Title: Quantum Computing II CPSC 321


1
Quantum Computing IICPSC 321
  • Andreas Klappenecker

2
Announcements
  • Monday, November 29, 600pm-715pm, HRBB 113,
    review session for midterm exam
  • Tuesday, November 30, midterm exam
  • CPSC 640 Quantum Algorithms
  • Elephant walk

3
Quantum Bits
4
The Stern-Gerlach Experiment
5
Quantum Bits
6
Memory
7
Quantum Computing in a Nutshell
8
Operations on a Quantum Computer
9
Example
10
Teleportation
11
Teleportation Its Simple!
12
Teleportation, Step by Step
  • Alice has two quantum bits
  • Bob has one quantum bit
  • Alice wants to teleport the state of one quantum
    bit
  • Alice and Bob share entangled bits
  • 00gt 11gt (1,0,0,1) normalized to length 1

13
Teleportation Set up
14
Teleportation Initial State
15
Step 1 - XOR
16
Step 2
17
Rewrite State
18
Measurement
19
Current Research Topics
20
Conclusion
  • The basic model is simple
  • Everyone can write a simulator of a quantum
    computer in a very short time
  • The computational model is different you need
    time to absorb that!
  • Numerous potential technologies!

21
Prepare for the Exam
  • Comprehensive Exam!
  • Emphasis more on newer topics
  • Datapath and Control
  • Caching
  • Pipelines
  • I/O
  • Multithreading
  • But also some older topics!

22
Prepare for the Exam
  • Read the book
  • Chapters 5,6,7 skim through later chapters and
    appendices
  • Skim through the previous chapters 1-4
  • Learn

23
Caching
  • Given A cache with some entries and a sequence
    of load/store instructions
  • Describe the evolution of the cache
  • When is it a hit or a miss?
  • What are the different eviction strategies?
  • LRU
  • Random
  • many others

24
Caching Basics
  • What are the different cache placement schemes?
  • direct mapped
  • set associative
  • fully associative
  • Explain how a 2-way cache with 4 sets works
  • If we want to read a memory block whose address
    is addr, then we search the set addr mod 4
  • The memory block could be in either element of
    the set
  • Compare tags with upper n-2 bits of addr

25
Implementation of a Cache
  • Sketch an implementation of a 4-way associative
    cache

26
Measuring Cache Performance
  • CPU cycle time
  • CPU execution clock cycles (including cache hits)
  • Memory-stall clock cycles (cache misses)
  • CPU time (CPU execution clock cycles memory
    stall clock cycles) x clock cycle time
  • Memory stall clock cycles
  • read stall cycles (rsc)
  • write stall clock cycles (wsc)
  • Memory stall clock cycles rsc wsc

27
Measuring Cache Performance
  • Write-stall cycle write-through scheme
  • two sources of stalls
  • write misses (usually require to fetch the block)
  • write buffer stalls (write buffer is full when
    write occurs)
  • WSCs are sum of the two
  • WSCs (writes/prg x write miss rate x write miss
  • penalty) write buffer stalls
  • Memory stall clock cycles similar

28
Cache Performance Example
  • Instruction cache rate 2
  • Data miss rate 4
  • Assume that 2 CPI without any memory stalls
  • Miss penalty 40 cycles for all misses
  • Instruction count I
  • Instruction miss cycles I x 2 x 40 0.80 x I
  • gcc has 36 loads and stores
  • Data miss cycles I x 36 x 4 x 40 0.58 x I

29
Pipelining
  • Pipeline hazards
  • structural hazards
  • hardware cannot support the combination of
    instructions that we want to execute during same
    clock cycle
  • control hazards
  • need to make decision based on instruction
    that is still executing
  • data hazards
  • instruction depends on results of a previous
    instruction that is still in pipeline
  • Various remedies, for instance,
  • stall pipeline
  • forwarding
  • delayed branch block

30
Pipelined Version
31
Pipelining
Learn how to find out dependencies using pipeline
diagram Need to know the pipeline hazards inside
out Q Given a sequence of instructions, give a
timing diagram Clock cycle IF ID
EX MEM WB
32
Timing Diagrams
33
Finding Dependencies
Dependencies that go backwards in time lead to a
data hazard
34
Forwarding
Data hazard add s0, t0, t1 sub t2, s0,
t3
35
Stalling the Pipeline
  • and needs result of lw operation
  • hazard forces stalling of the pipeline
  • and and or ops need to repeat in clock cycle 4
    what they did in previous clock cycle

36
Typical Questions (Small Sample!)
  • Chapter 6, problems 6.2, 6.3, 6.4
  • How much speed-up do you get by pipelining?
  • How many cycles will it take to execute this
    code? Problem 6.15
  • Loop unrolling, problem 6.30

37
Verilog?
  • I will ask little bits and pieces in mixed
    questions
  • There will be no extensive Verilog programming on
    paper
  • Little programming questions?
  • Yes
