CS 161Ch 7 Memory Hierarchy LECTURE 22

• Instructor L.N. Bhuyan
• www.cs.ucr.edu/bhuyan

2
Improving Caches

• In general, want to minimize Average Access
  Time
• Hit Time x (1 - Miss Rate) Miss
  Penalty x Miss Rate
• (recall Hit Time ltlt Miss Penalty)
• So far, have looked at
• Larger Block Size
• Larger Cache
• Higher Associativity
• What else to reduce miss penalty? Add a second
  level (L2) cache.

ReduceMiss Rate
3
Current Memory Hierarchy
Processor
Control
Secon- dary Mem- ory
Main Mem- ory
L2 Cache
Data-path
L1 cache
regs
Speed(ns) 0.5ns 2ns 6ns 100ns 10,000,000ns Size
(MB) 0.0005 0.05 1-4 100-1000 100,000 Cost
(/MB) -- 100 30 1 0.05 Technology Regs SR
AM SRAM DRAM Disk
4
How do we calculate the miss penalty?

• Access time L1 hit time L1 hit rate L1 miss
  penalty L1 miss rate
• We simply calculate the L1 miss penalty as being
  the access time for the L2 cache
• Access time L1 hit time L1 hit rate (L2 hit
  time L2 hit rate L2 miss penalty L2 miss
  rate) L1 miss rate

5
Do the numbers for L2 Cache

• Assumptions
• L1 hit time 1 cycle, L1 hit rate 90
• L2 hit time (also L1 miss penalty) 4 cycles,
  L2 miss penalty 100 cycles, L2 hit rate 90
• Access time L1 hit time L1 hit rate (L2 hit
  time L2 hit rate L2 miss penalty (1 - L2
  hit rate) ) L1 miss rate
• 10.9 (40.9 1000.1) (1-0.9)
• 0.9 (13.6) 0.1 2.26 clock cycles

6
What would it be without the L2 cache?

• Assume that the L1 miss penalty would be 100
  clock cycles
• 1 0.9 (100) 0.1
• 10.9 clock cycles vs. 2.26 with L2
• So gain a benefit from having the second, larger
  cache before main memory
• Todays L1 cache sizes 16 KB-64 KB L2 cache
  may be 512 KB to 4096 KB

7
An Example (pp. 576)

• Q Suppose we have a processor with a base CPI of
  1.0 assuming all references hit in the primary
  cache and a clock rate of 500 MHz. The main
  memory access time is 200 ns. Suppose the miss
  rate per instn is 5. What is the revised CPI?
  How much faster will the machine run if we put a
  secondary cache (with 20-ns access time) that
  reduces the miss rate to memory to 2? Assume
  same access time for hit or miss.
• A Miss penalty to main memory 200 ns 100
  cycles. Total CPI Base CPI Memory-stall
  cycles per instn. Hence, revised CPI 1.0 5 x
  100 6.0
• When an L2 with 20-ns (10 cycles) access time is
  put, the miss rate to memory is reduced to 2.
  So, out of 5 L1 miss, L2 hit is 3 and miss is
  2.
• The CPI is reduced to 1.0 5 x (10 40 x 100)
  3.5. Thus, the m/c with secondary cache is
  faster by 6.0/3.5 1.7

8
The Three Cs in Memory Hierarchy

• The cache miss consists of three classes.
• - Compulsory misses Caused due to
  first access to the block from memory small but
  fixed independent of cache size.
• - Capacity misses Because the cache
  cannot contain all the blocks for its limited
  size reduces by increasing cache size
• - Conflict misses Because multiple
  blocks compete for the same block or set in the
  cache. Also called collision misses. reduces by
  increasing associativity
• See Fig. 7.30 for performance

9
An Example (pp. 576)

• Q Suppose we have a processor with a base CPI of
  1.0 assuming all references hit in the primary
  cache and a clock rate of 500 MHz. The main
  memory access time is 200 ns. Suppose the miss
  rate per instn is 5. What is the revised CPI?
  How much faster will the machine run if we put a
  secondary cache (with 20-ns access time) that
  reduces the miss rate to memory to 2? Assume
  same access time for hit or miss.
• A Miss penalty to main memory 200 ns 100
  cycles. Total CPI Base CPI Memory-stall
  cycles per instn. Hence, revised CPI 1.0 5 x
  100 6.0
• When an L2 with 20-ns (10 cycles) access time is
  put, the miss rate to memory is reduced to 2.
  So, out of 5 L1 miss, L2 hit is 3 and miss is
  2.
• The CPI is reduced to 1.0 5 x (10 40 x 100)
  3.5. Thus, the m/c with secondary cache is
  faster by 6.0/3.5 1.7

10
Appendix B Memory Technology - SRAM

• SRAM Static Random Access Memory used as cache.

• Internal design of a 4x2 SRAM using D-FFs shown
  in Fig. B.23. How many transistors each D-FF
  have? - A row is selected as per row decoder,
  which corresponds to the msbs of the address.
  -The outputs for each bit can be
  connected through a tri-state buffer, connected
  to the column decoder. The circuit can be
  extended to include many chips and chip select
  signals (fig. B.21)
• A different organization is shown in Fig. B.24.
• Synchronous SRAM or DRAM Ability to transfer a
  burst of data given a starting address and a
  burst length suitable for transferring a block
  of data from main memory to cache.

11
Figs. B.23 and B.24 (Appendix B)

• Read SRAM from pp. B-26 through B-30
• Figs B.21, B.22, B.23 and B.24

12
Dynamic Random Access Memory - DRAM

• DRAM organization is similar to SRAM except that
  each bit of DRAM is constructed using a pass
  transistor and a capacitor, shown in Fig. B.25
• Less number of transistors/bit gives high
  density, but slow discharge through capacitor.
• Capacitor needs to be recharged or refreshed
  giving rise to high cycle time.
• Uses a two-level decoder as shown in Fig. B.26.
  Note that 2048 bits are accessed per row, but
  only one bit is used.
• Page-mode DRAM Why not use these bits without
  row access by changing column address only?
• Nibble-mode RAM provides 4 bits (nibble) for
  every row access

13
Figs. B.25 and B.26 (Appendix B)

• Read DRAM pp. B-31 to B-33
• Understand Figs. B.25 and B.26

14
Main Memory Organizations Fig. 7.13
C
P
U
C
P
U
C
P
U
M
u
l
t
i
p
l
e
x
o
r
C
a
c
h
e
C
a
c
h
e
C
a
c
h
e
B
u
s
B
u
s
B
u
s
M
e
m
o
r
y
M
e
m
o
r
y
M
e
m
o
r
y
M
e
m
o
r
y
M
e
m
o
r
y
b
a
n
k

1
b
a
n
k

2
b
a
n
k

3
b
a
n
k

0
interleaved memory organization
wide memory organization
M
e
m
o
r
y
one-word widememory organization
DRAM access time gtgt bus transfer time
15
Memory Access Time Example

• Assume that it takes 1 cycle to send the address,
  15 cycles for each DRAM access and 1 cycle to
  send a word of data.
• Assuming a cache block of 4 words and one-word
  wide DRAM (fig. 7.13a), miss penalty 1 4x15
  4x1 65 cycles
• With main memory and bus width of 2 words (fig.
  7.13b), miss penalty 1 2x15 2x1 33
  cycles. For 4-word wide memory, miss penalty is
  17 cycles. Expensive due to wide bus and control
  circuits.
• With interleaved memory of 4 memory banks and
  same bus width (fig. 7.13c), the miss penalty 1
  1x15 4x1 20 cycles. The memory controller
  must supply consecutive addresses to different
  memory banks. Interleaving is universally adapted
  in high-performance computers.
