JPEG and MPEG Standards

1
JPEG and MPEG Standards
2
Outline

• Transform-based Image and Video Coding
• Linear Transformation DCT
• Quantization
• Scalar Quantization
• Vector Quantization
• Entropy Coding
• Video Coding Motion Compensation

3
Transform-based Image Coding
Binary bit stream
Input Image
Linear Transform
Quanti- zatioin
Entropy Coding
4
Linear Transform

• If the signal is formatted as a vector, a linear
  transform can be formulated as a matrix-vector
  product that transform the signal into a
  different domain.
• Examples
• K-L Expansion
• Discrete Fourier Transform
• Discrete cosine transform
• Discrete wavelet transform

• Energy compaction property The transformed
  signal vector has few, large coefficients and
  many nearly zero small coefficients. These few
  large coefficients can be encoded efficiently
  with few bits while retaining the majority of
  energy of the original signal.

5
Block-based Image Coding

• An image is a 2D signal of pixel intensities
  (including colors).
• A block-based image coding scheme partitions the
  entire image into 8 by 8 or 16 by 16 (or other
  size) blocks. Then the coding algorithm is
  applied to individual blocks independently.

• Blocks may be overlapping or non-overlapping.
• Advantage parallel processing can be applied to
  process individual blocks in parallel. For
  hand-held devices, only one block needs be loaded
  into main memory each time.

6
JPEG Image Coding Algorithms
7
JPEG Decoding
DC
DC
IDPCM
8x8
Huffman
block
IDCT
IQ
AC
Huffman
AC
JPEG Decoding Process
8
Pre-Processing

• Color sub-sampling
• A color image is converted from RGB to YUV color
  space. Each pixel in each dimension is 1 byte.
• Sub-sample U-V planes 411 scheme.
• For every 16 by 16 block of a color image, six 8
  by 8 blocks are encoded.
• Level shifting Each pixel value is subtracted by
  128 so it ranges (128, 127).

Four 8?8 blocks of luminance pixels, plus two 8?8
sub-sampled chrominance components makes a 16 by
16 macro-block
9
Discrete Cosine Transform

• 8?8 two-dimensional separable DCT
• DCT is chosen because it leads to superior energy
  compaction for natural images.
• F(0,0) DC coefficient ranges (-128x64/4,127x16)
  needs 12 bits to represent (including sign bit).
  12 bits are more than enough for the remaining AC
  coefficients (u gt 0, or v gt 0)

10
Inverse DCT (IDCT)

• 8?8 two-dimensional separable IDCT
• IDCT can be computed using the same routine as DCT

11
DCT Basis Functions
12
Quantization of DCT Coefficients
13
DPCM of DC coefficients

• DC coding All DC coefficients of each 8 by 8
  blocks of the entire image are combined to make a
  sequence of DC coefficients.
• Next, DPCM is applied
• DiffDC(blocki) DC(blocki) DC(blocki1)
• Then DiffDCs will be encoded using Hoffman entropy

• Example
• Original
• 1216 ? 1232 ? 1224 ? 1248 ? 1248 ? 1208
• After DPCM
• 1216 ? 16 ? -8 ? 24 ? 0 ? -40

14
Huffman Encoding of DC Coefficients

• Encoding and decoding of Huffman code is done via
  look-up table.
• In JPEG, DC coefficients (after DPCM) are first
  grouped according to their magnitudes. Each
  category is assigned as a symbol and a Hoffman
  table is given. For example, 7 to 4 and 4 to 7
  are listed as category 3 which has a code "00.

• If the number is positive, the binary
  representation of the number will be append to
  the Hoffman code of the category number directly.
  For example, 6 is encoded as 00 110. If the
  number is negative, the appended code is the 1s
  complement of that number. For example, -5 is
  encoded as 00 010.
• Question Given such a table, how to devise a
  dedicated hardware to implement the encoding
  procedure?

15
JPEG Huffman Table Categories
16
JPEG DC Entropy Coding

• Example
• -9 category 4. Hence Base code 101
• 1s complement of (-9) 1C(1001) 0110
• Code word 101 0110 1010110
• Note that category 3 occurs most frequent and
  hence has shortest base code word.

17
AC Coefficients

• AC coefficients are first weighted with a
  quantization matrix
• C(i,j)/q(i,j) Cq(i,j)
• Then quantized.
• Then they are scanned in a zig-zag order into a
  1D sequence to be subject to AC Huffman encoding.
• Question Given a 8 by 8 array, how to convert it
  into a vector according to the zig-zag scan
  order? What is the algorithm?

Zig-Zag scan order
18
AC Coefficients Huffman Encoding

• The symbols for encoding AC coefficient consists
  both the number of significant bits, as well as
  runs of 0s preceding the nonzero AC coefficient.
  For example,
• 5 0 2 0 0 1 is encoded as 100101 11100110
  110110
• This is according to the table below

19
Huffman Decoding

• A look-up table procedure.
• Challenge How to perform decoding fast?
• Example a Huffman table for six symbols

• The decoding process can be modeled as a finite
  state machine with the following state diagram.
  It decodes one bit of input bit stream per clock
  cycle.
• Question How to make this process fast enough to
  match any input bit rate?

20
Huffman Decoding Implementation

• The FSM decoding model decodes one bit per clock
  cycle ? constant input rate.
• A FSM is a nonlinear recursive equation! ?
  look-ahead transform may be applied to expedite
  evaluation.
• Look-ahead means to exam two or more bits of the
  input stream per clock cycle.

• If the maximum code word length is examined per
  clock cycle, then it is possible to produce one
  output symbol per clock cycle, giving a constant
  output rate realization.
• The complexity of the combinational logic that is
  required for look-ahead transformation is the
  most difficult part.

21
Video Coding

• Video coding is often implemented as encoding a
  sequence of images. Motion compensation is used
  to exploit temporal redundancy between successive
  frames.
• Examples MPEG-I, MPEG-II, MPEG-IV, H.323, H.263,
  H.263, etc.
• Existing video coding standards are based on JPEG
  image compression as well as motion compensation.

22
MPEG Encoding
Buffer control
Current frame x(t)
r
Bit stream Buffer

VLC
DCT
Q
?
Q-1
IDCT

Qr(t) reconstructed residue
x(t) predicted frame


x(t) reconstructed current frame

Motion Estimation Compensation
x(t-1)
x(t)
Frame Buffer
This is a simplified block diagram where the
encoding of intra coded frames is not shown.
Motion vectors
23
MPEG Decoding
VLD Variable Length Decoding
Received bit stream
Bit stream Buffer
VLD
Q-1
IDCT

Qr(t) reconstructed residue
x(t) predicted frame


x(t) reconstructed current frame

Frame Buffer
Motion Compensation
x(t-1)
Motion vectors
24
Motion Estimation

• Three types of frames
• Intra (I) the frame is coded as if it is an
• Predicted (P) predicted from an I or P frame
• Bi-directional (B) forward and backward
  predicted from a pair of I or P frames.
• A typical frame arrangement is (subscripts are
  used to distinguish them)
• I1 B1 B2 P1 B3 B4 P2 B5 B6 I2
• P1, P2 are both forward-predicted from I1. B1, B2
  are interpolated from I1 and P1, B3, B4 are
  interpolated from P1, P2, and B5, B6 are
  interpolated from P2, I2.

25
Forward Motion Estimation
1
2
3
4
2
4
1
3
8
5
5
6
7
8
7
6
12
11
9
9
10
11
12
10
15
13
16
13
14
15
16
14
Current frame constructed From different
parts of reference frame
Reference frame
26
Block Motion Estimation

• MAD Mean absolute difference between the I,j-th
  pixel of the current block x(i,j) and the
  (Im,jn)-th pixel of the reference frame.
• (-p?m,n ? p) is the motion vector corresponding
  to the macro-block. M and N are search range.
• It is similar to DPCM in the temporal domain, and
  has less to do with object motion.

27
Video sequence Tennis frame 0
Prepared by Surin Kittitornkun
28
Video sequence Tennis frame 1
Prepared by Surin Kittitornkun
29
Frame Difference
Prepared by Surin Kittitornkun
30
What is motion estimation?
Prepared by Surin Kittitornkun
31
What is motion compensation ?
Prepared by Surin Kittitornkun
32
Motion Compensated Frame Difference
Prepared by Surin Kittitornkun
