The Power of Innovation
3
Spellman is the worlds leading independent
manufacturer of high voltage power supplies for
applications in
Biotechnology TOF Mass Spectrometry GC Mass
Spectrometry LC Mass Spectrometry Pharmaceutical
Analysis DNA Sequencing Chemical
Analysis Electron Microscopy Electrophoresis UV
Spectroscopy
Industrial/Commercial Ion Beam Implantation Vacuum
Deposition Electrostatic Coatings Capacitor
Charging Focused Ion Beam Color
Printing Microwave Heating Cable
Feed/Testing Telecommunications
Medical CT Imaging Image Intensifiers Bone
Densitometry Mammography PET Imaging Gamma
Cameras Lithotripsy Radiotherapy
X-Ray Analysis Baggage Screening Food
Inspection Explosive Detection Product
Inspection X-ray Spectrometers X-ray
Diffraction X-Ray Fluorescence NDT
4
Products for Core Application Areas
CT X-Ray generators for gantry mounted
rotating medical imaging
PFE Ultra high reliability cable systems for
undersea fiber optic communication
X-RAY Monoblock systems for security
screening
MASS SPEC High precession high voltage power
supplies Biotechnology
SEMI 160kV - 360kV high voltage power supplies
for semiconductor fabrication
5
Products from Spellmans United Kingdom and
Valhalla Divisions
Spellman Limited (UK)
MX10
MCP
EGM
(Valhalla)
NIM
602C
225
6
Spellman Quick History and Facts
? Spellman High Voltage was founded in 1947 by
William Spellman ? Purchased in 1968 by S.
Merrill Skeist ? 2007 marked our 60th year in
business ? Privately owned company, Loren Skeist
- President ? 8 facilities with operations in
USA, Mexico, Europe, Japan and China ? Over 1100
employees worldwide ? ISO 9001-2000 certified
facilities ? ISO 14001-2004 certified facilities
? LEAN Enterprise Manufacturing ? Double digit
growth for the past 5 years ? Annual sales volume
over 100 million
Hauppauge, New York Headquarters
7
Worldwide Facilities
Bohemia, New York, USA
Hauppauge, New York, USA
Metal Fabrication Facility65,000 Sq. Ft./6,040
Sq. meter
Main HQ Design/Production Facility 100,000 Sq.
Ft./9,300 Sq. meter

Valhalla, New York, USA
Matamoros, Mexico
LCC Production Facility Plant 1 87,850 Sq.
Ft./8,150 Sq. meter
Design/Production Facility 35,000 Sq. Ft./3,250
Sq. meter
8
Worldwide Facilities
Pulborough, UK
Matamoros, Mexico
European HQ Design/Production Facility20,000
Sq. Ft./1,822 Sq. meter
LCC Production Facility Plant 2 37,000 Sq.
Ft./3,437 Sq. meter

Toda, Japan
Suzhou, China
Japan HQ Sales /Service Facility6780 Sq.
Ft./630 Sq. meter
Chinese HQ Production/Sales/Service
Facility 17,225 Sq. Ft./1600 Sq. meter
9
Standard Products
Our standard product catalog offers literally
hundreds of modular, rack, and X-Ray high voltage
power supplies to choose from. From 250 volts
to 500 kilovolts From 200 milliwatts to 200
kilowatts Our Application Specific section
details many readily available customized
products.
10
Recent New Product Releases
SIC Option Card USB, Ethernet, RS232
CCM 3kW Capacitor Charging Module
SLM 300W/600W Modular HVPS
XRV 160kV to 450kV X-Ray Generator
11
World-Class High Voltage Engineering
Spellmans high voltage design team is the
largest in the industry. We have over 125
technical specialists in the USA and UK dedicated
to the research, design and development of
applied HV power supply technology.
Hauppauge, New York Engineering Department
12
Power Conversion Technology
We have expertise in various switch mode power
conversion topologies including Resonant
Quasi-Resonant Soft Switching Pulse Width
Modulated Linear
United States Patents Awarded 4,248,162
Electrostatic Air Cleaner 4,488,214 HP/HF
Inverter System 4,636,685 Magnetic Arc Spreading
Lamp Drive 4,805,081 MultiMode Control
System 5,668,708 Power Supply w/Reduced
Ripple 5,671,132 HV Bipolar CT Power
Supply 6,002,600 Reversible Polarity
HVPS 6,469,469 Variable Output Motor Drive System
We hold important high voltage power conversion
and control system patents.
13
Electrical Mechanical Designs
Spellman combines over six decades of high
voltage experience along with the most current
advances in electrical design, simulation and
validation technology like Analog and digital
circuit simulation E-field computer modeling
software Partial discharge measurement equipment
Mechanical designs benefit from verification
tools like CAD based finite element analysis
programs Thermal modeling analysis software
Hardware testing using HALT HASS with
Computer Modeling
our environmental vibration capabilities.
Environmental Vibration Chamber
Corona Detection Equipment
14
Insulation Systems
Spellman has vast expertise in high voltage
packaging and insulating systems. We have
developed many propriety encapsulation techniques
and processes. Our engineers work with a variety
of solid, liquid and gas insulation technologies
including
Air Silicone Encapsulants Epoxy
Encapsulants Dielectric Oil Insulating Gases
SF6 Hybrid systems
Vacuum Encapsulation Chamber
Encapsulated HVPS
These capabilities provide unmatched flexibility
for unique custom designs, most noted in our
Monoblock series of X-Ray Sources.
Monoblock
15
Digital Control and Interface Designs
Control and interface circuitry benefit from our
extensive digital and software design capability.
Spellmans engineers design with the latest
technologies including digital signal processors
(DSP), field programmable gate arrays (FPGA), and
fiber optics. We provide both industry standard
and custom communications interfaces,
including RS232, RS485 Universal Serial Bus
(USB) Ethernet (TCP/IP) CANbus / DeviceNet
Graphical User Interface (GUI)
USB, RS-232, and Ethernet Interface Card (SIC
Option)
16
Compliance and Safety
Safety and regulatory agency approvals like UL,
CSA, and IEC, can be provided. All standard
products bear the CE mark of approval for
radiated conducted emissions and the low
voltage safety directive.
Spellmans leadership in X-Ray generator
development includes custom X-Ray tube packaging
and expertise in sophisticated radiation leakage
testing.
17
Manufacturing Resources Machine Shop
USA
Spellmans dynamic mix of vertically integrated
Lean Enterprise manufacturing process along with
strategic outsourcing policies provide
flexibility in responding to customer needs.
Utilizing both captive and contract sources of
materials assures a high quality, on time and
efficiently made product.
Precision Machining Center
CNC Brake
Robotic Welding
Alodining
In-house Capabilities Sheet metal
fabrication Precision Machining Metal
plating Silk Screening Welding
Laser Punch
Pem Insertion
18
Manufacturing Resources
USA
UK
Spellmans Lean Enterprise manufacturing process
assures that product is fabricated in the most
cost effective and expedient manner possible.
Wave Solder
Module Assembly
SMT Machine
Factory Floor
Daily Stand Up Meetings
Component Lead Forming
19
Manufacturing Resources
Mexico
Highly trained assemblers technicians, over
500 employees Dedicated manufacturing
industrial engineering staff Medium/Large
volume runs components, subassemblies
completed units Identical processes as per our
USA facilities ISO 9001-2000 certified, LEAN
Enterprise Manufacturing
Factory Floor
Skilled Engineers and Technicians
Top Level Rack Assembly
High Power CT Test Bays
Automated Wave Solder
In Process Inspection
20
Spellman Quality Statement To understand and
provide what our customers value.
ISO90012000 CertificationSpellman's quality
system is ISO90012000 certified, covering
product development, manufacturing, and customer
service. ISO90012000 insures that we document
what we do and follow our procedures throughout
every phase of our operations.
SHV Hauppauge ISO 9001-2000 Certificate
SHV Mexico ISO 9001-2000 Certificate
SHV UK ISO 9001-2000 Certificate
SHV Valhalla ISO 9001-2000 Certificate
21
Spellman Environmental Policy
Spellman is committed to minimizing the
environmental impact of its operations, products,
and services while promoting environmental
awareness and good practices among its employees.
To achieve this we shall Set achievable
objectives Monitor, review, and continually
improve our systems Comply with all relevant
environmental legislation and regulations Work
with our suppliers to implement good
environmental practices Reduce our production
of waste, and our use of energy and hazardous
substances
Spellman is committed to provide products that
comply with RoHS and WEEE as required.
SHV-Hauppauge ISO 14001-2004 Certificate
SHV-UK IS0 14001-2004 Certificate
SHV-Bohemia ISO 14001-2004 Certificate
22
Sales and Support Capabilities
Spellman has over 2 dozen direct worldwide sales
professionals to support our customers. We take
pride in the relationships developed, along with
the integrity and trust weve created by being
the leader in high voltage power supply
technology for over 60 years.
Backgrounds are varied in the Sales organization
engineers, technicians, scientists business,
sales, support service personnel. Our
individual contributions may be different, but
our goal is the same
To understand and provide what our customers
value
Japan Sales Office
UK Sales Meeting
23
SpellmanYour Partner in Excellence

• Partnership We are more than a supplier,
  Spellman is your development partner, a critical
  member of your project design team.

• Size Facilities totaling over 365,000 ft²
  (33,909 m²) devoted to design, production,
  service and support in the USA, Mexico, Europe,
  Japan and China.

• Leverage Focus on your strengths and core
  competencies allow Spellman to meet your needs
  for advanced high voltage technology.

Loren Skeist, President

• Agility We are flexible to support small or
  large projects production runs from just a few
  to thousands.

• Relationship Trust is the basis of your
  relationship with Spellman.

24
Thank you for considering Spellman for your high
voltage power supply needs.
Visit www.spellmanhv.com for more information
