BIL106E

1
BIL106E

• Drived OtherDATA TYPES

2
Contents

• PRELUDE
• DRIVED DATA TYPES
• Definition
• Declaration
• Use
• PARAMETERIZED TYPES
• COMPLEX TYPE

3
Prelude

• There are three data types provided in F language
  that we have not yet considered
• Derived data type
• Parameterized types
• Complex type

4

• PRELUDE
• DRIVED DATA TYPES
• Definition
• Declaration
• Use
• PARAMETERIZED TYPES
• COMPLEX TYPE

5
Derived Data Types

• There are intrinsic data types (integer, real,
  character, logical and complex) in F Language.
• F includes the capability for programmers to
  create their own data types to supplement the
  five intrinsic types.
• They can be derived from
• Intrinsic data types integer, real, character,
  logical, complex
• Previously defined data types

6
Derived data types and structures

• F provides a "derived data type" in order to
  declare a "structure" used to store items of
  different types.
• The position in the structure, in which these
  data items are stored, are called the
  "components of the structure".
• Generic form of a derived type definition
• type, public type-name
• variable declaration_1
• variable declaration_2
• ..
• end type type-name

type, public tel_record character (len15)
name character (len25) surname integer
tel-no end type tel_record
7
Definition Declaration

• Suppose that the data includes first, middle,
  initial and last name, sex, social security
  number of individuals
• Definition of the derived type person
• type, public person
• character (len12) first_name
• character (len1) middle_initial
• character (len12) last_name
• integer age
• character (len1) sex ! M or F
• character (len11) social_security
• end type person
• Declaration of variables of derived type person
• type (person) jack, jill

8
Definition Declaration

• The derived type definitions may only appear in a
  module.
• The other modules can gain access to DT with
  public attribute in type definition

type, private type-name variable
declaration_1 variable declaration_2 .. end type
type-name
type, public type-name variable
declaration_1 variable declaration_2 .. end type
type-name
9
Use

• We put constant data in a derived type variable
  using Structure Constructor form
• jackperson("Jack","R","Hagenbach",47,"M","123-45-
  6789")
• jillperson("Jill","M","Smith",39,"F","987-65-4321
  ")
• Reffering to componentsvariablecomponent
• structure_namecomponent_name
• Examplejackfirst_name "Jack"jillage
  modified_age

10
Use

• A read statement will expect a sequence of data
  values which matches the components in both type
  and order.
• A print statement will output the value of a
  derived type variables as a sequence of its
  component parts.

11
Derived types in derived types

• type, public employee type(person)
  employee_pers character(len20) department
  real salaryend type employee
• type(person) john
• johnemployee_persage 34johndepartment
  "geotechnical engineering"

12
Arrays of derived types

• type(person), dimension(136) bil106class
• Thenbil106class(2)sex "M"
• bil106class(i) jack
• You can do operations on componentsbil106class(3
  )agebil106class(4)agename_surname jackname
  // jacksurname
• But no such operation is permissiblebil106class(
  3) - bil106class(4)

13
Arrays in derived types

• The derived data types of array_valued variables
• type, public golfer
• character(len15) first_name,last_name
• integer handicap
• integer, dimension (10) last_rounds
• end type golfer
• If a variable of type golfer is declared as
• type(golfer) Faldo
• then the score he achieved in his most recent
  rounds is written as
• Faldolast_rounds(10)

14

• PRELUDE
• DRIVED DATA TYPES
• Definition
• Declaration
• Use
• PARAMETERIZED TYPES
• COMPLEX TYPE

15
Parameterized Types

• Real numbers are stored in a computer as
  floating-point approximations to their true
  mathematical values.
• A real number is stored in a computer to about 6
  or 7 decimal digits of precision with an exponent
  range of around -1038 to 1038.
• An integer number can be in the range of -109 to
  109.
• Some computers such as super computers exceed
  these ranges considerably.

16

• Overflow will occur if a calculation would result
  in an exponent for a real number being larger
  than the maximum possible exponent allowed.
  Overflow results in an error condition.
• 9876543210.1234 would require an exponent of 10
  which is more than the computer will allow.

17

• Underflow will occur if a calculation would
  result in exponent for a real number being
  smaller than the minimum possible exponent
  allowed. The result of underflow is that the
  result of the calculation is treated as zero. It
  is not treated as an error by many processor.
• 0.0000000000375
• This number requires an exponent of -10 which is
  less than the computer will allow.

18

• Real variables may be parameterized in order to
  provide more than one representation of real
  numbers, with differing degrees of precision or
  exponent range.
• A processor which supports more than one
  representation of real numbers will specify a
  different kind type parameter for each
  representation.

19

• For computations in which more precision is
  needed than is available using the default real
  data type. Fortran provides parameterized real
  types. A parameterized type declaration has the
  form
• type-specifier (KIND kind-number), attributes
  list
• or
• type-specifier (kind-number), attributes list
• where kind-number is an integer constant or a
  constant integer expression whose value is
  positive. Kind numbers, called kind type
  parameters, for various types are machine
  dependent.

20

• There must be at least two kinds of real types,
  one for single-precision values and other for
  double-precision values, which provides
  approximately twice as many significant digits as
  single precision. The kind numbers for these two
  types typically are 1 and 2
• Real kind 1 Single-precision values with
  approximately 7 significant digits usually
  stored in 32 bits (default real type)
• Real kind2 Double-precision values with
  approximately 14 significant digits usually
  stored in 64 bits

21

• real a,b
• real c,d
• real, dimension (10) x,y
• integer, parameter kind11, kind24, kind32
• real (kindkind2) e,f
• real (kindkind1) g,h
• real (kindkind3), dimension(10) u,v

22

• The value of kind must be a named integer
  constant.
• real (kind4) e,f !not allowed
• Example A variable of kind type2 may have 14
  significant digits of precision and an exponent
  range of 100 on one machine.
• A real variable or constant whose kind type
  parameter is not specified, is of default real
  type.

23
selected_real_kind intrinsic function

• The selected_real_kind intrinsic function may be
  used to determine the kind type parameter of the
  real number representation on the current
  processor which meets at least a specified degree
  of precision and exponent range.
• real(kindselected_real_kind (p8, r30)) m
• real(kindselected_real_kind (p6, r30)) n
• The selected_real_kind intrinsic function has 2
  optional arguments
• p is a scalar argument specifying the minimum
  number of decimal digits required,
• r is a scalar integer argument specifying the
  minimum decimal exponent range required.
• The result of the selected_real_kind function is
  the kind type that meets or minimally exceeds the
  requirements specified by p and r.

24

• Example
• real (kind selected_real_kind (20, 50)) X
• declares that X is to be a real variable whose
  values are to have at least 20 decimal digits of
  precision and may be in the range -1050 to 1050.

25

• A reference to selected_int_kind has the form
• selected_int_kind (r)
• where r is an integer. It returns a kind type
  parameter that will provide a range of at least -
  10r to 10r, if such a kind is available
  otherwise it returns -1.
• integer, parameter Range20
  selected_int_kind(20)
• integer (kind Range20) M, N
• declare that Mand N are integer variables whose
  values may have up to 20 digits. If no such
  integer kind is available, a compiler error will
  result.

26

• To specify the kind of a constant, an underscore
  followed by a kind number is appended to the
  constant. For example
• 123456789_
• is an integer constant whose kind number is 3,
  and
• 12345678901234567890_Range20
• is an integer constant whose kind number is
  Range20, where Range20 is the named constant
  defined earlier by
• integer, parameter Range20 selected_int_kind(2
  0)

27

• When a value is assigned to a parameterized real
  variable in a program, it is important that the
  kind of the value being assigned is the same as
  the kind of the variable. Consider the following
  program
• program test
• implicit none
• real X
• integer, parameter DP selected_real_kind(14)

• real (kind DP) A, B
• X0.1
• B0.1_DP
• AX
• print , A
• A B
• print , A
• end program test

28

• On some systems the values displayed for A by
  the first two print statements resemble the
  following
• 0.1000000014901161
• 0.100000000000000
• It is important to ensure that all variables,
  arrays, and functions that areto have values of a
  particular kind are declared to be of that kind.
  For example, if R is a real variable of kind DP
  and Area is an ordinary (single-precision) real
  variable, the computation in the statement
• Area 3.1415926535898_DP R 2
• will be carried out in extended precision, but
  the resulting value will then be assigned to the
  single-precision variable Area, thus losing
  approximately half of the significant digits.

29

• As these examples illustrate, although mixed-kind
  expressions are permitted, accuracy may be lost
  because of the use of lower-precision constants
  or variables.

30

• PRELUDE
• DRIVED DATA TYPES
• Definition
• Declaration
• Use
• PARAMETERIZED TYPES
• COMPLEX TYPE

31
Complex Type

• A complex number is a number of the form abi
  where a and b
• are real numbers. The first real number, a, is
  called the real part of
• the complex number, and the second real number,
  b, is called the
• imaginary part.
• In Fortran, a complex constant is represented as
  a
• pair of real constants.
• (a, b)
• where a and b represent the real part and the
  imaginary part of the complex number,
  respectively.
• For example
• (1.0, 1.0) ? 1.0 1.0 i
• (-6.0, 7.2) ? -6.0 7.2i
• (-5.432, -1.4142) ? -5.432 -1.4142i

32

• The names of variables, arrays, or functions that
  are complex may be any legal Fortran names, but
  their types must be declared using the complex
  type statement. For example, the statements
• complex A, B
• complex, dimension (10, 10) Rho
• declare A, B, and the 10 X 10 array Rho to be
  complex variables.

33

• The statements
• integer, parameter DP selected_real_kind(14)
• complex(kind DP) Gamma
• or
• integer, parameter DP selected_real_kind(14)
• complex(DP) Gamma
• declare the variable Gamma whose type is complex
  of kind DP. For a complex value, this means that
  both the real part and the imaginary part are
  real values of kind DP (that is, both are
  double-precision values).

34
Example

• Define a data type for complex numbers, read two
  complex numbers, calculate their sum, difference
  and product, print the results.

• module complex_arithmetic
• type, public complex_number
• real real_part, imaginary_part
• end type complex_number
• end module complex_arithmetic
• program complex_example
• use complex_arithmetic
• type(complex_number) c1,c2,csum,sdiff,cprod
• read ,c1,c2
• csumreal_partc1real_partc2real_part
• csumimaginary_part c1imaginary_part
  c2imaginary_part
• cdiffreal_part c1real_part
  - c2real_part
• cdiffimaginary_part c1imaginary_part -
  c2imaginary_part
• cprodreal_part c1real_part
  c2real_part -
• c1imaginary_part c2imaginary_part
• cprodimaginary_part c1real_part
  c2imaginary_part
• c1imaginary_part c2real_part
• print , csum, cdiff, cprod
• end program complex_example
