Title: Gas Exchange


1
Gas Exchange
  • Chapter 16

2
Partial Pressure of Gases
  • Partial pressure pressure that a particular gas
    in a mixture exerts independently
  • Daltons Law total pressure of a gas mixture is
    the sum of partial pressures of each gas
  • Atmospheric pressure at sea level is 760 mm Hg
  • PATM PN2 P02 PC02 PH20 760 mm Hg

16-38
3
Gas Exchange in Lungs
  • Driven by differences in partial pressures of
    gases between alveoli capillaries

Fig 16.20
16-39
4
Gas Exchange in Lungs continued
  • Facilitated by surface area of alveoli, short
    diffusion distance between alveolar air
    capillaries, density of capillaries

Fig 16.21
16-40
5
Partial Pressures of Gases in Blood
  • When blood alveolar air are at equilibrium the
    amount of O2 in blood reaches a maximum value
  • Henrys Law this value depends on solubility of
    O2 in blood (a constant), temperature of blood (a
    constant), partial pressure of O2
  • The amount of O2 dissolved in blood depends
    directly on its partial pressure (PO2), which
    varies with altitude

16-41
6
Blood PO2 PCO2 Measurements
  • Provide good index of lung function
  • At normal PO2 arterial blood has about 100 mmHg
    PO2
  • PO2 is about 40 mmHg in systemic veins
  • PC02 is 46 mmHg in systemic veins

16-42
7
Fig 16.23
8
Disorders Caused by High Partial Pressures of
Gases
  • Total atmospheric pressure increases by an
    atmosphere for every 10m below sea level
  • Therefore, PP increases, and amt dissolved
    increases (Henrys Law).
  • Too much dissolved oxygen becomes toxic.

16-45
9
Disorders Caused by High Partial Pressures of
Gases
  • At sea level, nitrogen is physiologically inert
  • It dissolves slowly in blood
  • Nitrogen narcosis resembles alcohol intoxication
  • Amount of nitrogen dissolved in blood as diver
    ascends decreases due to decrease in PN2
  • If ascent is too rapid, decompression sickness
    occurs (the bends)

16-46
10
Brain Stem Respiratory Centers
  • Automatic breathing is generated by a rhythmicity
    center in medulla oblongata
  • Consists of inspiratory neurons that drive
    inspiration expiratory neurons that inhibit
    inspiratory neurons
  • activity varies in a reciprocal way may be due
    to pacemaker neurons

Fig 16.25
Insert fig. 16.25
16-48
11
Pons Respiratory Centers
  • Activities of medullary rhythmicity center is
    influenced by centers in pons
  • Apneustic center promotes inspiration by
    stimulating inspiratories in medulla
  • Pneumotaxic center antagonizes apneustic center,
    inhibiting inspiration

16-50
12
Chemoreceptors
  • Automatic breathing influenced by activity of
    chemoreceptors monitor blood PC02, P02, pH
  • Central chemoreceptors are in medulla
  • Peripheral chemoreceptors are in large arteries
    near heart (aortic bodies) in carotids (carotid
    bodies)

Fig 16.26
16-51
13
Effects of Blood PC02 pH on Ventilation
  • Chemoreceptors modify ventilation to maintain
    normal CO2, O2, pH levels
  • PCO2 is most crucial because of its effects on
    blood pH
  • H20 C02 ? H2C03 ? H HC03-
  • Hyperventilation causes low C02 (hypocapnia)
  • Hypoventilation causes high C02 (hypercapnia)

16-53
14
Effects of Blood PC02 pH on Ventilation
continued
  • Brain chemoreceptors are responsible for greatest
    effects on ventilation
  • H can't cross BBB but C02 can, which is why it
    is monitored has greatest effects
  • Rate and depth of ventilation adjusted to
    maintain arterial PC02 of 40 mm Hg
  • Peripheral chemoreceptors do not respond to PC02,
    only to H levels

16-54
15
Fig 16.30
16-55
16
Effects of Blood P02 on Ventilation
  • Low blood P02 (hypoxemia) has little affect on
    ventilation
  • Does influence chemoreceptor sensitivity to PC02
  • P02 has to fall to about half normal before
    ventilation is significantly affected

16-57
17
Effects of Pulmonary Receptors on Ventilation
  • Lungs have receptors that influence brain
    respiratory control centers via sensory fibers in
    vagus
  • Unmyelinated C fibers are stimulated by noxious
    substances such as capsaicin
  • Causes apnea followed by rapid, shallow breathing
  • Irritant receptors are rapidly adapting respond
    to smoke, smog, particulates
  • Causes cough
  • Hering-Breuer reflex is mediated by stretch
    receptors activated during inspiration
  • Inhibits respiratory centers to prevent
    overinflation of lungs

16-58
18
Hemoglobin (Hb) 02 Transport
  • Loading of Hb with O2 occurs in lungs unloading
    in tissues
  • Affinity of Hb for O2 changes with a number of
    physiological variables

16-60
19
Hemoglobin (Hb) 02 Transport
  • Each Hb has 4 globin polypeptide chains 4 heme
    groups that bind 02
  • Each heme has a ferrous ion that can bind 1 02
  • So each Hb can carry 4 02s

Fig 16.33
16-61
20
Hemoglobin (Hb) 02 Transport continued
  • Most 02 in blood is bound to Hb inside RBCs as
    oxyhemoglobin
  • Each RBC has about 280 million molecules of Hb
  • Hb greatly increases 02 carrying capacity of blood

Insert fig. 16.32
Fig 16.32
16-62
21
Hemoglobin (Hb) 02 Transport continued
  • Methemoglobin contains ferric iron (Fe3) -- the
    oxidized form
  • Lacks electron to bind with 02
  • Blood normally contains a small amount
  • Carboxyhemoglobin is heme combined with carbon
    monoxide
  • Bond with carbon monoxide is 210 times stronger
    than bond with oxygen
  • So heme can't bind 02

16-63
22
Hemoglobin (Hb) 02 Transport continued
  • 02-carrying capacity of blood depends on its Hb
    levels
  • Anemia Hb levels are below normal
  • Polycythemia Hb levels are above normal
  • Hb production controlled by erythropoietin (EPO)
  • Production stimulated by low P02 in kidneys
  • Hb levels in men are higher because androgens
    promote RBC production

16-64
23
Hemoglobin (Hb) 02 Transport continued
  • High P02 of lungs favors loading low P02 in
    tissues favors unloading
  • Ideally, Hb-02 affinity should allow maximum
    loading in lungs unloading in tissues
  • The extent to which 02 will be loaded or unloaded
    depends on
  • P02 of the environment
  • Affinity between hemoglobin and 02

16-65
24
Oxyhemoglobin Dissociation Curve
  • of Hb sites that have bound 02 at different
    P02s
  • Reflects loading unloading of 02
  • In steep part of curve, small changes in P02
    cause big changes in saturation

Fig 16.34
16-66
25
Oxyhemoglobin Dissociation Curve
  • Hb-02 affinity is affected by changes in pH
    temp
  • Affinity decreases when pH decreases (Bohr
    Effect) or temp increases
  • Occurs in tissues where temp, C02 acidity are
    high
  • Causes Hb-02 curve to shift right more
    unloading of 02

Fig 16.35
16-67
26
Effect of 2,3 DPG on 02 Transport
  • RBCs have no mitochondria cant perform aerobic
    respiration
  • 2,3-DPG is a byproduct of glycolysis in RBCs
  • production is increased by low 02 levels
  • Causes Hb to have lower 02 affinity, shifting
    curve to right
  • In anemia, total blood Hb levels fall, causing
    each RBC to produce more DPG
  • Fetal hemoglobin (HbF) has 2 g-chains in place of
    b-chains of HbA
  • HbF cant bind DPG, causing it to have higher 02
    affinity
  • Facilitates 02 transfer from mom to baby

16-68
27
Sickle-cell Anemia
  • Sickle-cell anemia affects 8-11 of African
    Americans
  • HbS has valine substituted for glutamic acid at 1
    site on b chains
  • At low P02, HbS crosslinks to form a
    paracrystalline gel inside RBCs
  • Makes RBCs less flexible more fragile

Fig 16.36
16-69
28
Thalassemia
  • Thalassemia affects primarily people of
    Mediterranean descent
  • Has decreased synthesis of a or b chains
    increased synthesis of g chains

16-70
29
Myoglobin
  • Is a red pigment found exclusively in striated
    muscle
  • Slow-twitch skeletal cardiac muscle fibers are
    rich in myoglobin

16-71
30
Myoglobin
  • Has only 1 globin binds only 1 02
  • Has higher affinity for 02 than Hb is shifted to
    extreme left
  • Releases 02 only at low P02
  • Serves in 02 storage, particularly in heart
    during systole

Insert fig. 13.37
Fig 16.37
16-72
31
C02 Transport
  • C02 transported in blood as dissolved C02 (10),
    carbaminohemoglobin (20), bicarbonate ion,
    HC03-, (70)
  • In RBCs carbonic anhydrase catalyzes formation of
    H2CO3 from C02 H2O

16-74
32
Chloride Shift
  • High C02 levels in tissues causes the reaction
    C02 H2O ? H2C03 ? H
    HC03- to shift right in RBCs
  • Results in high H HC03- levels in RBCs
  • H is buffered by proteins
  • HC03- diffuses down concentration charge
    gradient into blood causing RBC to become more
  • So Cl- moves into RBC (chloride shift)

16-75
33
Chloride Shift
Fig 16.38
16-76
34
Reverse Chloride Shift
  • In lungs, C02 H2O ? H2C03 ? H HC03-, moves
    to left as C02 is breathed out
  • Binding of 02 to Hb decreases its affinity for H
  • H combines with HC03- more C02 is formed
  • Cl- diffuses down concentration charge gradient
    out of RBC (reverse chloride shift)

Fig 16.39
16-77
35
Acid-Base Balance in Blood
  • Blood pH is maintained within narrow pH range by
    lungs kidneys (normal 7.4)
  • Most important buffer in blood is bicarbonate
  • H20 C02 ? H2C03 ? H HC03-
  • Excess H is buffered by HC03-
  • Kidney's role is to excrete H into urine

16-78
36
Effect of Bicarbonate on Blood pH
Fig 16.40
Insert fig. 16.40
16-79
37
Acid-Base Balance in Blood continued
  • 2 major classes of acids in body
  • A volatile acid can be converted to a gas
  • E.g. C02 in bicarbonate buffer system can be
    breathed out
  • H20 C02 ? H2C03 ? H HC03-
  • All other acids are nonvolatile cannot leave
    blood
  • E.g. lactic acid, fatty acids, ketone bodies

16-80
38
Acid-Base Balance in Blood continued
  • Acidosis is when pH lt 7.35 alkalosis is pH gt
    7.45
  • Respiratory acidosis caused by hypoventilation
  • Causes rise in blood C02 thus carbonic acid
  • Respiratory alkalosis caused by hyperventilation
  • Results in too little C02

16-81
39
Acid-Base Balance in Blood continued
  • Metabolic acidosis results from excess of
    nonvolatile acids
  • E.g. excess ketone bodies in diabetes or loss of
    HC03- (for buffering) in diarrhea
  • Metabolic alkalosis caused by too much HC03- or
    too little nonvolatile acids (e.g. from vomiting
    out stomach acid)

16-82
40
Acid-Base Balance in Blood continued
  • Normal pH is obtained when ratio of HCO3- to C02
    is 20 1
  • Henderson-Hasselbalch equation uses C02 HCO3-
    levels to calculate pH
  • pH 6.1 log HCO3-
    0.03PC02

16-83
41
Respiratory Acid-Base Balance
  • Ventilation usually adjusted to metabolic rate to
    maintain normal CO2 levels
  • With hypoventilation not enough CO2 is breathed
    out in lungs
  • Acidity builds, causing respiratory acidosis
  • With hyperventilation too much CO2 is breathed
    out in lungs
  • Acidity drops, causing respiratory alkalosis

16-84
42
Ventilation During Exercise
  • During exercise, arterial PO2, PCO2, pH remain
    fairly constant

Fig 16.41
16-86
43
Ventilation During Exercise
  • During exercise, breathing becomes deeper more
    rapid, delivering much more air to lungs
    (hyperpnea)
  • 2 mechanisms have been proposed to underlie this
    increase
  • With neurogenic mechanism, sensory activity from
    exercising muscles stimulates ventilation and/or
    motor activity from cerebral cortex stimulates
    CNS respiratory centers
  • With humoral mechanism, either PC02 pH may be
    different at chemoreceptors than in arteries
  • Or there may be cyclic variations in their values
    that cannot be detected by blood samples

16-87
44
Lactate Threshold
  • Is maximum rate of oxygen consumption before
    blood lactic acid levels rise as a result of
    anaerobic respiration
  • Occurs when 50-70 maximum 02 uptake has been
    reached
  • Endurance-trained athletes have higher lactate
    threshold, because of higher cardiac output
  • Have higher rate of oxygen delivery to muscles
    greater numbers of mitochondria aerobic enzymes

16-88
45
Acclimatization to High Altitude
  • Involves increased ventilation, increased DPG,
    increased Hb levels
  • Hypoxic ventilatory response initiates
    hyperventilation which decreases PC02 which slows
    ventilation
  • Chronic hypoxia increases NO production in lungs
    which dilates capillaries there
  • NO binds to Hb is unloaded in tissues where may
    also increase dilation blood flow
  • NO may also stimulate CNS respiratory centers
  • Altitude increases DPG, causing Hb-02 curve to
    shift to right
  • Hypoxia causes kidneys to secrete EPO which
    increases RBCs

16-89
Write a Comment
User Comments (0)
About PowerShow.com
