Software Testing Cmpe516 Fault Tolerant Computing

1
Software TestingCmpe516 Fault Tolerant Computing

• Serkan Utku Öztürk
• 2003700443 MS
• utku_at_utkuozturk.com

2
Agenda

• Examples
• Test Assessment
• Axiomatic Approach
• Types of Testing

3

• The purpose of testing is to uncover errors, not
  to certify correctness.

4
Error Elimination or Reduction?

• In most practical situations, total error
  elimination is a myth.
• Error reduction based on the economics of
  software development is a practical approach.

5
Errors Examples

• TeX (Knuth) 850 errors over a 10 year period.
• Windows 95 large error database maintained by
  Microsoft (proprietary)
• Several other error studies published.
• Error studies have also been published in other
  diverse fields such as in music, speech, sports,
  and civil engineering.

6
Languages and Errors

• The programming language used has no known
  correlation with the complexity of the errors one
  can make.
• It also has no known correlation to the number of
  errors in a program.

7
Human Capability and Errors

• Errors are made by all kinds of people regardless
  of their individual talents and background.
• Well known programmers make errors that are also
  made by freshmen in programming courses.
• Example SimCity

8
Errors Consequences

• An error might lead to a failure.
• The failure might cause a minor inconvenience or
  a catastrophe.
• The complexity of an error has no known
  correlation with the severity of a failure. The
  misplaced break is an example of a simple error
  that caused the ATT phone-jam in 1990.

9
Errors Unavoidable!

• Errors are bound to creep into software.
• This belief enhances the importance of testing.
• Errors that creep in during various phases of
  development can be removed using a well defined
  and controlled process of software testing.

10
System/Software Testing

• Error detection and removal
• determine level of reliability
• well-planned procedure - Test Cases
• done by independent quality assurance
  group (except for unit testing)

11
What is Test Assessment?

• Given a test set T, a collection of test inputs,
  we ask
• How good is T?
• Measurement of the goodness of T is test
  assessment.
• Test assessment is carried out based on one or
  more test adequacy criteria.

12
Test Assessment-continued

• Test assessment provides the following
  information
• A metric, also known as the adequacy score or
  coverage, usually between 0 and 1.
• A list of all the weaknesses in T, which when
  removed, will raise the score to 1.
• The weaknesses depend on the criteria used for
  assessment.

13
Test Assessment-continued

• Once coverage has been computed, and the
  weaknesses identified, one can improve T.
• Improvement of T is done by examining one or more
  weaknesses and constructing new test requirements
  designed to overcome the weaknesses.
• The new test requirements lead to new test
  specifications and to further testing of the
  program.

14
Test Assessment-continued

• This is continued until all weaknesses are
  overcome, i.e. the adequacy criterion is
  satisfied (coverage1).
• In some instances it may not be possible to
  satisfy the adequacy criteria for one or more of
  the following reasons
• Lack of sufficient manpower
• Weaknesses that cannot be removed because they
  are infeasible.

15
Test Assessment-continued

• The cost of removing the weaknesses is not
  justified.
• While improving T by removing its weaknesses, one
  usually tests the program more thoroughly than it
  has been tested so far.
• This additional testing is likely to result in
  the discovery of some or all of the remaining
  errors.

16
Test Assessment-Summary
0
Develop T
Select an adequacy criterion C.
1
2
Measure adequacy of T w.r.t. C.
Yes
3
Is T adequate?
No
Yes
4
Improve T
More testing is warranted ?
5
No
6
17
Principle Underlying Test Assessment

• A uniform principle underlies test assessment
  throughout the testing process.
• This principle is known as the coverage
  principle.
• It has come about as a result of extensive
  empirical studies.

18
Coverage Domains

• To formulate and understand the coverage
  principle, we need to understand
• coverage domains
• coverage elements
• A coverage domain is a finite domain that we want
  to cover. Coverage elements are the individual
  elements of this domain.

19
The Coverage Principle

• Measuring test adequacy and improving a test set
  against a sequence of well defined, increasingly
  strong, coverage domains leads to improved
  reliability of the system under test.

20
When Should Testing Stop?

• Terminate when an adequacy criterion is met
• a measure of how well the testing process has
  been performed
• relates a test set to the program, the
  specification, or both
• could relate a test set to the programs
  operational profile

21
Axiom (definition)

• an established principle a self-evident truth

22
Axiom 1

• Axiom 1 (Applicability) For every program, there
  exists a finite adequate test set.
• If the adequate test set is infinite (or even
  very large) it would be impossible to satisfy the
  criterion.

23
Axiom 2

• Axiom 2 (Non-exhaustive Applicability) There is
  a program P and a test set T such that P is
  adequately tested by T, and T is not an
  exhaustive test set.
• Exhaustive testing (testing every point in the
  domain) can be assumed to be adequate. An
  important part of testing is identifying a subset
  of the test domain which represents the whole
  domain

24
Axioms 3

• Axiom 3 (Monotonicity) If T is adequate for P,
  and T is a subset of T, then T is adequate for
  P.
• The addition of more test cases to an already
  adequate set does not make it inadequate.
  Therefore, the subset of the domain does not have
  to be the smallest possible subset. In some
  instances a larger subset might be easier to
  identify.

25
Axiom 4

• Axiom 4 (Inadequate Empty Set) The empty set is
  not adequate for any program.
• A program cannot be assumed to be adequate if it
  has not been tested at all. Dynamic testing
  assumes that the program has at least one input.

26
Axioms 5

• Axiom 5 (Anti-extensionality) There are programs
  P and Q such that P is equivalent to Q, T is
  adequate for P, but T is not adequate for Q.
• These axioms support program-based testing, not
  functionality or specification-based testing.
  Therefore, two programs which perform the same
  function but are implemented differently would
  require different test sets.

27
Axiom 6

• Axiom 6 (General Multiple Change) There are
  programs P and Q which are the same shape, and a
  test set T such that T is adequate for P, but T
  is not adequate for Q.
• Programs with the same shape (structure) may
  require different data sets to traverse their
  structure

28
Axiom 7

• Axiom 7 (Anti-decomposition) There exists a
  program P and a component Q such that T is
  adequate for P, T is the set of vectors of
  values that variables can assume on entrance to Q
  for some t of T, and T is not adequate for Q.
• The program P taken as a whole may not be able
  to stimulate all possible actions of component Q.
  Q must be tested in its own right.
• Example component Q could be a sorting
  routine. What if program P always provides data
  already sorted?

29
Axiom 8

• Axiom 8 (Anti-composition) There exist programs
  P and Q such that T is adequate for P and P(T) is
  adequate for Q, but P is not adequate for PQ.
• Testing must take into account the added
  complexity and interaction which occurs when two
  programs are composed. Hence the traditional
  need for integration testing.

30
Summary of Axiomatizing
31
Test Strategy

• UNIT TESTING (Module testing)
• debuggers, tracers
• programmers
• INTEGRATION TESTING
• communication between modules
• start with one module, then add incrementally
• SYSTEM TESTING
• manual procedures, restart and recovery, user
  interface
• real data is used
• users involved
• ACCEPTANCE TESTING
• user-prepared test data
• Verification Testing, Validation testing, Audit
  Testing

32
Types of Testing

• White Box Testing
• knowing internal working ,and exercising
  different parts
• test various paths through software if
  exhaustive testing is impossible, test high-risk
  paths
• Black Box Testing
• knowing functions to be performed and testing
  whether these are performed properly
• correct outputs from inputs. DBs accessed/updated
  properly
• test cases designed from user requirements
• appropriate at Integration, Systems and
  Acceptance testing levels

33
Types of Testing(cont.)

• Compatibility Testing
• Testing to ensure compatibility of an
  application or Web site with different browsers,
  OSs, and hardware platforms
• Conformance Testing
• Verifying implementation conformance to industry
  standards

34
Types of Testing(cont.)

• Functional Testing
• Validating that an application or Web site
  conforms to its specifications and correctly
  performs all its required functions.
• Load Testing
• Load testing is a generic term covering
  Performance Testing and Stress Testing.

35
Types of Testing(cont.)

• Performance Testing
• Performance testing can be applied to understand
  your application or WWW site's scalability, or to
  benchmark the performance in an environment of
  third party products such as servers and
  middleware for potential purchase.

36
Types of Testing(cont.)

• Regression Testing
• Similar in scope to a functional test, a
  regression test allows a consistent, repeatable
  validation of each new release of a product or
  Web site.
• Smoke Testing
• A quick-and-dirty test that ensures the major
  functions of a piece of software work without
  bothering with finer details.

37
Types of Testing(cont.)

• Stress Testing
• Testing conducted to evaluate a system or
  component at or beyond the limits of its
  specified requirements to determine the load
  under which it fails and how.
• Unit Testing
• Functional and reliability testing in an
  Engineering environment.

38
Conclusion

• Test Early / Test Often
• Developers perform unit testing
• Testers perform integration system testing
• Everyone owns a stake in the product development
  lifecycle
• Testing requires a scientific approach. It is
  crucial to have robust and reliable softwares.

39

• Any Question ?
