Genes, Genomes, and Genomics

1
Genes, Genomes, and Genomics
Bioinformatics in the Classroom June, 2003
2
Two again
Francis Collins, HGP
Craig Venter, Celera Inc.
3
Whats in a chromosome?
4
Hierarchical vs. Whole Genome
5
How many genes?

• Consortium 35,000 genes?
• Celera 30,000 genes?
• Affymetrix 60,000 human genes on GeneChips?
• Incyte and HGS over 120,000 genes?
• GenBank 49,000 unique gene coding sequences?
• UniGene gt 89,000 clusters of unique ESTs?

6
Current consensus (in flux )

• 15,000 known genes (similarity to previously
  isolated genes and expressed sequences from a
  large variety of different organisms)
• 17,000 predicted (GenScan, GeneFinder, GRAIL)
• Based on and limited to previous knowledge

7
How to we get from here
8
to here,
9
What are genes? - 2

• Complete DNA segments responsible to make
  functional products
• Products
• Proteins
• Functional RNA molecules
• RNAi (interfering RNA)
• rRNA (ribosomal RNA)
• snRNA (small nuclear)
• snoRNA (small nucleolar)
• tRNA (transfer RNA)

10
What are genes? - 2

• Definition vs. dynamic concept
• Consider
• Prokaryotic vs. eukaryotic gene models
• Introns/exons
• Posttranscriptional modifications
• Alternative splicing
• Differential expression
• Genes-in-genes
• Genes-ad-genes
• Posttranslational modifications
• Multi-subunit proteins

11
Prokaryotic gene model

• Small genomes, high gene density
• Haemophilus influenza genome 85 genic
• Operons
• One transcript, many genes
• No introns.
• One gene, one protein
• Open reading frames
• One ORF per gene
• ORFs begin with start,
• end with stop codon (def.)

TIGR http//www.tigr.org/tigr-scripts/CMR2/CMRGen
omes.spl NCBI http//www.ncbi.nlm.nih.gov/PMGifs/
Genomes/micr.html
12
Eukaryotic gene model

• Large genomes, low gene density
• Homo sapiens genome 25 genic
• Posttranscriptional modification
• 5-CAP, polyA tail, splicing
• Open reading frames
• One ORF per exon, dont all contain starts/stops
• Mature mRNA contains ORF par definitionem
• Multiple translates
• One gene many proteins via alternative splicing

• Posttranscriptional modification
• 5-CAP, polyA tail, splicing
• Open reading frames
• One ORF per exon, dont all contain starts/stops
• Mature mRNA contains ORF par definitionem
• Multiple translates
• One gene many proteins via alternative splicing

13
Expansions and Clarifications

• ORFs
• Start triplets stop
• Prokaryotes gene ORF
• Eukaryotes gene ORF, or
• Final mRNA contains ORF
• Exons
• Remain after introns have been removed
• Flanking contain non-coding sequence (5- and
  3-UTRs)

14
Where do genes live?

• In genomes
• Example human genome
• Ca. 3,200,000,000 base pairs
• 25 chromosomes 1-22, X, Y, mt
• 28,000-45,000 genes (current estimate)
• 128 nucleotides (RNA gene) 2,800 kb (DMD)
• Ca. 25 of genome are genes (introns, exons)
• Ca. 1 of genome codes for amino acids (CDS)
• 30 kb gene length (average)
• 1.4 kb ORF length (average)
• 3 transcripts per gene (average)

15
Sample genomes
Species Size Genes Genes/Mb
H.sapiens 3,200Mb 35,000 11
D.melanogaster 137Mb 13.338 97
C.elegans 85.5Mb 18,266 214
A.thaliana 115Mb 25,800 224
S.cerevisiae 15Mb 6,144 410
E.coli 4.6Mb 4,300 934
 List of 68 eukaryotes, 141 bacteria, and 17
archaea at http//www.ncbi.nlm.nih.gov/PMGifs/Geno
mes/links2a.html
16
The value of genome sequences lies in their
annotation

• Annotation Characterizing genomic features
  using computational and experimental methods
• Genes Four levels of annotation
• Gene Prediction Where are genes?
• What do they look like?
• Domains What do the proteins do?
• Role What pathway(s) involved in?

17
So much DNA so few genes
18
Genomic sequence features I

• Repeats
• Transposable elements, simple repeats
• RepeatMasker
• Uses Smith Waterman algorithm to align sequences
  to known repeats
• Advantage avoid spurious matches to repetitive
  elements
• Disadvantage mask sequences that gene
  prediction programs may need for statistics

19
Genomic sequence features II

• Non-coding RNAs (ncRNA)
• tRNA tRNASCAN-SE
• Identifies candidates by scanning for pol III
  promoters. Then it uses an algorithm to determine
  the RNA.
• rRNA, snRNA, miRNA, etc. COVE
• Identified by performing similarity searches and
  RNA structure analysis using covariance models.

20
Genomic sequence features III

• Genes
• Vary in density, length, structure, number of
  introns, number of splice forms, etc.
• Identification method depends on evidence,
  expertise and methods available.
• Gene identification usually requires concerted
  application of bioinformatics methods and wet
  experimentation.
• Pseudo genes
• Look-a-likes of genes not transcribed. Obstruct
  gene finding efforts.

21
Gene identification

• Homology-based gene prediction
• Similarity Searches (e.g. BLAST, BLAT)
• Genome Browsers
• RNA evidence (ESTs)
• Ab initio gene prediction
• Gene prediction programs
• Prokaryotes
• ORF identification
• Eukaryotes
• Promoter prediction
• PolyA-signal prediction
• Splice site, start/stop-codon predictions

22
Gene prediction through comparative genomics

• Purifying selection Conserved regions between
  two genomes are useful or else they would have
  diverged.
• If genomes are too close in the phylogenetic
  tree, there may be too much noise.
• If genomes are too far apart, analogous regions
  may be missed.

23
Genome Browsers
NCBI Map Viewer www.ncbi.nlm.nih.gov/mapview/
Generic Genome Browser (CSHL) www.wormbase.org/db
/seq/gbrowse
Ensembl Genome Browser www.ensembl.org/
UCSC Genome Browser genome.ucsc.edu/cgi-bin/hgGate
way?orghuman
Apollo Genome Browser www.bdgp.org/annot/apollo/
24
Gene discovery using ESTs

• Expressed Sequence Tags (ESTs) represent
  sequences from expressed genes.
• If region matches EST with high stringency then
  region is probably a gene or pseudo gene.
• EST overlapping exon boundary gives an accurate
  prediction of exon boundary.

25
Tools for EST analysis

• BLAST (Basic Local Alignment Search Tool)
• Smaller exons will be missed due to smaller
  score.
• SIM4 (http//pbil.univ-lyon1.fr/sim4.html)
• Useful tool to map a gene to genomic sequence
• Allows for large gaps (introns)

26
Ab initio gene prediction

• Prokaryotes
• ORF-Detectors
• Eukaryotes
• Position, extent direction through promoter
  and polyA-signal predictors
• Structure through splice site predictors
• Exact location of coding sequences through
  determination of relationships between potential
  start codons, splice sites, ORFs, and stop codons

27
Tools

• ORF detectors
• NCBI http//www.ncbi.nih.gov/gorf/gorf.html
• Promoter predictors
• CSHL http//rulai.cshl.org/software/index1.htm
• BDGP fruitfly.org/seq_tools/promoter.html
• ICG TATA-Box predictor
• PolyA signal predictors
• CSHL argon.cshl.org/tabaska/polyadq_form.html
• Splice site predictors
• BDGP http//www.fruitfly.org/seq_tools/splice.htm
  l
• Start-/stop-codon identifiers
• DNALC Translator/ORF-Finder
• BCM Searchlauncher

28
How it works I Motif identification

• Exon-Intron Borders Splice Sites

Exon Intron
Exon  gaggcatcaggtttgtagactgtgtttcag
tgcacccact ccgccgctgagtgagccgtgtc
tattctaggacgcgcggg tgtgaattaggtaagaggtt
atatctccagatggagatca ccatgaggaggtgagtg
ccattatttccaggtatgagacg
Splice site Splice site
Exon Intron
Exon  gaggcatcagGTttgtagactgtgtttcAG
tgcacccact ccgccgctgaGTgagccgtgtc
tattctAGgacgcgcggg tgtgaattagGTaagaggtt
atatctccAGatggagatca ccatgaggagGTgagtg
ccattatttccAGgtatgagacg
Splice site Splice site
Motif Extraction Programs at http//www-btls.jst.g
o.jp/
29
How it works II - Movies
Pribnow-Box Finder 0/1 Pribnow-Box Finder all
30
How it works III The (ugly) truth
31
Gene prediction programs

• Rule-based programs
• Use explicit set of rules to make decisions.
• Example GeneFinder
• Neural Network-based programs
• Use data set to build rules.
• Examples Grail, GrailEXP
• Hidden Markov Model-based programs
• Use probabilities of states and transitions
  between these states to predict features.
• Examples Genscan, GenomeScan

32
Rule Based - GeneFinder

• Compares expected vs. observed frequencies to
  score features such as codon bias via Log
  Likelihood Ratios (LLR).
• Each position of a sequence is scored in respect
  to its potential of being a splice site or
  translational start site.
• LLR scores and ORF identification determine
  maximum-length coding segments.
• Total score for a gene is the sum of exon scores
  minus the gap penalty.
• Rather bad for first and last exons.

33
Neural Networks - Grail, GrailEXP

• Utilizes sensors trained on a set of known genes
  of the organism.
• Sensors examine
• Frame Bias Matrix - Uses codon bias to determine
  ORFs.
• Fickett Pentamer position weight matrices.
• Dinucleotide Fractal Dimensions - Transition of
  sequential dinucleotides is represented as
  fractal dimension. CDS differ from nCDS.
• GrailExp incorporates similarity-based method by
  adding a blastn component to its prediction
  algorithm. Runs reliably on unmasked sequences.

34
HMM Genscan, Genomescan

• Genscan uses known transcriptional and
  translational signals and then uses HMM to model
  coding and non-coding regions.
• Genomescan incorporates similarity-based method
  by adding a blastX component to its prediction
  algorithm, using the translated sequence to
  search protein db.

35
Evaluating prediction programs

• Sensitivity vs. Specificity
• Sensitivity
• How many genes were found out of all present?
• Sn TP/(TPFN)
• Specificity
• How many predicted genes are indeed genes?
• Sp TP/(TPFP)
• Programs that combine statistical evaluations
  with similarity searches most powerful.

36
Gene prediction accuracies

• Nucleotide level 95Sn, 90Sp (Lows less than
  50)
• Exon level 75Sn, 68Sp (Lows less than 30)
• Gene Level 40 Sn, 30Sp (Lows less than 10)
• Selected readings
• Parra et al. (2003). Comparative Gene Prediction
  in Human and Mouse. Genome Research 13108-117.
• Rogic et al. (2001). Evaluation of Gene-Finding
  Programs in Mammalian Sequences. Genome Research
  11817-832.
• Guigo et al. (2000). An Assessment of Gene
  Prediction Accuracy in Large DNA Sequences.
  Genome Research 101631-1642.
• Reese et al. (2000). Genome Annotation Assessment
  in Drosophila melanogaster. Genome Research
  10483-501.
• Burge and Karlin (1997). Prediction of Complete
  Gene Structures in Human Genomic DNA Tab. 1. JMB
  26878-94.

37
Common difficulties

• First and last exons difficult to annotate
  because they contain UTRs.
• Smaller genes are not statistically significant
  so they are thrown out.
• Algorithms are trained with sequences from known
  genes which biases them against genes about which
  nothing is known.
• Masking repeats frequently removes potentially
  indicative chunks from the untranslated regions
  of genes that contain repetitive elements.

38
The annotation pipeline

• Mask repeats using RepeatMasker.
• Run sequence through several programs.
• Take predicted genes and do similarity search
  against ESTs and genes from other organisms.
• Do similarity search for non-coding sequences to
  find ncRNA.

39
Annotation nomenclature

• Known Gene Predicted gene matches the entire
  length of a known gene.
• Putative Gene Predicted gene contains region
  conserved with known gene. Also referred to as
  like or similar to.
• Unknown Gene Predicted gene matches a gene or
  EST of which the function is not known.
• Hypothetical Gene Predicted gene that does not
  contain significant similarity to any known gene
  or EST.
