RDFStorePerl API for RDF Storage

• INTAP meeting
• 14 January 2002
• JRC, Ispra (I)
• Alberto Reggiori areggiori_at_webweaving.org
• JRC/IPSC

2
Outline

• The RDF view of the Web - Semantic Web
• RDF applications and tools requirements
• RDFStore
• API
• Storage
• Querying
• Sample code and applications
• SW related applications
• Next steps
• Demonstration

3
The RDF model

• RDF (Resource Description Framework) is a
  foundation to structure data over the Web, using
  the Web itself
• RDF provides a simple and consistent mechanism to
  organise, describe, manage, associate, combine
  and navigate Web resources ? the Web is like a
  globally linked database

4
RDF concepts
Semantic Web
RDF/XML
N-triples
Namespace
Statement
Class or property
Applications and Tools
Context
RDF (schema) model
URI
Resource or value

Data
Web
5
RDF applications and tools requirements

• Storage
• There is no real Semantic Webif we store RDF
  models
• very fast and scalable
• support atomic and/or transactional operations
• deal with arbitrary sized data
• handle multiple connections concurrently
• avoiding a 'stagger' situation
• distributed and federated
• compression
• Caching

• API
• Easy and straightforward to use
• Modular and flexible
• Users need an abstraction to
• Parsing (canonical and strawman)
• Navigation
• Validation
• Managing constructs (set/get, add/remove)
• Persistence and querying
• Inference
• Must be either resource and model/statement
  centric

6
Processing models

• Model or Statement centric
• a model is seen as a set of statements (logician
  view)
• Add, remove, find, get, count triples primitives
• Set operations on models (union, difference,
  intersection)
• Stanford API, Jena and RDFStore

• Resource centric
• manipulate an RDF model in terms of resources
  having properties (OO view)
• Models are just containers of resources, literals
  and statements
• Add, remove, set/get property methods
• Jena, Redland (soon RDFStore)

7
RDFStore

• RDFStore is a Perl library to parse, store and
  manage RDF constructs
• Model centric API
• Pure Perl implementation of the Stanford Draft
  Java API plus some extensions
• Easy to install
• perl Makefile.pl make make test make install
• Easy to use
• use RDFStore

8
Toolkit features

• Modular interface using packages and perltie
• Expat based XML streaming SiRPAC and strawman RDF
  parsers
• In-memory, local and remote on-disk hashed data
  storage (SDBM, BerkeleyDB and DBMS)
• Triples matching and SQUISH/RDQL query
• Free-text searching of literals
• Simple contexts support
• Basic RDF Schema inference
• Free software - BSD license
• Tested on FreeBSD, Linux (some win32)

9
Storage and indexing

• Multiple single key hash based DBs along with
  Perl based Object Serialization
• Transparently read/write local and remote DBs
• One RDFStore database currently consists of 7
  on-disk hashed DB files
• resources, literals, namespaces, statements,
  references, model and index
• 237.822 triples get stored in 31MB db
  (thesaurus)
• On-disk Sleepycat BerkeleyDB database with
  locking performs 183 read operations/second
• Remote DBMS has been tested for 2000/tps

10
Remote DBMS storage

• Custom built, fast DBMS server with hooks into
  the Perl Language
• optimized network routing daemon with a single
  thread/process per database
• TCP/IP based storage library
• Forking, non blocking IO and extensive buffering
• Original author Dirk Willem van-Gulik
  ltdirkx_at_webweaving.orggt

11
Requirements

• Required CPAN modules
• XMLParser (which requires expat)
• Storable
• Digest
• DigestMD5
• DigestSHA1
• URI (which requires MIMEBase64)
• Optionals
• BerkeleyDB
• DBMS (distributed with RDFStore)

12
API overview
13
Packages overview
14
API core classes
http//rdfstore.sourceforge.net/documentation/api.
html
15
Sample code
Sample perl scripts
16
Sample applications

• RDF parser
• http//rdfstoredemo.jrc.it
• RDQL/SQUISH
• http//rdfstoredemo.jrc.it/rdql
• rdf2gif (rdfviz)
• http//rdfstoredemo.jrc.it/rdf2gif.pl
• RSS viewer
• http//xml.jrc.it/wap
• Multilingual Thesaurus
• RDF Schema
• http//etbrowse.jrc.it/thesaurus/thes.rdfs
• API
• http//etbrowse.jrc.it/thesaurus/ETBT/API.html
• Display, search and indexing tool
• http//etbrowse.jrc.it/thesaurus/classifier.pl
• European Treasury Browser (ETB)
• http//etbrowse.jrc.it/

17
Sample RDQL query
SELECT ?title_value, ?title_language,
?subject_value,?subject_language,
?description_value, ?description_language,
?language, ?identifier FROM
lthttp//etbrowse.jrc.it/xml/rdf/example10.xmlgt WHE
RE ( ?x, ltdctitlegt, ?tt), ( ?tt,
ltrdfvaluegt, ?title_value), ( ?tt,
ltdclanguagegt, ?ttl), ( ?ttl, ltdcqRFC1766gt,
?title_language), ( ?x, ltdcsubjectgt,
?ss1), ( ?ss1, ltetbthesETBTgt, ?ss2),
( ?ss2, ltrdfvaluegt, ?subject_value), ( ?ss2,
ltdclanguagegt, ?ss3), ( ?ss3,
ltdcqRFC1766gt, ?subject_language), ( ?x,
ltdcdescriptiongt, ?dd), ( ?dd,
ltrdfvaluegt, ?description_value), ( ?dd,
ltdclanguagegt, ?ddl), ( ?ddl,
ltdcqRFC1766gt, ?description_language), ( ?x,
ltdcidentifiergt, ?identifier), ( ?x,
ltdclanguagegt, ?ll1), ( ?ll1, ltdcqRFC1766gt,
?language) USING rdf for lthttp//www.w3.org/199
9/02/22-rdf-syntax-nsgt, rdfs for
lthttp//www.w3.org/2000/01/rdf-schemagt,
dc for lthttp//purl.org/dc/elements/1.1/gt,
dcq for lthttp//purl.org/dc/terms/gt, dct
for lthttp//purl.org/dc/dcmitype/gt, etb
for lthttp//eun.org/etb/elements/gt,
etbthes for lthttp//eun.org/etb/thesaurus/elements
/gt
18
Existing RDFStore applications

• RDF web service API for MusicBrainz (Robert Kaye
  rob_at_eorbit.net)
• http//www.musicbrainz.org
• OCLC work on automatic classification (Devon
  Smith devon_at_taller.pscl.cwru.edu)
• Scorpion and Wordsmith crawler
• Volga PRISM standard based novels (Prasad A.
  Chodavarapu prasad_at_bhaavana.net)
• http//volga.bhaavana.net/cgi-bin/rdexplorer.cgi
• European Treasury Browser (ETB) -
  http//etb.eun.org
• http//etbrowse.jrc.it
• DC/DCQ/DCEDU
• http//eun.org/etb/elements.dtd
• http//eun.org/etb/elements/
• http//eun.org/etb/thesaurus/elements/
• http//eun.org/etb/thesaurus.rdf

19
DCQ example

• ltdcqmodifiedgt
• ltdcqW3CDTFgt
• ltrdfvaluegt2001-05-31T14201000lt/rdfva
  luegt
• lt/dcqW3CDTFgt
• lt/dcqmodifiedgt
• modified records-gtfind(
• records-gtfind(node,DCQmodified)-gtelements
  -gtobject, RDFvalue)-gtelements-gtobject-gttoString


20
What RDFStore does not doyet ?

• Resource centric API
• First order/predicate logic or intelligent
  inferencing
• Mapping and/or dumb-down
• lot of other things.
• .rocks )

21
Other Perl API
http//xml.jrc.it/rdfapi_perl/
22
Demo time
23
RDFStore links

• Software project
• http//rdfstore.sourceforge.net
• Demo
• http//rdfstoredemo.jrc.it
• RDFStore vs. rdfdb
• http//groups.yahoo.com/group/rdfstore/message/14
• Documentation
• http//rdfstore.sourceforge.net
  /documentation/api.html
• http//rdfstore.sourceforge.net /dbms.html
• http//rdfstore.sourceforge.net
  /documentation/pod
• YahooGroups developer mailing list
• http//groups.yahoo.com/group/rdfstore
