Automated Testing Tool for UML Behavioral Descriptions

1
Automated Testing Tool for UML Behavioral
Descriptions
M.Tech. Project
Guided by
Presented by
Venkat
Prof. S.Ramesh
Prof. Sridhar Iyer
2
Outline of the Talk

• Overview of the Software Testing
• Literature Survey
• Stress on Statecharts
• Importance of Testing Statecharts
• Coverage Metrics
• Design Specification of StateTest Tool
• Conclusions
• Demo

3
Testing Fundamentals

• Testing Objectives
• Test Information Flow

4
Test Information Flow
5
Test Case Design

• Three elements
• Test specification
• Test requirements
• Clues
• Fault Conditions
• Reachability
• Necessity
• Propagation

6
An Example

• void Check_square(int do_square,double x)
• double y x
• if(do_square)
• y x x
• printf(squared value larger? d\n,y gt x)
• The fault is that was used when should have
  been

7
Fault Conditions

• Reachability (do_square is true)
• Necessity (x!2 x!0)
• Propagation (x lt1) (to differentiate
  the truth value between
  (xx gtx) and (xxgtx))

8
Testing Techniques

• White-Box Testing
• Basis path testing
• Deriving Test cases
• Flow graph
• Cyclomatic Complexity
• Finding independent paths
• Graph Matrices
• Control Structure Testing
• Condition testing
• Data flow testing
• Loop testing

9
Testing Techniques

• Black-Box Testing
• Equivalence Partitioning
• (Range,specific value)?one valid, two invalid
  inputs
• (Boolean,member of a set)?one valid, one invalid
  inputs
• Boundary Value Analysis(BVA)
• Ex (1). If 0ltalt5, then test with (-1, 0, 1)
  and (4, 5, 6)
• Ex (2). If the i/p has n values, then test
  with i/p s (n-1), (n), and (n1) values
• Comparison Testing
• Specially for Safety-critical systems

10
Testing Strategies

• Unit Testing
• To test the modules
• Integration Testing
• To test interfaces between modules
• Top-down
• Could be DFS / BFS followed
• Bottom-up
• Regression Testing
• Validation Testing
• Validation test criteria
• Configuration review
• Alpha and Beta testing
• System Testing
• Recovery
• Security
• Stress
• Performance

11
Spiral Model of S/W Testing
12
Literature Survey

• AdaTest and Cantata
• For State Machine Testing
• IPL Algo. For Coverage Metrics
• Property-Based Testing
• Suggests the Testing at Source code level, rather
  than at higher level
• TASPEC is the Central entity
• ATTOL Software
• ATTOL UnitTest, ATTOL SystemTset, ATTOL Coverage
• 1 Software Testing Tool
• 1Base, 1CR, 1CM, 1DataTree, 1Test,
  1Reports, 1Reuse

13
A Brief Look At UML

• Result of the Three OO methodologies
• Booch Method by Grady Booch
• OMT by James Rumbaugh
• OOSE by Ivar Jacobson
• Statechart is one of the Nine building blocks
  supported by the UML

14
Statecharts A Visual Formalism for Complex
Systems

• Origins Of Statecharts
• FSMs
• STDs
• Harel Statecharts
• Limitations of State Machines
• Doesnt
• Provide State Hierarchy
• Have History Info.
• Have Concurrent States

15
Semantics of Statecharts

• State
• Event
• Transitions
• Event Guard / Action Transition

16
Example for Statechart Semantics
17
More features of Statecharts

• Generalization
• Simplifies by Factorization
• Orthogonality
• Simplifies by Segmentation
• History Info.
• To memorize the substate last visited

18
Example for Generalization
19
Example for Orthogonality
20
Example for History state
21
Importance of Testing Statecharts

• Statecharts play crucial role in modeling
• Safety-critical systems
• Networking Protocols
• GUIs (Graphical User Interfaces)
• OOD (Object-Oriented Design)

22
Methodology of Testing SCs
23
Coverage Metrics

• State Coverage
• Ratio of number of states covered and total
  number of states in the given state model
• Event Coverage
• Ratio of number of events covered and total
  number of events in the given state model
• Transition Coverage
• Ratio of number transitions exercised and total
  number of transitions in the given state model
• State-Event Coverage
• Ratio of state-event pairs exercised and number
  of states multiply number of events in the given
  state model

24
Design Specification of StateTest Tool

• Two inputs and Three outputs
• Input_1 Statechart specification generated
  by Statechart Editor(SCE) by BARC
• Input_2 Test Script File
• Output_1 Pass / Fail report
• Output_2 Coverage Metrics
• Output_3 Error Report

25
Statechart Spec. and Test Cases Formats
26
DFD Level 0 for StateTest
27
DFD Level 1 for StateTest
28
Implementation Details

• StateTest tool is implemented by using JAVA
  language
• StateTest tool has just four classes

29
Object Specification of StateTest

• Four Classes
• StatesInfo
• Reads the Statechart specification file
• CopyStateHierarchy
• Reads the hierarchical from the StatesInfo class
• TestScriptReading
• Reads the Test Script file
• ReportGenerator
• Generates pass / fail report

30
Initial Object Specification for StateTest
31
Detailed Object Specification for StateTest Tool
32
Experiments

• Code generated by SCE (BARC tool) from the
  Statechart figures
• Statecharts Specification as a 4-tuple by
  StateTest tool internally
• Experimented with many complex Statecharts
• Execution time of each test case is reasonable

33
Conclusions

• StateTest Tool is effective for Statechart
  Testing
• Future work
• Can be generalized to other input files
• Orthogonality
• History

34
Thank You
