DeepDetect: An Extensible System for Detecting Attribute Outliers

1
DeepDetect An Extensible System for Detecting
Attribute Outliers Duplicates in XML

• Q. Peter Lau, Wynne Hsu, Judice Koh, Mong Li Lee
• School of Computing
• National University of Singapore

2
eXtensible Markup Language (XML)

• Hierarchical organization
• Semi-structured data
• Related Elements are grouped together
• Elements may not be similar
• Elements may not be present
• Elements may not have an ordering

3
XML
Transactions
Branch_Code
Type
Transactions
Branch_Code
Type
4
4
Checking
Savings
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction

• Hierarchical Organization
• Relevant Transactions grouped under Accounts

4
XML
Transactions
Branch_Code
Type
Transactions
Branch_Code
Type
4
4
Checking
Savings
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction

• Different but related elements grouped together

5
XML
Transactions
Branch_Code
Type
Transactions
Branch_Code
Type
4
4
Checking
Savings
Transaction
Transaction
Transaction
Transaction

• ltBankgt Element not present

6
XML

• Increasing being used as a medium of data
  exchange on the WWW
• Data is increasingly being stored in XML format
• Native XML database systems
• Example
• UniProt database of Worldwide protein sequences
  (www.uniprot.org )

7
Artifacts in XML

• Dirty data
• Redundancies
• Discrepancies
• Errors
• May manifest as
• Duplicates
• Attribute Outliers

8
Duplicates

• Real world entities that are copies of one
  another
• But sometimes duplicates are natural occurrences
• User must direct what to look out for
• Most data-cleaning work in XML focus on Duplicates

9
Duplicates
Transactions
Branch_Code
Type
Transactions
Branch_Code
Type
4
4
Checking
Checking

• Green Duplicate transactions may be a natural
  occurrence
• Red Duplicate accounts may be illegal

10
Attribute Outliers

• Deviating Patterns
• A univariate point that exhibits deviating
  correlation behavior with respect to other
  attributes
• May indicate
• Discrepancies, errors
• Suspicious activity

11
Attribute Outliers
Transactions
Branch_Code
Type
Transactions
Branch_Code
Type
4
4
Checking
Savings
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction

• Left Transaction with deviating amount
• Right Transaction with deviating destination
  Bank

12
Detecting Artifacts

• Naïve Approach
• Map the XML data to relational tables and apply
  detection techniques for relational data
• Problems
• Handling of missing attribute values
• Hierarchical encoding is lost
• Direct methods that work on XML should be used

13
DeepDetect

• Extensible system for detecting artifacts
• Provides common facilities for various artifact
  detection algorithms
• Consists of modules that have different
  components
• Currently detects
• Duplicates
• Attribute Outliers

14
DeepDetect General Flow

• Load XML document
• Specify discretization rules
• Configure artifact detection algorithms
• Run detection algorithms
• Inspect results and make corrections
• Export XML

15
GUI Module

• Obtains user input for
• Discretization Rules
• Detection Parameters
• Corrections
• Presents results of detection algorithms

GUI
Specification
Data Preparation
Artifact Detection
16
Specification Module

• Computes the discretization for values
• Make the corrections specified by the user on
  export

GUI
Specification
Data Preparation
Artifact Detection
17
Data Preparation Module

• Formats the XML document to a more convenient
  form
• Extract the structure tree of an XML

GUI
Specification
Accounts
Data Preparation
Account ()
Artifact Detection
Transactions
Branch_Code
Type
Transaction ()
Amt
Type
Branch
18
Data Preparation Module

• Index XML Tree
• Similar to depth first order
• Store depth

GUI
Specification
Accounts (1, 14)
Data Preparation
Account (2, 13)
Transactions (3, 12)
Artifact Detection
Transaction (4, 11)
Amt (5, 6)
Type (7, 8)
Bank (9, 10)
30
C
YZ
19
Artifact Detection Module

• Contains the various detection algorithms
• Duplicate
• Attribute Outlier
• Detection algorithms may make use of structure
  tree and indexed XML tree

GUI
Specification
Data Preparation
Artifact Detection
20
Duplicate Detection

• Input User define entities XML data
• Extract candidates and tuples
• Tuple Amt, 50
• Candidate Set of tuples
• Score pair-wise tuple similarity
• E.g. using edit distance
• Classify duplicate candidates
• Output Duplicate Clusters

21
Attribute Outlier Detection
Transactions
Branch_Code
Type
Transactions
Branch_Code
Type
4
4
Checking
Savings
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction
Transaction

• XML Hierarchy can be used to partition objects
  into subspaces in which to detect outliers
• Uncovers outliers more relevant to their locality

22
Attribute Outlier Detection

• Input XML data parameters
• Generate Subspaces
• Count Supports of projections on subspace
• Score each potential outlier
• Identify Outliers by computing thresholds per
  subspace
• Output Outliers

23
Attribute Outlier Detection

• Support for projection Amt/ 100, Type/C,
  Bank/YZ is 1
• Support for projection Type/C, Bank/YZ is
  3
• Outlier score for Amt w.r.t. Amt/ 100,
  Type/C, Bank/YZ is 1 / 3

24
Implementation
XML
Handler 2a
Handler 1
SAX
Handler 2b

• SAX used instead of DOM
• SAX event chaining
• XML is further split into different element files
  and indexed by depth first traversal
• Do not need to re-parse redundant elements using
  SAX

25
Features

• Set discre-tization bins

26
Configure Duplicate Detection
27
Configure Attribute Outlier Detection
28
Viewing Duplicate Clusters
29
Viewing Attribute Outliers
30
Conclusion

• Detecting artifacts in XML data require
  specialized techniques
• The DeepDetect architecture provides common
  facilities for different detection algorithms
• Future Work
• Better visualization of artifacts for user
  inspection
• The use of Aggregates to summarize relevant nodes
  at higher levels of abstraction for artifact
  detection

31
End

• QA
