Keystone Coach Works, Inc

1
Keystone Coach Works, Inc

• Disaster Response Units
• DRU-1 DRU-2

2
Keystone Coach Works, Inc

• Designed as Canteen
• Function
• Components
• Backup Systems
• Ease of Service

3
Keystone Coach Works, Inc

• Function Section

4
Keystone Coach Works, IncFunction

• Engineered as Canteen
• Lower Floor Height
• Wiring
• Flexibility
• Driver Friendly
• Seating for Crew

5
Keystone Coach Works, IncFunction

• Serving Window
• Interior Height 30
• Exterior Height 62
• Personal Contact

6
Keystone Coach Works, IncFunction

• Wide Aisle
• Over 40 Counter to Counter

7
Keystone Coach Works, IncFunction

• True Serving Circle
• Dru-1 Triangle
• Stove Coffee Maker
• Microwave
• Serving Window
• Primary Supply Cabinet

8
Keystone Coach Works, IncFunction

• True Serving Circle
• DRU-2 Triangle
• Stove, Coffee Microwave
• Refrigerator
• Serving Window
• Primary Supply Cabinet

9
Keystone Coach Works, IncFunction

• Meal Prep Area
• Flip Counter on Both Side Multiple Setups
• Cargo Tie downs
• Strap Food Contains Down for Stop Go Feeding
• Plenty of Room for Crew to Prepare Meals

10
Keystone Coach Works, IncFunction

• Flexibility

11
Keystone Coach Works, IncFunction

• Flexibility
• Flip Counters

12
Keystone Coach Works, IncFunction

• Flexibility
• Flip Counters
• Multiple Cabinets

13
Keystone Coach Works, IncFunction

• Flexibility
• Flip Counters
• Multiply Cabinets
• Storage Compartments
• Cargo Tie Downs

14
Keystone Coach Works, IncFunction

• Flexibility
• Flip Counters
• Multiply Cabinets
• Storage Compartments
• Cargo Tie downs
• Low Rear Entry Steps
• Step Bumper is Standard, Hitch Step
  is option

15
Keystone Coach Works, IncFunction

• Lighting
• 12 Volts 110 Interior Exterior

16
Keystone Coach Works, Inc

• Components Systems Section

17
Keystone Coach Works, IncSpecifications Dru-1

• Overall length ... 20 9
• Width . 8
• Height ... 11 2
• Approx Weight .... 9385 lbs
• Approx Carrying Capacity ..... 1315
  lbs
• Fuel Capacity . 37 gal.
• Fresh Water Capacity 15 gal.
• Generator ... 7.0 Kw
• 12 Volt Power Converter . 50 amp
• Roof Top Air Conditioning ..
  13,500 BTU
• Seating Capacity .. 5
• Height to Serving Window .. 62
• Propane .... 40 lbs

18
Keystone Coach Works, Inc Specifications Dru-2

• Overall length 24 8
• Width ... 8
• Height ..... 11 2
• Approx Weight . 10,807 lbs
• Approx Carrying Capacity .. 3,243
  lbs
• Fuel Capacity ... 55 gal.
• Fresh Water Capacity ....... 36
  gal.
• Waste Tank Capacity ..... 27 gal.
• Hot Water Capacity .. 10 gal.
• Generator ..... 12.0 Kw
• 12 Volt Power Converter ... 50 amp
• Roof Top Air Conditioning . 13,500
  BTU
• Seating Capacity . 4
• Refrigerator ..... 14 cu ft.
• Height to Serving Window ... 62
• Propane .... 40 lbs

19
Keystone Coach Works, IncAudible Visual Warning
Equipment

• Light Bar Cab Mounted
• 2 Rear Beacons
• 2 Ocsilazer Lights on Front Bumper
• V-Con Siren w/PA 100 Watt Speaker
• Backup Warning Alarm

20
Keystone Coach Works, IncComponents

• Electrical System
• Commercial Generator
• Remote Start/Stop Hour Meter Switch
• Properly Sized Generator
• Sound Insulated Generator Compartment
• Dru-1 7.0 gas power generator
• Dru-2 12.0 gas power generator

21
Keystone Coach Works, IncElectrical System

• Circuit Panel
• 5 Interior Outlets
• 3 Exterior Outlets
• 1 Interior Outlet on Lighted Switch for Coffee
  Marker
• 12v Switches for Interior Lights Water Pump

22
Keystone Coach Works, IncElectrical System

• Exterior Shoreline Connector w/Cord
• Automatic Transfer Switch Box
• 50 amp 12v. Power Converter
• Auxiliary Battery
• Isolator for Aux Battery

23
Keystone Coach Works, IncElectrical System

• Separate Circuit Breakers for 12v System
• 12v Fuse Panels
• Switches for 12v Lighting
• 4 12v Dome Lights
• 110 Fluorescent Lights
• Dru-1, 2- 4 2 bulb
• Dru-2, 3- 4 2 bulb

24
Keystone Coach Works, IncExterior Scene Flood
Lights

• 4 Weldon 12v Scene Lights
• 2 Kwik-Raze 110v/500w Quartz Flood Lights
• 2 Halogen 12v Cargo Lights Above Rear Door

25
Keystone Coach Works, IncLPG System

• 2 20lb Propane Tanks
• Tie Down Mount for Tanks
• High Pressure Propane Lines
• Single Tank Regulator
• Exterior Compartment
• Vented Compartment thru Door and Floor

26
Keystone Coach Works, IncWater System

• DRU-1
• 15 gal. Fresh Water Tank
• S.S. Bar Sink w/Faucet
• Single Stage 12v Water Pump
• Exterior Water Fill Inlet
• Water Tank Drain Cock

27
Keystone Coach Works, IncWater System

• DRU-2
• 46 gal. of Fresh Water
• 36 gal. Water Tank
• 10 gal. LPG/110v Hot Water Tank
• 27 Gallon Waste Tank
• S.S. Bar Sink w/Faucet
• 3 Bowl S.S. Sink
• Single Stage 12v Water Pump
• Exterior Water Fill Inlet
• City Water Hook-up
• Water Tank Drain Cock

28
Keystone Coach Works, IncBasic Service Equipment

• DRU-1
• Three Burner LPG Stove Top
• DRU-2
• Castle Brand 4 Burner LPG Stove Top
• Castle Brand 30 Commercial Griddle

29
Keystone Coach Works, IncBasic Service Equipment

• Dru-1
• Microwave
• Dru-2
• 2 Microwave Convection Ovens
• Refrigerator/Freezer Side by Side 110v/LPG

30
Keystone Coach Works, IncBasic Service Equipment

• DRU-1
• Exterior 10 Awning
• DRU-2
• Exterior 12 Awning
• Cargo System
• 3 12 Cargo Belts
• 5 Track Section Street Side
• 1 Track Section Curb Side
• Multi-Function can be used either Horizontal or
  Vertical

31
Keystone Coach Works, IncBasic Service Equipment

• 3 Burner Bunn Pour-O-Matic
  Coffee Marker w/Pots

32
Keystone Coach Works, IncInterior Outfitting

• Stainless Steel Counter Tops
• Cabinets Plywood Construction w/formica
• Serving Window 34 x 34 Automotive Safety Glass
• Aluminum Serving Ledge

33
Keystone Coach Works, IncInterior Outfitting

• 2 Flip S.S. Counter Tops Install in Rear Cargo
  Area
• Dru-1
• 3 Passenger Seating with Seat Belts
• Dru-2
• 2 Passenger Seating with Seat Belts

34
Keystone Coach Works, IncInterior Outfitting

• Interior Cabinets
• Curb Side Lower
• Street Side Upper Lower
• Locking T-Handles
• Storage Bins
• Large Cabinet with Shelves

DRU-1 Road Side View
35
Keystone Coach Works, Inc Interior Walls
Flooring

• Kemlite .060 Lining on 3/8 Plywood Walls,
  Ceiling
• Insulation Walls Ceiling
• RCA Heavy Duty Rubber Transit Ribbed Flooring
• Subfloor
• H.D. 12ga. Steel Floor
• 1.125 Plywood Floor

DRU-1 Rear View
36
Keystone Coach Works, IncLettering / Decals

• Approved Identification Package
• Installation of Shield Decals
• Customized Division or City Name (one
  line of text included)
• Additional Text, Stripes Graphics Available for
  additional cost

37
Keystone Coach Works, IncAir Conditioning
Misc.

• Coleman Low Profile 110v 13,500 BTU A/C with Heat
  Strip
• Class 3 Trailer Hitch
• Uniden Scanner Radio
• 5 lb. ABC Fire Extinguisher
• Optional Rear Hitch Step

38
Keystone Coach Works, Inc

• Backup System Section

39
Keystone Coach Works, IncBackup System

• Why Backup System ?
• All DRUS have Dual Systems for
• Lighting
• Cooking
• Coffee Service

40
Keystone Coach Works, IncBackup System

• Dual Lighting System
• Powered By 110v or 12v
• Interior Lighting
• Exterior Lighting

41
Keystone Coach Works, IncBackup System

• Cooking Capability's
• Propane or 110v
• LPG Stove
• 110v Microwave
• Dru-2
• Dual Power Refrigerator 110v or LPG
• Hot Water 110v or LPG

42
Keystone Coach Works, IncBackup System

• Coffee Service
• 110v
• Bunn Coffee Maker will make coffee by pouring hot
  water heated on the stove thru the system (3 pots
  will fill reservoir to start making hot coffee)

43
Keystone Coach Works, Inc

• Ease of Service Section

44
Keystone Coach Works, IncEase of Service

• Easy Setup
• Easy Reach to Components
• Unit Can be used by one Person
• All Equipment is user Friendly
• Comfortable Work Environment
• Multiply Crew can work with out being cramped

45
Keystone Coach Works, IncEase of Service

• Continuous Work Surfaces
• DRU-1
• Total Counter Space 21 11
• Curb Side 10 3
• Street Side 11 8
• DRU-2
• Total Counter Space 23 3
• Curb Side 12 2
• Street Side 11 1

46
Keystone Coach Works, IncEase of Service

• Counters are Set at a Good Working Height
• Serving Window is Set at Comfortable Height for
  Customer Server

47
Keystone Coach Works, IncEase of Service

• Cleaning
• Kemlite Walls
• Stainless Steel Counter Tops
• Permanent Mounted Rubber Floor

48
Keystone Coach Works, IncEase of Service

• Winterization
• Drain Water Tank and add RV Antifreeze
• Remove Coffee Maker
• Additional Procedures for DRU-2
• Bypass Hot Water Tank Drain
• Blow Out Water System with Air thru City Water
  Hookup
• Drain Waste Tank

49
Keystone Coach Works, IncEase of Service

• Maintenance
• Most Components are Available Locally
• Dru-2 Cooking Units are commercial grade
• Most Parts can be install by your staff
• Cabinets Repairs can be done at Local Cabinets
  Shops (no welding required)

50
Keystone Coach Works, Inc
DRU-1
DRU-2

• Custom Layout and Design are Available
• 412-833-1900
• Kcwi_at_Verizon.net
• 4786 Library Road - Bethel Park, PA 15102
