Underway Replenishment

1
Underway Replenishment
2
Lesson Contents

• Replenishment Ships
• UNREP Terms
• UNREP Procedures

• RAS Equipment
• UNREP Communications

3
UNREP Ships

• Oilers
• Cimarron (AO-177)
• Henry J Kaiser (TAO-187)
• Ammunition Ships
• Kilauea (TAE-26)
• Combat Stores Ships
• Mars (TAFS-1)
• Sirius (TAFS-8)

• Fast Combat Support Ships
• Sacramento (AOE-1)
• Supply (AOE-6)
• Aircraft Carriers (CV/CVN)
• Amphibious Assault Ships (LHA/LHD)

4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
Replenishment Terms

• Underway Replenishment (UNREP)
• any method of transferring fuel, ammunition, and
  stores from one ship to another
• Replenishment at Sea (RAS)
• same as above specifically for fuel transfer
• Fueling at Sea (FAS)
• any method of transferring fuel

9
Replenishment Terms

• Connected Replenishment (CONREP)
• a method of transferring fuel, ammunition, and
  stores from one ship to another through lines and
  hoses connecting the two ships.
• Vertical Replenishment (VERTREP)
• a method of transferring ammunition and stores
  from one ship to another by helicopter

10
Connected ReplenishmentMethods

• Cargo
• STREAM Method
• Highline Method
• Burton Method
• Housefall Method

• Fuel
• STREAM Method
• Astern Refueling Method
• Close-In Method

11
STREAM

• Standard Tensioned REplenishment Alongside Method
• uses a tensioned spanwire to support the cargo
  trolley or the fueling hose from the delivery
  ship to the receiving ship

12
Cargo STREAM Components
Padeye (Sliding or Fixed)
Receiving Ship
Delivery Ship
13
Fuel STREAM Components
Padeye
Probe Receiver
Receiving Ship
Delivery Ship
14
Replenishment Terms

• ROMEO CORPEN / ROMEO SPEED
• Replenishment Course and Speed
• Course and speed used during UNREP

15
Replenishment Terms

• Control Ship
• Guide
• Responsible for staying on R CORPEN and SPEED
• usually the delivery ship except when receiving
  ship is a carrier

16
Replenishment Terms

• Approach Ship
• Responsible for making the approach on the
  control ship

17
Replenishment Terms

• Delivery Ship
• usually the control ship
• supplies fuel, ammunition or stores to the
  receiving ship
• Receiving Ship
• receives fuel, ammunition, or stores from the
  supply ship

18
Replenishment Procedures

• 3-4 days prior
• receiving ship submits a LOGREQ
• LOGREQ (Logistics Request)
• requests stores, fuel, parts
• LOGREQ reply
• name of delivery ship
• rendezvous location and time
• breakdown of supplies to be transferred
• expected R CORPEN/SPEED

19
Replenishment Procedures

• Day of replenishment
• Rendezvous at appointed place and time
• Control ship
• takes tactical control of all ships to be
  replenished
• establishes R CORPEN/SPEED
• assigns stations and order of connected
  replenishment

20
Replenishment Formation(Connected Replenishment)
Control Ship
Replenishment Station Port 270R 30-50yds
Replenishment Station Stbd 090R 30-50yds
Waiting Station Port
Waiting Station Stbd
Lifeguard Station 180R 1,000yds
21
Replenishment Formation(Vertical Replenishment)
Control Ship
VERTREP Station anywhere within 5,000yds
of Delivery Ship except replenishment
station waiting station and lifeguard station
22
Replenishment Formation
Control Ship
Approach Ship
500yds
1. Steady on R Corp/Spd 2. Making preps to
receive on starboard side
In waiting station
23
In Waiting Station

• Examine the wake of control ship
• Your wake should be parallel / keep about 5yd
  separation between wakes
• Match speeds with control ship
• Determine Lateral Separation Using Radian Rule

24
Lateral Separation

• 100-120 ft (30-40yds) for most combatants
• 150ft (50yds) for carriers / less maneuverable
  ships

25
Radian Rule
D
R
?
? 6 degrees or 354R
26
Replenishment Formation
Control Ship
Approach Ship
500yds
Ready for approach
In waiting station
27
Replenishment Formation
Control Ship
Approach Ship
Ready for approach
Ready for approach Increases speed to at least
3-5 kts faster than R Speed
28
Replenishment Formation
Control Ship
Approach Ship
Ready for approach
(300-500yds) Commencing Approach
29
Replenishment Formation
Control Ship
Approach Ship
Ready for approach
(300-500yds) Commencing Approach
30
Coming Alongside

• Two methods
• Coast-in Method
• Slow to R Speed at a predetermined point and
  coast in
• Back Down Method
• All Back 2/3, then before ship slows too fast,
  speed up engines to R Speed

31
Ship to Ship Interaction
32
Replenishment
Control Ship
Approach Ship
1st Line
33
Phone and Distance Line
Day
G
R
Y
B
W
G
Night
Control Ship
Approach Ship
Double Blue Chemlights at 60, 100, 140, 180 yds
34
Replenishment
Delivery Ship
Receiving Ship
15 mins to breakaway
35
Replenishment
Delivery Ship
Receiving Ship
Executing breakaway
36
Breakaway

• Receiving ship returns all lines and rigging in
  an orderly fashion.
• Delivery ship returns phone and distance line.
• Receiving ship prepares breakaway song.

37
Emergency Breakaway

• Accelerated normal breakaway.
• Either ship can initiate for any reason
• engineering casualty
• steering casualty
• Sound six short blasts on whistle
• Sound Emergency Breakaway over 1MC

38
Breakaway
Delivery Ship
Receiving Ship
All lines clear
