National LightRail: Towards a National Optical Research Network

1
National LightRail Towards a National Optical
Research Network

2
NLR Footprint and Layer 1 Topology
SEA
POR
SAC
BOS
NYC
CHI
OGD
DEN
SVL
CLE
WDC
PIT
FRE
KAN
RAL
NAS
STR
LAX
PHO
WAL
ATL
SDG
OLG
DAL
JAC
3
National Light Rail

• Dark Fiber National footprint
• Serves very high-end Experimental and Research
  Applications
• 4 - 10GB Wavelengths initially
• Capable of 40 10Gb wavelengths at buildout
• Partnership model

4
Rationale for NLR

• Current market demonstrates willingness of
  private sector setting stage for strong
  partnership of academia, corporations and
  government
• Research community in USA and worldwide working
  on large scale research and development
  applications calling for increasing bandwidth as
  evidenced by the Grid and Terascale projects
• Unified approach best investment for biggest
  payoff for the most users
• Federal program funding support focused on
  research and experimental applications needing
  significant network capacity
• Leadership worldwide in research and education
  increasingly dependent upon large-scale
  collaborative research activities
• Meet the future needs of the research and
  community most economically

5
Drivers and Motivations

• RESEARCH Network research tools
• EXPERIMENTAL Exp. infrastructure
• OPERATIONAL 24/7 high performance
• Aubrey Bush
• NSF

6
Drivers and Motivations

• Cost
• Control
• Flexibility
• Responsiveness
• Innovation
• End-to-End networking

7
Why Fiber?

• Capacity needed is not otherwise affordable
• Capabilities needed are not available
• Cheaper in the long range
• Leverage with carriers
• Insurance against monopoly behavior
• Stable and predictable anchor points

8
Why Fiber? Innovation

• Research cant be held hostage to what industry
  thinks the market want.
• Infrastructure investments of the past are
  getting in the way of real innovation.
• The situation is reminiscent of the telco
  infrastructure situation before APRANET.
• Bob Kahn
• CRA-Snowbird 02

9
Optical Transport - Light Rail

• Multi-State interest in a larger geographic fiber
  based infrastructure
• Vendors very interested in selling National
  footprint

10
Goals and Uses

• Research! (including Network Research)
• Experimentation in networking and in education
• Regional fiber/ ? efforts in edu research
  sectors
• Education
• Academic Med. Center driven Clinical activities
• Development implementation of network
  computing technologies not otherwise likely to be
  generally available commercially as early as
  needed in RE.
• Enabling deterministic and other e2e bandwidth/
  ?s, dark fiber and conduit for Grid, eScience
  etc. for Regionals etc.

11
NLR Service Offerings

• Waves!!!!
• Dark Fiber
• MetaPoP capabilities
• Dedicated OC-192c or 10GE waves
• No wave can interfere with others
• Shared IP service
• Must be able to tolerate outages
• Supports experimental code
• Subdivided waves for dedicated uses
• Delivered as gigabit Ethernet

12
NLR Governance

• LLC - Equity Partners
• Joint Research Council
• Joint Technology Council
• Distributed Network Engineering/ Operations
• Waves governed/managed by various groups

13
Backers

• Carnegie Mellon/PSC
• Virginia Tech
• Duke
• Georgia Tech
• Florida
• Texas

14
Backers

• CENIC
• PNWGP
• NCAR
• SURA
• UCAID

15
Technology Partners

• Cisco Systems
• Level 3

16
COSTS

• 80.2 MILLION
• Over
• 5 Years

17
NLR Footprint and Layer 1 Topology
SEA
POR
SAC
BOS
NYC
CHI
OGD
DEN
SVL
CLE
WDC
PIT
FRE
KAN
RAL
NAS
STR
LAX
PHO
WAL
ATL
SDG
OLG
DAL
JAC
18
National Light Rail Lambda Route Map
REGEN
TERMINAL
OADM
Metro 10 Gig E
4
Seattle
Chicago
Denver
Cleveland
Kansas
Ogden
Boise
4
2
4
4
6
2
6
4
Salt Lake City
Portland
StarLight
2
Boston
5
Pittsburgh
Sacramento
2
Sunnyvale
15808 LH System
15808 ELH System
2
4
4
Fresno
15540 Metro System
4
10 Gig E
4
New York City
Washington DC
OC192
4
Los Angeles
2
4
4
2
Stratford
4
San Diego
4
4
Walnut
Nashville
Dallas
Raleigh
Olga
Pheonix
Atlanta
4
19
NLR POP Architecture
Long Haul OC48/OC192/10GigE DWDM
NLR
DWDM
10 Gig E or OC192
Gig E
20
Calren/DC/HPR/NLR POP Architecture
CalRen DC
HPR
NLR
Long Haul OC48/OC192/10GigE DWDM
DWDM
10 Gig E or OC192
Gig E
CalREN/DC
HPR
NLR
15500
21
Questions?
