Software Design

1
Software Design
2
Instrument Sequencer
Components Controller
OIWFS
Detector Controller
3
Instrument Sequencer
Components Controller
OIWFS
Detector Controller
4
Dual datum for grating turret and OIWFS
Support for Lake Shore temperature controller
Added offset command
Modified IS to suit NIFS sequences
Modified OIWFS to suit NIFS components
Modified CC to suit NIFS components
Built and ran NIRI s/w
5
Dual datum for grating turret
Support for Lakeshore temperature controller
Added offset command
Modified IS to suit NIFS sequences
Modified OIWFS to suit NIFS components
Modified CC to suit NIFS components
Built and ran NIRI s/w
6
Built and ran NIRI software

• Get EPICS to run April-July 2000
• Get old NIRI s/w to run July-August 2000
• Get new NIRI s/w to run September 2000

7
Built and ran NIRI software

• Get EPICS to run April-July 2000
• Get old NIRI s/w to run July-August 2000
• Get new NIRI s/w to run September 2000

5 months
8
Modify CC/OIWFS/IS for NIFS

• Eliminate extra components from Capfast
  schematics
• Add NIFS components (Flip mirror and grating
  turret) to Capfast schematics
• Remove unused sequences
• Add LUTs and pvs for each new component
• Modify sequence startup files
• Modify engineering interface screens

9
Modify CC/OIWFS/IS for NIFS

• Eliminate extra components from Capfast
  schematics
• Add NIFS components (Flip mirror and grating
  turret) to Capfast schematics
• Remove unused sequences
• Add LUTs and pvs for each new component
• Modify sequence startup files
• Modify engineering interface screens

3 months
10
Added Offset Command

• Modify Capfast schematics to support extra
  command
• Modify sequence code to handle new command

11
Added Offset Command

• Modify Capfast schematics to support extra
  command
• Modify sequence code to handle new command

1 week
12
Support for Lake Shore Temperature Controller

• Extended NIRIs tcon record to handle a dual
  controller (the Lake Shore 340)
• Added device support for the Lake Shore
  (devTconLS340 and devAILS340)
• Added driver support for the Lake Shore
  (drvLS340)
• No changes required to use with Omega controller

13
Support for Lake Shore Temperature Controller

• Extended NIRIs tcon record to handle a dual
  controller (the Lake Shore 340)
• Added device support for the Lake Shore
  (devTconLS340 and devAILS340)
• Added driver support for the Lake Shore
  (drvLS340)
• No changes required to use with Omega controller

1 month
14
Dual Datum (Fine control)

• Modify Hall-step record

15
Dual Datum (Fine control)

• Modify Hall-step record

To be started
16

• Using NIRI software enabled us to have working
  software within eight months

17
Issues

• Does NIRI satisfy Gemini?

• Software not yet tested with hardware does
  it work?
