady Booch The last announcement I want to hear
  from a pilot when I am flying is Is there a
  programmer on board?

46
Errors are systematic faults

• They are designed in
• The FORTRAN line
• DO I1.10
• rather than
• DO I1,10
• caused problems for the Project Mercury flight
  control software. This is a design error. Entire
  mainframes have been brought down with an
  inadvertent semicolon !

47
What is safety?

• Safety is the freedom from accidents or losses
• Safety is not reliability!
• Reliability is the probability that a system will
  perform its intended function satisfactorily
• A handgun is a very reliable piece of equipment
  but it is not very safe!
• Windows 95 is safe, but not very reliable!

48
What is safety?

• Safety is not security!
• Security is protection or defense against attack,
  interference, or espionage

49
Safety related concepts

• Accident is a loss of some kind, such as injury,
  death, or equipment damage
• telephone system going down on the East coast was
  a big loss -gt safety in one sense
• Risk is a combination of the likelihood of an
  accident and its severity
• risk p(a) s(a)

50
Safety related concepts

• an airplane crashing has a high severity but a
  very low probability gt ultimately low risk
• Hazard is a set of conditions and/or events that
  leads to an accident

51
Other safety related concepts

• A failure is the nonperformance of a system or
  component, a random fault
• a random failure is one that can be estimated
  from a pdf,
• failures are events
• e.g. a component failure

52
Other safety related concepts

• An error is a systematic fault
• a systematic fault is a design error
• Errors are states or conditions
• e.g. a software bug
• A fault is either a failure or an error

53
Other safety related concepts

• Safety must be considered in the context of the
  system, not the component
• It is less expensive and far more cost effective
  to build in safety early than try to tack it on
  later
• The Hazard Analysis ties together hazards,
  faults, and safety measures

54
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

55
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

Safety analysis
Handled at the architectural level and
mechanistic level
56
Safety Analysis

• You must identify the hazards of the system
• You must identify the faults that can lead to
  hazards
• You must define safety control measures to handle
  hazards
• These culminate in the Hazard Analysis
• The Hazard Analysis feeds into the Requirements
  Specification

57
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

58
Hazard Causes

• Release of energy
• electromagnetism (microwave oven)
• radiation (nulcear power plant)
• electricity (electrocution hazard from ECG leads)
• heat (infant warmer)
• kinetic (runaway train)
• Release of toxins

59
Hazard Causes

• Interference with life support or other
  safety-related function
• Misleading safety personnel
• Failure to alarm
• alarming too much - Therac 25. These were
  ignored and people were killed

60
Types of Hazards

• Actions
• inappropriate system actions taken
• F-18 pilot pulling up landing gear
• appropriate system actions not taken
• Timing
• too soon
• too late
• fault latency time

61
Types of Hazards

• Sequence
• skipping actions
• actions out of order
• Amount
• too much
• too little

62
Example Hazards

• Actions
• incorrectly energizing a medical treatment laser
• failure to engage landing gear
• Timing
• cardiac pacemaker paces too fast
• flight control surface adjusted too slowly

63
Example Hazards

• Sequence
• empty the vat, THEN add the reagent
• out of sequence network packets controlling
  industrial robot
• Amount
• electrocution from muscle stimulator
• too little oxygen delivered to ventilator patient

64
Means of Hazard Control

• Obviation the possibility of the hazard can be
  removed by being made physically impossible
• use incompatible fasteners to prevent cross
  connections
• Education the hazard can be handled by
  educating the users so that they wont create
  hazardous conditions through equipment misuse
• dont look down the barrel when cleaning your
  rifle

65
Means of Hazard Control

• Alarming announcing the hazard to the user when
  it appears so that they can take appropriate
  action
• alarming when the heart stops beating
• Interlocks the hazard can be removed by using
  secondary devices and/or logic to intercede when
  a hazard presents itself
• car wont start unless it is in Park

66
Means of Hazard Control

• Internal checking the hazard can be handled by
  ensuring that a system can detect that it is
  malfunctioning prior to an incident
• CRC checks data for corruption whenever it is
  accessed
• Safety equipment
• goggles, gloves

67
Means of Hazard Control

• Restricting access to potential hazards so that
  only knowledgeable users have such access
• using passwords to prevent inadvertently starting
  service mode
• Labelling
• High Voltage -- DO NOT TOUCH

68
Hazard Analysis
What do you do about it?
How long is the exposure to hazard?
How can this happen?
How long to discover?
How long can it be tolerated
How bad if it occurs?
Hazardous condition
How frequently?
Hazard
Level of
Toleran
Fault
Likeli
Detection
Control
Exposure
risk
ce time
hood
time
Measure
time
T1
Hypo-
Severe
5 min
Ventilator
rare
30 sec
Independent
1 min
ventilation
fans
pressure
alarm,
action by
doctor
Esphageal
often
30 sec
C)2 sensor
1 min
Intubation
alarm
User
often
0
Noncompati
0
misattaches
ble
breathing
mechanical
circuit
fasteners
used
Overpressur
Severe
250 ms
Release
rare
50 ms
Secondary
55 ms
e
valve
valve opens
failure
69
When is a system safe enough?

• (Minimal) No hazards in the absence of faults
• (Minimal) No hazards in the presence of any
  single point failure
• a common mode failure is a single point failure
  that affects multiple channels
• a latent fault is an undetected fault which
  allows another fault to cause a hazard
• Your mileage may vary depending on the risk
  introduced by your system

70
TUV Single Fault Assessment
71
Single Fault Assessment

• T0 is fault tolerance time for the first fault
• T1 is the time after the first fault that the
  second fault is likely (via MTBF)
• For testing used for safety, test time TT must be
  done periodically
• TT lt T1 lt T0
• This is not always possible
• e.g. RAM tests

72
Safety Measures

• You cannot depend on a safety measure that you
  cannot test!
• CAN bus with 2 nodes provides a CRC on mesages
  checked at the chip level, but the chips provide
  no way of testing to see if it is working.
• Therefore, it cannot be relied on as a safety
  measure

73
Fail-Safe States

• Off
• Emergency stop -- immediately cut power
• Production stop -- stop after the current task
• Protection stop -- shut down without removing
  power
• Partial Shutdown
• Degraded level of functionality

74
Fail-Safe States

• Hold
• No functionality, but with safety actions taken
• Manuel or External control
• Restart (reboot)

75
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

76
Risk Assessment

• For each hazard
• determine the potential severity
• determine the likelihood of the hazard
• determine how long the user is exposed to the
  hazard
• determine whether the risk can be removed

77
TUV Risk Level Determination Chart
W3
W2
W1
S1
1
-
-
G1
2
1
-
E1
G2
3
2
1
S2
G1
4
3
2
E2
G2
5
4
3
E1
6
5
4
S3
E2
7
6
5
S4
8
7
6
Risk parameters S Extent of damage S1 slight
injury S2 severe irreversible injury, to one of
more persons or the death of a single person S3
death of several persons S4 Catestrophic
consequences, several deaths E Exposure
time E1 seldom to relatively infrequent E2
frequent to continuous G Hazard Prevention G1
possible under certain conditions G2 hardly
possible W Occurrence probability of hazardous
event W1 very low W2 low W3 relatively high
78
Sample Risk Assessments
Device
Hazard
Extent of
Exposure
Hazard
Probability
TUV Risk
damage
time
Prevention
level
Microwave
Irradiation
S2
E2
G2
W3
5
oven
Pacemaker
Pace too
S2
E2
G2
W3
5
slowly
Pace too
S2
E2
G2
W3
5
fast
Power
Explosion
S3
E1
--
W3
6
station
Airliner
Crash
S4
E2
G2
W2
8
79
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

80
Safety Measures

• Safety measures do one of the following
• remove the hazard
• reduce the risk
• identify the hazard to supervisory control
• The purpose of the safety measure is to ensure
  the system remains in a safe state

81
Safety Measures

• Adequacy of measures
• safety measures mut be able to reliably detect
  the fault
• safety measures must be able to take appropriate
  actions

Component
Fault/Error
Software class
Examples of acceptable measures
1
2
Interrupt handling
no interrupt or too
rq
functional test or time-slot
and execution
frequent
monitoring
no interrupt or too
rq
comparison of redundant
frequent and
functional channles by either
interrupt related
- reciprocal comparison
to different
- independent hardware
sources
comparator
- independent time-slot and logical
monitoring
82
Risk Reduction

• Identify the fault
• Take corrective action, either
• use redundancy to correct and move on
• feedforward error correction (Hamming codes)
• redo the computational step
• feedback error detection (take corrective action
  first)
• go to a fail-safe state

83
Fault Identification at Run-Time

• Faults must be identified in lt TO
• Fault identification requires redundancy
• Redundancy can be in terms of
• channel
• device
• data
• control

Architectural

Detailed design
84
Fault Identification at Run-Time

• Redundancy may be either
• homogenous (random faults only)
• does not detect errors
• peform functions the same way on the same thing
  multiple times
• heterogenous (systematic and random faults)
• includes errors -gt present in all channels
• perform processing differently and hopefully you
  didnt make the same mistake!

85
Fault Tree Analysis Symbology
A condition that must be present to produce the
output of a gate
An event that results from a combination of
events through a logic gate
Transfer
A basic fault event that requires no further
development
A fault event because the event is
inconsequential or the necessary information is
not available
AND gate (also OR gate)
An event that is expected to occur normally
NOT gate
86
Subset of Pacemaker Fault Analysis
Pacing too slowly
Condition or event to avoid
Secondary conditions or events
OR
Shutdown fault
Time-base fault
Invalid pacing rate
OR
AND
OR
AND
Crystal failure
Watchdog failure
Bad command rate
Data corrupted in vivo
Software failure
CPU H/W failure
Rate command corrupted
CRC hardware failure
Primary or fundamental faults
87
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

88
Safe Requirements

• Requirements specification follows initial hazard
  analysis
• Specific requirements should track back to hazard
  analysis
• must be shown to FDA, etc
• Architectural framework should be selected with
  safety needs in mind
• has the hooks in place

89
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

90
Use Good Design Practices

• Good design practices allow you to
• manage complexity
• view the system at various levels of abstraction
• zoom in on a particular area of interest
• identify hot spots of special concern
• have consistent quality
• easily test
• build and use high quality components
• Regulatory agencies look at this!!

91
Use Good Design Practices

• Manage your requirements
• trace requirements to design elements
• trace design elements back to requirements

remote communications
adjust trajectory
class a
class b
remote communication
requirements specification
class c
class d
class e
use cases
design model
92
Use Good Design Practices

• Use iterative development
• integrating many times finds more defects
• iterative prototypes can result in more reliable
  and safe systems

93
Use Good Design Practices

• Use component-based design architectures
• third party components may be very well tested in
  they are in wide use
• require bug lists from component vendors
• this bit Microsoft once

94
Use Good Design Practices

• Use Visual Modeling
• UML
• Ward-Mellor
• Use executable models
• animate models
• execute and debug at modeling level of abstraction

95
Use Good Design Practices

• Use frameworks
• a framework is a partially completed application
  which is specialized by the user
• Microsoft foundation classes
• Object Execution Framework
• frameworks reduce the work of developing new
  applications
• frameworks rely on well-tested patterns

96
Use Good Design Practices
User Model
Framework

80-90 of application code is housekeeping code

System
97
Use Good Design Practices

• Use Configuration Management
• only use unit-testing components in builds

parameters
data aquisition
SYSTEM
CM Database
drivers
OS
98
Use Good Design Practices

• Design for test
• product testing
• built-in-testing to ensure
• invariants are truly invariant
• functional invariants
• quality of service invariants (e.g. performance)
• faults are detected

99
Good Design Practices

• Isolate Safety Functions
• Safety-relevant systems are 200-300 more effort
  to produce
• Isolation of safety systems allows more expedient
  development
• Care must be taken that the safety system is
  truly isolated so that a defect in the non-safety
  system cannot affect the safety system
• different processor
• different heavy-weight tasks (depends on the OS)

100
Safety Architecture Patterns

• Protected Single-Channel Pattern
• Dual-Channel Pattern
• Homogenous Dual Channel Pattern
• Heterogenous Peer-Channel Pattern
• Sanity Check Pattern
• Actuator-Monitor Pattern
• Voting Multichannel Pattern

101
Protected Single Channel Pattern

• Within the single channel, mechanisms exist to
  identify and handle faults
• All faults must be detected within the fault
  tolerance time
• May be imposssible
• to test for all faults within the fault tolerance
  time
• to remove common mode failures from the single
  channel
• Generally, less recurring system cost
• no additional hardware required

102
Protected Single Channel Pattern
If Im not getting life ticks, Ill shut down!
Single Channel Train Braking System
103
Dual Channel Architecture Patterns

• Separation of safety-relevant from nonsafty
  relevant where possible
• Separation of monitoring from control
• Generally easier to meet safety requirements
• timing
• common mode failures
• Generally higher recurring system cost
• additional hardware required

104
Homogenous Dual-Channel Pattern

• Identical channels used
• Channels may operate simultaneously (Multichannel
  Vote Pattern)
• Channels may operate in series (Backup Pattern)
• Good at identifying random faults but not
  systematic faults
• Low RD cost, higher recurring cost

105
Homogenous Dual-Channel Pattern
106
Heterogenous Peer-Channel Pattern

• Equal weight, differently implemented channels
• may use algorithmic inversion to recreate initial
  data
• may use different algorithm
• may use different teams (not fool proof because
  of hot spots that can cause failures)
• Good at identifying both random and systematic
  faults

107
Heterogenous Peer-Channel Pattern

• Generally safest, but higher RD and recurring
  cost

108
Heterogenous Peer-Channel Pattern
109
Sanity Check Pattern

• A primary actuator channel does real computations
• A light-weight secondary channel checks the
  reasonableness of the primary channel
• Good for detection of both random and systematic
  faults
• May not detect faults which result in small
  variance
• Relatively inexpensive to implement

110
Monitor-Actuator Pattern

• Separates actuation from the monitoring of that
  actuation
• If the actuator channel fails, the monitor
  channel detects it
• If the monitor channel fails, the actuator
  channel continues correctly
• Requires fault isolation to be single-fault
  tolerant
• actuator channel cannot use the monitor itself

111
Monitor-Actuator Pattern
112
Dual-Channel Design Architecture
113
Safety Executive Pattern

• Large scale architectural pattern
• Controller subsystem (safety executive)
• One or more watchdog subsystems
• check on system health
• ensure proper actuation is occurring
• One or more actuation channels
• Recovery subsystem (Fail safe processing channel)

114
Safety Executive Pattern

• Appropriate when
• A set of fail-safe system states needs to be
  entered when failures identified
• Determination of failures is complex
• Several safety-related system actions are
  controlled simultaneously
• Safety-related actions are not independent
• Determining proper safety action in the event of
  a failure can be complex

115
Safety Executive Pattern
116
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

117
Detailed Design for Safety

• Make it right before you make it fast
• simple, clear algorithms and code
• optimize only the 10-20 of code which affects
  performance
• use safe language subsets
• ensure you havent introduced any common mode
  failures

118
Detailed Design for Safety

• Thoroughly test
• unit test and peer review
• integration test
• validation test

119
Detailed Design for Safety

• Verify that it remains right throughout program
  execution
• exceptions
• invariant assertions
• range checking
• index and boundary checking
• When its not right during execution, then make it
  right with corrective or protective measures

120
Detailed Design for Safety

• Use safe language subsets
• strong compile-time checking
• if you use C, use lint
• strong run-time checking
• exception handling
• avoid void
• avoid error prone statements and syntax
• you can make C safe but its not safe out of the
  box

121
Detailed Design for Safety

• Language choice
• Compile time checking (C versus Ada)
• Run-time checking (C versus Ada)
• Exceptions versus error codes
• Language selection
• C treats you like a consenting adult. Pascal
  treats you like a naughty child. Ada treats you
  like a criminal

122
Pascal example

• Program WontCompile
• type
• MySubRange 0 .. 20
• Day (Monday, Tuesday, Wednesday, Thursday,
  Friday, Saturday, Sunday)
• var
• MyVar MySubRange
• MyDate Day
• begin
• MyVar 9 will not compile -- range error!
• MyDate 0 will not compile -- wrong type!
• end.

123
Ada example
Procedure MyProc is Var MyArray array (1..10)
of integer j integer b byte begin for j
in 0 .. 10 loop MyArray(j) j6 -- raises
exception on first time
--through end loop b MyArray(10) -- will
fail run-time range check end MyProc
124
Exceptions

• Some languages (Pascal, Modula-2) have a
  draconian error handling policy
• exception raised and program terminated
• not good for embedded systems
• Ada and C allow run time recovery through
  user-defined exceptions and exception handlers

125
Exceptions

• A lot of extra code to check the statement
• aj b

126
Detailed Design for Safety

• Do not allow ignoring of error indications
• checking of return values is a manuel process
• user of the function must remember each and every
  time
• easy to circumvent this error handling system
• Separate normal code from error handling code

127
Detailed Design for Safety

• Handle errors at the lowest level with sufficient
  contect to correct the problem

128
Error handling code

• a getfone(b, c)
• if (a)
• switch (a)
• case 1 ..
• case 2 ..
• d getftwo(b,c)
• if (d)
• switch (a)
• case 1 ..
• case 2 ..

in this code the normal execution path is a
getfone(b,c) d getftwo(b,c)
129
Built-in exception types

• procedure enqueue (q in out queue v in FLOAT)
  is
• begin
• if full (q) then
• raise overflow
• end if
• q.body(q.head q.length) mod qSize v
• q.length q.length 1
• end enqueue

130
Caller of the sequence handles exception

• procedure testQ(q in out queue) is
• begin
• for j in 1 .. 10 loop
• enqueue(q, random(1000))
• end loop
• exception
• when overflow gt
• puts(Test failed due to queue overflow)
• end testQ

131
C exception handling

• Extends capabilities beyond that of Ada
• Exceptions extended by type rather than value
• possible to create hierarchies of exception
  classes and catch by thrown subclass type
• class can contain different types of information
  about the kind of device that failed
• this facilitates error recovery, debugging, and
  user error reporting

132
Making C safe

• Overloading the operator with index range
  checking improves the safety of arrays
• Make classes of scalars and overload the
  assignment operator allows additional range and
  value checking

133
Detailed Design for Safety

• Data Validity Checks
• CRC (16 bit or 32 bit)
• identifies all single or dual bit errors
• detects high percentage of multiple bit errors
• table or compute-driven
• chips are available
• checksum
• redundant storage
• ones complement

134
Detailed Design for Safety

• Redundancy should be set every write access
• Data should be checked every read access

135
ANSI C Exception Class Hierarchy
exception
logic error
runtime error
domain error
out of range
range error
overflow error
invalid argument
length error
136
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

137
Safety Process (Development)

• Do Hazard Analysis early and often
• Track safety measures from hazard analysis to
• requirments specification
• design
• code
• validation tests
• Test safety measures with fault seeding

138
Safety Process (Deployment)

• Install safely
• ensure proper means are used to set up system
• safety measures are installed and checked
• Deploy safely
• ensure safety measures are periodically checked
  and serviced
• Do not turn off safety measures
• Decommision safely
• removal of hazardous materials

139
Concept
IEC Overall Safety Lifecycle
Overall scope definition
Hazard and risk analysis
SRS Safety Related System E/E/PES
Electrical/Electronic/Programmable electronic
system
Overall safety requirements
Safety requirements allocation
SRS E/E/PES realization
Overall planning
SRS other technology realization
External risk reduct. facilities
Ops mainten. planning
Valida tion planning
Install. planning
Overall installation and commissioning
Overall safety validation
Overall modification and retrofit
Overall operation and maintenance
Decommissioning
140
Eight steps to safety

• Identify the hazards
• Determine the risks
• Define the safety measures
• Create safe requirements
• Create safe designs
• Implement safety
• Assure the safety process
• Test, test, test

141
Safety in Testing in RD

• Use fault-seeding
• Unit (class) testing
• white box
• procedural invariant violation assertions
• peer reviews
• Integration testing
• grey box
• Validation testing
• black box
• externally caused faults
• (Grey box) internally seeded faults

142
Safety Testing During Operation

• Power on Self-Test (POST)
• Check for latent faults
• All safety measures must be tested at power on
  and periodically
• RAM (stuck-at, shorts, cell failures)
• ROM
• Flash
• Disks
• CPU
• Interfaces
• Buses

143
Safety Testing During Operation

• Built-In Tests
• Repeats some of POST
• Data integrity checks
• Index and pointer validity checking
• Subrange value invariant assertions
• Proper functioning
• Watchdogs
• Reasonableness checks
• Lifeticks

144
A simplified Example A linear Accelerator
145
Unsafe Linear Accelerator
Beam Intensity Beam Duration
CPU
Radiation Dose
1. Set Dose 2. Start Beam 3. End Beam
Sensor
146
Fault Tree Analysis
Over radiation
AND
OR
Radiation command invalid
CPU Halted
OR
OR
Shutoff timer failure
Beam engaged
CPU failure
Software defect
Software defect
EMI
EMI
147
Hazards of the Linear Accelerator
Hazard
Level of
Tolerance
Fault
Likelihood
Detection
Control
Exposur
risk
Time T1
time
measure
e time
Over
Severe
100 ms
CPU
rare
50 ms
Safety
50m ms
radiati
locks
CPU
on
up
checks
lifetick at
2 5 ms
Corru
often
10 ms
32 bit
15 ms
pt data
CRCs on
setting
data
s
checked
every
access
Under
Moderat
2 weeks
corrup
often
10 ms
32 bit
15 ms
radiati
e
t data
CRCs on
on
setting
data
checked
every
access
Inadve
sefere
100 ms
beam
often
n/a
curtain
0 ms
rtant
left
mechanica
radiati
engage
lly shuts
on on
d
at power
power
during
down
on
power
down
148
Safe Linear Accelerator
Self test results shared prior to operation
Periodic watchdog service
Safety CPU
CPU
Beam Intensity Beam Duration
Radiation Dose
1. Set Dose 2. Start Beam 3. End Beam
Sensor
Deenergize
Mechanical shutoff when curtain low
149
Summary

• Safety is a system issue
• It is cheaper and more effective to include
  safety early on then to add it later
• Safety architectures provide programming in the
  large safety
• Safe coding rules and detailed design provide
  programming in-the-small safety

150
End of module
