Web-based DatabasesTechnical Implementation
2
Introduction

• Working at the CERN laboratory in Geneva in 1989,
  Tim Berners-Lee initiated his WWW Project based
  on three key concepts Uniform Resource Locators
  (URLs), Hypertext Transfer Protocol (HTTP), and
  Hypertext Markup Language (HTML)
• URLs define uniquely where documents (resources)
  can be found on the network
• HTTP is the protocol used to transfer Web pages
  via a TCP/IP network from a Web server to a Web
  browser.
• It is a stateless protocol, meaning that each
  connection is closed once the server responds. In
  other words, each request is executed
  independently, without any knowledge of the
  requests that came before it. This statelessness
  is incompatible with the concept of a database
  transaction.
• Programmers get around this by the use of cookies
  and server APIs
• HTML is a document formatting language used to
  create Web pages

3
Introduction

• The Web has been hugely successful, because it is
  simple to use, portable, platform-independent,
  has a standard interface, is inexpensive (low
  cost-per-desktop) and supports distributed
  hypermedia
• However, the biggest shortcoming of the Web is
  that, in its most basic form, it is file-based
  and static
• It has all the disadvantages of file-based
  systems redundancy, duplication, absence of
  referential integrity (dangling 404 links),
  poor version control, poor support for multi-user
  authoring, etc.
• Files are static structures the content of the
  Web document does not change unless the source
  file itself changes. On the other hand, a dynamic
  Web page is one that is generated on-the-fly
  each time it is accessed
• Dynamic Web documents can
• respond to user input from the client browser,
  such as a HTML form
• be customised for and by individual users, e.g by
  use of cookies

4
Databases and E-Commerce

• Moving to a database has implications
• if a site merely consists of a few HTML pages,
  then a basic PC could theoretically act as the
  Web server
• however, a database-driven site needs a powerful
  machine laden with memory and with
  multiprocessing capabilities
• Increasingly, Web sites incorporate intelligent
  value-adding services for example
• context-related banner advertising (e.g
  Altavista)
• boost sales or suggest purchases by building
  profiles and monitoring buyer behaviour (e.g
  Amazon, CD Universe)
• Successful brand relationships are based on
  trust, as well as a deep understanding of each
  individual - their personal tastes, interests,
  expertise, and opinions
• This is not a mass market of 100 million people,
  this is 100 million markets each with one person
  in it (Tom Vassos, IBM)
• Databases are the backbone of e-commerce /
  Internet marketing

5
Web-DBMS Integration

• Many DBMS vendors (e.g Oracle, Microsoft, Lotus)
  provide proprietary solutions
• It is preferable to establish a generic set of
  requirements before selecting/acquiring a
  specific solution. These requirements are
• secure data access with authentication mechanisms
• open systems which are interoperable and support
  connectivity via non-proprietary standards
• scalable, maintainable, cost-effective technology
• ease-of-use and ease-of-administration
• acceptable performance
• powerful application development / application
  generation capabilities which support flexible,
  customisable solutions
• support for transactions that span multiple HTTP
  requests

6
Web-DBMS Integration
DBMS server
Three-tier Architecture
Web browser
DBMS server
Web server
Netscape Navigator, Microsoft Internet Explorer,
etc.
Microsoft SQL Server, Oracle, Informix, Sybase,
etc.
Web browser
Apache, Microsoft Internet Information Server
(IIS), NCSA Server, CERN Server, etc.
DBMS server
7
Web-DBMS Integration

• There are a variety of approaches to integrating
  the Web and databases
• Common Gateway Interface (CGI)
• Server-Side Directives
• Cookies
• Server Application Programming Interface (API)
• Java / JDBC / JSQL
• Javascript / JScript
• Active Server Pages (ASP) , VBScript and ActiveX
• ColdFusion
• PHP
• CORBA

8
Common Gateway Interface (CGI)

• A CGI script can generate pages dynamically
• CGI scripts are typically written in PHP, C,
  Perl, Awk, Tcl, or Unix shell scripts
• Parameters may be passed by the browser
  (typically using a HTML form) to the server in
  encoded namevalue pairs
• The CGI script then decodes and splits the
  parameters, executes its tasks, and usually
  returns a file/document of a server-configured
  MIME type to the client for example
• Web user submits product order via a Web form
  CGI processes data and returns either an
  acknowledgement of receipt or an input validation
  error in HTML format
• Web user submits a query to find a video clip
  CGI script searches the server and returns the
  clip in MPEG format
• Web user submits a request to search an on-line
  email directory CGI script connects to the
  directory database, processes the query, and
  sends back data as plain text TXT format

9
Common Gateway Interface (CGI)

• Advantages
• Web server independence
• Language independence
• Wide acceptance
• Simplicity
• Disadvantages
• All CGI communication between client (browser)
  and server back-end must pass through the Web
  server hence, there may be bottlenecks
• Statelessness of HTTP means that transactions
  cannot be readily supported
• Possible security problems with CGI scripts
  (backdoors)
• High overhead on server of multiple threads being
  concurrently executed

10
Server Side Directives

• A server-side directive / server-side include is
  an embedded instruction in a HTML file that is
  parsed by the server when the document is
  requested
• With NCSA-compliant servers, you can
• include the current time/date in a designated
  format
• include the results of an executable programme,
  system command, or CGI script
• include text / HTML code contained in another
  file
• include document history data (date created, date
  last modified)
• Server-side directives add overheads on the
  server, and are potential security hazards

11
Cookies

• Cookies are small text files that are stored on
  the browser machine
• Once a CGI script is invoked, it either creates
  the cookie (if it is a first time visit) or it
  takes the parameters saved in the cookie
• a common example is to save someones name,
  address, credit card details in a cookie so that
  greetings may be personalised and default values
  may be filled in on an order form
• Not all browsers support cookies, for security
  reasons

12
Server APIs

• Server APIs are proprietary non-CGI gateways
  that extend the services of a Web server for
  example
• Microsofts IIS Web server has an API called
  ISAPI
• Netscapes Web servers offer the NSAPI
• APIs create connections between the Web server
  and back-end applications using OLE/ActiveX,
  DLLs, DCOM, shared objects, etc.
• API programming is significantly more difficult
  than CGI programming, but overcomes most of its
  drawbacks

13
Java

• Java is a proprietary language created by Sun
  Microsystems although proprietary, Sun ardently
  protect it as a standard to assure conformance
• non-conformant derivatives and extensions can be
  problematic (e.g Microsoft J)
• Java is a write once-run anywhere language
• With previous open languages, such as C, the
  source code had to be separately compiled to
  machine code for each target platform
• Java compiles to byte-code, which can then be
  interpreted by a Java Virtual Machine (JVM)
• Most WWW browsers have embedded JVMs, so Java
  applets can be included within Web documents

14
JDBC / JSQL

• JDBC (Java Database Connectivity) is modelled
  after Microsofts ODBC
• JDBC is a layer between the Java application
  (applet) and the DBMS
• A JDBC driver for the particular DBMS must be
  installed
• Connections / calls to the database are made
  using formatted instructions as specified by the
  JDBC API
• JSQL is a mechanism by which static SQL
  statements may be embedded in Java. The Java
  class libraries are extended so as to be able to
  recognise and parse programmatic SQL statements

15
Javascript / JScript

• Javascript is a scripting language developed by
  Netscape it more closely resembles C than Java
• JScript is Microsofts version of Javascript
  they are not fully compatible with each other
• Both Javascript and JScript are primarily for
  client-side scripts embedded within HTML
  documents
• Netscape LiveWire Pro supports server-side
  Javascript with additional constructs for
  database connectivity

16
Microsoft Active Components

• Microsoft Active Server Pages (ASPs) can
  dynamically generate Web pages on-the-fly by
  embedding instructions within document templates
• The instructions activate ActiveX components,
  VBScript / JScript modules, and/or SQL commands
  which are parsed at run-time
• ASPs run on Microsoft IIS server, and can
  generate pages based on what browser type the
  user has, what language the users machine
  supports, and on what preferences the user has
  specified

17
Macromedia ColdFusion

• ColdFusion is an easy-to-learn server-side
  scripting language
• It supports rapid application development
• Cold Fusion Markup Language (CFML) is embedded
  into HTML code
• Connect with database and run query
  simultaneously
• ltCFQUERY Name"Patients" dbtype"dynamic"
  connectstring"DBdriver DBfile"gt SELECT ID,
  FirstName, LastName FROM Patients ORDER BY
  FirstNamelt/CFQUERYgt
• Access Query Results
• ltSELECT name"PatientID"gt ltCFoutput
  QUERY"Patients"gt ltOPTION valueIDgt
  FirstName LastName lt/OPTIONgt lt/CFoutputgtlt/SE
  LECTgt
• Insert Data using Cfquery (SQL)
• ltCFquery name"Treatment" dbtype"dynamic"
  connectstring"DBdriver DBfile"gt INSERT into
  Treatment VALUES (PatientID, EventID, Now(),
  Dosage, Severity, Time)lt/CFquerygt

18
Sample ColdFusion Code

• ltcfquery name"GetRecordtoUpdate"
  datasource"StudentInfo"gt
• SELECT FROM student WHERE student_ID
  URL.student_ID
• lt/cfquerygt
• lthtmlgt
• ltheadgt
• lttitlegtUpdate Formlt/titlegt
• lt/headgt
• ltbodygt
• ltcfoutput query"GetRecordtoUpdate"gt
• ltform action"updateaction.cfm" method"Post"gt
• ltinput type"Hidden" namestudent_ID"
  value"student_ID"gt
• ltbrgt
• ltlabel for"first_name"gt First Name lt/labelgt
• ltinput type"text" name"first_name"
  id"first_name" value"f_name"gt
• ltbrgt
• ltlabel for "last_name"gtLast Name lt/labelgt

Copy paste this code into Dreamweaver to see
how it works
19
PHP

• PHP is a widely-used general-purpose scripting
  language that is especially suited for Web
  development and can be embedded into HTML
• www.php.net
• PHP Hypertext Pre-processor
• PHP can be run as a CGI binary, but more
  generally it is integrated as a module into
  server software (e.g. Apache)
• Very commonly used in conjunction with Apache
  server and MySQL database (all open source)
• See introductory tutorial at http//ie2.php.net/tu
  t.php

20
PHP A Simple Example
ltHTMLgt ltBODYgt lt?PHP db mysql_connect("loca
lhost", "dbuser") mysql_select_db("mydb",db)
result mysql_query("SELECT fname, lname,
position FROM employees",db) ?gt ltTABL
E BORDER1gt ltTRgtltTDgtNAMElt/TDgtltTDgtPOSITIONlt/TRgt
lt?PHP while (myrow mysql_fetch_row(result))
printf("lttrgtlttdgts slt/tdgtlttdgtslt/tdgtlt/trgt\
n", myrow1, myrow2, myrow3)
?gt lt/TABLEgt lt/BODYgt lt/HTMLgt
21
CORBA

• Common Object Request Broker Architecture (CORBA)
  is an open standard three-tier model with
  client/server capabilities
• Any object can communicate with any other object
  for example, one Java applet can send
  requests/instructions to another
• CORBA is a better alternative to CGI
• CORBA replaces CGI
• IIOP replaces HTTP
• It is faster because the client (browser) can
  invoke an object
• CORBA maintains state between invocations
• CORBA objects may be distributed across multiple
  servers

22
OMG CORBA
Web browser
DBMS server
ORB
O R B
O R B
Objects
TPS
Web browser
ORB
Tier 3 Legacy Applications
Tier 2 Server
Tier 1 Client
23
From HTML to XML

• Computers are fundamentally dumb something that
  is common sense and obvious in a given
  context to a human may be meaningless to a
  machine
• Machines use meta-data to describe the semantics
  of information
• HTML is superficial it merely describes how a
  Web browser should present and arrange text,
  images and push-buttons
• a major shortcoming of HTML is the absence of
  semantics
• Extensible Markup Language (XML), released as a
  standard by W3C in 1998, redresses this, and has
  been enthusiastically adopted into industries
  ranging from manufacturing to medicine
• XML separates content and presentation XML by
  itself describes content presentation (layout
  format) is specified using Extensible Stylesheet
  Language (XSL) / Cascading Style Sheets (CSS)

24
HTML Problems

• In its present from, Web data is no more
  intelligible than a fax transmission
• Your doctor may be able to pull up your drug
  reaction history on his Web browser, but he
  cannot then e-mail it to a specialist and expect
  her to be able to paste the records directly into
  the a hospital database. Her computer would not
  know what to make of the information, which would
  be no more intelligible to it than ltH1gtblah
  blahlt/H1gt ltBgtblah blah blahlt/Bgt
• It is hoped that XML can help resolve two of the
  Web's biggest inhibiting problems
• the Internet is a speed-of-light network that
  often moves at a crawl
• although nearly every kind of information is
  available on-line, it can be maddeningly
  difficult to find the one piece you need
• Both problems arise in large part from the
  superficial nature of HTML

25
HTML Problems

• HTML slows down response times
• Today's on-line interactive Web sites are often
  slow to respond. If you merely change the
  quantity or shipping method of your order, with
  the effect that only a few digits have changed in
  the total, you must ask a distant, overburdened
  server to send you an entirely new page, graphics
  and all !
• HTML is poor for Web searches
• Because there is no way to mark-up something as,
  for example, the price of an item, it is
  effectively impossible to use price information
  in your searches

26
Sample Document HTML

• Example The following rendered HTML document has
  an obvious extrinsic meaning (to the reader), but
  it has no intrinsic meaning (to the computer)

27
Sample Document HTML
To the computer, this is just a HTML table
consisting of rows and columns
28
Sample Document XML
29
Data Interrogation

• If a document is encoded in XML using an agreed
  Document Type Definition (DTD), then it may be
  interrogated using data manipulation languages
  such as SQL, XQL, XML-QL for example
• SELECT Result.Mark
• FROM Exam_Results
• WHERE Student_ID 84068912
• AND Result.Code MS859

30
XML and Document Exchange

• For centuries, people have conducted business by
  exchanging standard-format documents such as
  purchase orders and invoices
• However, HTML was not designed with the purpose
  of business-to-business document exchange in mind

• XML, in contrast, was designed specifically for
  such a purpose and can therefore facilitate
  electronic commerce
• In HTML, a document is encoded for a particular
  language. This means that it may be impossible,
  for example, to exchange documents between
  Ireland (English) and South Korea (Hangul)
• Because XML uses Unicode, it enables exchange of
  information not only between different computer
  systems but also across national and cultural
  boundaries
