Research Overview: Security and Incentives in Emerging Applications

1
Research Overview Security and Incentives in
Emerging Applications

• Sheng Zhong

2
Summary of Previous, Ongoing and Future Research

• Privacy and Anonymity in Computer Networks
  GZ02, ZLLY04a
• Incentives in Ad Hoc Networks ZYC03, ZLLY04b
• Privacy-Preserving Data Mining Z03, YZW04
• Other Interesting Topics ZY03, AFYZ04

3
Part 1 Privacy and Anonymity in Computer Networks

• Finished Optimistic Mix for Exit Polls GZ02
• Under Review Privacy-Preserving Location-based
  Services ZLLY04a

4
Optimistic Mix GZ02

• A mix network (consisting of a group of mix
  servers) is a construction for anonymizing
  communications.
• Security requirements
• Privacy Infeasible to associate any input with
  the corresponding output.
• Verifiability Functionality of the mix can be
  verified.

5
Global Picture of a Mix

• Operations of each server
• Rerandomization generate a set of random
  ciphertexts corresponding to the same set of
  cleartexts
• Reshuffling change the order of ciphertexts
  randomly

Ciphertexts
Mix Server
Mix Server
Mix Server
Private Algorithm for Joint Decryption
6
Designing a Mix

• Key Technical Question How to ensure each server
  follow the protocol?
• Zero-knowledge proofs, but proofs in previous
  solutions are expensive.
• We proposed Proof of Product with Checksum, which
  is much more efficient.
• However, Proof of Product with Checksum also
  introduces a type of attack. We use a novel
  technique double encryption to defeat this
  attack.

7
Our Result and Open Question

• We design a mix that is more efficient than any
  previous work with provable security.
• In normal cases (no cheating), our mix only needs
  a few modular exponentiations. Thus it is more
  efficient than previous work.
• Our mix net achieves privacy similar to standard
  ElGamal-based mix nets its operations are
  publicly verifiable.
• Open Question Can we further improve the
  efficiency? For example, can we avoid using
  modular exponentiations?

8
Progress of Talk

• Privacy and Anonymity in Computer Networks
• Finished Optimistic Mix for Exit Polls GZ02
• ? Under Review Privacy-Preserving Location-based
  Services ZLLY04a
• Incentives in Ad Hoc Networks ZYC03, ZLLY04b
• Privacy-Preserving Data Mining Z03, YZW04
• Other Interesting Topics ZY03, AFYZ04

9
Privacy-Preserving Location-based Services

• Problem 1 A user authorizes a set of entities to
  retrieve her location information. This set will
  be dynamically changing.
• At any moment, all entities in the designated set
  are able to retrieve her location, while any
  other entity learns no information about her
  location.

10
Design Techniques

• Each user stores his location information on a
  location server, encrypted using a key
  specifically chosen for the set of entities that
  are authorized to retrieve the location
  information.
• Only the entities in the given set can derive the
  key to decrypt the location information.
• Infeasible for any other entity to derive the
  key.
• To achieve the above goal, we use a cryptographic
  technique motivated by Akl and Taylors work on
  hierarchical access control AT83 and Fiat and
  Naors work on broadcast encryption FN93.

11
Solution to Problem 1 Illustrated
User 1
Entity a
Location encrypted using K1
Entity b
Authorized by User 1
User 2
CANNOT derive K1
Entity c
CAN derive K1
Location Server
User 3
Entity d
Entity e
Entity f
12
Privacy-Preserving Location-based Services
Problem 2

• Dating service Does anybody around me satisfy
  these requirements This can be easily
  implemented
• Users register with a server and provide
  profiles.
• Server keeps track of all users locations.
• When a user sends a request, the server searches
  for another user with the same locations whose
  profile matches the requirements.
• However, in the above solution, users are tracked
  either by the service provider or by any other
  users. Can this service be implemented without
  revealing any users current location?

13
Analysis of Problem 2

• When there is an incoming request for match, it
  is very easy for the service provider to find the
  set of registered users that meet the requestors
  requirements.
• ? The technical problem is how to decide whether
  any of the matched users locations is the same
  as the requestors without revealing either the
  requestors or the matched users locations.

14
Solution to Problem 2 and Open Question

• We give a two-round protocol for problem 2.
• Privacy is guaranteed under the Decisional
  Diffie-Hellman assumption.
• Computational overhead A user needs to do 3
  modular exponentiations The server needs to do
  k1 modular exponentiations (for k matched
  users).
• Open Question Can we design an (efficient)
  one-round protocol for this problem?

15
Progress of Talk

• Privacy and Anonymity in Computer Networks
  GZ02, ZLLY04a
• ? Incentives in Ad Hoc Networks
• Finished Sprite ZYC03
• Under Review Corsac ZLLY04b
• Privacy-Preserving Data Mining Z03, YZW04
• Other Interesting Topics ZY03, AFYZ04

16
Sprite ZCY03

• Wireless multi-hop networks are formed by mobile
  nodes, with no pre-existing infrastructure.
• Nodes depend on other nodes to relay packets.
• A node may have no incentive to forward others
  packets.

packet
17
Sprite System Architecture
Credit-Clearance System
Internet
Wide-area wireless network
18
Big Picture Saving Receipts
Credit-Clearance System
Internet
Wide-area wireless network
A
packet
D
C
B
receipt
receipt
(protected by digital signature)
19
Big Picture Getting Payment
Credit-Clearance System
Internet
receipt
C
A
D
B
20
Our Results on Mobile Ad Hoc Networks

• We designed a simple scheme to stimulate
  cooperation.
• Cheating cannot increase a players expected
  welfare.
• In case of collusion, cheating cannot increase
  the sum of colluding players expected welfares.
• Evaluations have shown that the system has good
  performance.

21
Corsac ZLLY04b

• Further game-theoretic study of ad hoc networks.
• Consider routing and packet forwarding as a
  complete game.

22
Packet Forwarding Ideal Solution

• A standard solution concept in game theory ?
  dominant action.
• An action is dominant if it brings the maximum
  utility to each player regardless of other
  players actions.
• A protocol is Forwarding-Dominant if forwarding
  traffic is a dominant action of each node.
• Note that, in Sprite, forwarding packets only
  maximizes the expected welfare.

23
Difficulties in Incentive-Compatible Design

• Although AE03 claims that they have found a
  dominant-action solution, we show that
  forwarding-dominant protocols do NOT really
  exist!
• There are also other difficulties in
  incentive-compatible design of ad hoc networks,
  e.g., determining link costs requires help of
  neighbors.

24
New Solution Concept Cooperation-Optimal
Protocols

• We propose a new solution concept for the entire
  game of routing and forwarding.
• A protocol is cooperation-optimal if
• its routing protocol is a dominant-action
  solution to the routing subgame
• for ANY routing decision generated by actions
  designated in routing protocol, following its
  forwarding protocol is optimal for each node.

25
Corsac A Cooperation-Optimal Protocol

• Corsac a Cooperation-optimal routing-and-forward
  ing protocol in wireless ad-hoc networks using
  cryptographic techniques
• Several cryptographic techniques are used in
  designing Corsac.
• We are able to show Corsac is cooperation-optimal.

26
Open Question for Incentive-Compatible Ad Hoc
Networks

• Are there any alternative solution concepts
  (which are both feasible and useful)?
• Can we significantly reduce the communication
  overhead? (All existing solutions/pseudo-solutions
  need too much communication.)

27
Progress of Talk

• Privacy and Anonymity in Computer Networks
  GZ02, ZLLY04a
• Incentives in Ad Hoc Networks ZYC03, ZLLY04b
• ? Privacy-Preserving Data Mining
• Tech Report Privacy-Preserving Mining of
  Frequent-itemset Z03
• Under Review Privacy-Preserving Classification
  without Loss of Accuracy YZW04
• Other Interesting Topics ZY03, AFYZ04

28
Privacy-Preserving Mining of Frequent Itemsets
Z04

• Association Rule Milk ? Cereal.
• Milk, Cereal is frequent (i.e., Milk, Cereal
  is large).
• Milk, Cereal/Milk is close to 1.
• The key technical problem in association-rule
  mining is to find frequent itemsets.

29
Privacy in Distributed Mining

• Distributed Mining
• Two (or more) miners.
• Each miner holds a portion of a database.
• Goal Jointly mine the entire database.
• Privacy Each miner learns nothing about others
  data, except the output.

30
Vertical Partition Weakly Privacy-Preserving
Algorithm

• Vertical Partition ? Each miner holds a subset of
  the columns.
• Algorithm provides weak privacy ? only support
  count ( of appearances of candidate itemset) is
  revealed.
• Computational Overhead Linear in of
  transactions.
• Previous solution has a quadratic overhead.

31
Vertical Partition Strongly Privacy-Preserving
Algorithm

• Algorithm provides strong privacy ? no
  information (except the output) is revealed.
• Computational Overhead Also linear in of
  transactions.
• Slightly more expensive than weakly
  privacy-preserving algorithm.

32
Horizontal Partition

• Horizontal Partition ? Each miner holds a subset
  of rows.
• Computational Overhead Still linear in of
  transactions.
• Works for two or more parties.
• Previous solution only works for three or more
  parties.

33
Progress of Talk

• Privacy and Anonymity in Computer Networks
  GZ02, ZLLY04a
• Incentives in Ad Hoc Networks ZYC03, ZLLY04b
• Privacy-Preserving Data Mining
• Tech Report Privacy-Preserving Mining of
  Frequent-itemset Z03
• ? Under Review Privacy-Preserving Classification
  without Loss of Accuracy YZW04
• Other Interesting Topics ZY03, AFYZ04

34
Privacy-Preserving Classification without Loss of
Accuracy YZW04

• Scenario A large number of customers, each
  holding a piece of data.
• Problem Learn classification rules on their
  data.
• Naïve solution Survey customers to collect data,
  and then learn rules from the collected data.
• Why doesnt it work? Because we have a privacy
  requirement
• The sensitive attributes of these customers need
  to be protected.

35
Previous Solutions

• Previous solutions use randomization techniques
  in the survey.
• Basic Idea Change the survey question with a
  (small) probability.
• Example To survey for customers marital status
  (which is sensitive), ask Are you married with
  probability 95, and Are you single with
  probability 5.
• Cannot decide whether a customer is married from
  his answer.

36
Tradeoff

• The essence of the previous solution is to trade
  accuracy for privacy
• The more each customer's private information is
  protected, the less accurate result the miner
  obtains
• Conversely, the more accurate the result is, the
  less privacy the customers have.
• Question Is it possible to protect customer
  privacy without loss of accuracy?

37
Our Solution

• We propose a privacy-preserving method to compute
  joint frequencies
• ? of values (or tuples of values) in the
  customers' data conditioned on the class value.
• No info about the sensitive data is revealed.
• Compared with general-purpose cryptographic
  protocols, this method
• requires no interaction between customers
• each customer only needs to send a single flow of
  communication to the data miner
• but we still have a cryptographically strong
  guarantee of privacy .

38
Application of Our Solution

• Using the above proposed method, we can construct
• a privacy-preserving algorithm for naïve Bayes
  learning
• a privacy-preserving algorithm for ID3 tree
  learning
• a privacy-preserving algorithm for association
  rule learning.
• The privacy guarantee and efficiency vary for
  different applications.

39
Next Step in Privacy-Preserving Data Mining

• Is there an efficient protocol for privately
  computing the scalar product of integer vectors?
• A central question in many PPDM problems.
• Can we add economic considerations to
  privacy-preserving data mining?

40
Progress of Talk

• Privacy and Anonymity in Computer Networks
  GZ02, ZLLY04a
• Incentives in Ad Hoc Networks ZYC03, ZLLY04b
• Privacy-Preserving Data Mining Z03, YZW04
• ? Other Interesting Topics
• Finished Verifiable Distributed Oblivious
  Transfer and Mobile-Agent Security ZY03 ?
  Covered in last talk skipped.
• Finished Data Entanglement AFYZ04

41
Data Entanglement AFYZ04

• Question Suppose you store your data on a remote
  server. How do you ensure that it is not
  corrupted by the server?
• Answer Have your data entangled with some VIPs
  such that
• corruption of your data ? corruption of theirs.
• Ideally, we should have All-or-nothing Integrity
  (AONI) with high probability,
• one user cannot recover data ? no user can
  recover data

42
Basic Framework of Models
43
Models Recovery Algorithms and Adversaries

• What recovery algorithms do users have?
• All users use a standard-recovery algorithm
  provided by the system designer.
• All users use a public-recovery algorithm
  provided by the adversary.
• Each individual uses a private-recovery algorithm
  provided by the adversary.
• What kind of adversary?
• Destructive adversary that reduces the entropy of
  the data store
• Arbitrary adversary

44
Our Results

• AONI is possible in standard recovery model
• AONI is impossible in public/private recovery
  model with general adversary
• AONI is possible in private recovery model with
  entropy-reducing adversary.

45
Open Question in Data Entanglement

• Is there a model ?
• in which AONI is possible, but
• has weaker assumptions than the standard recovery
  model?
• Can we extend the model to consider multiple
  rounds of operations?

46
THANK YOU
