ICS 214A: Database Management Systems

1
ICS 214A Database Management Systems

• Notes 04 Record-Oriented File Systems
• Professor Chen Li

2
Overview

• Provides a tuple read/write interface to files
• Provides the abstraction of a file as a
  collection of records on top of the basic file
  system.
• Records can be
• fixed size or variable length
• short, long, or very long
• attributes can be fixed length or variable length
• simple or complex (e.g., containing set-valued
  attributes)
• Operations supported
• create, delete, open, close, alter, drop
• read, insert, update, delete record
• scan all records in a file

3
Record Manager Functionality

• Storage allocation store tuples in file blocks
• Tuple addressing give tuple an identifier (id)
  and provide fast access via that id.
• Enumeration fast enumeration of all tuples of a
  relation.
• Content addressing give fast accessible via
  attribute values.
• Maintenance update/delete a tuple and its
  access paths.
• Protection support for security encryption or
  tuple-granularity access control.

4
Basic-Item Representations

• Integer (short) 2 bytes
• e.g., 35 ---gt 00000000 00100011
• Real, floating point
• Characters use ASCII coding
• Boolean TRUE -gt 11111111, FALSE-gt00000000
• Dates
• Integer, days since Jan 1, 1900
• 8 characters, YYYYMMDD
• 7 characters, YYYYDDD (not YYMMDD! Why?)
• Time
• Integer seconds since midnight
• Characters HHMMSSFF

5
String representation

• String of characters
• Null terminated
• Length given
• - Fixed length

3
6
Record Representation

• Record a collection of data items
• CREATE TABLE emp(e int, name char(10), dept
  char(2))
• Type of records
• Fixed vs variable format
• Fixed vs variable length

7
Fixed format

• Format defined by a schema
• fields
• type of each field
• order in record
• meaning of each field
• Example (fixed format and fixed length)
• E, 2 byte integer
• E.name, 10 char.
• Dept, 2 byte code

55
s m i t h
02
Records
83
j o n e s
01
8
Variable format

• Record itself contains format
• Self Describing,
• Example variable format and length

Fields Code identifying field as
E Integer type Code for Ename String
type Length of str.
9
Why Variable format?

• Sparse records
• Evolving formats
• Repeating fields
• Different books have different numbers of authors
• A fixed schema might not be suitable
• Pick the maximal number of authors?
• Waste space

3
B_title Java
Author Tom
Author Jack
10
Variants between fixed - variable formats

• Example 1 Include record head
• record type
• record length
• time stamp
• other stuff ...

1310
5
27
. . . .
timestamp
type
length
11
Example 2

• Hybrid format
• one part is fixed, other variable
• E.g. All employees have E, name, dept. Other
  fields vary.

25
Smith
Toy
2
retired
Hobbychess
of var fields
12
Variations in record internal organization
Field length

3
F3
10
F1
5
F2
12
total size
3
32
5
15
20
F1
F2
F3
0 1 2 3 4 5
15 20
offsets
13
Long Fields

• Tuples containing long fields may not fit on a
  page
• Two approaches
• Separate pages for long fields. Store long fields
  on separate pages and keep pointer in the record.
• Tuple Fragmentation fragment a tuple into
  multiple pages and store tuple as a linked list
  of parts.

14
Questions

• We have seen examples for
• Fixed format and length records
• Variable format and length records
• Does fixed format and variable length make sense?

• Does variable format and fixed length make sense?
• Other issues
• Compression
• within record, e.g. code selection
• collection of records, e.g. find common patterns
• Encryption

15
Next how to place records in blocks?
records

• blocks ...
• a file

assume fixed length blocks
16
Place records on disk outline

• (1) Separating records
• (2) Spanned vs. unspanned
• (3) Mixed record types clustering
• (4) Split records
• (5) Sequencing
• (6) Storing records in a page

17
(1) Separating records
R2
R1
R3

• Approaches
• Fixed size no need to separate
• Variable length
• special marker
• give record lengths (or offsets)
• within each record
• in block header each record has a length field

18
(2) Spanned vs. Unspanned

• Unspanned records must be within one block
• block 1 block 2
• ...
• Spanned records can be stored in different
  blocks
• block 1 block 2 ...

R1
R2
R3
R4
R5
R1
R2
R3 (a)
R3 (b)
R6
R5
R4
R7 (a)
19
Storing spanned records

• need indication need indication
• of a partial record of continuation
• plus a pointer to rest ( from where?)

20
Comparisons

• Unspanned
• simpler,
• but may waste space
• Spanned
• essential if record size gt block size

21
Example

• 106 records
• each of size 2,050 bytes (fixed)
• block size 4096 bytes
• Therefore
• Total space 4 x 109
• Total wasted 2 x 109
• Utilization 50

22
BLOBS

• Large values for records
• Images (GIF, JPG)
• Movies (MPEG)
• Signals (audio, radar,)
• Called binary, large objects (BLOBS)
• Storage
• Sequence of blocks
• Using consecutive blocks or linked-list of blocks
• We might stripe data across multiple disks to
  improve output bandwidth
• Retrieval
• Sequential scan
• Random access need an indexing structure

23
(3) Mixed record types

• Mixed - records of different types
• e.g. EMPLOYEE, DEPT tuples allowed in same block
• Why? Clustering
• Records that are frequently accessed together
  should be in the same block
• Variation of clustering store related records
  in the cylinder

EMP
e1
DEPT
d1
DEPT
d2
24
Clustering Example

• Q1 select A, C_NAME, C_CITY,
• from DEPOSIT, CUSTOMER
• where DEPOSIT.C_NAME CUSTOMER.C.NAME
• Q2 SELECT FROM CUSTOMER
• If Q1 is frequent, clustering is good
• But if Q2 is frequent clustering is bad

CUSTOMER,NAMESMITH
DEPOSIT,NAMESMITH
DEPOSIT,NAMESMITH
25
(4) Split records

• Typically for hybrid format
• Fixed fields in one block
• Variable fields in another block

R1 (a)
R1 (b)
Blocks with variable fields.
R2 (a)
R2 (b)

• Block with fixed fields.

R2 (c)
26
Question

• What is difference between
• splitting records, and
• simply using two different record types?
• Efficiency?

27
(5) Sequencing

• Ordering records in file (and block) by some key
  value
• Why sequencing?
• Typically to make it possible to efficiently read
  records in order

28
Sequencing Options

• (a) Next record physically contiguous
• ...
• (b) Linked

Next (R1)
R1
R1
Next (R1)
29
Sequencing Options (cont)

• (c) Overflow area
• Records
• in sequence
• We will talk about indexing structures later!

R1
R2
R3
R4
R5
30
(6) Storing Records in Pages
Free space

• Different structures for fixed-length records and
  variable-length records
• Fixed-length just the starting position
• Variable-length need the length as well

31
Block header

• May contain
• - File ID (or RELATION or DB ID)
• - This block ID
• - Record directory
• - Pointer to free space
• - Type of block (e.g. contains recs type 4 is
  overflow, )
• - Pointer to other blocks like it
• - Timestamp ...

32
Managing space within each page

• Each page header stores (besides other things)
• information about contiguous free space and
• unused (possibly segmented) space on the page.
  E.g., bitmap
• Insertion, deletion, update, and reorganization
  change the amounts of contiguous free space and
  unused space

33
Operations on Pages

• Read a record
• Insert a new record
• Delete an existing record
• Update a specific record
• Bulk load tuples into a relation
• Reorganize a page
• Except reading a record, all other operations can
  cause changes to free space on the page.

34
Finding space to insert a tuple

• If tuple fits in page contiguous free space
  easy.
• If tuple fits in page contiguous free space
  unused (segmented) space
• reorganize the page and compress
• If tuple does not fit, we could split the record
  and store the pieces in two pages, and leave
  leave forwarding address on the first page.

35
Tuple Identification

• Option 1 Relative byte address offset in the
  file
• OK for insert-then-read-only DBs
• Disadvantages record can't easily grow, deleted
  space not easily reclaimed.
• Option 2 (indirect) page, index
• Disadvantages expensive reorganization to fix
  overflows

pageno
dir_index
3
7446
7446
this tuple
36
Indirection within a block

• In the indirect option
• Notice that the offset is the slot offset, not
  the offset of the starting position of the record
• Reason this indirection allows easy record
  movements within a block
• E.g., when reorganizing space within a page, we
  can move the records and set the new offsets of
  the header slots.
• This change will not affect the rids.

37
Next pointer swizzling

• Pointers in records
• Records can have pointers pointing to other
  records
• Useful for object-oriented databases
• How to use pointers efficiently in memory

38
Database address versus memory address
dbaddr
memory
database address
Memory address
Translation table

• Database address
• usually record physical address
• Memory address
• the address of the record in the memory, if it
  has been fetched from the hard disk.
• Records not fetched into memory dont have such
  addr
• The translation table does the mapping

39
Pointer swizzling
dbaddr
memory
Record A
Record B
In memory
Memory address
Swizzled
Translation table

• Suppose record A has a pointer to record B
• If B is memory, we need to go through the
  translation table to find Bs address in memory
• We can save this time by pointing from A to the
  Bs memory address
• Called pointer swizzling

40
Pointer swizzling (cont)
Record A
Record B
disk
unswizzled

• If record B is not in memory, then As pointer is
  unswizzled
• Thus we need a bit to indicate whether As
  pointer is swizzled
• This swizziling information needs to be
  maintained when
• Record A is read from or write to disk
• Record B is read from or write to disk
