Title: Internet2%20End-to-End%20Performance%20Monitoring%20Initiative%20Update


1
Internet2 End-to-End Performance Monitoring
Initiative Update
  • Eric L. Boyd and Jeff W. Boote, Internet2
  • August 6, 2003

2
E2E piPES
  • Project End-to-End Performance Initiative
    Performance Environment System (E2E piPES)
  • Goal To allow end-users and network operators
    to determine performance capabilities, locate
    problems, and contact the right person to get a
    problem resolved.
  • Approach Collaborative project combining the
    best work of many organizations, including
    DANTE/GEANT, NLANR/DAST, SLAC, UCL, etc.

3
BNI AMI
  • Project Backbone Network Infrastructure Abilene
    Measurement Infrastructure
  • Goal Instrument Next Generation Abilene network
    with extensive performance measurement
    capabilities
  • Approach Collaborative project among E2E, BNI,
    and Indiana NOC.

4
E2E piPES Architecture
5
Intra-PMP-Module Protocol
6
Intra-PMP Module Components
  • Domain Interface Web Service Interface to
    Request Performance Data
  • Performance Measurement Controller (PMC)
    Schedules Tests
  • Performance Measurement Point (PMP) Performs
    Tests, Stores Results in Database
  • Source Initiates Test Request
  • Target Accepts Test Request Starts Test

7
Domain Interface
  • Request Interface
  • Accepts External Result Requests
  • Compares Requestor Role to Policy
  • Rejects Request or Queries Response Interface
  • Response Interface
  • Accepts Result/Tool Requests
  • Compares Requester Identity, Source Role to
    Policy
  • Decides if Tool is Available
  • Rejects Request or Supplies Capability

8
Initiator / Acceptor Performance Measurement
Controller
  • Initiator PMC
  • Supplies Capability, Identity, Tool
  • Acceptor PMC
  • Accepts/Rejects/Delays Request Based on Policy
  • Contacts Target PMP to Initiate Test
  • Accepts/Rejects Request Based on PMP Response

9
Target / Source Performance Measurement Point
  • Source PMP
  • Accepts/Rejects Requests to Start Test based on
    Identity
  • Starts Tests
  • Target PMP
  • Accepts Test from Source PMP
  • Stores Results Locally
  • Sends Data to DB Gatekeeper

10
Database Gatekeper
  • Accepts/Rejects Requests to Store Data based on
    Identity
  • Accepts/Rejects Requests to Release Data based on
    Role, Identity
  • Supplies Performance Data

11
E2E piPES Architecture v1.0
12
PMC Distributed Scheduling Algorithm (e.g. iperf)
13
piPEs Tool Deployment on Abilene
  • All tests on IPv4 and IPv6
  • OWAMP Deployed on 10/11 nodes (nms4)
  • IPERF UDP In deployment beta on 2 nodes (nms1)
  • IPERF TCP In deployment beta on 2 nodes (nms1)
  • Traceroute In deployment beta on 2 nodes (nms4)
  • Router Data Deployed on all 11 nodes (router
    interface)
  • Flow Data Deployed on 10/11 nodes (nms3)

14
piPEs / AMI Rollout (Beta)
15
piPEs / AMI Rollout (Future)
16
piPEs / AMI Rollout (Future)
17
Performance Data as a Web Service
  • We wish to create a web service that will allow
    other applications to request and receive test
    results.
  • Possible Consumers
  • Testing/Analysis Engine
  • Web-based Display Engine
  • High Energy Physics Routing
  • Application Problem Detection

18
E2E piPEs Architecture (Grid)
19
Demo
  • http//abilene.internet2.edu/observatory
  • http//abilene.internet2.edu/owamp/status_map.cgi

20
Questions?

21
www.internet2.edu
22
Additional Slides to Answer Questions if Needed
23
piPEs / AMI Development Testing Environment
24
Abilene OWAMP deployment
  • 2 overlapping full meshes (IPv4 IPv6)
  • 11 measurement nodes 220 ongoing tests
  • UDP singletons
  • Rate 10 packets/second
  • Packetsize (32 byte payload)
  • Results are continuously streamed back to
    Measurement Portal for long-term archive and
    data dissemination (Near real-time)

25
piPEs / AMI Internal Resources
  • Eric Boyd piPEs development, project
    coordination
  • Jeff Boote OWAMP, piPEs development
  • Prasad Calyam piPEs development
  • Raj Swaminathan piPEs development
  • Chris Heermann AMI
  • Matt Zekauskas - AMI
  • Susan Evett - Documentation
  • Russ Hobby Campus Deployment
  • George Brett Schema, Grid Service

26
piPEs External Resources
  • Yee-Ting Li UCL (50)
  • Paul Mealor UCL (up to 100)
  • Warren Matthews SLAC
  • Jim Ferguson et al NLANR / DAST
  • Nicolas Simar et al DANTE
  • Many early adopter volunteers

27
Testing / Analysis Engine
  • Problem Encode Matt Z.s Brain
  • Open Questions
  • What are measurement results are acceptable for
    a given application (family)?
  • What tools generate those results?
  • How do you handle incomplete data?
  • How do you rank multiple result-generators?
  • What is the iterative decision tree to understand
    E2E problem?

28
Measurement Schema
  • Measurement Types?
  • e.g. BW, Latency, Loss, Jitter
  • Measurement Units?
  • e.g. Seconds vs. Microseconds
  • Map Tools to Measurements?
  • e.g. OWAMP -gt 1-way Latency
  • Measurement Metadata?
  • Database Table Design?

29
Access, Authentication, Authorization
  • Roles for Access
  • Standard End-User?
  • Near Neighbor (Test Buddy)?
  • NOC Staff / Network Engineer?
  • Shibboleth for Implementation
  • Each campus decides who in each role
  • Others trust campus designation

30
Other RD Issues
  • Design system to scale (eliminate
    centralization)?
  • How to discover PMPs?
  • How to insert On-Demand tests into
    Regularly-Scheduled test set
  • Balance centralization and distributed database
    requirements
