Title: Performance Task Team Report


1
Performance Task Team Report
Andrew Germain CEOS WGISS NS-8 London,
England, UK April 2000
2
Network Performance Testing Highlights
  • Many new routes -- International High performance
    networks peer in the US in NY, Chicago
  • New tests
  • CONAE (resumed 4-00)
  • Malaysia (19-20 Jan 2000)
  • SeaStart (Bangkok) (9-99)
  • Tokai Univ (9-99)
  • UNEP Added Geneva, Norway, Beijing, Bangkok,
    Costa Rica
  • Testing Stopped
  • CSIRO (2-99)
  • DLR (7-99)
  • INPE (8-98)
  • START (China) (8-99)

3
Virtual CEOSnet - 4/2000
4
N A S A - ESDIS Science Data Network
J. Smith, A. Germain 3 April 2000
5
CEOS GOIN Performance Test Sites
UNEP
Stockholm
EUMETSAT
IRE-RAS
UCL
NSAU
CCRS
DLR
JRC
UNESCO
ESRIN
UNEP
GSFC
NASDA
ISRAEL
START
GOIN99
AIT
NAMRIA
ISRO
UNEP
UNEP
UKM
UNEP
INPE
CONAE
CSIRO
CEOS Sink
GOIN Sink
Sink Source
6
Site Updates
  • CCRS (Canada) Stable
  • Routed stable -- direct peering between NISN and
    CANet3 in Chicago -- to CCRS via a 5 mbps access
    circuit.
  • Business Hours Median (BHM) 3.3 Mbps
  • China START Regional Center
  • No performance testing since 8/99
  • BHM performance was 18 Kbps
  • Route now via ATT, satellite -- APAN would be
    better
  • CONAE (Argentina) Testing resumed 4-00
  • Thruput about 200 kbps via Telintar
  • Was 20 kbps when last tested (96)
  • CSIRO (Australia)
  • no thruput testing since 2/99

7
(No Transcript)
8
(No Transcript)
9
Site Updates
  • DLR (Oberpfaffenhofen, DE)
  • Route now via NY, TEN-155 to DFN
  • Datasink stopped 7/99 -- will try to restart
  • ESRIN (Frascati, IT)
  • BHM dropped to 60kbps (was 80 kbps)
  • typical range (BH) 25-1600 kbps (was 30-650
    kbps)
  • Routing ALTERNET - Dante (TEN-155) GARRnet
    (Milan)-ESRIN
  • seems fairly stable -- fairly congested
  • NASA switch to Abilene might help somewhat
  • Eumetsat (Darmstadt, DE)
  • Performance testing still not running -- will try
    again
  • Now (as of 18 Jan 2000) using EU-Xlink via Qwest
  • was NASA-ESOC dedicated circuit
  • Hops 7-gt13, RTT 210 -gt 110, Loss 3 -gt 10

10
(No Transcript)
11
(No Transcript)
12
Site Updates (cont.)
  • INPE (Sao Paolo, BR) No testing since 8/98
  • Being reconfigured
  • IRE-RAS (Moscow, RU)
  • Via Internet -- Teleglobe, Relarn
  • MIRnet is another possibility
  • Sink down since 2/24
  • Small performance improvement 1 Jan 2000
  • BHM 14 kbps, Daily range 3 - 260 kbps
  • Was BHM 8 kbps, Daily range 2 - 200 kbps
  • Israel Further improved performance
  • Route change 16 March 2000 NASA peers with ILAN
    in Chicago
  • Performance now 1.7 mbps -- but somewhat unstable
  • Was about 100 kbps previously

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
Site Updates (cont.)
  • CEO/JRC (Ispra, IT)
  • BH Median about 140 Kbps average daily peak is
    about 1700 Kbps
  • Route SWITCH (NY) to JRC
  • AlterNet from GSFC via MAE-E, Abilene from JPL
  • Fairly high congestion on both routes -- probably
    trans-Atlantic
  • Malaysia
  • Thruput tested 19-20 Jan 2000 30 kbps
  • Route via ATT.net, satellite
  • NASDA (Tokyo, JP)
  • NASA-NASDA removed private E1 and installed
    private 3 mbps ATM service on 8 Feb 2000 -- for
    mission support only.
  • Performance typically 1.8 mbps
  • 512 kbps science channel on private E1 replaced
    by TransPAC for Science traffic
  • Performance over TransPac 850 kbps -- limited by
    NASDA

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Site Updates (cont.)
  • Thailand (Sea Start)
  • Testing started 9-99 (FTP) -- Route improved 1-00
  • GSFC - gtSeaStart
  • 1999 Median BH 5 kbps, Typical daily peak
    186 kbps
  • 2000 Median BH 54 kbps, Typical daily peak
    136 kbps
  • SeaStart-gt GSFC
  • Daily peak unchanged at 200 kbps, Median 10 - 50
  • Route via AlterNet-gt NY, then Teleglobe via
    satellite
  • Serious congestion
  • Tokai Univ (Tokyo)
  • Testing started 9-99 (FTP) -- Results stable
  • Typical range 40-375 kbps (median 230 kbps)
  • Route initially via SINET, now IIJ from MAE-W

23
(No Transcript)
24
(No Transcript)
25
Site Updates (cont.)
  • UK
  • Now testing to UCL and Oxford, from GSFC and JPL
  • Via JAnet and NASA dedicated ATM (VC 2 Mbps)
  • JAnet peering in NY GSFC via Alternet, JPL via
    Abilene
  • NASA ATM Steady -- BH Median 1.3 Mbps, Min
    1.2 Mbps
  • JAnet Congested Max 2.7 mbps, BH Median (via
    Abilene) 500 kbps, (via Alternet) 100 kbps,
    Min 175 / 50 kbps.
  • UNEP
  • Now testing to 6 sites via Geneva to UNEP
    satellites
  • Geneva 300-400 kbps
  • Norway 100-200 kbps
  • Beijing 60 kbps
  • Bangkok two modes 40 or 80 kbps
  • Nairobi 120 kbps
  • Costa Rica 90 kbps

26
Current Network Performance
27
Current Network Performance - Hourly
28
(No Transcript)
29
(No Transcript)
