Next Generation Digital

1
Part 4

• Next Generation Digital
• Libraries Supporting
• Interoperability,
• Semantics, and Quality

2
(No Transcript)
3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
OAI, ODL, DL-in-a-box

• Open Archives Initiative
• since 1999, www.openarchives.org
• Open Digital Libraries
• since 2001, from www.dlib.vt.edu
• with Hussein Suleman (now U. Cape Town)
• DL-in-a-box
• NSDL support since 2001
• Aimed to help new collections / services projects
• http//dlbox.nudl.org

9
Open Archives Initiative (OAI)

• Advocacy for interoperability
• Standard for transferring metadata among digital
  libraries
• Protocol for Metadata Harvesting (PMH)
• Simplicity
• Generality
• Extensibility
• Support for PMH gt Open Archive (OA)

10
OAI Technical Umbrella forPractical
Interoperability
Metadata Harvesting
Reference Libraries
Museums
Publishers
E-PrintArchives
that can be exploited by different communities
11
OAI Repository Perspective
Required Protocol
Set Structure
URI Scheme
MDO
MDO
MDO
MDO
MDO
MDO
MDO
MDO
Required DC
DO
DO
DO
DO
12
OAI Black Box Perspective
13
Tiered Model of Interoperability
Mediator services
Metadata harvesting
Document models
14
The World According to OAI
Service Providers
Discovery
Current Awareness
Preservation
Data Providers
15
?
users
digital objects
16
Monolithic and/or Custom-built web-based applicati
on
?
?
digital library
17
componentized digital library
18
open digital library
19
Protocol for Metadata Harvesting
20
OPEN ARCHIVE
21
Open Digital Library Deployments

• NDLTD (www.ndltd.org)
• Computer Science Teaching Center (www.cstc.org)
• Computing and Information Technology Interactive
  Digital Educational Library (www.citidel.org)
• Open Archives Distributed (NSF, DFG)
  enhancements to PhysNet
• OCKHAM
• Open to others through DL-in-a-box

22
Open Digital Library

• Network of Extended Open Archives where each node
  acts as either a provider of data, services or
  both.
• Component Node
• Protocol Arc

23
Open Digital Library Components

• Running now
• XML-File (data provider from file system)
• Search simple or in-memory (Essex) or
  generalized
• Union, browse, recent, filter
• E-journal/review, Submit, Edit, Annotation
• Recommender, Rating Mirroring (see JCDL02)
• Working with NCSA from DB, unstructured text
• Others in process
• Classification/categorization
• Registry (and other connections with web services)

24
Example Open Digital Library
ODLRecent
USER INTERFACE
Recent
PMH
ODLUnion
Filter
PMH
ODLUnion
Union
Browse
PMH
ODLBrowse
PMH
ODLUnion
Filter
PMH
Search
ODLSearch
ETD DL for the Networked Digital Library of
Theses and Dissertations (www.ndltd.org)
Students and researchers
ETD collections
25
Open Digital Library Extended
As Metadata Search Service Provider
As Metadata Browse Service Provider
As Whats New Service Provider
As Annotation Search Service Provider
As Recommend Rate Service Provider
DBBrowse Browse Engine
IRDB-1 Search Engine
Recommend
IRDB-2 Search Engine
Whats New Engine
Rate Engine
XML File Coll. Data Provider 1
DBUnion Archive Merger Component
Annotation Engine
Harvest from data providers
XML File Coll. Data Provider 2
Filter
XML File Coll. Data Provider 3
OAI-PMH Data Provider
Submit Archive
OAIB (NCSA from RDBMS)
26

• CITIDEL Technology Features
• Component architecture (Open Digital Library)
• Re-use and compose re-deployable digital library
  components.
• Built Using Open Standards Technologies
• OAI Used to collect DL Resources and DL
  Interoperability
• XSL and XML Interface rendering with
  multi-lingual community based translation of
  screens and content (Spanish, )
• Perl Component Integration
• ESSEX Search Engine Functionality
• Very fast, utilizing in-memory processing
• Includes snap-shots for persistence
• Multi-scheming
• Integrates multiple classifications / views
  through maps, closure

27
Multi-dimensional Categorization
28
OCKHAM Initiative, Contact Info

• Supported by DL Federation, Mellon, NSF,
• P2P University Network involving
• Emory, Notre Dame, U. Arizona, Virginia Tech,
• PI Martin Halbert
• Phone [phone]
• Email mhalber_at_emory.edu
• OCKHAM URL
• http//ockham.library.emory.edu

29
The Problem

• Digital library development is complex and
  expensive.
• Various DL development communities (in the USA at
  least) are not working together well.
• Results exhibit much incompatibility, little
  common practice, slow progress, and no leverage
  on investment.
• If this continues, we are just going to languish
  and fester.

30
Lightweight Protocols

• Lightweight, or relatively small and simple
  protocols seem to have clear advantages over
  Full protocols that attempt to be
  comprehensive.
• Successes of protocols considered lightweight is
  illuminating.
• Examples TCP/IP, HTTP, LDAP, and the OAI PMH

31
Reference Models

• Reference Model a common vocabulary and
  description of components, services, and
  inter-relationships that comprise a system under
  consideration
• Useful as a tool to foster consensus and common
  understanding in a time of rapid change and/or
  disagreement
• Explored in CS6604 class project with 2 focus
  groups librarians, education experts

32
Current Focus Peer-to-Peer (P2P) Lightweight
(Protocol) Reference Models

• Builds on successful example of the OAI PMH,
  clearly understood minimalist concept of metadata
  distribution, implemented in simple protocols
  (e.g., ODL)
• Leads to developing simple reference models of
  specific subsystems, with associated simple
  protocols and standards
• Testing in NSDL, connecting university libraries
  to support teaching learning

33
OCKHAM Proposed Services

• Alerting
• Browsing
• Cataloging
• Conversion
• OAI Z39.50
• Pathfinding
• Registry prototype in CS6604 now
• (plus others such as from adapted ODL)

34
DL Student Research Gonçalves

• 5S as a basis for developing digital libraries
• Theory
• Syntax, Semantics Definitions, Relationships
• Specification of requirements
• Generation of systems
• Quality

35
Motivation for 5S

• DLs are not benefiting from formal theories as
  have other CS fields DB, IR, PL, etc.
• DL construction difficult, ad-hoc, lacking
  support for tailoring/customization
• Conceptual modeling, requirements analysis, and
  methodological approaches are rarely supported in
  DL development.
• Lack of specific DL models, formalisms, languages

36
(No Transcript)
37
5S Layers
Societies
Scenarios
Spaces
Structures
Streams
38
5S Model Examples, Objectives
39
Intra-Model Relationships Streams

• Participant concepts text, image, video,
  audio
• Relations
• contains ? video ? image ? video? audio
• Streams define the basic content types over which
  digital objects are built the latter being the
  ultimate carriers of the information in the DL.
• However some complex types of streams (e.g.,
  video) may themselves be associated with simpler
  types of streams (e.g., images, audio).
• This relation indicates that a video contains a
  image as one of its frames or a specific audio
  recording.

40
(No Transcript)
41
DL Services/Activities Taxonomy (Gonçalves)
Information Satisfaction Services
Infrastructure Services
Add Value
Repository-Building
Preservational
Creational
Browsing Collaborating Customizing Filtering Provi
ding access Recommending Requesting Searching Visu
alizing
Annotating Classifying Clustering Evaluating Extra
cting Indexing Measuring Publicizing Rating Review
ing (peer) Surveying Translating (language)
Conserving Converting Copying/Replicating Emulatin
g Renewing Translating (format)
Acquiring Cataloging Crawling (focused) Describing
Digitizing Federating Harvesting Purchasing Submi
tting
42
Services, Definitions, Parameters

• In the table each service is characterized by
• parameters (input, output)
• of the initial and final events
• of the scenarios that compose those services and
• respective pre- and post-conditions which are
  represented in terms of rules on DL relations.
• All other previous definitions and keys apply
  here.
• That set is complemented with the following
  definitions

43
Services Related Definitions

• A query q is the representation of user interest
  or information need.
• Hyptxt is an hypertext wherein anchor is a node.
• A log_entry is a descriptive metadata
  specification about an event of a scenario.
• Let doi doi1, doi2,, doin be a set of
  digital objects and Ct c1, c2,,cn is a set
  of labels for categories. A classifier classCt
  doi ? 2Ct is a function that maps a digital
  object to a set of categories.
• A cluster cluk do1k, do2k, , donk is a
  subset of a set of digital objects.

44
(No Transcript)
45
(No Transcript)
46
DL Services I/O Behavior

• Regarding the prior figure, which shows
• Instantiations of the Services Definition model
• Inputs and outputs of examples of infrastructure
  and information satisfaction DL services
• Key
• CDL Collection
• ICDL index for collection CDL
• doi digital object
• Soc Society

47
(No Transcript)
48
Defining Quality in Digital Libraries
49
(No Transcript)
50
Completeness of Metadata (1)

• Degree of completeness of a metadata
  specification msx
• Completeness(msx) 1 - (no. of missing
  attributes in msx/ total attributes of the schema
  to which msx conforms)
• According to 5S definition of conformance

51
Completeness of Metadata (2)

• Example of application
• OCLC NDLTD Union
• average of completeness of all metadata
  specifications (records)
• of the NDLTD union Archive
• administered by OCLC
• as of Feb, 23, 2004
• regarding to the Dublin Core metadata standard
  (15 attributes)

52
Completeness of Metadata (3)
53
Collection Completeness (1)

• Defn A complete DL collection Cx is one which
  contains all the pertinent existing digital
  objects.
• completeness(Cx)
• Cx /ideal collection
• can be defined as the ratio between the size of
  Cx and the ideal real-world collection

54
Collection Completeness (2)

• Example of use. Computing collections
• The ACM Guide is a collection of bibliographic
  references and abstracts of works published by
  ACM and other publishers.
• The Guide can be considered a good approximation
  of an ideal computing collection it contains
  most of the different types of computing-related
  literature (about 735K works)

55
(No Transcript)
56
Reliability (1)

• Scope operations of DL
• Defn the probability that the service will not
  fail during a given period of time Hansen83
• Example of use CITIDEL services
• Example details using log analysis April 1

57
Reliability (2)
58
Extensibility, Reusability (1)

• Scope Design and Implementation of DL services
• Two main classes
• Composability of services
• Extensibility
• Reusability
• Quality aspects of models and implementations
• completeness, consistency, correctness, soundness

59
Extensibility, Reusability (2)

• Micro-Reusability(Serv) (? LOC(smx)
  reused(sei),
• smx ? SM, sei ? Serv, sex runs sei) / ?LOC(sm),
  ?sm ? SM,
• where LOC corresponds to the number of lines of
  code of a service manager
• Macro-Reusability(Serv) ? reused(sei), sei ?
  Serv/ Serv, where reused is a indicator
  function defined as
• 1, if ? smj sej reuses si
• 0, otherwise

60
Extensibility, Reusability (3)

• Example ETANA-DL
• Consider
• Services
• Use of existing ODL component
• Lines of Code (LOC)
• Reused from component
• Added for implementation

61
(No Transcript)
62
Extensibility, Reusability (5)

• Macro-Reusability(ETANA DL Services)
• 3/13 0.23
• only a few important services are componentized
• Micro-Reusability
• 3630/11910 0.304
• we can re-use a very significant percentage of
  DL code by implementing common DL services as
  components

63
Review of Gonçalves Achievements in Past Year

• Book Chapters
• Fox, E. A., Gonçalves, M. A., Luo, M., Chen, Y.,
  Krowne, A., Zhang, B., McDevitt,, K.
  Pérez-Quiñones, M., Cassel, L. N. Harvesting
  Broadening the Field of Distributed Information
  Retrieval. In Multimedia Distributed Information
  Retrieval, eds. Fabio Crestani, Mark Sanderson,
  and Jamie Callan, 2003.
• Fox, E., McMillan, G., Suleman, H., Gonçalves,
  M., Networked Digital Library of Theses and
  Dissertations. Invited chapter for Digital
  Libraries Policy, Planning, and Practice, eds.
  Judith Andrews and Derek Law, Ashgate Publishing,
  2003
• Journal papers
• 5S TOIS paper (April 2004, issue)
• S. Perugini, M. A. Gonçalves, and E. A. Fox. A
  Connection-Centric Survey of Recommender Systems
  Research. Journal of Intelligent Information
  Systems, Jun, 2004.
• Zhu, Q., Gonçalves, M. A., Fox, E. A.. 5SGraph
  A Domain-Specific Visual Modeling Tool for
  Digital Libraries. Journal of the American
  Society for Information Science and Technology,
  submitted 2003, in revision
• Baoping Zhang, Marcos Andre Goncalves, Yuxin
  Chen, Edward A. Fox, and Pavel Calado, "Combining
  Support Vector Machines and Structural Rules for
  Effective Filtering of OAI-Based Repositories",
  submitted to Journal of Digital Libraries
  (Springer Verlag) Special Issue on Asian Digital
  Libraries, 2004

64

• Conference papers
• Pável P. Calado, Marcos André Gonçalves, Edward
  A. Fox, Berthier Ribeiro-Neto, Alberto H. F.
  Laender, Altigran S. da Silva, Davi C. Reis,
  Pablo A. Roberto,Monique V. Vieira, and Juliano
  P. Lage. The Web-DL Environment for Building
  Digital Libraries from the Web. JCDL'2003, Third
  Joint ACM / IEEE-CS Joint Conference on Digital
  Libraries, May 27-31, 2003, Houston.
• Marcos André Gonçalves, Ganesh Panchanathan,
  Unnikrishnan Ravindranathan, Aaron Krowne, Edward
  A. Fox, Filip Jagodzinski, and Lillian Cassel.
  The XML Log Standard for Digital Libraries
  Analysis, Evolution, and Deployment. Proc.
  JCDL'2003, Third Joint ACM / IEEE-CS Joint
  Conference on Digital Libraries, May 27-31, 2003,
  Houston.
• Qinwei Zhu, Marcos André Gonçalves, Rao Shen,
  Lillian Cassel, Edward A. Fox. Visual Semantic
  Modeling of Digital Libraries. ECDL'2003, 7th
  European Conference on Research and Advanced
  Technology for Digital Libraries, 17-22 August,
  2003, Trondheim, Norway.
• Rohit Kelapure, Marcos André Gonçalves, Edward A.
  Fox. Scenario-Based Generation of Digital Library
  Services. ECDL'2003, 7th European Conference on
  Research and Advanced Technology for Digital
  Libraries, 17-22 August, Trondheim, Norway
• Marco Cristo, Pavel Calado, Edleno Moura, Nivio
  Ziviani, Berthier Ribeiro-Neto, and Marcos André
  Gonçalves. Combining Link-Based and Content-Based
  Methods for Web Document Classification. CIKM
  2003, 3-8 November, New Orleans, Louisiana, USA,
  2003.
• Baoping Zhang, Marcos Andre Goncalves, and Edward
  A. Fox. An OAI-based Filtering Service for
  CITIDEL from NDLTD. ICADL 2003, 6th International
  Conference of Asian Digital Libraries, 8-11
  December, Kuala Lumpur, Malaysia, 2003
• U. Ravindranathan, R. Shen, M. A. Goncalves, W.
  Fan, E. A. Fox, and J. W. Flanagan. ETANA-DL A
  Digital Library for Integrated Handling of
  Heterogeneous Archaeological Data. To be
  presented at ACM-IEEE Joint Conference on Digital
  Libraries (JCDL 2004), Tucson, AZ, June 7-11,
  2004.

65

• Conference papers
• U. Ravindranathan, R. Shen, M. A. Goncalves, W.
  Fan, E. A. Fox, and J. W. Flanagan. ETANA-DL A
  Digital Library for Integrated Handling of
  Heterogeneous Archaeological Data. To be
  presented at ACM-IEEE Joint Conference on Digital
  Libraries (JCDL 2004), Tucson, AZ, June 7-11,
  2004.
• M. A. Goncalves, E. A. Fox, A. Krowne, P. Calado,
  A. H. F. Laender, A. S. da Silva, and B.
  Ribeiro-Neto. The Effectiveness of Automatically
  Structured Queries in Digital Libraries. To be
  presented at ACM-IEEE Joint Conference on Digital
  Libraries (JCDL 2004), Tucson, AZ, June 7-11,
  2004.
• Alberto H. F. Laender, M. A. Goncalves, Pablo A.
  Roberto. BDBComp Building a Digital Library for
  the Brazilian Computer Science Community. To be
  presented at ACM-IEEE Joint Conference on Digital
  Libraries (JCDL 2004), Tucson, AZ, June 7-11,
  2004.
• U. Ravindranathan, R. Shen, M. A. Goncalves, W.
  Fan, E. A. Fox, and J. W. Flanagan. Prototyping
  Digital Libraries Handling Heterogeneous Data
  Sources - The ETANA-DL Case Study. European
  Conference on Digital Libraries (ECDL 2004),
  Bath, UK, September 12-17, 2004. (submitted)
• Other publications
• R. da S. Torres, C. B. Medeiros, M. A. Goncalves,
  and E. A. Fox. An OAI-based Digital Library
  Framework for Biodiversity Information Systems.
  Department of Computer Science, Virginia Tech,
  Technical Report No. TR-04-01, 2004.
• R. da S. Torres, C. B. Medeiros, M. A. Goncalves,
  and E. A. Fox. An OAI Compliant Content-Based
  Image Search Component. Demo to be presented at
  ACM-IEEE Joint Conference on Digital Libraries
  (JCDL 2004), Tucson, AZ, June 7-11, 2004.
• R. da S. Torres, C. B. Medeiros, Renata Q.
  Dividino, Mauricio A. Figueiredo, M. A.
  Goncalves, E. A. Fox, and R. Richardson. Using
  Digital Library Components for Biodiversity
  Systems. Poster to be presented at ACM-IEEE Joint
  Conference on Digital Libraries (JCDL 2004),
  Tucson, AZ, June 7-11, 2004.
• U. Ravindranathan, R. Shen, M. A. Goncalves, W.
  Fan, E. A. Fox, and J. W. Flanagan. ETANA-DL
  Managing Complex Information Applications An
  Archaeology Digital Library. Demo to be presented
  at ACM-IEEE Joint Conference on Digital Libraries
  (JCDL 2004), Tucson, AZ, June 7-11, 2004.
• Qinwei Zhu, Marcos André Gonçalves, E. Fox.
  5SGraph Demo A Graphical Modeling Tool for
  Digital Libraries. Proc. JCDL'2003, Third Joint
  ACM / IEEE-CS Joint Conference on Digital
  Libraries, May 27-31, 2003, Houston.

66
Proposed Outline of Dissertation(Marcos André
Gonçalves)

• Chapter 1 Introduction and Motivation
• Chapter 2 Background and Related Work
• Chapter 3 Streams, Structures, Spaces,
  Scenarios and Societies the 5S Formal Model for
  Digital Libraries
• Chapter 4 Towards a Digital Library Theory A
  Formal Digital Library Ontology based on 5S
• Chapter 5 Applications of the 5S Model/Ontology
• 5.1 Declarative Specification of DLs the 5S
  Language
• 5.2 Semantic Visual Modeling of DLs the 5SGraph
  Tool
• 5.3 (Semi-) Automatic Generation of Componentized
  DLs The 5SGen Tool
• 5.4 Evaluating DLs The XML Log Standard for DLs
• 5.5 Formally comparing Architectures Fedora and
  Buckets (time permitting)
• Chapter 6 Defining Quality in Digital Libraries
• Chapter 7 Conclusions and Future Work
• Appendix 1- Mathematical Preliminaries

67
Questions/Discussion?
