Functions

1
Chapter 3

• Functions

2
1. Introduction

• Experience has shown that the best way to develop
  and maintain a large program is to construct it
  from smaller pieces or components.
• This chapter describes many key features of the
  C language that facilitate the design,
  implementation, operation, and maintenance of
  large programs.

3
2. Program Components in C

• C programs are typically written by combining
  new functions the programmer writes with
  pre-packaged functions available in the C
  standard library.
• You need to familiarize yourself with the rich
  collection of functions and classes in the C
  standard library.

4
3. Math Library Functions

• Math library functions allow the programmer to
  perform certain common mathematical calculations.
• Functions are normally called by writing the name
  of the function followed by a left parenthesis
  followed by the argument (or comma separated
  argument list) followed by a right parenthesis
• cout ltlt sqrt ( 900.0 )

5
3. Math Library Functions (cont.)

• To use the math library functions include the
  header file math.h (this header file is called
  cmath in the new C standard library)
• Forgetting to include the math header file when
  using math library functions is an error.
• Some math library functions are summarized in
  Figure 3.2 (pg. 147)

6
4. Functions

• Functions allow the programmer to modularize a
  program.
• All variables declared in function definitions
  are local variables -- they are known only in the
  function in which they are defined.
• Most functions have a list of parameters that
  provide a means for communicating information
  between functions.
• A functions parameters are also local variables.

7
5. Function Definitions

• The format of a function definition is
  ret-type func-name ( param-list)
  declarations and statements
• The return-type of void indicates that a function
  does not return a value.

8
5. Function Definitions (cont.)

• The declarations and statements in braces form
  the function body, or block.
• Variables can be declared in any block
• There are three ways to return control to the
  point at which a function was invoked.
• when the function-ending right brace is reached
• return
• return expression

9
6. Function Prototypes

• A function prototype tells the compiler the name
  of the function, the type of data returned by the
  function, and the number of parameters the
  function expects to receive, the types of these
  parameters, and the order in which they are
  expected.
• The compiler uses function prototypes to validate
  function calls.

10
6. Function Prototypes (cont.)

• Given the following prototype int maximum
  (int, int, int)
• This prototype states that maximum takes three
  arguments of type int, and returns a result of
  type int.
• Another important feature of function prototypes
  is the coercion of arguments (forcing of
  arguments to the appropriate type)

11
7. Header Files

• Each standard library has a corresponding header
  file containing the function prototypes for all
  the functions in the library and definitions of
  various data types and constants needed by these
  functions.
• Figure 3.6 (pg. 155) lists some common C
  standard library header files that may be
  included in C programs.

12
7. Header Files (cont.)

• Standard library header files are use by putting
  the file name inside lt gt , for example include
  ltstdlib.hgt
• The programmer can create custom header files.
  These should end in .h These are included by
  putting the file name inside double quotes, for
  example include square.h

13
8. Random Number Generation

• Consider the following statement i rand( )
• This generates an integer between 0 and RAND_MAX
  (a symbolic constant defined in ltstdlib.hgt)
• Scale the output with the modulus () operator
  i rand( ) 6 This would produce numbers
  from 0 to 5

14
8. Random Number Generation (cont.)

• The rand function actually produces pseudo-random
  numbers.
• You seed the random number generator by passing a
  seed to the function srand ( ) srand( seed )
• Typically you seed it with the clock. srand (
  time (0) )

15
9. A Game of Chance and Introducing enum

• The line enum Status CONTINUE, WON,
  LOST creates a user-defined type called an
  enumeration
• Variables of type Status can only be defined one
  of the values declared in the enumeration.

16
10. Storage Classes

• C provides four storage class specifiers auto,
  register, extern, and static.
• An identifiers storage class determines the
  period during which that identifier exists in
  memory.
• The storage class specifiers can be split into
  two storage classes automatic storage class and
  static storage class (dynamic will be discussed
  later)

17
10. Storage Classes (cont.)

• Automatic Storage Class.
• The auto and register keywords are used to
  declare variables of the automatic storage class.
• Such variables are created when the block in
  which they are declared is entered, and they
  exist while the block is active, and they are
  destroyed when the block is exited.
• the auto keyword is rarely used.
• the register keyword can be ignored by the
  compiler.

18
10. Storage Classes (cont.)

• Static Storage Class
• The keywords extern and static are used to
  declare identifiers for variables and functions
  of the static storage class.
• Such variables exist from the point at which the
  program begins execution until termination.

19
10. Storage Classes (cont.)

• Static Storage Class (cont.)
• Local variables declared static are still known
  only in the function in which they are defined,
  but they retain their values when the function
  exits.
• In the following line static int count 1
  the variable is initialized only one time.
• extern and static are discussed in Chap. 18

20
11. Scope Rules

• The portion of the program where an identifier
  has meaning is known as its scope.
• For example, when we declare a local variable in
  a block, it can be referenced only in that block
  (or blocks nested within that block)
• Storage duration (or Lifetime) does not affect
  the scope of an identifier.

21
12. Recursion

• A recursive function is one that calls itself
  either directly or indirectly through another
  function.
• Recursive functions have two parts
• Stopping Condition(s) -- solving the base
  case(s).
• Recursive call -- breaking the problem down.

22
12. Recursion (cont.)

• long factorial ( long number )
  if (number lt 1 ) // base case return
  1 else // recursive case return
  number factorial ( number -1 )

23
13. Example Using Recursion The Fibonacci Series

• The Fibonacci series 0, 1,1,2,3,5,8,13,21,
  begins with 0 and 1 and has the property that
  each subsequent Fibonacci number is the sum of
  the previous two.
• The function to calculate the ith Fibonacci
  number is quite naturally recursive.
• What would the code for this would look like

24
14. Recursion vs. Iteration

• Similarities
• Both iteration and recursion are based on a
  control structure (iteration uses a repetition
  structure recursion uses a selection structure)
• Both iteration and recursion involve repetition
  Iteration explicitly uses a repetition structure
  recursion achieves repetition through repeated
  function calls.

25
14. Recursion vs. Iteration (cont.)

• Similarities (cont.)
• Iteration and recursion each involve a
  termination test (iteration terminates when the
  loop condition fails recursion terminates when a
  base case is recognized).
• Both iteration and recursion can occur
  infinitely An infinite loop can occur with
  iteration, and infinite recursion can occur when
  the base case is not reached.

26
14. Recursion vs. Iteration (cont.)

• Recursion has many negatives
• It repeatedly invokes the mechanism, and
  consequently the overhead, of function calls.
• This can be expensive in both terms of processor
  time and memory.
• So Why use recursion?
• some problems map very nicely to a recursive
  solution. Thereby making code writing easier.

27
15. Functions with Empty Parameter Lists

• In C, an empty parameter list is specified by
  writing either void or nothing at all in
  parentheses. The declaration void
  print ( ) specifies that the
  function print does not take any arguments and
  does not return a value.

28
16. Inline Functions

• Implementing a program as a set of functions is
  good from a software engineering standpoint, but
  function calls involve execution-time overhead.
• C provides inline functions to help reduce
  function-call overhead -- especially for small
  functions.

29
16. Inline Functions (cont.)

• The qualifier inline before a functions return
  type advises the compiler to generate a copy of
  the functions code in place (where appropriate)
  to avoid a function call.
• The tradeoff is larger compiled code.
• inline float cube ( const float s)
  return s s s

30
17. References and Reference Parameters

• Two ways to invoke functions in many programming
  languages are call-by-value and
  call-by-reference.
• When an argument is passed call-by-value, a copy
  of the arguments value is made and passed to the
  called function.
• With call-by-reference, the caller gives the
  called function the ability to directly access
  the callers data, and to modify it.

31
17. References and Reference Parameters (cont.)

• Call-by-reference is good for performance reasons
  because it eliminates the overhead of copying
  large amounts of data.
• A reference parameter is an alias for its
  corresponding argument.
• To indicate that a function parameter is passed
  by reference, simply follow the parameters type
  in the function prototype by an ampersand () and
  use the same convention in the header.

32
17. References and Reference Parameters (cont.)

• void sqr_by_ref( int cRef)
  cRef cRef // cRef is changed
• To specify a reference to a constant, place the
  const qualifier before the type. This gives the
  security of call-by-value but avoids the overhead
  of copying a large object.

33
17. References and Reference Parameters (cont.)

• References can also be used as aliases for other
  variables within a function
• int count 1 // variable int cRef count
  // alias cRef //increments count
  //using its alias
• Reference variables must be initialized in their
  declarations and cannot be reassigned to other
  variables.

34
18. Default Arguments.

• Function calls may commonly pass a particular
  value of an argument. The programmer can specify
  that such an argument is a default argument, and
  can provide a default value for that argument.
• When a default argument is omitted in a function
  call, the default value of that argument is
  automatically inserted by the compiler and passed
  in the call.

35
18. Default Arguments. (cont.)

• Default arguments must be the rightmost arguments
  in the functions parameter list.
• int boxVolume (int length 1, int width
  1, int height 1)
• Appropriate calls
• cout ltlt boxVolume()
• cout ltlt boxVolume(10)
• cout ltlt boxVolume(10, 5)
• cout ltlt boxVolume (10, 5, 2)

36
19. Unary Scope Resolution Operator

• It is possible to declare local and global
  variables of the same name. C provides the
  unary scope resolution operator () to access a
  global variable.
• cout ltlt name // local variable cout ltlt
  name // global variable
• Example code pg. 189.

37
20. Function Overloading

• C enables several functions of the same name to
  be defined as long as these functions have
  different sets of parameters (at least as far as
  their types are concerned)
• Overloading functions that perform closely
  related tasks can make the program more readable
  and understandable.

38
21. Function Templates

• Overloaded functions are normally used to perform
  similar operations that involve different program
  logic on different data types.
• If the program logic and operations are identical
  for each data type, this may be performed more
  compactly and conveniently using function
  templates.

39
21. Function Templates (cont.)

• All function template definitions begin with the
  template keyword followed by a list of formal
  type parameters to the function enclosed in angle
  brackets (lt and gt).
• Every formal type parameter is preceded by the
  class keyword.
• The function definition follows and is defined
  like any other function.

40
21. Function Templates (cont.)

• Example template ltclass Tgt T maximum
  (T val1, T val2) T max
  val1 if (val2 gt max) max val2
  return max

41
21. Function Templates (cont.)

• Sample calls
• cout ltlt maximum(1,2)
• cout ltlt maximum (3.5, 4.7)
• cout ltlt maximum (c, h)
• With this code, three functions are created and
  compiled, one for integers, one for doubles, and
  one for characters.
