The Memory Hierarchy CPSC 321

1
The Memory Hierarchy CPSC 321

• Andreas Klappenecker

2
Some Results from the Survey

• Issues with the CS curriculum
• CPSC 111 Computer Science Concepts Prg
• CPSC 310 Databases
• CPSC 431 Software Engineering
• Something from the wish list
• More C
• More Software Engineering
• More focus on industry needs
• Less focus on industry needs

3
Some Results from the Survey

• Why (MIPS) assembly language?
• More detailed explanations of programming
  language xyz.
• Implement slightly reduced version of the Pentium
  4 or Athlon processors
• Have another computer architecture class
• Lack of information on CS website about
  specialization...

4
Follow Up

• CPSC 462 Microcomputer Systems
• CPSC 410 Operating Systems
• Go to seminars/lectures by Bjarne Stroustrup,
  Jaakko Jarvi, or Gabriel Dos Reis

5
Todays Menu

• Caches

6
Memory

• Current memory is largely implemented in
• CMOS technology. Two alternatives
• SRAM
• fast, but not area efficient
• stored value in a pair of inverting gates
• DRAM
• slower, but more area efficient
• value stored on charge of a capacitor (must be
  refreshed)

7
Static RAM
8
Static RAM
9
Dynamic RAM
10
Dynamic RAM
11
Memory

• Users want large and fast memories
• SRAM is too expensive for main memory
• DRAM is too slow for many purposes
• Compromise
• Build a memory hierarchy

12
Locality

• If an item is referenced, then
• it will be again referenced soon
• (temporal locality)
• nearby data will be referenced soon
• (spatial locality)
• Why does code have locality?

13
Memory Hierarchy

• The memory is organized as a hierarchy
• levels closer to the processor is a subset of any
  level further away
• the memory can consist of multiple levels, but
  data is typically copied between two adjacent
  levels at a time
• initially, we focus on two levels

14
Memory Hierarchy
15
Two Level Hierarchy

• Upper level (smaller and faster)
• Lower level (slower)
• A unit of information that is present or not
  within a level is called a block
• If data requested by the processor is in the
  upper level, then this is called a hit, otherwise
  it is called a miss
• If a miss occurs, then data will be retrieved
  from the lower level. Typically, an entire block
  is transferred

16
Cache
A cache represents some level of memory between
CPU and main memory More general definitions
are often used
17
A Toy Example

• Assumptions
• Suppose that processor requests are each one
  word,
• and that each block consists of one word
• Example
• Before request C X1,X2,,Xn-1
• Processor requests Xn not contained in C
• item Xn is brought from the memory to the cache
• After the request C X1,X2,,Xn-1,Xn
• Issues
• What happens if the cache is full?

18
Issues

• How do we know whether the data item is in the
  cache?
• If it is, how do we find it?
• Simple strategy direct mapped cache
• exactly one location where data might be in the
  cache

19
Direct Mapped Cache

• Mapping address modulo the number of blocks in
  the cache, x -gt x mod B

20
Direct Mapped Cache

• Cache with 1024210 words
• tag from cache is compared against upper portion
  of the address
• If tagupper 20 bits and valid bit is set, then
  we have a cache hit otherwise it is a cache
  missWhat kind of locality are we
  taking advantage of?

21
Direct Mapped Cache Example
22
Direct Mapped Cache Example
23
Direct Mapped Cache Example
24
Direct Mapped Cache

• Taking advantage of spatial locality

25
Hits vs. Misses

• Read hits
• this is what we want!
• Read misses
• stall the CPU, fetch block from memory, deliver
  to cache, restart
• Write hits
• can replace data in cache and memory
  (write-through)
• write the data only into the cache (write-back
  the cache later)
• Write misses
• read the entire block into the cache, then write
  the word

26
Hits vs. Miss Example
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
What Block Size?

• A large block size reduces cache misses
• Cache miss penalty increases
• We need to balance these two constraints
• How can we measure cache performance?
• How can we improve cache performance?

35

• The performance of a cache depends on many
  parameters
• Memory stall clock cycles
• Read stall clock cycles
• Write stall clock cycles

36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
Cache Block Mapping

• Direct mapped cache
• a block goes in exactly one place in the cache
• Fully associative
• a block can go anywhere in the cache
• difficult to find a block
• parallel comparison to speed-up search

40
Cache Block Mapping

• Set associative
• Each block maps to a unique set, and the block
  can be placed into any element of that set
• Position is given by
• (Block number) modulo ( of sets in cache)
• If the sets contain n elements, then the cache is
  called n-way set associative

41
Cache Types
